USER MANUAL ErgoMixx MS61B6170 BOSCH

gungen jederzeit über Ihren Fachhändler, bei dem Sie das Gerät gekauft haben, oder direkt bei unserer Landesvertretung anfordern. Die Garantie bedingungen für Deutschland und die Adressen nden Sie auf den letzten vier Seiten dieses Heftes. Darüber hinaus sind die Garantie- bedingungen auch im Internet unter der benannten Webadresse hinterlegt. Für die Inanspruchnahme von Garantie- leistungen ist in jedem Fall die Vorlage des Kauf beleges erforderlich. Änderungen vorbehalten.8 en Intended use Intended use Read and follow the operating instructions carefully and keep for later reference! Enclose these instructions when you give this appliance to someone else. If the instructions for correct use of the appliance are not observed, the manufacturer’s liability for any resulting damage will be excluded. This appliance is intended for domestic use only. Use the appliance only for processing normal amounts of food and for normal amounts of time for domestic use. The appliance is only suitable for cutting or mixing food. The appli- ance is not suitable for preparing mashed potatoes (or purées of foods with a similar consistency). It must not be used for processing other substances / objects. Use the appliance only with original parts and accessories. Do not place the appliance on or near hot surfaces, e.g. hobs. The blender jug is not suitable for use in the microwave. This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Keep children away from the appliance and connecting cable and do not allow them to use the appliance. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children. Safety instructions W Warning! Danger of electric shock and fire! Only use the appliance indoors at room temperature and up to 2000 m above sea level. The appliance may only be connected to a power supply with alternating current via a correctly installed socket with earthing. Ensure that the protective conductor system of the domestic supply has been correctly installed. Connect and operate the appliance only according to the type plate specifications. Use only if power cord and appliance show no signs of damage. To avoid potential hazards, repairs such as replacing a damaged cable must only be carried out by our customer service personnel. Do not connect the appliance to or operate it by means of a time switch or remote control socket. Never leave the appliance unattended while it is switched on! We recommend that the appliance is never switched on for longer than is necessary to process the ingredients.9

• Safety instructions The mains cable must not come into contact with hot parts or be pulled across sharp edges. Never immerse the base unit in water or place it in the dishwasher. Do not use the appliance with damp hands and do not operate at no load. Do not immerse the appliance in the ingredients above the blender foot-base unit connection point. After each use, whenever the appliance is unsupervised, prior to assembly, prior to disassembly, prior to cleaning and in the event of an error, the appliance must always be disconnected from the mains. W Warning! Risk of injury! Care should be taken when handling sharp cutting blades and emptying the bowl as well as during cleaning. Immediately after using the appliance, wait for the blade in the blender foot to come to a standstill. Prior to replacing accessories or replacement parts that are moved during operation, the appliance must be switched off and disconnected from the mains. Do not attach or remove accessories until the appliance is at a standstill. Never grip the blade in the blender foot. Never clean the blade in the blender foot with bare hands. Use a brush. W Warning! Risk of scalding! Take care when processing hot food. Hot food may splash during processing. Never place blender foot on hot surfaces or use in very hot food. Leave boiling food to cool down to at least 80°C before processing. Before using the hand blender in a cooking pot, take the pot off the hotplate. W Warning! Risk of suffocation! Do not allow children to play with packaging material.10 en Contents Depending on the model: 9 Whisk with gears 10 Masher attachment with gears 11 Multifunction accessory 12 Universal cutter with lid With the universal cutter, you can use the appliance at full power. If the universal cutter is not included with the hand blender, it can be ordered from customer service (order no. 12027758). Operation The appliance is suitable for blending mayonnaise, sauces, mixed drinks, baby food, cooked fruit and vegetables. For puréeing soups. Use the universal cutter for cutting / chop- ping raw food (onions, garlic, herbs, etc.)! We recommend you use the blender jug provided. However, other suitable receptacles can also be used. Caution! The bottom of the receptacle you use must not have any bumps or steps in it. ■ Clean all parts before using for the first time. X Fig. B ■ Completely unwind the mains cable. ■ Place the blender foot on the base unit and lock into position. ■ Plug the mains plug into the mains. ■ Place the food in the blender jug or another tall receptacle. The appliance works better if there is some liquid in the ingredients. ■ Set the required speed with the speed control (Fig. B-5). It is recommended using a low speed setting for liquids, hot food and for mixing (e.g. muesli into yoghurt). The high speed settings are recommended for processing more solid foods. ■ Firmly hold the hand blender and jug. ■ Switch on the hand blender by pressing the required On button. Congratulations on the purchase of your new Bosch appliance. You can find further information about our products on our website. Overview Please fold out the illustrated pages. X Fig. A 1 Base unit 2 Power cord 3 Speed control Operating speed can be adjusted continuously between the lowest (●) and highest (12) speed (only in conjunction with button 4a). 4 On button The hand blender remains switched on as long as an On button (a or b) is pressed. a Controllable speed (with speed control 3) b Turbo speed The turbo speed is used for the uni- versal cutter (if included in delivery). 5 Release buttons To remove the blender foot, press both release buttons at the same time. 6 Blender foot Plastic or metal (depending on model) Attach the blender foot and lock into position. 7 Blender blade 8 Blender jug with lid Using the blender jug will prevent the ingredients from splashing. Place the lid on the blender jug to keep processed food in it. Contents Intended use p. 8
• Safety instructions p. 8
• Overview p. 10
• Operation p. 10
• Cleaning p. 11
• Troubleshooting p. 11
• Recipes and tips p. 11
• Disposal p. 12
• Guarantee p. 1211

