USER MANUAL Buffet Star 3 in 1 BEEM

SBEEM - Elements of Lifestyle

• Nummerierung gemäß Gerätebeschreibung Technische Daten Modell Buffet Wärmer, Warmhalteplatte & Grill Buffet Star 3 in 1 Typnummer B18.001 Abmessungen Grill (B x H x T) 657 x 77 x 380 mm Abmessungen Buffetwärmer (B x H x T) 657 x 155 x 380 mm Abmessungen Gastronormbehälter (B x H x T) 325 x 60 x 177 mm (GN 1/3) Füllinhalt je Gastronormbehälter: 2,2 l Nettogewicht Grill 3,35 kg Nettogewicht Buffetwärmer 4,24 kg Betriebsspannung 220 - 240 V~ Netzfrequenz 50 Hz Leistung (maximal) 740 W Schutzklasse I12 Buffet Star 3 in 1 DE BEEM - Elements of Lifestyle13 EN Buffet Star 3 in 1 BEEM - Elements of Lifestyle Dear Customer, before using the appliance, please read the instructions contained in this user manual on startup, safety, intended use as well as cleaning and care. Open the fold-out page at the beginning and end of the user manual in order to view the illustrations during reading. Keep this user manual in a safe place and pass it on to any future owners together with the appliance. General notes Copyright This document is copyrighted. Any dupli- cation or reprinting, in whole or in part, as well as reproduction of the illustrations even in modied form is only permitted with the written approval of the manufac- turer. Notes on environmental protection The packaging materials used can be recycled. When no longer re- quired, dispose of the packaging materials according to local environmental regula- tions. This product may not be disposed of in the domestic refuse within the Eu- ropean Union. Dispose of the appli- ance via communal collection points. Guarantee We will remedy any faults due to mate- rial aws or manufacturing faults free of charge within the guarantee period of two years. For commercial or equivalent use, e.g. in hotels, guest houses or communal premis- es, or if the customer is not a consumer as dened by the German Civil Code, the guarantee period is 6 months. This does not infringe the warranty disclaimer. The guarantee does not cover faults caused in particular by improper use, failure to observe instructions in the user manual and safety precautions, use of force, modications, unauthorised at- tempted repairs and attempted repairs by unqualied third parties. Faults caused by normal wear are also excluded. Please visit our website to obtain more information on comprehensive guarantee conditions, available accessories and spare parts as well as user manuals in various languages. General notes. . . . . . . . . . . . . . . . . . . . 13 Safety instructions . . . . . . . . . . . . . . . 15 Startup . . . . . . . . . . . . . . . . . . . . . . . . . 17 Appliance description .............18 Operation and use ................18 After using . . . . . . . . . . . . . . . . . . . . . . 19 Storage .........................19 Cleaning and care . . . . . . . . . . . . . . . . 19 Troubleshooting . . . . . . . . . . . . . . . . . 20 Spare parts and other accessories . . 21 Technical data . . . . . . . . . . . . . . . . . . . 21 Contents14 Buffet Star 3 in 1 EN BEEM - Elements of Lifestyle WARNING If not used for its intended purpose and/ or used in any other way, the appliance may be or become a source of danger. Use the appliance only for its in- ► tended purpose. Observe the procedures described in ► this user manual. No claims of any kind will be accepted for damage resulting from use of the appli- ance for other than its intended purpose. The risk must be borne solely by the user. If used commercially, please pay attention to the changes in the guarantee period. Limitation of liability All technical information, data and in- structions contained in this user manual represent the latest status at the time of printing. No claims can be made based on the specications, illustrations and descrip- tions of this user manual. The manufacturer assumes no liability for damage or injury resulting from failure to observe the user manual, use for other than the intended purpose, unprofessional repairs, unauthorised modications or use of non-approved spare parts and/or con- sumables. Declaration of Conformity Herewith, BEEM Company declares that this unit is in conformity with the funda- mental requirements and the other rel- evant stipulations of Directive 2206/95/ EU and 2004/108/EU. The full declaration of conformity can be found under www. beem.de. Symbols used DANGER This indicates an imminent hazardous situation, which could lead to severe physical injury or death. Follow these instructions to avoid ► danger. WARNING This indicates a possible hazardous situation, which could lead to severe physical injury or death. Follow these instructions to avoid ► danger. CAUTION This indicates a potentially hazardous situation, which could lead to minor injuries or material damage. Follow these instructions to avoid ► danger. NOTE A note contains additional informa- ► tion to simplify the use of the appli- ance. Intended use This appliance is intended primarily for non-commercial use in closed rooms for grilling and keeping food warm in Gas- tronorm containers or on the hotplate in normal domestic quantities. Any use other than previously stated