Brand	EBENCH
Model	KH 350
Product type	Compact hi-fi system
Power supply	230 V AC, 50 Hz
Output power	2 x 5 W RMS (sinusoidal power), 100 W PMPO
CD player	Semiconductor laser
Radio	FM (87.5 – 108 MHz) and AM (522 – 1620 kHz)
FM antenna	Flexible antenna
AM antenna	Built-in ferrite frame
Main functions	CD, radio, AUX, headphone, equalizer (Flat, Classic, Rock), CD programming, random play, repeat
Volume adjustment	+/- keys
Standby	POWER button
Remote control	Yes, with 2x AAA battery (not included)
Headphone jack	3.5 mm stereo mini-jack
AUX input	RCA jack
Number of speakers	2 passive speakers (red/black cables)
Display	LCD
Care and cleaning	Soft cloth slightly damp; no chemicals, alcohol or solvents
Safety	Do not open the cabinet; beware of laser radiation; avoid moisture; leave at least 10 cm ventilation space at rear and above, 5 cm on sides

Frequently Asked Questions - KH 350 EBENCH

How do I set the time on my KH 350?

In standby mode, press MEMO/PROGRAM. Use the SKIP/SEARCH keys to set the hours, then press MEMO/PROGRAM again. Set the minutes the same way and confirm.

How do I program radio stations?

Select the band (FM/AM) with BAND. Search for a station with SKIP/SEARCH. Press MEMO/PROGRAM, then use MEMO-UP/REPEAT to choose a preset (1-10). Press MEMO/PROGRAM to memorize.

How do I repeat a CD track?

During playback, press MEMO-UP/REPEAT once to repeat all tracks, or twice to repeat one track. REPEAT appears. Press again until it disappears to deactivate.

How do I connect an external device (MP3 player, etc.)?

Use an RCA cable to connect your device's output to the AUX input on the back of the KH 350. Press the AUX key to listen.

How do I clean the device?

Use a soft cloth slightly dampened with a mild detergent. Do not use alcohol, thinner, or harsh chemicals.

What to do if there is no sound?

Check that the volume is not at minimum (VOLUME +). Ensure the speakers are properly connected (red wire to +, black to -). Try unplugging and replugging the device after a few seconds.

How do I use the equalizer?

Press the EQ key to cycle through modes: Flat (neutral), Classic (accentuated mids), Rock (accentuated bass/treble).

Can I use headphones with this system?

Yes, connect headphones with a 3.5 mm jack plug into the PHONES jack on the front. The speakers are then automatically muted.

How can I improve FM reception?

Fully extend the flexible antenna and orient it for better reception. Avoid placing the device near other electrical appliances (TV, monitor).

How do I create a programmed playlist on CD?

Stop playback with STOP. Press MEMO/PROGRAM. Select a track with SKIP/SEARCH, then press MEMO/PROGRAM to add it. Repeat for other tracks. Press PLAY/PAUSE to play the program.

USER MANUAL KH 350 EBENCH

1. MEMO-UP/REPEAT-Taste

1. Haut-parleur

2. Compartment CD

3. Touche OPEN/CLOSE
4. Touche STANDBY

Reproduction programme

WERKING MET KOPTELEFOON

Enioyn otpoov Equalizer

Evpyonoinan Tnc I toupyiac twv CD

Evepyonoing Tnc aeitoupyiac Tou

paiooovou

Evpyonoinn Tnc aeitoupviaac Aux

Σuδεσακουσικων

PuOioTnC EvTaOnc hou

Avaumu /Σβnσiμo

Evpyonoinan I oupviac yia naiEio

Evpyonoinan tuxiaic eadoans

EvapEn n eTaooC CD/laAeimua

Enioyn nepioxnc kupatwv AM/FM

Evpyonoinon 1eitoupyaicnpoypaiaiou

AM Antenna in ferrite incorpora t

1. VOLUME +/- nappaimet
2. PLAY/PAUSE-nappain
3. STOP-nappain
4. CD-nappain
5. OPEN/CLOSE-nappain
6. AUX-nappain
7. TUNER-nappain
8. TUNING/SKIP/SEARCH +/- nappaimet

LAITTEEN KAYTTOONOTTO

Kaiuttimien liiantä

Varning! Fara for elchock!

ANSLUTNING AV ANDRA APPARATER

Frequency range VHF/FM 87.5 MHz to 108 MHz Frequency range MW/AM 522 kHz to 1620 kHz

Aerials

FM dipole aerial AM built-in ferrite aerial

OPERATING INSTRUCTIONS

Warning and Safety Information

Please read the operating instructions very carefully prior to using the device and ensure that they are kept and easy to find for future reference. All precautionary and safety procedures should be followed exactly as well as the following safety procedures.

Caution! Danger of electric shock!

Never open the appliance or component housings! None of the components included within the scope of the delivery can be serviced by the user. Any servicing is to be carried out by qualified personnel only.

This warning symbol informs the user of the dangerous voltage in the device.
This warning symbol informs the user of important operating information for this device.
Warning!

