Brand	Bomann
Model	FW 447 CB
Product type	Electric meat grinder
Power supply	220-240 V~, 50/60 Hz, 550 W
Net weight	Approx. 3.32 kg
Noise level	82 dB(A)
Main functions	Meat grinding, sausage making, kibbeh preparation, cookie molding
Included accessories	3 grinding discs (fine, medium, coarse), knife, auger, pusher, filling tray, sausage attachment, kibbeh attachment (2 parts), cookie attachment with slider
Material of knife and discs	Steel
Safety	Safety switch, reverse function for clearing jams, pusher provided to avoid contact with moving parts
Maximum continuous use	10 minutes, followed by a 10-minute cooling down
Control type	On/Off/Reverse switch (ON/O/R) and function selector I/II
Cleaning	Clean accessories by hand, do not immerse the motor block, do not use abrasive products or dishwasher
Storage	In its original packaging, in a dry and ventilated place; lightly oil the discs after drying
Intended use	Household only, for grinding and shaping food
Repairability	Do not repair yourself, contact customer service or a qualified professional
Warranty	Check the warranty terms provided with the appliance
Number of accessories	7 pieces (excluding tray and pusher)

Frequently Asked Questions - FW 447 CB BOMANN

How to assemble the meat grinder?

Place the spiral housing on the motor block aligning the marks. Insert the auger until it clicks, then the knife (cutting edge facing outward). Add the disc of your choice (fine, medium or coarse) and screw on the closure. Finally, install the filling tray. Always use the pusher to push the food.

How to use the reverse function in case of jamming?

If the auger is jammed, set the switch (6) to O (stop) and wait for the motor to stop completely. Set the function button (7) to II, then press R on the button (6) to activate reverse. Hold until the jam is released. Then, turn off the appliance and remove the residues.

What types of meat can I grind?

You can grind all kinds of boneless meat, cut into pieces of about 2.5 cm. Avoid bones, tendons, and cartilage. For a finer result, first use the coarse disc, then pass again with a fine or medium disc. Lightly oil the discs before use.

How to clean the appliance after use?

Always unplug the appliance and let it cool down. Never immerse the motor block in water; wipe it with a damp cloth. Wash the accessories (auger, knife, discs, tray) by hand with soapy water, rinse and dry thoroughly. Do not put in dishwasher as it will tarnish the surfaces.

What to do if the appliance does not start?

First, check that the plug is correctly inserted and that the outlet works (test with another appliance). Ensure that the function button (7) is on I and the switch (6) is on ON. If the appliance still does not start, check the main fuse. If the problem persists, contact a professional.

How long can I use the appliance continuously?

Do not use the appliance for more than 10 minutes consecutively. After each use, let it cool down for at least 10 minutes before using again. This prevents motor overheating.

How to make sausages with the attachment?

Attach the sausage attachment after assembling the grinder (knife and disc). Use natural or artificial casings. For natural casings, soak them in water beforehand. Thread the casing onto the attachment, tie a knot at one end, then place the sausage meat in the tray. Run the appliance in FORWARD mode. Do not overfill the casing to avoid bursting during cooking. Form the sausages by twisting the casing.

How to use the cookie attachment?

Install the cookie attachment on the auger housing. Insert the slider into the notches to adjust the shape. Place a cookie dough (like shortbread) in the tray and push it with the pusher. Grasp the dough strands at the outlet and cut to desired length. You can vary the shapes depending on the chosen attachment.

What are the safety risks to know?

Never touch moving parts. Always use the pusher provided, never fingers or utensils. Before changing attachments, turn off and unplug the appliance. The knife is very sharp, handle with care when cleaning. Do not leave the appliance unattended during operation. Keep out of reach of children.

Is the appliance under warranty?

Yes, the Bomann FW 447 CB meat grinder is covered by a legal warranty of conformity. Check the warranty terms provided with your appliance. In case of problem, contact your dealer or Bomann customer service. Do not attempt to repair the appliance yourself, as this would void the warranty.

USER MANUAL FW 447 CB BOMANN

Cet appeareil sert a

Consummation electrique max. 1200 W

Thank you for selecting our product. We hope that you will enjoy use of the appliance.

Symbols in this user manual

Important notes for your safety are marked distinctively. Pay absolute attention to them to avoid accidents and damage to the device:

WARNING:

Warns of dangers for your health and indicates potential risks of injury.

CAUTION:

Indicates potential dangers for the device or other objects.

NOTE:

Highlights tips and information for you.

Contents

Location of Controls 3

Illustrations A-D 4

General Safety Instructions 33

Special safety instructions for this unit. 33

Description of Parts / Supplied parts 34

Intended use 35

Unpacking the appliance. 35

Preparation 35

Assembly of the meat grinder 35

Assembly of the sausage attachment 35

Mounting of the "Kebbe" attachment 35

Assembly of the cookie attachment. 35

Electrical connection 36

Application instructions. 36

Cleaning 36

Storage 36

Troubleshooting 37

Noise development 37

Specifications 37

Disposal 37

General Safety Instructions

Read the operating instructions carefully before putting the appliance into operation and keep the instructions including the warranty, the receipt and, if possible, the box with the internal packing. If you give this device to other people, please also pass on the operating instructions.

