USER MANUAL MWG 2289 CB BOMANN

• Do not remove any installed parts from inside the oven or anything from the inside of the door!

DO NOT REMOVE THIS COVER. DO NOT operate this oven if the door is bent, warped or otherwise damaged and does not close rmly. DO NOT tamper with the door safety interlocks. MAINTENANCE should be carried out only by a qualied serviceman. Remove plug or disconnect from the mains before removing cover.

WAARSCHUWING - HOOGSPANNING

WAARSCHUWING - MAGNETRONSTRALING

• The appliance is designed exclusively for private use and for the envisaged purpose. This appliance is not t for commercial use.

• Do not use it outdoors. Keep it away from sources of heat, direct sunlight, humidity (never dip it into any liquid) and sharp edges. Do not use the appliance with wet hands. If the appliance is humid or wet, unplug it immediately.

• When cleaning or putting it away, switch off the appliance and always pull out the plug from the socket (pull the plug itself, not the lead) if the appliance is not being used and remove the attached accessories.

• Do not operate the machine without supervision. If you leave the room you should always turn the device off. Remove the plug from the socket.

• The device and the mains lead have to be checked regularly for signs of damage. If damage is found the device must not be used.

• Use only original spare parts.

• In order to ensure your children’s safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach. WARNING! Don’t let small children play with foils for danger of suffocation! Important Safety Information! Please read carefully and keep for future use.

• The microwave oven is intended for heating foods and drinks. Drying foods or clothes or heating electric pads, slippers, sponges, wet cleaning rags, or similar can cause injuries, combustion, or re.

• The microwave oven is not suitable for warming/heating up living animals.

• When the door or the door seals are damaged, the microwave oven must not be used until it has been repaired by a qualied specialist.

• Please do not repair the device yourself, but have it repaired by an authorised specialist. Carrying out mainte- nance or repair work which involves removal of the cover that protects the surroundings from microwave radia- tion is dangerous unless carried out by an expert.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid a hazard.

• Do not heat liquids in closed containers. DANGER OF EXPLOSION!

• Do not place your microwave in a cupboard.

• The appliance requires sufcient space for air circulation in order to function properly. Leave a distance of 20 cm above, of 10 cm on the back, and of 5 cm on both sides of the appliance. Do not cover the appliance. Never block the openings of the appliance. Do not remove the feet.

• Place the appliance with the back facing a wall.31

• The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless they are continuously supervised.

• Only suitable tableware should be used such as: glass, porcelain, ceramics, heat-resistant plastic or special microwave tableware.

• If food is being heated or cooked in combustible materials, such as plastic or paper containers, the micro- wave oven should be checked frequently due to the risk of re.

• If smoke is produced, turn the device off and remove the plug. Keep the door closed in order to suffocate any ames.

• The contents of babies, bottles and jars of baby food must be stirred or shaken and the temperature checked before use. There is a danger of burns.

• Use oven cloths or kitchen gloves when removing the containers. DANGER OF BURNS!

• Food with a shell or skin, such as eggs, sausages, sealed jars etc. must not be heated up in the microwave as they may explode even when heating by the microwaves is nished. WARNING Delay in boiling: During boiling, particularly during the reheating of liquids (water), it may happen that the boiling temperature has been reached but the typical bubbles have not yet started to rise. The liquid does not boil evenly. When the vessel is removed this so-called delay in boiling may result in the sudden formation of bubbles when the vessel is kno- cked, causing the water to boil over. There is a serious danger of burns! In order to achieve even boiling, please place a glass rod or similar item, but nothing metallic, in the vessel.

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or in- struction concerning use of the appliance in a safe way and understand the hazards involved.

• Children shall not play with the appliance.

• Cleaning and user maintenance shall not be made by children unless they are older 8 years and supervised.

• Keep the appliance and its cord out of reach of children less than 8 years.

• Any dirt on the door frame/door seal and neighbouring parts must be carefully cleaned with a damp cloth.

• Clean the microwave oven regularly and remove any food residues from the interior.

• If the machine is not clean the surface may be damaged, affecting its serviceable life and possibly resulting in hazardous situations.

• Do not use any aggressive abrasive cleaners or sharp metal scrapers to clean the glass door. You could scratch the surface. This can destroy the glass.

• Steam cleaner is not to be used.

• Also follow the instructions which are given in the “Cleaning” chapter.

• Do not operate the appliance with an external timer or separate remote control system.

• for heating up and cooking solid or liquid foods

• for browning and grilling solid foods. It is intended for the use in households and for similar applications, such as:

• in staff kitchens of stores, ofces, and other industrial areas;

• by guests in hotels, motels, and other housing facilities;

• in agricultural estates;

• in bed and breakfasts.32 Warning Labels on the Appliance Please note the warning label on the back of the microwave oven:

DO NOT REMOVE THIS COVER. DO NOT operate this oven if the door is bent, warped or otherwise damaged and does not close rmly. DO NOT tamper with the door safety interlocks. MAINTENANCE should be carried out only by a qualied serviceman. Remove plug or disconnect from the mains before removing cover. Overview of the Components 1 Power control 2 Timer 3 Door opener 4 Grilling grid 5 Roller ring 6 Door lock 7 Viewing window 8 Grill heating 9 Turntable 10 Mica sheet Information on Grilling and Combined Operation

• As heat radiation is used during grilling and combined operation, please use only heat-resistant tableware. Plastic containers are not suitable.

