USER MANUAL MSM88166 BOSCH

• de8 Robert Bosch Hausgeräte GmbH Contents For your safety p. 8
• Overview p. 9
• Operating the appliance p. 10
• Cleaning p. 10
• Recipes and tips p. 10
• Instructions on disposal p. 11
• Warranty conditions For your safety Before use, read these instructions carefully in order to become familiar with important safety and operating instructions for this appliance. If the instructions for correct use of the appliance are not observed, the manufacturer’s liability for any resulting damage will be excluded. This appliance is designed for processing normal household quantities in the home or similar quantities in non-industrial applications. Non-industrial applications include e.g. use in employee kitchens in shops, offices, agricultural and other commercial businesses, as well as use by guests in boarding houses, small hotels and similar dwellings. Use the appliance for processing normal quantities of food for domestic use. The appliance is only suitable for cutting or mixing food. It must not be used for processing other objects or substances. Please keep the operating instructions in a safe place. If passing on the appliance to a third party, always include the operating instructions. , General safety instructions Electric shock risk The appliance must not be used by children. The appliance and its power cord must be kept away from children. Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and if they understand the hazards involved. Children shall not play with the appliance. Connect and operate the appliance only in accordance with the specifications on the rating plate. Only use indoors. Do not use the appliance if the power cord and/or appliance are damaged. Switch off the appliance and disconnect from supply before changing accessories or approaching parts that move in use. Always disconnect the appliance from the supply if it is left unattended and before assembling, disassembling or cleaning. p. 11

Congratulations on the purchase of your new BOSCH appliance. In doing so, you have opted for a modern,

igh-quality domestic appliance.

ou can find further information about our products on our web page. enRobert Bosch Hausgeräte GmbH 9 Do not place the power cord over sharp edges or hot surfaces. To prevent injury, a damaged power cord must be replaced by the manufacturer or his customer service or a similarly qualified person. Only our customer service may repair the appliance. , Safety instructions for this appliance Risk of injury Electric shock risk Do not use the hand blender with damp hands and do not operate it at no load. Do not immerse the appliance in liquid above the blender foot-base unit connection point. Never immerse the base unit in liquids and do not clean in the dishwasher. Caution when processing hot liquids. Liquids may splash during processing. Never place blender foot on hot surfaces or use in very hot food. Leave hot food to cool down to at least 80 °C before processing with the blender! Before using the hand blender in a cooking pot, take the pot off the hotplate. Operate the hand blender with original accessories only. Do not attach or remove tools until the appliance is at a standstill. Recommendation: Never switch on the appliance for longer as you need to processing the ingredients. The blender jug is not suitable for use in the microwave. Risk of injury from sharp blades/rotating drive! Never grip the blade in the blender foot. Never clean the blades with bare hands. Use a brush. These operating instructions refer to various models. An overview of the different models can be found on the illustrated pages (Fig.

Overview Please fold out the illustrated pages. Fig.

1 Base unit 2 Power cord 3 Speed control Operating speed can be adjusted steplessly between the lowest ( ) and highest (12) speed (only in conjunction with button 4a). 4 ON button a Controllable speed (with speed control 3) b Turbo speed The hand blender remains switched on as long as an On button (a or b) is pressed. The turbo speed is used for the universal cutter (if included in delivery). 5 Release buttons To remove the blender foot, simulta- neously press both release buttons. 6 Blender foot Attach the blender foot and lock into position. 7 Blender blade 8 Blender jug Using the blender jug will prevent the ingredients from splashing. 9 L

Place the lid on the blender jug to keep in the processed food.