• The appliance is designed exclusively for private use and for the envisaged purpose. This appliance is not fit for commercial use.
• Do not use it outdoors. Keep it away from sources of heat, direct sunlight, humidity (never dip it into any liquid) and sharp edges. Do not use the appliance with wet hands. If the appliance is humid or wet, unplug it immediately.
• When cleaning or putting it away, switch off the appliance and always pull out the plug from the socket (pull the plug itself, not the lead) if the appliance is not being used and remove the attached accessories.
• Do not operate the machine without supervision. If you leave the room you should always turn the device off. Remove the plug from the socket.
• The device and the mains lead have to be checked regularly for signs of damage. If damage is found the device must not be used.
• Use only original spare parts.
• In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

WARNING:

Don't let small children play with foils for danger of suffocation!

Special safety instructions for this unit

WARNING: Risk of injury!

• Before replacement of accessories or additional parts which move during operation, the device must be switched off and cut off from the mains.
• Do not touch moving parts.
• Before changing accessories, wait until the knife has come to standstill.

WARNING: Risk of injury!

• Before switching on, make sure that the accessories attachment has been installed correctly and is seated securely.
  Always use the supplied tamper. Never insert your fingers or tools into the filling neck!
• Handle the knife with the necessary care when taking out and cleaning it!
• Always disconnect the appliance from the supply if it is left unattended and before assembling, disassembling or cleaning.
• Do not repair the device by yourself. Please contact authorized personnel. In order to avoid hazards, a damaged mains cable must be replaced with an equivalent cable by the manufacturer, our customer service or any other qualified specialist.
• This appliance shall not be used by children.
• Keep the appliance and its cord out of reach of children.
  Children shall not play with the appliance.
• Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved.
• Do not break up hard items such as bones or shells.
• Do not manipulate safety switches.

Description of Parts / Supplied parts

1 Pusher
2 Filling tray
3 OPEN button (Open)
4 Accessory compartment
5 Motor
6 Switch ON/O/R (On/Off/reverses)
7 Function switch I/II (On/reverses)
8 Release button PUSH (Push)
9 Spiral housing

Illustrations A to D:

10 Spiral
11 Knife
12 3 steel discs (fine, medium, coarse)
13 Plug
14 Sausage attachment
15 2-part "Kebbe" attachment
16 Cookie attachment
17 Rail for biscuits

Intended use

This appliance serves

• Cut up foodstuff.
• You can shape noodles or dough with different attachments.

It is exclusively intended for this purpose and may be only used appropriately.

It may only be used in the manner described in these operating instructions.

You may not use the appliance for commercial purposes.

Use for any other purpose is considered improper and not for the intended purpose and can result in damage to property and personal injury.

The manufacturer shall not be liable for damages caused by not intended use.

Unpacking the appliance

1. Remove the device from its packaging.
2. Remove all packaging materials like foils, filling materials, cable holders, and carton packaging.
3. Check the scope of deliveries for completeness.
4. If the packaging content should be incomplete or if damages should be noticeable, do not operate the appliance. Return it to the distributor immediately.

NOTE:

• There may still be dust or production remains on the device. We recommend that you clean the device as described under "Cleaning".
• The accessories are packed in re-sealable foil bags. Keep these bags for safekeeping/storage of the appliance.

Preparation

Please see the overviews on pages 3 and 4.

1. Place the spiral housing (9) in the two o'clock setting into the spiral drive.
2. Keep the release button (8) pressed down. Twist the spiral housing in counterclockwise direction at the same time, until it locks in place.
3. Place the filling tray on to the filler neck in such a way that the fixture for the tray is above the motor block.
4. Push the spiral (10) into the horizontal section of the spiral housing until the axle locks in place.

See also the sections on assembling the meat grinder, the "Kebbe" attachment, the sausage attachment or the biscuit attachment.

Assembly of the meat grinder

• Please also observe our illustrations under "A" (Page 4).

• Please follow points 1 to 4 as described under "Preparation".

• Insert the knife with the sharpened edge outwards onto the shaft of the scroll.

• Select a steel disc (12).

NOTE:

The guides are located in the recesses on the spiral housing.

1. Rotate the catch clockwise.
2. Put the pieces of meat on to the filling tray (2) and into the filler neck.

See below "Electrical connection/Application instructions".

Assembly of the sausage attachment

• Please also observe our illustrations under "B" (Page 4).

• First proceed as described under "Preparation" and "Assembly of the Meat Grinding", points 1 to 6.

• Position the sausage attachment on the spiral housing.

• Rotate the catch clockwise.
• Fill the sausage paste on to the filling tray and into the filler neck.

See below "Electrical connection/Application instructions".

Mounting of the "Kebbe" attachment

NOTE:

Tubes of meat or dough paste can be made with the "Kebbe" attachment.

• Please also observe our illustrations under "C" (Page 4).

