USER MANUAL KB M35 STEBA

Instructions for use 16

Mode d'emploi 23

This insulated appliance is for private and indoor use only and must not be used commercially. It is suitable for grilling, baking, cook au gratin and warming of food. Please read the instruction manual carefully and keep it at a safe place. When the appliance is given to another person the instruction manual should be passed to that person, too. Only use the appliance as described in

the instruction manual and pay attention to the safety information. No liability for damages or accidents will be accepted, which are caused by not paying attention to the instruction manual. Remove all packaging and sticker. Wash up all parts carefully (see cleaning).

Safety information

Hot surface! There is danger of burning when touching the surface during operation. Set the back of the device with a distance of 10cm to the kitchen wall.

• Connect and operate the appliance in accordance with the specifications shown on the rating label.
  This device is no built-in oven and cannot be used like this.
• Do not use if the plug cord is damaged. Verify before every use.
• Do not plug with wet hands.
• Connect the power plug to a properly installed and easily accessible socket only.
• To unplug the power plug, always pull the plug – not the cable.
  Plug off the appliance after each use or in case of failure.
• Do not pull at the cord. Don't pull it over edges and don't bend it too much.
• Keep the cord away from hot parts.
  The appliance can be used by children aged 8 and above and persons with limited physical, sensory or mental capabilities or lack of experience/knowledge, provided that are supervised or have been provided with instruction in the safe use of the appliance and have understood the resulting dangers. Children must not use the packaging as a toy. Cleaning and user maintenance must not be carried out by children unless they are 8 years or older and are supervised.
• Children under the age of 8 must be kept away from the appliance and the connecting cable.

• Children should be supervised to ensure that they do not play with the appliance or packaging material (e.g. Plastic Bags).

• The appliance must not be operated using a timer or a separate remote system!

• Never leave the appliance unattended when in use.

• Do not leave the appliance outdoors or in a damp area.

• Never place anything on top of the device and do not cover the ventilation slots.

• Never immerse the unit in water.

• Leave a space of about 10cm around the device.

• Never use the device after a malfunction, e.g. if it felt down or has been damaged in any other manner.

• The manufacturer is not liable for damage which is occurring due to the usage of the appliance in a different way as described or a mistake in the handling has been made.
• To prevent injury, repairs such as replacing a damaged cord, should only be carried out by a customer service.

The device gets hot, only transport if it cooled down.

• Only use the device as described in this manual.

• You must not wrap the grill with tin foil (accumulation of heat).

• You must not put any materials such as paper, cardboard, plastic etc. into the appliance.

Hint! Housing and glass get hot. Danger of

burns! Touchable surfaces will be hot during operation! Place the device on a flat and insensitive surface

with and keep a distance of at least 70cm to burnable materials.

• During operation steam emerge. Keep hands and face away.
• If an extension cable is used, it has to have a cross-section of 1.5mm^2
• If a GS-tested 16 A multi-pin extension is used, it may not be charged with more then 3680 watts due to fire hazard.
• Make sure that children do not tease the cable or that a trip hazard occurs.

• The device must always be disconnected from the power supply if it is not supervised and before assembling, disassembling or cleaning.

• Attention: as dripping fats can easily ignite the radiator, never grill without a pan! When removing the full pan, do not tip any grease on the radiator.

• Please use the enclosed handle to remove the wire grill and baking tray.
  Clean after every use.
• Always push the crumb tray under the lower radiator and the reflector above the upper radiator.

Cleaning

Attention! Pull the plug before cleaning and allow the device to cool down.

• Never immerse the unit into water.

• Fat residues must be removed for reasons of hygiene and fire hazard.

• Do not use abrasives, oven spray or solvents.
• Clean the housing and the interior with a damp cloth with detergent, clean the glass with glass cleaner and dry.
• The crumb tray, the upper reflector and accessories can be cleaned in hot water and then dried. The crumb tray and the upper reflector must always be inserted again after cleaning.

Workplace

Important:

Never place this device on or next to hot surfaces (e.g. hot stoves). Only use it on a even, stable and a heat resisting surface. It is important that no inflammable items are near to the device. Do not place the device on the edge of the table so that it cannot be touched by children or fall down when touched.

Put into operation

Plug in the device.

By setting the timer the following light shine:

• the red light to indicate that the device works

• the interior lighting

By setting the temperature the following light shines:

• the temperature control light

Once the desired temperature is reached, the temperature control light turns off.

After the time runs out a signal can be heard and all lights turn off.

Important: Heat the appliance up for at least 5 min. The appliance can smoke slightly when used the first time. Never put oversized food inside the oven and prevent any contact to the heating elements. Food which contains much fat should be grilled on the wire grill in position 2; the baking pan should be put at position 1. If necessary turn the thermostat a little lower. Always insert the crumb tray.

Timer

The device only works when the timer is set. Fully inflate the watch (turn to 90min) and then reset to the desired time. Please consider the preheating time of 5 minutes when setting the time. If the food is not brown enough, then extend the time. When the time has elapsed, the device switches off and a short signal sounds. If the device is no longer needed, unplug the power cord and set the switches to OFF.

Settings

Thermostat

Functions in addition to programs:

rotisserie spit
Convection
rotisserie spit +convection
Programs:
Upper heat
Lower heat
Upper & lower heat

Timer

1)Baking or +

For baking, cooking, crisping.

Set the time and temperature according to the recipe. The heating element glow differently. The fan distributes the temperature evenly in the interior. With convection, set the thermostat slightly higher.

2) Lower heat C or( ± )

For Pizza, fries etc.

Set the max. temperature.

Cook crispy only with lower heat for the last 5 minutes.

3) Defrosting (二) + (二)

Defrost the food with low temperatures in the baking tray.

4) Upper heat ( 0 or + = )

For grilling of sausage, meat, cook au gratin, etc.

Set the max. temperature.

Insert the grill pan into a lower slot, insert the food onto the wire grill with a distance to the upper heating element.

The food must not contact the radiator!

5) Rotisserie grilling l + l or l + l

For grilling poultry, rolled pork roast, etc.

Set the max. temperature.

Insert the grill pan at the bottom to allow the fat to drip off. High-fat foods can splash.

Fix a rotisserie fork at the spit.

Put the tied meat or poultry on the spit and fix it with the second rotisserie fork.

Be careful, that the meat is in the middle of the spit. Put the spit with the meat on the rotisserie handle and insert the top of the spit in the spit motor opening on the right side of the inner housing. Then put the other side of the spit on the spit holder.

To remove the ready cooked food, use the spit handle and the pan handle.

Correct Disposal of this product

This marking indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return

your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling.

Packaging disposal: Do not throw away the package materials. Please put it in the recycling bin.

Gift box: Paper, should be put to the old paper collection point. Plastic packaging material and foils should be collected in the special collection containers.

Service and Repair:

If the appliance must be repaired, please get in touch with your trader or with the manufacturer:
