IAN 277582 - Watch AURIOL - Free user manual and instructions

Brand	Auriol
Model	IAN 277582
Product type	Analog quartz watch
Display	Hour, minute and second hands
Water resistance	5 bar (50 meters) according to DIN 8310
Bezel	Rotating (only on models HG01619A/B/C/D/E/F/H/K/M)
Crown	2 positions: normal and pulled (position 1)
Power supply	Battery (type not specified, replacement in specialized store)
Warranty	3 years from date of purchase
Cleaning	Soft dry cloth, exterior only
Case material	Not specified (likely stainless steel or alloy)
Case diameter	Approximately 40 mm (estimate)
Weight	Approximately 50 g (estimate)
Main functions	Time display, timing via rotating bezel
Maintenance	Annual water resistance check
Recycling	Used batteries at recycling center; watch at collection point

Frequently Asked Questions - IAN 277582 AURIOL

How to set the time on my Auriol IAN 277582 watch?

Pull the crown to position 1 to stop the second hand. Turn the crown to set the hour and minute hands. Push the crown back in to restart the second hand.

How to replace the watch battery?

Battery replacement must be done by a professional at a specialized store. Do not open the watch yourself.

Is my watch waterproof?

Yes, it is water resistant up to 5 bar (50 meters) according to DIN 8310. However, water resistance is not permanent: have it checked annually.

How to use the rotating bezel?

The rotating bezel allows you to measure a duration. Turn it counterclockwise to align the zero marker with the minute hand, then read the elapsed time on the bezel.

How to clean my watch?

Clean the exterior of the watch with a soft, dry cloth. Do not use chemical or abrasive products.

What to do if my watch stops working?

Check if the battery is dead. If the battery is new and the watch still does not work, contact customer service or return it to the seller.

What is the warranty period?

The warranty is 3 years from the date of purchase. Keep the receipt as proof.

Does the warranty cover loss of water resistance?

No, loss of water resistance is not covered by the warranty. Water resistance must be checked regularly.

How to dispose of my old watch?

Do not throw the watch in household waste. Drop it off at a collection point for electronic products or inquire with your municipality.

Can I swim with my watch?

Yes, it withstands 5 bar pressure, so it is suitable for swimming and light water activities. Avoid scuba diving.

USER MANUAL IAN 277582 AURIOL

Operation and Safety Notes

FR BE

MONTRE

3 BAR	√	×	×	×
5 BAR	√	√	×	×
10 BAR	√	√	√	×
20 BAR	√	√	√	√

ARMBANDUHR

Einleitung

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the unit as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Preparations for use

• Changing the battery
  Note: Have batteries changed in a specialist shop.

Display

1 Minute hand
2 Crown
3 Second hand

4 Hour hand
5 1st position
6 Bezel (rotating outer ring)

(HG01619A/B/C/D/E/F/H/K/M)

Setting the time

1. To set the time, pull the crown 2 out to the 1st position 5.
2. Turn the crown 2 to set the hour and minute hands 4, 1.
3. When the crown 2 is pushed back to the normal position the second hand 3 begins to run.

Watertightness

This watch is watertight to five bar in accordance with DIN 8310. Figure C shows the permissible areas of use. Please note that the watertightness is not a permanent feature. It should be checked annually and particularly before subjecting it to special conditions, as the function of the inbuilt sealing elements diminishes with daily use.

Timing (HG01619A/B/C/D/E/F/H/K/M)

The bezel 6 is used to indicate a period of time (e.g. jogging time).

The amount of time elapsed can be read easily from the bezel.

Thebezel6 in anti-clockwise direction to mark the start of timing.

Cleaning and maintenance

Clean the product on the outside only with a soft, dry cloth.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste.

Information on collection points and their opening hours can be obtained from your local authority.

Faulty or used batteries must be recycled in accordance with Directive

2006 / 66 / EC and its amendments.

Return the battery and / or the device through the appropriate collection facilities.

Environmental damage through incorrect disposal of the batteries!

Batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows:

Cd = cadmium, Hg= mercury, Pb = lead. That is why you should dispose of used batteries at a local collection point.

Warranty

The device has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of product defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this device is 3 years from the date of purchase. Should this device show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it - at our choice - free of charge to you.

The warranty period begins on the date of purchase. Please keep the original sales receipt in a safe location. This document is required as your proof of purchase. This warranty becomes void if the device has been damaged or improperly used or maintained.

The warranty applies to faults in material or manufacture. This warranty does not cover product parts subject to normal wear, thus possibly considered consumables (e.g. batteries) or for damage to fragile parts, e.g. switches, rechargeable batteries or glass parts.

The warranty further excludes a reduction in water tightness. The state of water tightness is not a permanent property and should therefore be regularly maintained. Please note, opening and repairs performed by unauthorized individuals will void any warranty.

C

MONTRE

Introduction

HG01619I/HG01619J/HG01619K/

HG01619L/HG01619M/HG01619N/

HG01619O

Version: 10/2016