• Please follow points 1 to 4 as described under "Prepara

• Position the 2-piece Kebbe attachment on the shaft of the spiral.

NOTE:

The guides on attachment are located in the recesses on the spiral housing.

1. Rotate the catch clockwise.
2. Place your meat or dough paste on the filling tray and into the filler neck.

See below "Electrical connection/Application instructions".

Assembly of the cookie attachment

iNOTE:

You can shape different forms with this attachment after preparing a cookie dough. This is particularly suitable for so-called "Spritzgebäck" (cookies).

• Please also observe our illustrations under "D" (Page 4).

• Please follow points 1 to 4 as described under "Preparation".

• Insert the cookie attachment (16).

• Rotate the catch clockwise.

• Slide the rail (17) through the slots on the cookie attachment.

See below "Electrical connection/Application instructions".

Electrical connection

• Ensure that the function switch is set to "0" (Off).
• Connect the appliance to a correctly installed and earthed socket.

Function switch (I/II)

Use the switch (7) to select the desired operating mode for the switch (6).

Switch Functions Forward/Return (ON/O/R)

The appliance is equipped with a forward and return function. If the scroll should block, you can use the return function, in order to release it.

Forward:

• Turn the switch (7) to "I".
• Turn the switch (6) to "ON". The appliance is in the "Forward" mode.

- Return:

• Turn the switch (6) to "O" and wait until the motor stops.
• Turn the switch (7) to "ill". Press "R" on the switch (6). The appliance will be in the "Return" mode as long as you keep the switch pressed down.

Switching off

• Move the safety switch (6) to "O" and pull the power plug.

Application instructions

WARNING: Risk of injury!

Always use the supplied tamper. Never insert your fingers or tools into the filling neck!

CAUTION:

Do not use the appliance for longer than 10 continuous minutes. Let it cool for 10 minutes before using it again.

NOTE:

• Cut the meat into pieces of about 2.5 ~cm . Please take care that the meat does not contain any bones or sinews.
• For coarse cutting, use the disc with the largest holes.
• In a second step, select the steel disc with the fine or medium-sized holes, depending how fine you want to cut.
• Coat the steel discs beforehand lightly with vegetable oil.
• Coat the steel discs beforehand lightly with vegetable oil.

Making sausages

• You can use either natural or artificial intestines.
• If you have decided for natural intestines, soak them beforehand for some time in water.
  Make a knot at the end of the intestine.
• Push the intestine over the sausage attachment.
• You can use either natural or artificial intestines.

• If you have decided for natural intestines, soak them beforehand for some time in water.
  Make a knot at the end of the intestine.

• The sausage mass is pressed through the sausage attachment and the sausage intestine is filled.

• Make sure that the sausage intestine is filled "loosely", since otherwise the intestine could burst because the sausage expands when cooking and/or frying.
  After the first sausage has achieved the require length, press the sausage together at the end of the sausage attachment with your fingers.
• Until you have acquired routine, you can switch the appliance off after each sausage section.
• Twist the sausage once or twice around its own axis.

Cookie attachment

• Screw the cookie attachment on and adjust the required cookie shape.
• Put the dough on the filling tray and filler.
• Hold the dough strands at the outlet with your hand and cut off the required length.

Cleaning

WARNING:

Always pull the power supply plug before cleaning and wait until the appliance has cooled down.
- Never immerse the motor assembly in water for cleaning.
It could result in an electric shock or fire.

CAUTION:

• Do not use a wire brush or other abrasive utensils for cleaning.
• Do not use aggressive or abrasive cleaning agents.

Motor assembly

• Only wipe the motor assembly with a damp cloth and dry with a dry cloth after.

Filling tray, spiral, spiral housing and all accessories

CAUTION:

Do not clean these parts in the dishwasher. The surfaces could become lacklustre.

• These parts can be cleaned by hand in the wash basin.
• Rinse with clear water and dry the parts.

Storage

• Clean the device as described. Let the accessories dry completely.
  We recommend that you store the device in its original packaging when it is not to be used for a longer period.
  Always store the device at a well ventilated and dry place outside the reach of children.
• You may store the accessories in the accessory tray (4). Press the OPEN (3) button to open the tray.
• Regularly coat the steel discs with vegetable oil. Use the re-sealable foil bags for the storage.

Troubleshooting

Malfunction Possible cause Remedy
The device does not function.	The device is not supplied with power.	Check the outlet with a different device.
		Insert the power plug correctly.
		Check the mains fuse.
	The device is defective.	Contact our Service or a specialist.
	The function switch (7) is set to "II".	Set the function switch to "I".
The device is blocked.	Meat residue is sticking to the spiral.	1. Set the switch (6) to "O" and wait until the motor has stopped.2. Set the function switch (7) to "II".3. Set the switch (6) to "R" to loosen the blocked meat residue.4. Switch the device off and pull the power plug.5. Now remove any sticking residue.

Disposal

Meaning of the "Wheelie Bin" Symbol

Take care of our environment, do not dispose of electrical applications via the household waste.

