PLGK 12 A1 - Battery PARKSIDE - Free user manual and instructions
Find the device manual for free PLGK 12 A1 PARKSIDE in PDF.
| Product type | Fast charger for lithium-ion battery |
| Brand | Parkside |
| Charger model | PLGK 12 A1 |
| Compatible battery | PAPK 12 A1, PAPK 12 A2, PAPK 12 B1 |
| Battery type | Lithium-ion |
| Included battery capacity | 2 Ah (2000 mAh, 24 Wh, 3 cells) |
| Charger input power | 220–240 V ~, 50–60 Hz, 50 W |
| Charger output power | 12 V, 2.4 A |
| Charging time | Approximately 60 minutes |
| Protection class | II (double insulation) |
| Charging temperature | 10 °C to 40 °C |
| Storage temperature | 0 °C to 50 °C, optimal charge state 50–80% |
| LED indicators | Red (charging), green (charging complete) |
| Charger warranty | 3 years |
| Battery warranty | 6 months |
| Maintenance | Clean with a dry cloth; store in a clean, dry place away from sunlight |
| Spare parts | Replacement battery available on order (www.kompernass.com or by phone) |
| Main functions | Fast charging of Parkside X12V Team batteries, protection against overcharge and short circuit |
| Use | Indoor only |
Frequently Asked Questions - PLGK 12 A1 PARKSIDE
User questions about PLGK 12 A1 PARKSIDE
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Battery in PDF format for free! Find your manual PLGK 12 A1 - PARKSIDE and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. PLGK 12 A1 by PARKSIDE.
USER MANUAL PLGK 12 A1 PARKSIDE
Translation of the original instructions
NL BE
ACCU 2 Ah + OPLADER
Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.
FR BE
GB/IE Translation of the original instructions Page 15
All Parkside tools and the chargers PLGK 12 A1 / PLGK 12 B2 of the X12V Team series are compatible with the PAPK 12 A1 / PAPK 12 A2 / PAPK 12 B1 battery pack.
Intended use. 16
Features 16
Package contents 16
Technical specifications 17
General safety instructions 17
Use and handling of the cordless electrical power tool 18
Extended safety guidelines. 19
Safety guidelines for battery chargers 19
Before use 20
Charging the battery pack (see fig. A). 20
Maintenance and storage 21
Kompernaβ Handels GmbH warranty 22
Service. 24
Importer 24
Disposal. 25
Notes on the EC Declaration of Conformity 26
Ordering a replacement battery. 26
Telephone ordering 27
Introduction
Congratulations on the purchase of your new appliance. You have chosen a high-quality product. The operating instructions are part of this product. They contain important information about safety, usage and disposal. Before using the product, please familiarise yourself with all of the operating and safety instructions. Use the product only as described and for the range of applications specified.
Please also pass these operating instructions on to any future owner.
Intended use
This charger is exclusively intended for charging PARKSIDE batteries of the PAPK 12 A1/A2/B1 series. This rechargeable battery is suitable for:
This rechargeable battery is not intended for commercial use. Any other usage of or modification to the appliance is deemed to be improper and carries a significant risk of accidents. The manufacturer accepts no responsibility for damage attributable to misuse.
Features
1 Batterypack
2 Releasebuttons
Red charge control LED
Green charge control LED
High-speedcharger
Package contents
12Ah battery
1 charger
1 set of operating instructions
Technical specifications
2 Ah battery: PAPK 12 A2
Type:LITHIUMION
Rated voltage: 12 V = = (DC)
Capacity: 2000 mAh/24 Wh
Cells: 3
Charger: PLGK 12 A1
INPUT:
Rated voltage: 220-240 V (AC), 50-60 Hz
Rated power consumption: 50 W
Fuse (internal): 2 A
OUTPUT:
Rated voltage: 12 V (DC)
Rated current: 2.4 A
Charging time: approx. 60 min
Protectionclass:ll/ (double insulation)
General safety instructions
WARNING!
- Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.
Use and handling of the cordless electrical power tool
a) Charge a rechargeable battery unit using only the charger recommended by the manu facturer. Chargers are often designed for a particular type of rechargeable battery unit. There is the danger of fire if other types of rechargeable battery units are used.
b) Only the rechargeable battery units supplied are to be used with an electrical power tool. The use of other rechargeable battery units may lead to the danger of injury or fire.
c) When they are not being used, store rechargeable battery units away from paperclips, coins, keys, nails, screws or other small metal objects that could cause the contacts to be bridged. Short-circuiting the contacts of a rechargeable battery unit may result in heat damage or fire.
d) Fluids may leak out of rechargeable battery units if they are misused. If this happens, avoid contact with the fluid. If contact occurs, flush the affected area with water. Seek additional medical help if any of the fluid gets into your eyes. Escaping battery fluid may cause skin irritation or burns.