ce crush blade 14 Multifunction accessory with tools 15 Multifunction accessory with tools and dicer If the universal cutter is not included with the hand blender, it can be ordered from customer service (order no. 753122). With the universal cutter use the appliance at full power to prepare honey spread (according to the recipe). You can find the recipe in the operating instructions of the universal cutter. Place the lid on the universal cutter to keep in the processed ingredients. Operation The appliance is suitable for blending mayonnaise, sauces, mixed drinks, baby food, cooked fruit and vegetables. For puréeing soups. Use the universal cutter for cutting/chopping raw food (onions, garlic, herbs)! It is recommended to use the supplied blender jug. However, other suitable receptacles can also be used. Warning! The bottom of the receptacle which you use must not have any bumps or recesses. Before using the appliance for the first time, clean all parts of it. Fig. Completely unwind the power cord. Place the blender foot on the base unit and lock into position. Insert the mains plug. Place food in the blender jug or another tall receptacle. The appliance works better if there is some liquid in the ingredients. Set the required speed with the speed control (Fig. -5). It is recommended to use a low speed setting for liquids, hot food and for mixing (e.g. muesli in yoghurt). The high speed settings are recommended for the processing of more solid foods. Firmly hold the hand blender and jug. Switch on the hand blender by pressing the required On button. When switching on the hand blender, hold it at a slight angle to prevent it from “sticking” to the bottom of the blender jug. The hand blender remains switched on as long as the On button is pressed. To prevent the ingredients from splashing, do not press the On button until the blender foot has been immersed in the ingredients. Always switch off the hand blender before taking it out of the processed food. Release the On button after processing. After using the appliance: Remove mains plug. Press the release buttons and remove the blender foot from the base unit. Cleaning Warning! Surfaces may be damaged. Do not use abrasive cleaning agents. If processing e.g. red cabbage or carrots, the plastic parts will become discoloured by a red film which can be removed with a few drops of cooking oil. Pull out the mains plug! Wipe the base unit with a damp cloth and then wipe dry. Blender jug and lid can be washed in the dishwasher. Clean the blender foot in the dishwasher or with a brush under running water. Dry the blender foot in an upright position (blender blade face up) so that any trapped water can run out. Note: Appliances with spiral cable: Never wind the cable around the appliance!

Important information The appliance requires no maintenance. Thorough cleaning protects the appliance from damage and keeps it functional. Electric shock risk Never immerse the base unit in liquids and do not clean in the dishwasher. Before cleaning the appliance, pull out the mains plug! Do not use a steam cleaner!

enRobert Bosch Hausgeräte GmbH 11 Troubleshooting If the fault cannot be eliminated, please contact customer service. Recipes and tips Mayonnaise 1 egg (egg yolk and egg white) 1 tbs. mustard 1 tbs. lemon juice or vinegar 200–250 ml oil Salt, pepper to taste Ingredients must be at the same temperature! Put the ingredients in the jug. Place hand blender in the bottom of the jug and switch on (turbo speed) until the mixture emulsifies. Slowly raise the switched on blender as far as the upper edge of the mixture and lower again until the mayonnaise is ready. Tip: According to this recipe you can also make mayonnaise with egg yolk only. However, use only half the amount of oil. Vegetable soup 300 g potatoes 200 g carrots 1 small stick of celery 2 tomatoes 1 onion 50 g butter 2 l water Salt, pepper to taste Skin and seed the tomatoes. Chop up cleaned and washed vegetables and sauté in the hot butter. Add water and salt. Leave to cook for a good 20–25 min. Take the pan off the cooker. Purée the soup in the pan with the blender. Season with salt and pepper. Crêpes dough 250 ml of milk 1 egg 100 g flour 25 g melted cooled butter Put all ingredients in the jug in the indi- cated sequence and blend to a smooth dough. Blended milk drinks 1 glass of milk 6 large strawberries

10 raspberries or 1 banana (sliced) Put the ingredients in the jug and blend. Add sugar to taste.

ip: For a milk shake add a scoop of ice cream or use very cold milk. Instructions on disposal This appliance is identified according to the European guideline 2012/19/EU on waste electrical and electronic equipment – WEEE. The guideline specifies the framework for an EU-wide valid return and re-use of old appliances. Please ask your dealer or inquire at your local authority about current means of disposal. Warranty conditions The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee.

Fault Remedial action Appliance switches off during use. The overload protection feature has been activated. Switch off the appliance and pull out the mains plug. Leave the appliance to cool down for approx. 1 hour in order to deacti- vate the overload protec- tion device. Switch on appliance again. Subject to alterations.