Dispose of obsolete or defective electrical appliances via municipal collection points.

Please help to avoid potential environmental and health impacts through improper waste disposal.

You contribute to recycling and other forms of utilization of old electric and electronic appliances.

Your municipality provides you with information about collecting points.

Noise development

The sound pressure level in the ear of an operator (LpA) was measured according to DIN EN ISO 3744.

Specifications

Model: .FW 447 CB

Power supply: 220-240 V~, 50/60 Hz

Nominal power consumption: 550 W

Max. power consumption: 1200 W

Sound pressure level: 82 dB(A)

Protection class:

Net weight (without accessories): approx. 3.32 kg

The right to make technical and design modifications in the course of continuous product development remains reserved.

This device complies with all current CE directives, such as electromagnetic compatibility and low voltage directive and is manufactured according to the latest safety regulations.

HacaKa DnB BnroTOBHeHn neuBa

Habeprh hacdkny dny BurotoBneHH neuBa i yctaHObity fOpmy, kA Bam Notpi6Ha.
3anobHITb ticOM TaIIO I 3aHTaKeHHnpoDyKTIB.
- PntpmmyTe cmytn ticTa ha BIXoDi 3 cOpMn pykoH i BiDpi3aIte ix Ha notpi6Hy DOBXHHy.

YiueHenH

NONEPEDXEHNA.

• PpeTUM KI NOATN ONUUeHNA pINaDy, 3aBXDN BNTAYTE BNILKY 3 PO3ETKN eNEKTPOXNBnEHNA I YekaTe, NOKI pINaD He OXONOHe.
  Ahi B komy pazi He onyckaTe MoTOp B Body 3 MeToHO OHnueHH KopnyCy. Lc MoKe npu3BecTn Do eNeKtpuHoro ynapy abo noxekxi.

YBAGA.

He BnKOpNCbOyIe npoTMy a6o a6pa3mBHi 3ac06 nIra YIuHJ.
He BnKOpncToBMyTe aRpeCnBHi a6o abpa3nBHi 3ac06n DnA YmUeHH.

Motop npnilaNy

Kopnyc MOTopy cnii TiiBkn Ombupatn BONORO TKAHHO i nicra Lboro 06cyuBaTN cyXIO TKAHHO.

Ta4 3aBAHTaxeHH npOyKrib, cnipanb, Kopnyc cnipani i Bce npna

YBAGA.

He ouuuyte ci detani B nocydomnhi MaunHi. Nobepxhi detane MoKyTB BTPaTNT 6nCK.

LJI Detani Bu MoKete OuyBAtn BpyHy y Boi 3doab-HeHHa3ac06iDnMnTTNocdy.
CnolickyTe deTani uHIO BOHO i npOtpaTe Hx cyXIO TKAHHOIO.

36epirahnra

ПочсбтБе ппад,як опсаHo.ДaIte ппадию no-BHICTO BnCOxHyTN.
- RaKIO npuHaIe BnKOpNCTOByBaTmMeTbCra TpBaNIN Yac, peKOMeHDoBaHO 36epiratu Ioro B opriHaJIbHi yNAKOBU.
3aBxN 36epiraTe npuiaD no3a 30HO IOcKHOCTI dTe B cyXOMy, DObpe npoBITpOBAHOMy Mic#.
- PpnaJdMoxHa 36epirAty BIDInky dIpy npnlaJa (4). HATNCHTb KHOIKy OPEN (3),IO6 BiKpnTn IOTOK.
Perynepno 3mauynpe pewiTPO pocmHHoO oIcIO.KopncTyTEcnaKekTNAMN30JbH，UO3acti6aOTbc，Uo636epiratnpnnd.

YcyHeHHH HeCnpaBHOcTei

IpaHHJXMBHeHHa:.....220-240B,3mHHOCTpyMy,50/60T

Homihalhe cnoxmbHH eneKtpoeheprii: 550 B

MaKcImaJIbHe cIoxKmbaHnEeKeTpoEhepi:1200BT

3ByKOBNI TNCK: 82D5(A)

Tpryna enektpo6e3neuhocti:

Bara HETTO (6e3 npnna) .. np6n. 3.32 K

CoxpaHEno npaBO Ha texHnueckne I KOHcTpkyIIOHHbIe N3-MeHeHmB pAMkax npoDoJkaIoUeIcna pa3pa6OToN npOdyKta.

DaHHoe yCTpOCTBO COOTBeTCTByET BCEM TeKUIM DnpeKTNBAM CE, TAKIM KAK 3NEKTPOMaTHNTHAOR COBMECTMOCb N Hn3KOE HaPRAKeHHe; OHO IPOUN3BeDEHO B COOTBeTCTBmC HOBeuMMN PpaBnAmM TexHKn 6e3OnaCHOCTN.

PykoBODTO NOJb3OBaTeJIa

Bnaoradapm 3a nokykny hauero n3denny. Mbln aedeemc, TTO BbI cyD0BONbCTBnEM 6yTe IIOb3OBAbCnM.