ON! RISK OF EXPLOSION! Never charge
non-rechargeable batteries.
Protect the rechargeable battery from heat; for example, from continuous exposure to sunlight, fire, water and moisture. There is a risk of explosion.
Extended safety guidelines
Do not use a damaged or modified battery.
Damaged or modified batteries may behave unexpectedly and cause fires, explosions or pose a risk of injury.
- Do not expose a battery to fire or excessively high temperatures. Fire or temperatures in excess of 130^ C ( 265^ F ) can cause an explosion.
■ Follow all instructions regarding charging and never charge the battery or the cordless tool outside the temperature range given in the operating instructions.
Incorrect charging or charging outside of the permissible temperature range can destroy the battery and increase the risk of fire.
WARNING!
- Do not use any accessories that are not recommended by PARKSIDE. Unsuitable accessories can lead to a risk of electric shock or fire.
Safety guidelines for battery chargers
This appliance may be used by children aged 8 years and above and by persons with limited physical, sensory or mental capabilities or lack of experience and knowledge, provided that they are under supervision or have been told how to use the appliance safely and are aware of the potential risks. Do not allow children to use the appliance as a toy. Cleaning and user maintenance tasks may not be carried out by children unless they are supervised.
- To avoid potential risks, damaged mains cables should be replaced by the manufacturer, their customer service department or a similarly qualified person.
The charger is suitable for indoor use only.
WARNING!
To avoid potential risks, damaged mains cables should be replaced by the manufacturer, their customer service department or a similarly qualified person.
ATTENTION!
This charger can only charge the following ④atteries: PAPK 12 A1 / PAPK 12 A2 / PAPK 12 B1.
A current list of battery compatibility can be found at www.lidl.de/Akku.
Before use
Charging the battery pack (see fig. A)
CAUTION!
Always unplug the appliance before you remove the battery pack from or connect the battery pack to the charger.
NOTE
- Never charge the battery pack if the ambient temperature is below 10^ or above 40^ . If a lithium-ion battery is to be stored for an extended period, the charge level should be checked regularly. The optimum charge level is between 50% and 80% . The storage climate should be cool and dry and the ambient temperature should be between 0^ and 50^ .
Insert the battery pack into the high-speed charger 5
Insert the power plug into the socket. The charge control LED lights up red.
The green charge control LED4 indicates that charging is complete and the battery pack is ready for use.
Push the battery pack into the appliance.
Switch the high-speed charge ⑤ off for at least 15 minutes between successive charging processes. Also disconnect the power plug from the mains power socket.
Maintenance and storage
If you do not intend to use the appliance for an extended period, remove the batteries and store it in a clean, dry place away from direct sunlight.
If a lithium-ion battery is to be stored for an extended period, the charge level should be checked regularly. The optimum charge level is between 50% and 80% . The optimum storage environment is cool and dry.
Never try to repair damaged batteries.
Maintenance of batteries should only be carried out by the manufacturer or an approved customer service centre.
This appliance comes with a 3-year* warranty valid from the date of purchase. In the event that this product has any faults, you, the buyer, have certain statutory rights. Your statutory rights are not limited in any way by the warranty described below.
*Charger only (rechargeable battery: 6 months)
Warranty conditions
The warranty period starts on the date of purchase. Please keep your receipt in a safe place. This will be required as proof of purchase.
If any material or manufacturing fault occurs within three years* of the date of purchase of the product, we will either repair or replace the product for you or refund the purchase price (at our discretion). This warranty service requires that you present the defective appliance and the proof of purchase (receipt) within the three-year warranty period, along with a brief written description of the fault and of when it occurred.
If the defect is covered by the warranty, your product will either be repaired or replaced by us. The repair or replacement of a product does not signify the beginning of a new warranty period.
Warranty period and statutory claims for defects
The warranty period is not prolonged by repairs effected under the warranty. This also applies to replaced and repaired components. Any damage and defects present at the time of purchase must be reported immediately after unpacking. Repairs carried out after expiry of the warranty period shall be subject to a fee.
Scope of the warranty
This appliance has been manufactured according to strict quality guidelines and inspected meticulously prior to delivery.