is considered as improper use.15 EN Buffet Star 3 in 1 BEEM - Elements of Lifestyle Safety instructions Inspect the appliance for visible signs ■ of damage before use. Do not use a damaged appliance. This appliance is not intended for use ■ by persons (including children) with re- stricted physical, sensory or mental ca- pabilities or with insufcient experience and/or knowledge unless they are supervised by a person responsible for their safety or have received instruc- tions on the use of the appliance from such a person. Children must be supervised to ensure ■ that they do not play with the appli- ance. Store the appliance and accessory ■ parts out of the reach of children. Do not leave the appliance unattended ■ during operation. Only allow repairs to the appliance ■ to be carried out by an authorised specialist or by the works customer service; this particularly applies to re- placing a damaged connecting cable. Unqualied repairs can lead to consid- erable danger for the user. They will also invalidate the guarantee. Repairs to the appliance during the ■ guarantee period may only be carried out by service centres authorised by the manufacturer, otherwise the guar- antee will become invalid in the event of damage or subsequent damage. Defective parts may only be replaced ■ with original spare parts. Only original spare parts guarantee that the safety requirements are met. Only use spare parts from the manu- ■ facturer or spare parts that are speci- cally recommended by the manufac- turer. The guarantee will otherwise be invalidated. Do not use this appliance together with ■ an external timer or a separate remote control system. DANGER Danger from electric current! Do not use the appliance if the mains ► cable or mains plug is damaged. Do not open the housing of the ap- ► pliance. Danger from electric current if live connections are touched and/ or the electrical and mechanical conguration is changed. Never immerse the appliance or the ► mains plug in water or other liquids. Pull the plug out of the mains socket, ► when changing the attachments, – if you are not using the appliance, – if a malfunction occurs during op- – eration, before you clean the appliance. – Risk of suffocation! Never play with packaging material. ► Risk of suffocation.16 Buffet Star 3 in 1 EN BEEM - Elements of Lifestyle WARNING Danger of burns! The appliance becomes very hot ► during operation. Hold the appliance with the handles only. Use a pot holder or a kitchen towel ► if you need to touch hot parts of the appliance. Allow the appliance to cool down ► completely. when changing the attachments, – before you clean the appliance. – Take care when opening the lid; hot ► steam can escape. Do not operate the appliance without ► inserting the grilling plate or the frame attachment into the Gas- tronorm containers. CAUTION Do not pull the connecting cable ► to remove the plug from the mains socket. Never operate the appliance when ► the containers are empty. Do not use sharp objects or abra- ► sive cleaning agents to clean the surfaces. Never lift or turn the appliance with ► the mains cable. Do not put plastic containers onto ► the hot plate/grilling plate; they could melt. Requirements for the place of use For safe and trouble-free operation of the appliance, the place of operation must sat- isfy the following requirements: Place the appliance on a rm, dry, at, ■ waterproof and heat-resistant surface. Do not put the appliance in the vicinity ■ of heat or steam sources or near am- mable materials. Do not install the appliance in a hot, ■ wet or very humid environment. The mains socket must be easily ac- ■ cessible and allow fast disconnection in the event of an emergency. The surface nishes on furniture may ■ contain substances that can be detri- mental to the rubber feet of the appli- ance. If necessary, place a mat under the feet of the appliance. Do not put the appliance underneath ■ a wall cupboard or another piece of furniture.17 EN Buffet Star 3 in 1 BEEM - Elements of Lifestyle Electrical connection For safe and trouble-free operation of the appliance, the following instructions on the electrical connection must be observed: Before connecting the appliance, ■ compare the connection data (voltage and frequency) on the rating plate with those of your mains power supply. The data must correspond in order to avoid damage to the appliance. If in doubt, ask your electrical appliance retailer. The mains socket must be protected ■ by at least a 10 A automatic circuit breaker. Ensure that the mains lead is undam- ■ aged and is not laid over sharp edges. The mains cable must not pulled ■ tightly, bent or come into contact with hot surfaces. Route the cable to prevent risk of trip- ■ ping. The electrical safety of the appliance ■ is only assured when it is connected to a properly installed protective earth (PE) conductor system. Connection to a mains socket without PE conductor is forbidden. If in doubt, the electrical system must be checked by a qualied electrician. The manufacturer assumes no liability for injury or damage caused by a missing or interrupted protective earth conductor. Startup Unpacking Remove the