CIMBOJBI DAHHOM pyKOBODCTBE NOJB3OBaTeJI

Baxhbly yka3aHn, kacaioiueBauei 6e3oNaCHOCTN, OTMe-yeHbI ocO6o.Bo n36exHaHne HeCuaCTbIX CnyaAEB N NOBpeK-DeHnY cTPOcTBa ObaaJte Ha HxocO6oe BNImaHne:

PENEUYIPEKDEHNE:

IpeDynpexJeHne 06 onaChocn dIg 3dOpobBy, yka3bIbaeT Ha BO3MOXHOCTb NOBpeXDeHn.

BHIMAHINE:

IToTeHuaJIbHaonachOcTBdIyCTpoIcTBAuINdpYnx npEMeTOB.

I PIMMEUAHNIA:

CobetbI INHopmaqnaI DnBac.

CoepkaHne

PacnoJoxeHne 3
IInIOCTpaAaA-D 4
O6uye yka3aHnno TeXnke 6e3oNaChocTn. 54
CneuaIbHbIe IHCTpyKUIN IO TexHKe 630NaChOCTn DnA 3TOrO yCTpOiCtBa. .54
Onicahne deTanei / nocTabnBEmbIX deTanei 56
Ha3nayeHne 56
PacnaKOBka yctpoiCTBa. 56
IodroTobka. 56
C6opka Mscopy6kn 56
UctaHOBKa HacaKdIIN COcICOK 56
UctaHOBKa HacaKm DnT Ke66e 57
UctahOBka Hacaikn Dnne neeHb. 57
IoiKIOUeHne 3JIeKTPoNTaHn. 57
Hnctpykui nno nncnoB3oBaHHIO 57
Ynctka 58
XpaheHne 58

YcTpaHHe HeIcnpaBHOCTeI 58

TexHueckme xapaKTepeNCTMkn 58

067ne yka3aHnno texhNke 6e3onachocTn

Ipeepnauanom 3Kcnpnyataun npnbopa BHNMaTeIbNo npOuHTaIe npnnaeraemyo INHCTpyKUIO NO 3KcnpyaTAtUN COxpaHNTe ee B HAdekHom MeCTe, BMeCTe C rapaHTnHBIM TaHOOM, KACCOBbIM YekOM N, PO BO3MOXHOCTN, KAPTOHNO Kopo6koC yNAKOBOChbIM MaTePnAOnM. Ecln daete KOMy-JINbo NonoJIb-3OBaTbCpnpbOpom, O6raTeNbHO daIte BnpiJaCy daHHyo INHCTpyKUIO NO 3KcnpyaTAtUN.

ПльзутесьприбормTOЛькочасьIMобраOMиnoHa3haueHIO.Pri6bOpHeпрдha3haueHДЯКOMMepcheCKORIOICNOLb3OBAHIA.
He noIb3yItecb np6bOp mo OTKpbItbIM He6o. IpeOxpanaIte np6bOp ot Xapbl, pIpaBIX coNHeHbIX lyHei, BnaXHOCTn (Hn B KOem cnYae He norgpykaIte erO B BoUy) n ydApOB 06 octpIe yrbl. He npKacaiTeCB K np6bOp BnaXHBIM pykam. Ecn np6bOp yBaXHNcra nn HAMOK, TyT Je BbHbTe BNk Ky n03ETKn.
Iocne 3KcNpyatauM,MOHTaxe npHnAaNeXHOCTeY, HCTKE HINI NIOOMKe pnp6opa Bcerda BbIHMaTe BUNKy n3 pO3ETKn (TAHNTe 3a BNky,a He 3a Ka6eb).
He octabnIte BkHoueHHbIe 3neKtpnp6bpI 6e3 npncMoTpa.BbIXOJa N3 NOMeueHnB CcerDa BBIKIOaHTe np6Op.BbIHbTe uTekep n3 p03eTkn.
- Pn6bop n Ka6eBcTeBOro nHTaHnHa Heo6xOdMPO peryIaRPHo 06CneIOBaTb Ha HauNue CNEIOB NOBpeKDeHn. PnO6HapUKeHn IOBpeKDeHn NOnb3OBaTbCra Pn6bOpom 3aPpeuAETcR.
IcnoJb3yIteToJIbKOOpnHaHaJIbHbIe3aIuaCTN.
- 13 coobpaekhen 6e0anacOCTn DnT DeTeH He octabIyIeJekaTb yNakOBky (IIaCTNKOBbIe MeuK, KapTOH, NeHONlact n T.D.) 6e3 npICMOTpa.

PENyIPEXKDEHNEI

He no3BOJnIe TeTm INpTaB c nOIN3TNHeHOBo IJIeHKO. Onachocb ydybja!

CneuaJIbHbIe HNCTpyKcII N O TexHnke 6e3OpaCHOCTn IJRA 3TOrO yCTpO'CTBa

YcTpoCTBO He IpeDxHa3HaueHo IJIa IcNoJIb3OBAHnB KOMMepHeCKHX CEJIAX.

