(8) Handle (insulated gripping surface) (9) Locking screw for protective guard (10) Holding rod (11) Two-pin spanner for clamping nut (12) Index mark (13) Spring ring

Accessories shown or described are not included with the product as standard. You can find the complete selection of accessories in our accessories range. Technical Data Straight grinder GGS 8 SH Article number 3 601 B14 3.. Rated power input W 1200 Power output W 700 Rated speed

Grinding spindle thread M 14 Max. spindle length mm 31 Tool holder mm 20 Max. grinding disc thickness mm 32 Max. grinding tool diameter mm 125 Max. cup brush diameter mm 100 Weight according to EPTA-Pro- cedure01:2014 kg 4.4 Restart protection ● Straight grinder GGS 8 SH Protection class / II A) Rated no-load speed for the selection of appropriate application tools in accordance with ENIEC62841-2-3. The actual no-load speed is lower for safety reasons and according to production tolerances. The specifications apply to a rated voltage [U] of 230 V. These spe- cifications may vary at different voltages and in country-specific mod- els. Noise/Vibration Information Noise emission values determined according toENIEC62841-2-3. Typically, the A-weighted noise level of the power tool is: Sound pressure level 90dB(A); Sound power level 98dB(A). Uncertainty K=3dB. Wear hearing protection! Vibration total values a

(triax vector sum) and uncertainty K determined according toENIEC62841-2-3: Surface grinding (roughing):