• When food is only being grilled, metal or aluminium tableware may also be used -but not during combined or microwave operation.

• Do not place anything on top of the housing as this becomes hot. Always leave the ventilation slits uncovered.

• Please use the grilling grid to move the food to be cooked nearer to the heating element. Suitable Microwave Tableware

• The ideal material for use in a microwave is transparent and allows the microwave radiation to heat the food evenly.

• Round/oval dishes and plates are more suitable than rectangular ones as the food in the corners may overcook.

• Microwaves are not able to penetrate metal, so that no metal ves- sels or plates should be used. CAUTION: Do not use any paper dishes made of recycled material as these may contain small amounts of metal, which may result in sparks or res. The list below is intended to help you select suitable microwave table- ware: Material Suitable for microwave grill combination * Heat-resistant glass vessel yes yes yes Non-heat-resistant glass vessel no no no Heat-resistant ceramic vessel/plate yes yes yes Plastic vessels suitable for microwave use yes no no Kitchen roll yes no no Metal tray no yes no Grilling grid no yes no Aluminium foil and foil containers no yes no *) Combination of microwave with grill. Initial Operation

• Press the button below the timer clock to open the door of the microwave. The door swings open.

• Remove any accessories from the cooking chamber and unpack. Place the roller ring on the recessed area of the cooking chamber and move it back and forth until it locks into place.

• Place the turntable on the roller ring in such a way that the turntable cannot be moved anymore.

• Check the device for any visible damage, particularly in the area of the door. If any damage is found, the machine must not be used.

• In order to avoid interference to other machines when the micro- wave oven is operated, do not place it in the direct vicinity of other electronic devices.

• Remove any protective foils that may be adhered to the housing.

• Insert the mains plug into a properly installed power socket. CAUTION:

• Do not remove any installed parts from inside the oven or from inside the door!

• The mica sheet (10) is also part of the appliance and must not be removed. It protects the electronic component located behind it from dirt.33 Using the Device What you should know about microwave operation

• Your device works with microwave radiation, which heats up water particles in food in a very short time. There is no heat radiation and therefore hardly any browning.

• Only food should be heated up with this device.

• The device is not suitable for baking in oating fat.

• Only 1-2 portions should be heated up at the same time. Otherwise the microwave will become less efcient.

• In order to interrupt the cooking process, turned the timer to “0”.

• Microwaves provide their full energy levels immediately. Pre-heating is therefore not necessary.

• Never operate the microwave function when the oven is empty.

• The microwave oven does not replace your traditional cooker. It is used mainly for:

• defrosting deep-frozen food

• rapid warming/heating of food or drinks

• cooking meals. Operation

1. Place the food to be heated in a suitable piece of tableware.

2. Open the door and place the vessel in the middle of the glass plate.

Then close the door. (For safety reasons the oven only operates when the door is tightly closed.)

3. Adjust the microwave power as required:

Power Micro- wave in

Field of Application LOW Keeping warm

Melting cheese etc. DEFROST Defrosting 36 Defrosting frozen food MED Low 58 Continued cooking M.HIGH Medium 81 Cooking e.g. meat HIGH High 100 Rapid heating GRILL Grill 100 Grilling and browning on top COMBI.1 Grill + microwave

Defrosting and grilling COMBI.2 Grill + microwave

Cooking and browning COMBI.3 Grill + microwave

4. Set the required cooking time with the timer. The cooking time de-

pends on the quantity and constituency of the contents of the oven. With a little practice you will soon learn to estimate the cooking time. NOTE:

• preparation of food in a microwave oven is very much faster than in a conventional cooker. Set the cooking time to a low level if you are not sure and continue cooking again if necessary.

• once the cooking time is set the oven switches itself on. The light inside the oven goes on.

• Please note: A cover should be placed over the food when oper- ating the microwave. When the time has nished the oven switches off automatically. A sound is heard. The food should then be removed. Cleaning

Turn the microwave off and remove the mains plug. CAUTION:

• Do not use any wire brush or other abrasive objects.

• Do not use any acidic or abrasive detergents.

• Do not use a metal scraper to clean the viewing window. The surface could be scratched and the glass could possibly break. Interior

• Keep the interior of the oven clean. Splashes and overowing liquids on the walls of the oven can be removed with a damp cloth. If the oven is very dirty a mild detergent can also be used.

• Wipe off the viewing window on the inside and outside with a damp cloth and remove splashes and stains from overowing liquids regu- larly. External Walls

• The external walls of the microwave should only be cleaned with a damp cloth. Please ensure that no water enters the openings in the housing and therefore inside the device.

• The switches should also only be cleaned with a damp cloth. Accessories

• The glass plate should occasionally be cleaned with washing-up liquid or in the dishwasher.

• Clean the roller ring and the inner bottom surface regularly. Remove the roller ring and clean by hand using a mild detergent. Dry the roll- er ring thoroughly and then reinstall it on the bottom of the cooking chamber.

• Clean the grill after each use with a dishwashing detergent or place it in a dishwasher for cleaning. Odours

• In order to remove any unpleasant odours that may emanate from the microwave, place a dish lled with water and lemon juice that is suitable for microwave use in the oven and heat it for approximately 5 minutes. Then wipe out the oven with a soft cloth. Oven light