NcnoIb3OBAHnE BpynX ueJnx HHe B COOTBeTCTBmC INHCTpykUyM CNHTaeTCa HnPaBnIbHbIM N MOxET npNBecTN K nopue IMyIeCTBa N IINHON TpaBMe.

N3ROBNTJIbHe Hecet OTBeTCTBeHHOCTn 3a yUeep6,C8ra3AHHbI C HEPAPBUNbHbIM NCTIOJIb30BaHnEM.

PacnaKOBka yctpoNCTBa

1.ИЗВЕКИТЕУСТЮСТВОИЗEROУNAKOBКИ.
2. YdaJInte BCE yIaNKOBOUHbIe MaTePnAJIbI, TAKHe KaK fONbI, 3aONHJIOUJIne MaTePnAJIbI, DePkaTeJI N Ka6EJI N KApTOHHyO yIaNKOBY.
3. Поверп Te KOMПЕКTHOCТи NOCTaBKN.
4. Ecni KOMPJIeKT NOCTaBKN HENONHbI INN 3aMeTHbI MEXAHnHeCKne NOBpeXdEHN, He BKnIOuAte npNbOp. Cpa3y XeBepHnTe BeCb KOMPJIeKT pOdaBly.

ПРМЕЧАнЯ:

Ha yctpoiCTBe MOrYt OcTaBaTbCn PbIb N OcTaTKn Ipn3BOJCTBeHHbIX MaTePnaIOB. PekomeHnyeTcN NouChiTb yctpoiCTBO B COOTBETCTBm C pa3deIOM "UcTka".

I\Pi\PiMeUaHInA:

• Akceccyapbl ynaKOBaHbI B nakeTb 3 foJIbMHOropa3oBOrO nCIOJIb3OBAHn. CoXpaHnTe 3TN nakeTb dIpy XpaHEnn np60pa n akceccyapob.

IodroTOBka

VcnoIb3yIte nIIIOCTpaIuHa cTp.3n4.

1. Bctabte 6nok uHeka (9)B noIooKeHnn "Ha 2 yaca" B npIN BOd uHeka.
2. YdepKINBAIte KHOIIky OcBO6OKeHn8 (8) HaxaToi. NOBepHInTe 6NOK CNIPAIN PpOTMB YacOBo CTpeKN Do er03aueJIKBaHnB B NOCADOHOM THe3De.
3. YctaHOBInTe IOnaIOUJI NToK HA IOnaIOUHy TOpNOBHy TaK, UTObI KpENIIeHne IOTKa paCnOraIocb HAd 6JIOKOM DBNrAteJIa.
4. BctabTe uHEK (10) B rOpn3oHTaIbHyIO qAcTb KOpnyCa uHEKa, yTO6bl OcB BOUJIHa CBOE MECTO.

Takke obpatntecb K pa3dennam C onncaHem c6opkn MrcOpy6kn, yctanobkn HacaKn Inn Ke6be, HacaKn Inn cocncok NII HacaKn IIN neuehber.

C6opka Mscopy6kn

IcnoIb3yIte IJIIOCTpaun "A" (CTP.4).
BbInOnHInTe nyKtb1-4Ba pa3deJe "IpaTRObKa".

1. YctaHOBnTe HOK Ha BaI WHeKa OCTpbIMN KpOMKaMn HApKy.

2. BbIbepeTe ceTatTuH hacaKy (12).

I PIMMEUAHNA:

HanpaBnIouIe DOnKbI BXOINb B BbiEMKn B KOpNcye

7.Повернiteстор no caloboi ctpeJIke.
8.Пложніт e Kycочн Mяса H a n odaioци nIoTOK (2) nВ nOdaIOUyI roPLOBnHy.

O6paTntecbKpa3dny"PtoKnIOueHHe 3eKTPoNTaHn/ HNCTpykUIM NO NcONb3OBAHNO daJe.

YcTaHOBKa HacaKn DnA COcNcOK

• NcnoIb3yIte IINIOCTpaun "B" (ctp. 4).
  BbIIOJIHNTe IyHKtby 1-6 Bpa3dEJax "PoiIroTOBa" n "C6opka Mrcopy6kn".

• YctaHOBIne HacaIky IyIcOcICoK Ha Kopnyc IWeHa
  8.Повернiteстор noЧасови стрелke.

• PtojKeTe COcncOuyh foapH Ha noDaiouI JnToK (1) n B noaioUIO ropIOBHy.

O6paTntecbKpa3dny“PoiKnIooHHe 3NeKtpOniTahn/ HNCTpykUIM NO IcONb3OBaHHo"daJe.

YcTaHOBKa HacaKn Ie66e

IPYMEUAHNA:

Hacadka nIg Ke66e no3B0n8et DeIaTb Tpy6oKu N3 MrcHO ro qapwa uIN TecTa.

• IcnoIb3yIte nJIJIIOCTpaIuN "C" (CTP. 4).
  BbInOnHInTe nyHkTb1-4Ba pa3deJe "IpaTOBka"

• YctaHOBiTe HacaKny IJn Ke66e n3 2 JcAteH Na BAN UHEKA.