appliance, all accessory parts and the user manual from the box. Remove all packaging materials and protective foils from the product and the accessories before using it for the rst time. NOTE Do not remove the rating plate or ► any warning signs on the appliance. If possible, keep the original packag- ► ing during the guarantee period in order to be able to pack the ap- pliance properly in the event of a guarantee claim. Transport damage will invalidate the guarantee. Check the delivery contents Check for visible signs of damage or missing items. Report incomplete or damaged con- tents to your supplier immediately. Before using for the rst time Clean the appliance and the acces- sories as described in the section Cleaning and care. NOTE Due to production residue (grease), ► it is possible that a new appliance may smoke lightly. Ensure sufcient ventilation.18 Buffet Star 3 in 1 EN BEEM - Elements of Lifestyle Appliance description (See illustration on the left fold-out page) Handle1 Base appliance2 Indicator lights3 Rotary switch for the left heating zone4 Rotary switch for the middle heating 5 zone Rotary switch for the right heating zone6 Frame attachment7 Heating element8 Inserted containers9 Grill plate10 Gastronorm container11 Lid12 User manual (not illustrated)13 Rotary switch left and right heating zone Level Function Heating zone switched off Keep-warm function Rotary switch middle heating zone Level Function Heating zone switched off Keep-warm function Grill function, gentle Grill function, strong Operation and use Switching the appliance on/off The three heating zones of the appliance can be switched on and offer via the rotary switches (4, 5, 6). The middle heating zone also has a grilling function. The indi- cator lights (3) light up when the appliance is heating. To switch off the appliance, turn all three rotary switches to level . To keep food warm, turn the rotary switch of the respective heating zone to level . For the grilling function, turn the rotary switch of the left and right heating zone (4, 6) to level and the rotary switch for the middle heating zone (5) either to level for gentle grilling or level for fast grilling. Using the buffet warmer Remove the grill plate (10) and put the frame attachment (7) onto the base appliance (2). Fill the Gastronorm containers (11) with food and insert them into the frame attachment (7). Turn the rotary switch of the heating zone used to level . Place the lid (12) onto the Gastronorm containers (11) to prevent food from drying out. Using as hot plate Remove the frame attachment (7) and put the grill plate (10) onto the base appliance (2). Turn all three rotary switches to level

EN Buffet Star 3 in 1 BEEM - Elements of Lifestyle Using as a table top grill Remove the frame attachment (7) and put the grill plate (10) onto the base appliance (2). Grease the grill plate (10) lightly. Turn the rotary switch for the left and right heating zones to level and the rotary switch for the middle heating zone for gentle grilling (e.g., shrimps) to level or to level for fast grilling (e.g,. meat). After the appliance has heated up, you can begin with grilling. NOTE Grill on the middle heating zone and ► keep the grilled food warm on the adjacent heating zones. After using Switch off the appliance and pull the plug out of the mains socket. Allow the appliance to cool down com- pletely. Rinse the containers and the grill plate with water. Clean the appliance and the accesso- ries used as described in the section Cleaning and care. Storage If you do not intend to use the appliance for a longer period of time, clean it as de- scribed in the section Cleaning and care. Store the appliance and all accessory parts at a dry, clean and frost-free loca- tion, which is protected against direct sunlight. Cleaning and care Before beginning work, pay attention to the safety instructions in the section on safety! Cleaning the appliance Wipe the base appliance (2) with a slightly damp cloth. All other parts can be cleaned in a warm washing-up liquid solution or in the dish washer. Dry all parts of the appliance thor- oughly after cleaning. NOTE Dried and caked food residues can ► be removed more easily if you allow them to soak in warm washing-up liquid solution for 10 minutes before cleaning.20 Buffet Star 3 in 1 EN BEEM - Elements of Lifestyle Troubleshooting The following table will help you locate and eliminate minor faults: Fault Possible cause Remedy The appliance does not work after turning the rotary switch. Plug not inserted into socket. Insert plug. Automatic circuit breaker in electrical distribution board tripped. Switch on the automatic circuit breaker again. The automatic circuit breaker in the electrical distribution board trips. Too many appliances connect- ed to the same power circuit. Reduce the number of appliances on the power circuit. Appliance is defective. Contact customer service. NOTE If you cannot resolve the problem with the steps described above, please contact ► customer service.21 EN Buffet Star 3 in 1 BEEM - Elements of Lifestyle Spare parts and other accessories Item* Article No. Designation 11, 12 900 735 001 Gastronorm container with lid