The warranty covers material faults or production faults. The warranty does not extend to product parts subject to normal wear and tear or to fragile parts which could be considered as consumable parts such as switches, batteries or parts made of glass.
The warranty does not apply if the product has been damaged, improperly used or improperly maintained. The directions in the operating instructions for the product regarding proper use of the product must be strictly followed. Uses and actions that are discouraged in the operating instructions or for which cautions are given must be avoided in all cases.
This product is intended solely for private use and not for commercial purposes. The warranty will be deemed void in cases of misuse or improper handling, use of force and modifications/repairs that have not been carried out by one of our authorised service centres.
Warranty claim procedure
To ensure prompt processing of your case, please observe the following instructions:
Please have the receipt and item number (e.g. IAN 123456) available as proof of purchase.
■ You will find the item number on the type plate on the product, an engraving on the product, on the front page of the operating instructions (below left) or as a sticker on the rear or bottom of the product.
If functional errors or other defects occur, please contact the service department listed below, either by telephone or by e-mail.
- You can return a defective product to us free of charge to the service address that will be provided to you. Ensure that you enclose the proof of purchase (receipt) and information about what the defect is and when it occurred.
You can download these instructions along with many other manuals, product videos and installation software from www.lidl-service.com.
This QR code will take you directly to the Lidl service page (www.lidl-service.com) where you can open your operating instructions by entering the article number (IAN) 123456.
Service
WARNING!
Have your appliances repaired by the Service Centre or a trained electrician, and use only original spare parts. This will ensure that the safety of the appliance is maintained.
Always ensure that the power plug or the mains cable is replaced only by the manufacturer of the appliance or by an approved customer service provider. This will ensure that the safety of the appliance is maintained.
GB Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
IE Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
IAN320149_1901
Importer
Please note that the following address is not the service address. Please use the service address provided in the operating instructions.
KOMPERNASS HANDELS GMBH
BURGSTRASSE 21
44867 BOCHUM
GERMANY
www.kompernass.com
Disposal
ckaging protects the appliance from damage during transport. The packaging materials have been selected for their environmental friendliness and disposal attributes, and are therefore recyclable.
Returning the packaging into the material cycle conserves raw materials and reduces the amount of waste generated. Dispose of packaging materials that are no longer needed in accordance with applicable local regulations.
- dispose of power tools in your normal domestic waste!
European Directive 2012/19/EU requires that worn-out power tools are collected separately and recycled in an environmentally compatible manner.
Do not liion
Defective or worn-out rechargeable batteries must be recycled according to Directive 2006/66/EC. Take the battery pack and/or appliance to a nearby collection facility.
Please consult your local authorities regarding suitable disposal of worn-out power tools/battery packs.
Dispose of the packaging in an environmentally friendly manner.
Note the labelling on the packaging and separate the packaging material components for disposal if necessary. The packaging material is labelled with abbreviations (a) and numbers (b) with the following meanings: 1-7: plastics, 20-22: paper and cardboard, 80-98: composites
Your local community or municipal authorities can provide information on how to dispose of the worn-out product.
Notes on the EC Declaration of Conformity
This appliance complies with the basic requirements and other relevant provisions of the Electromagnetic Compatibility Directive 2014/30/EU and the Low-Voltage Directive 2014/35/EU.
The complete original Declaration of Conformity is available from the importer.
CE
RoHS Directive (2011/65/EU)*
*The manufacturer bears full responsibility for compliance with this conformity declaration. The object of the declaration described above complies with the requirements of the Directive 2011/65/EU of the European Parliament and Council of 8 June 2011 on the limitations of use of certain dangerous substances in electrical and electronic appliances.
Ordering a replacement battery
If you want to order a replacement battery for your appliance, you can do so easily via the Internet on www.kompernass.com or by telephone. Due to limited stocks, this item may sell out in a relatively short time.
NOTE
- Online ordering of replacement parts might not be possible in some countries. If this is the case, please contact the Service hotline.
The promotion is limited to one battery per customer/appliance and also to a period of two months after the promotion. Thereafter, the replacement battery can still be ordered as a replacement part under other conditions.
Telephone ordering
GB Service Great Britain
Tel.: 0800 404 7657
E-Mail: kompernass@lidl.co.uk
IE Service Ireland
Tel.: 1890 930 034
(0,08 EUR/Min., (peak))
(0,06 EUR/Min., (off peak))
E-Mail: kompernass@lidl.ie
To ensure fast processing of your order, have the article number of your appliance to hand (e.g. IAN 320149) in case of questions. The article number can be found on the type plate or the title page of these instructions.