ПРIMECHИЗ:

HaipabJIIOUe Ha HacaIKe DOJIxHbI BXOJNTb B BblEMKnB KOpnyce UHeKa.

6.Повернiteстор no уасьои стрлкe.
7.ПОJOXNTE MЯСHоJФAPUИЛТЕСTOHa NODaHOUJI JOTOKI B NODAHOUJIO ROPLOBHy.

O6paTMEcB K pa3dny "IoiKIOUeHHe 3IEKTPoNTaHn/ HCTpykUnn No IcNoNb3OBaHnO" daJe.

YcTaHOBka HacaKINnneHb

ПИМЕЧАНО:

3Ta Hacadka no3B0JraT nonyauTb pa3nHhble foopmbi n3 roTOBOro Tecta dIg neueHb. Oco6eHHO xopoio nonyauIoCTc Ta KaHa3bIbAembIe IInpITUre63K (BID neueHb).

• IcnoIb3yIte nIIJIIOCTpaUN "D" (CTP. 4).
  BbInOHHTeIyHKtby1-4BaPazene"PiOtroTOBaKa

5.BcTaBbTe hacAnky dny neeHbY (16).
6.ПовернITE стогор по уасов�стpenke.
7. CnEynTe no HanpaBnaIoum (17) uepe3 pa3bembl Ha- cadkn dnn neeHb.

O6paTnTeB K pa3dny "IoiKIOHcHHe 3eKTPOnrTaHn/ HnCTpykUIN IO nCNoJIb3OBaHmO" daJIee.

IopKIOUeHne 3JekTpOnnTaHn

• PeneKIOUaTeIb cyHKuIN DOJKeH 6bITb B NOJIOKeHn "O" (BbIKI.).
  BkIIOUHTe npHbOp B npaBnIbHo ycTaHOBJIeHHyU n3a- 3emEHHyO 3eKtpnHeckyO p03ETky nepMeHHOrTO KA.

IpeeknouateIb cyHKn (I/II)

Ncnonb3ynte nepeknioateNB (7) nBb6opa jenaemoro pekma pa6oTb nInepeknioateNA (6).

Функшипеклоча TeBnepeHa3aON/O/R)

Pnp6op mmeT cyHKUHO pa6oTBbNEpeN ha3aN. EcmnIuHEK 3actONOpNTcR,TO BKJIIOueHHeM cyHKUHN Ha3aMDOXHOOCBO6OHTb erO.

-ФункцьВпесад:

-ПовернITEпеклочаь (7)Н "I".
- YctahOBInTe nepeKlnHouatelb (6) B noIOxKeHne "ON". PnIbOp 6ydt paOtaTb B peKmE "BpePeD".

-ФункинHaazd:

• YctahOBInTe nepeKlnHouaTeInb (6) B nIOJIOKeHne "O" INdoXdITeCb OCTaHOBKn DBnIraTeJIa.
  YctahOBHTe nepeKIOHATeIb (7) B noIOXeHMe "II". HaxMITE "R" Ha nepeKIOHATeIe (6). Pnp6op 6ydet B peKIMe "O6paTHoro xOda", noka bbl ydepXnBaTe nepeKIOHATeIb HaxaTbIM.

BbIKIOueHne

• YctaHOBInTe IpeekHouaTeInb (6) B noIOxKeHne "O" N BblbTe BnIKy n3 p03eTKn.

HCTpykunno nCNOJb3OBaHNIO

PNEUYPEXKDEHNE: Pnck TpaBmbl!

Bcerda noIb3yITeCb npnIaeroMoT pAm6oBko.HnkOrda He BCTaBnIe TaIbUcI INN KxOHHbIe PpeMTeB I NOaIOuYIO roPNOBuHy!

BHIMAHINE:

He nCIOJIb3yIte npi6op DoJIbSe 10 MmHyT B HENpepbHOM pexime. DaIte emy ocTbB TeueHne 10 MmHyT nepei nCIOJIb3OBAHnEM CHOBA.

PIMEAHNA:

HapeaTe McoHa KycOuKn npMepHo 2,5 cm.CneJeTc 3a Tem, YTo6bI B Mace He nonaJIncb KOCTn IIN cyXoxKn-
-Дя Круннoi Hape3kn Mca NcnoJb3yIte HacaKy c 60JIbUIMN OTBepCTnMn.
Ha Btopor mare BbIbepnte cTaNbHyIO HacaIky C MEIKIMN IIN CpeHNMI ONBepCTNMAI, B 3aBNCMOCTN OT TORO, KAK Bbl XOTNTe N3MeNbYHTb IpOdyKTbl.
3apaaHe CmaKbTe HacaKy He6oJIbUIM KOJInueCTBOM pactIteJIbHOrO MaCna.