Cleaning When switching on the hand blender, hold it at a slight angle to prevent it from “sticking” to the bottom of the blender jug. The hand blender remains switched on as long as the On button is pressed. To prevent the ingredients from splashing, do not press the On button until the blender foot has been immersed in the ingredients. Always switch off the hand blender before taking it out of the ingredients. ■ Release the On button after processing. After using the appliance: ■ Pull out the mains plug. ■ Press the release buttons and remove the blender foot from the base unit. Cleaning The appliance must be thoroughly cleaned after each use. W Risk of electric shock Never immerse the base unit in liquids and do not clean in the dishwasher. Before cleaning the appliance, pull out the mains plug! Do not steam-clean the appliance! Caution! Surfaces may be damaged. Do not use abrasive cleaning products. Note: The plastic parts may become discoloured when processing certain ingredients such as red cabbage or carrots, however this can be removed with a few drops of cooking oil. ■ Pull out the mains plug! ■ Wipe the base unit with a damp cloth and then wipe dry. ■ The blender jug can be cleaned in the dishwasher. ■ Clean the blender foot in the dishwasher or with a brush under running water. ■ Dry the blender foot in an upright position (blender blade face up) so that any trapped water can run out. Note: Appliances with a spiral cable: Never wind the cable round the appliance! Troubleshooting Problem Appliance switches off during use. Remedy The overload protection device is activated. ■ Switch off the appliance and pull out the mains plug. ■ Leave the appliance to cool down for approx. 1 hour in order to deactivate the overload protection device. ■ Switch the appliance on again. If the fault cannot be eliminated, please contact customer service. Recipes and tips Mayonnaise – 1 egg (egg yolk and egg white) – 1 tbsp mustard – 1 tbsp lemon juice or vinegar – 200-250 ml oil – Salt and pepper to taste Ingredients must be at the same temperature! ■ Put the ingredients in the jug. ■ Place the hand blender on the base of the jug and blend the ingredients (turbo speed) until the mixture emulsifies. ■ Slowly raise the switched-on blender as far as the upper edge of the mixture and lower again until the mayonnaise is ready. Tip: According to this recipe, you can also make mayonnaise with egg yolk only. However, then use only half the amount of oil. Vegetable soup – 300 g potatoes – 200 g carrots – 1 small stick of celery – 2 tomatoes – 1 onion – 50 g butter – 2 l water – Salt and pepper to taste12 en Disposal ■ Skin and de-seed the tomatoes. ■ Chop cleaned and washed vegetables and sauté in the hot butter. ■ Add water and salt. ■ Leave to cook for 20-25 min. ■ Take the pot off the cooker. ■ Purée the soup in the pot with the blender. ■ Season with salt and pepper. Crêpes dough – 250 ml milk – 1 egg – 100 g flour – 25 g melted, cooled butter ■ Put all ingredients in the jug in the indicated sequence and blend into a smooth dough. Blended milk drinks – 1 glass of milk – 6 large strawberries or 10 raspberries or 1 banana (cut up into slices) ■ Put the ingredients in the jug and blend. ■ Add sugar to taste. Tip: For a milkshake, add a scoop of ice cream or use very cold milk. Disposal

Dispose of packaging in an environ- mentally-friendly manner. This appliance is labelled in accordance with European Directive 2012/19/EU concerning used electrical and electronic appliances (waste electrical and electronic equipment – WEEE). The guideline determines the frame- work for the return and recycling of used appliances as applicable throughout the EU. Please ask your specialist retailer about current disposal facilities. Guarantee The guarantee conditions for this appliance are as dened by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee. Changes reserved.13

• Calls are charged at the basic rate, please check with your telephone service provider for exact charges IL Israel C/S/B/ Home Appliance Ltd. 1, Hamasger St. North Industrial Park Lod, 7129801 Tel.: 08 9777 222 Fax: 08 9777 245 mailto:csb-serv@csb-ltd.co.il www.bosch-home.co.il IN India,Bhārat, BSH Household Appliances Mfg. Pvt. Ltd. Arena House, Main Bldg, 2nd Floor, Plot No. 103, Road No. 12, MIDC, Andheri East Mumbai 400 093 Toll Free 1800 266 1880* www.bosch-home.com/in

• Expert tips & tricks for your appliance

• Warranty extension options

• Discounts for accessories & spare-parts

• Digital manual and all appliance data at hand

• Easy access to Bosch Home Appliances Service Free and easy registration – also on mobile phones: www.bosch-home.com/welcome Expert advice for your Bosch home appliances, need help with problems or a repair from Bosch experts. Find out everything about the many ways Bosch can support you: www.bosch-home.com/service Contact data of all countries are listed in the attached service directory. Thank you for buying a Bosch Home Appliance! Looking for help? You´ll find it here. *8001148036* 8001148036 (990301)MSM67_de-ar.book Seite 97 Montag, 23. Juni 2014 3:19 15 Bildseiten_MSM67.fm Seite 98 Montag, 16. Februar 2015 12:55 12 MSM66_67.indd 98 20.02.2015 17:56:54