Non-perceivable escape of laser radiation if the device interlocks are opened or damaged. Avoid any contact, especially eye contact, with the laser beam! Danger of serious eye injuries exists.

SETTING-UP THE DEVICE

• When setting-up the device ensure that it is not in the immediate vicinity of water, e.g. on a bathtub, wash basin, rinsing sideboard, in damp cellars, next to a swimming pool, etc.
• When setting-up the device ensure that it is not in the immediate vicinity of heat sources, e.g. ovens, air heaters or other heat generating devices.
• Ensure that the device is set-up upon a stable and level base.
• The device must be set-up in a place that guarantees sufficient all-round ventilation. The distance between the device's rear-side and wall should not be less than 10cm , also not less than 10cm above the device and at least a 5cm space on either side. Thus the device should not be placed in book shelves, other closed off cabinets or on wall shelving units filled with other items. In addition, the ventilation can be impaired if the device is placed on a bed, blanket or similar surface.

• Ensure that no foreign substances or liquids can enter the device through the ventilation inlets.

• The laser scanner of the CD player can ingress humidity when:

• the set-up position is quickly changed from a cold area to a warm area

• a heating unit is suddenly turned on
• the unit is set-up in a differently acclimatised room.

Malfunctions can occur if there is a build-up of condensation within the device. In this case the device should not be used for several hours until normal playing is once again possible.

POWER SUPPLY

When using the device in mains supply operation it is imperative that you comply with all technical data and instructions found in the operating manual and those on the device.

• Caution! Use only the mains cable supplied with the device otherwise there is a danger of fire and/or electrical shocks!
• When disconnecting from the mains, be sure to grip the plug when pulling out from the socket and never pull out by gripping the cable.
• Never handle the mains cable and/or the plug with damp or wet hands because of the danger of electrical shocks!
• Handle electrical cables with care; do not buckle or crimp the cable. Cables should not be laid on the floor in such a way it is possible to step on them. Please be especially careful with the mains cable between the electrical socket and the device.
• Using cables and plugs which do not correspond to the stipulated voltage can result in fire and/or electrical shocks. If the equipment is not going to be used for a long period of time, it should be unplugged from the mains power supply and the batteries removed. The device is still electrically live even if it has been turned off but the plug is still in the mains supply socket.

OPERATING ELEMENTS AND DISPLAY

FUNCTION

1. Loudspeakers
2. CD compartment
3. OPEN/CLOSE button
4. STANDBY

Opens/closes the CD compartment

Switches the appliance on/puts the appliance on standby mode

1. EQ button
2. CD button
3. TUNER button
4. AUX button
5. Phones
6. VOLUME +/- buttons
7. POWER button
8. Signal receiver for remote control
   13.LCD display
9. INTRO button
10. MIX button
11. PLAY/PAUSE button
12. BAND button
13. MEMO/PROGRAM button
14. MEMO-UP/REPEAT button
15. TUNING/SKIP/SEARCH +/- buttons

Activates the preview function
Activates the random play function
Starts playing/pauses CD
Selects AM/FM waveband
Activates the programming function
Repeats individual/all CD tracks

When used with CD player: skips to the beginning of the next track/to the beginning of the track which is currently playing or forward/ reverse search; When used with the tuner: automatic tuning

Stops playing the CD

1. STOP button

Remote control

1. POWER button
2. MUTE button
3. EQ button

OPERATING INSTRUCTIONS

1. MIX button
2. BAND button
3. INTRO button
4. MEMO-UP/REPEAT button
5. MODE/REMAIN button p l aying time of entire CD 9. MEMO/PROGRAM button
6. VOLUME +/- buttons
7. PLAY/PAUSE button
8. STOP button
   13.CD button
9. OPEN/CLOSE button
10. AUX button
11. TUNER button
12. TUNING/SKIP/SEARCH +/- buttons

Changes display: track playing time/remaining

SWITCHING THE SYSTEM ON

Connecting the loudspeakers

To connect the loudspeakers, connect each black cable to the (-) connecting terminal and each red cable to the (+) connecting terminal at the back of the appliance.

Mains operation

Before you continue, check whether the mains voltage stated on the back of the appliance corresponds with your local mains voltage. Then insert the mains plug of the appliance into a socket.

Inserting the batteries into the remote control

Open the lid of the battery compartment. Insert the batteries (2xAAA, not included in the scope of the delivery) as indicated by the positive and negative pole markings. Close the battery compartment.

Note: If the equipment is not be used for a long period, take the batteries out of the remote control.

Setting the time

After pressing the MEMO/PROGRAM button in the standby mode, press the SKIP/SEARCH but tons (forwards/backwards) until the correct hour appears on the display.
- Press the MEMO/PROGRAM button again and then press SKIP/SEARCH (forwards/backwards) until the correct minute appears on the display.
Press the MEMO/PROGRAM button. The correct time will now appear on the display.

Adjusting the volume

To adjust the volume, press the + / - button.