I3roTOBHeHne COcHcOK

• MoXH0 INCIOJIb3OBA Tb HaTypaJIbHbIe IIN NCKYcCTBeHHbIe KNUKJ.
• EcnBbpeunnnncnncnbsobatb HATypabhbte KUNKIN, PpeBaPntelbHO 3amOHTe INX B OBe Ha HeKOToPoe Bpemr.
• 3aBryKInTe y3eJHa KOHcE KINJHK.
• HadehbeTe KMIshky Ha HacadKy dny COcNcOK.
  CocncoHbI papI npOaBnBaETcYpe3 hacAnky dIPO COcNcOK, IN KUIIka 3aONIHReTc.
  3aONHnIe COcncOHyIO KNUKy HE CNIUkOM NIOTHO, NOCKoNbKy B IPOTNBOM CJIyae OHa MOKeT JIoNHyTb N3-3a pacuImpeHnI qap7a pnp BapKe nIN JapKe.
• Pocne noIyueHnepBoCocNHyJHOI dINHb3aKMTe KNUKy Ha KOHc HacAnDInr COCnCK nJIbUAMN.
• POKa Bbl He npno6peTe TEOnbIT, MoKHO BblKJIIOHaTb PnI-6Op nOcne nOlyuHnKaKDoCocNKn.
• 3akpyTnte cooccky Bokpyr cBoei oCn ODN HIN IIN da p3a.

I3ROTOBHeHne neeHb

• YctahOBInTe Hacadky IaIypeHbI N 3aIaIte Tpe6yeMyIO fOpMy Ira neHeh.
  -ПомecHTte TECTO Ha noDAKUIM IOTOK IN BTOPNOBHy.
  -Полдержавиerte 3aToBkyИЗ TeCTaHa BbIXOde pyKoI n HapezaTe NeueHbe HxKHOДПINHbI.

UncTka

NPEyTNPEXDEHNE:

-ПердчNTКОВ BCERДа ВИHIMаTe BUNKу n3 pO3eTKn IdoxuaIaTeCb OCTbBaHnЯ np6opa.
HnKOrda He nOpykaIte 6IOK DIBrataTeN B YoD yIaYnCTKn.3To MoKET npINBeCTN K NopaxKeHNo 3NeKTPnHeCKIM TOKOM INI BOCJIaMeHENIO.

BHIMAHINE:

He nnoB3yTe MeTaJIuYeCKyU TeKU INn INhIe abpa3nBhIe KxOHHbIe npHaJdJIeXHooCTN IIN OCHTN.
He nCnoJIb3yIte arpeccnBhIe nn a6pa3nBHbIe YnCTa-

Bnok Dnuratena

-БлкдьгателчсптTeToJIbKO npOTnKoB BnaKHOI TkaHbIOи 3aTEM cyXOITKaHbIO.

Ipaun JIOK, HneK, Kopnyc HHeKa n BCE HacaKn

BHIMAHINE:

He MoTe 3Tu DeTaN B NocyDomoeuHou MaunHe. NobepxHOCTN MOYr TOTyCKHTb.

• MoIte 3tN DeTaTn B paKOBIne BpyHyko.
• Onolochite mCTO BODI IN BbCyWITE.

XpaHeHne

-ПочИсте устюгв,кak onиcaHo.Плнocью пocушптЕ насади.
- Eçnl yctpoiCTBO He 6ydet NcNoIb3ObaTbCRA dIITeJIbHOe Bpem, To peKOMeHnyeTcXpaHITb erO bOpINHaJIbHOI yIaKOBKe.
BceTgxaHnTe yctpoNCTBO BXopoOIO npOBeTpnaEMOM n CyXOM MeCTe, He NOCTyTHOM DeTm.
Bb moKeTe xpaHnTb akceccyapbI B cneuaHbHom OTdene IINr HacdoK (4).Hakmnte KhoNky OPEN (3),YTo6bl OTKpbItbOTcK.
- Perynapno Cma3bIaIte HacaKn He6oJIbIIM KONUeCTBOM paTNTeBHOrO macna. IcNoJIb3yIte 3akpbIbAOuIeCRA NaKeTbI nФoJIbIg IpnXpaHeHn.

YcTaPaHHe HEnCnpaBHOcTei

jia 1ai all ci 1ai all CE 1i jie 1ie jie ai

aaiai ai Ls jiaiaiall jill lgs g gssbinae gse 51

aill

glal 1000 7
Aeall 8
aiill g aiill 9

"aaai" Jaaai ai 1sJi

aalal 121 pdsu yjgul jy jnll

3

.

a

aillll jie bjjjai

aill 1 gall

Aailll lalally jolll gaiy sall slls

aLdo gie Ie baoaln jay yjll lqan aai

a a a a a a a a a a a a a a a a a a

yjglj jglj

laalaaa aai jai jai jai jai

.

a 1

将 1 2 3^1 变化为 1 2 3^2

j_L = 1 a_1 = 2 a_2 = 3

Aa 1

a 2

a. a. 151 o. 151

.3

iislaol oig iolal aolll lai

！

J 1

jill jia jia jie jie jie jie

a5jai1j2j1 jali

aaii iieiiee iieiie

i

1

1

BOMANN®

C. Bomann GmbH

Internet: www.bomann.de