PLAYING A CD

Press the CD button.
- Open the CD compartment with the OPEN/CLOSE button.
- Insert the CD with the labelled side facing upwards in the CD compartment.
- Close the CD compartment. When the CD starts, the total number of tracks will appear on the h e display.
- Press the CD PLAY/PAUSE button. The first track of the inserted CD is played. The display i n d i cates the number of the current track and the playing time of the track.
To activate the pause function, press the PLAY/PAUSE button. The display indicates how much of the track's playing time has lapsed. To continue playing the CD, press the PLAY/ PAUSE button.
- To stop the CD, press the CD STOP button. The display indicates the total number of tracks and the total CD playing time.

FURTHER CD PLAYER FUNCTIONS

Repeat function

This function allows you to play an individual track or all the tracks on one CD repeatedly.

• To play all the tracks on the inserted CD repeatedly, press the MEMO-UP/REPEAT button once. REPEAT appears on the display.
  To play an individual track repeatedly, press the MEMO-UP/REPEAT button twice while the CD is playing. REPEAT appears on the display.
• To deactivate the repeat function, press the MEMO-UP/REPEAT button again until REPEAT disappears from the display.

Mix function

With the mix function, the tracks of the inserted CD are played in random order. To activate this function, press the MIX button. MIX appears on the display. To deactivate the mix function, press the STOP or MIX button.

Programmed play function

With the programming function you can compile your own music programme. Before programming, the CD must be stopped by using the STOP button.

Press the MEMORY/PROGRAM button.
To select the required track number, press the SKIP/SEARCH button (forwards or backwards).
Press the MEMO/PROGRAM button again in order to programme the selected track.
- Repeat steps 2 and 3 until all the required tracks have been programmed.
Press the PLAY/PAUSE button. MEMO appears on the display.
- Press the STOP button in order to end the programmed play function.
Press the MEMO/PROGRAM button and the PLAY/PAUSE button in order to continue using the programmed play function.
- Open the CD compartment or switch the CD player off in order to delete the programmed track order.

Equaliser function

The music can be played with three different equaliser curves (flat, classic and rock). Each equaliser curve emphasises treble, middle and bass in its own characteristic way. Press the EQ button to select the required equaliser curve.

USING THE RADIO

Press the TUNER button in order to select the radio mode.
Press the BAND button to select the waveband (AM or VHF/FM).
- Start the automatic tuning function by holding the SKIP/SEARCH button (forwards/backwards) down for 1-2 seconds. When it has located a station, the tuning function stops automatically. In the case of stations which have a very weak signal the automatic tuning function does not stop. If a VHF/FM station is received in stereo, this is indicated on the display.

Programming stations

It is possible to programme a maximum of 10 VHF/FM and 10 AM stations, i.e. a total of 20 stations.

• When a station with a good reception has been located (see section "Using the radio"), press the MEMO/PROGRAM button. MEMO/PROGRAM lights up on the display.
  Press the MEMO-UP/REPEAT button until the required programme location is displayed.
  To store the located station in the selected programme location, press the MEMORY/PROGRAM button; MEMO/PROGRAM disappears from the display.
• Repeat steps 2 to 5 to store further stations. If necessary, change the waveband using the BAND button.

OPERATING INSTRUCTIONS

Selecting programmed stations

• Select the waveband (VHF/FM or MW/AM) of the required station with the BAND button.
• Keep on pressing the MEMO-UP/REPEAT button until the required programme location and the station frequency appear on the display.

AERIALS

VHF/FM

Unwind the aerial cable entirely and put the aerial in such a position that the best possible reception is achieved. Note: do not connect the VHF/FM aerial cable to an outdoor aerial!

MW/AM

A ferrite aerial has been built into the appliance for MW/AM reception. The reception can be improved by turning the appliance.

USING THE HEADPHONES

Insert the headphones plug (3.5 mm stereo miniplug) into the headphones socket. This automatically switches the loudspeakers off.

CONNECTING OTHER APPLIANCES

If you wish to connect another audio appliance (e.g. a cassette deck) to your design audio system in order to use the system's loudspeakers to play music, you must connect this appliance with a cinch cable to the inputs marked "AUX" on the back of your design audio system. Then press the AUX button; it is now possible to start playing music from the connected appliance via the design audio system.

MAINTENANCE

Cleaning the device

Use a slightly damp soft cloth and a mild cleaning detergent. Use no chemicals, alcohol, thinning agents or other solvent-containing cleaners.

Malfunctions

Pull out the mains connection plug if a malfunction or incorrect function occurs; after a few seconds reconnect the electrical supply using the mains connection plug. When using the radio, other electrical appliances in the vicinity (e.g. televisions, monitors etc.) may cause interference. The appliance should be kept away from such sources of interference.

DECLARATION OF CONFORMANCE

We, Kompernaß Handelsgesellschaft mbH, Burgstr. 21, D-44867 Bochum, Germany, declare this appliance to be in conformance with all applicable international standards, safety requirements and EC Directives.

No. of appliance/Type: KH 350

Bochum, 31.12.2002

Hans Kompernaß
- Manager -
