USER MANUAL BA 3233 SEVERIN

Instructions for use

Before using the appliance, the user should

read the following instructions carefully.

Connection to the mains supply

The appliance should only be connected to

an earthed socket installed in accordance

with the regulations.

Dual-voltage selector:

With the dual voltage selector, the iron can

be set to different supply voltages by using a

screwdriver or similar tool. Make sure that

the set voltage corresponds with the supply

This product complies with all binding CE

labelling directives.

3. Temperature control knob, infinitely

12. Power cord with plug

Important safety instructions

● Do not use the iron if it has been

dropped onto a hard surface, or shows

any other sign of damage, or is seen to

● The steam travel iron is not suitable for

regular domestic use.

● Great care is necessary when using any

appliance, especially near chil-dren. Do

not leave the steam iron unattended

while connected or on an ironing board.

Always remove the plug from the wall

socket and place the steam iron on its

● The appliance operates at very high

temperatures. Do not touch any part of

the appliance except the handle. Burns

can occur from touching the hot parts of

the housing or the soleplate and from hot

water or steam. When operating the

steam iron, hold only by the handle. Do

not allow steam to escape in the direction

● The iron must be used and stored on a

stable and durable surface only.

● With the iron placed on its base stand,

ensure that this too is on a stable and

● Do not allow the power cord to touch

hot surfaces. Do not coil the power cord

round the appliance.

● Always switch off and remove the plug

from the wall socket after use, and also

- in case of any malfunction,

● Before the appliance is used, the main

body including the power cord as well as

any attachment fitted should be checked

thoroughly for any defects. Should the

appliance, for instance, have been

dropped onto a hard surface, it must no

longer be used: even invisible damage

may have adverse effects on the

operational safety of the appliance.

● The power cord should be regularly

examined for any signs of damage. In the

event of such damage being found, the

appliance must no longer be used.

● Do not operate the appliance if excessive

force has been used to pull the power

cord. Damage cannot always be detected

from the outside; the entire unit should

therefore be checked by a qualified

technician before it is used again.

● Before refilling or emptying the water

reservoir, remove the plug from the wall

● When removing the plug from the wall

socket, never pull on the power cord;

always grip the plug itself.

● This appliance is not intended for use by

any person (including children) with

reduced physical, sensory or mental

capabilities, or lacking experience and

knowledge, unless they have been given

supervision or instruction concerning the

use of the appliance by a person

responsible for their safety.

● Children should be supervised to ensure

that they do not play with the appliance.

● No responsibility will be accepted if

damage results from improper use, or if

these instructions are not complied with.

● This appliance is intended for domestic

use only and not for commercial

● In order to comply with safety

regulations and to avoid hazards, repairs

of electrical appliances must be carried

out by qualified personnel, including the

replacement of the power cord. If repairs

are needed, please send the appliance to

one of our customer service departments.

The addresses can be found in the

appendix to this manual.

Before the iron is used, fold the handle

upwards until it locks securely into the

After use, the handle can be folded down for

space-saving storage by pressing the release

With the steam function activated, an

additional hot steam jet is emitted from the

soleplate. This function is very useful for

removing stubborn creases or when ironing

difficult or thick fabrics.

● In order to use the steam function, the

temperature control must be set to the

steam-section marked on the control

Fill the water reservoir before using the

steam function or the spray nozzle.

Remove the plug from the wall socket

before filling the reservoir.

This steam iron is to a large extent

resistant to hard water (up to 15º dH).

Although normal tap water may be used,

it is advisable to use distilled,

demineralised or decalcified water.

Should you be unsure about the hardness

of the water in your area, please enquire

at the relevant local authority

Open the cover of the water fill hole.

Fill the empty water reservoir using the

measuring cup provided. Fill the

reservoir to the indicated “Max” level

General information about ironing

Always check first whether a label with

ironing instructions is attached to the article

The meaning of the ironing symbols is as

These markings can also be found on the

temperature control in the form of dot

● Laundry to be ironed should be sorted

according to the fabric ironing

temperature. Follow the ironing symbols

and start with the lowest temperature.

● When ironing highly sensitive fabrics, or

if you are not sure about the fabrics, you

may carefully test-iron at a non-visible

point, e.g. inside of seam. Start with the

● If the laundry is being dried in a dryer

before ironing, the temperature should

be adjusted to “iron dry”. Very dry

6fabrics are difficult to iron.

Clean the steam iron before using for the

first time, according to the instructions given

in the paragraph General care and cleaning.

This will result in the removal of possible

dust particles from the soleplate and

subsequently lessen the smell typically

encountered when first switching on.

Please ensure sufficient ventilation.

● Steam ironing requires high

temperatures. The temperature level for

steam ironing is indicated on the

temperature control knob.

After filling the reservoir with water,

place the steam iron upright on its base

stand and insert the plug into the wall

Set the temperature control knob to the

required ironing temperature as

indicated by the ironing symbols.

During the heating-up process the

indicator light will be on. The light will go

out once the required ironing

temperature is reached.

● Before ironing any fabrics, the soleplate

should be cleaned by passing it over an

old, clean cotton cloth, while using the

steam jet function; this helps to flush out

any dirt residues or lint particles trapped

inside the openings in the soleplate.

● With the steam switch, the steam

function can be activated as required, or

completely switched off for dry ironing.

● For dry ironing, the water reservoir may

● Place the steam iron upright on its base

stand after use and remove the plug from

Using the spray nozzle

The laundry can be dampened by pressing

the spray button. This will help to smooth

out difficult areas. The spray nozzle may be

used at any temperature level during dry or

General care and cleaning

● Before cleaning the appliance, ensure it is

disconnected from the power supply and

has cooled down completely.

● To avoid the risk of electric shock, do not

clean the appliance with water and do

not immerse it in water.

If necessary, the unit may be wiped with

a dry fuzz-free cloth.

Starch, fat and other deposits on the

soleplate may be removed with a woollen

cloth soaked in a vinegar-water solution.

In order to protect the clean soleplate,

you may occasionally apply a small

amount of paraffin to the warm plate,

wiping it off with a woollen cloth.

● Do not use abrasives or harsh cleaning

● Do not put vinegar or other descalers

into the water reservoir.

● After a long period of non-use, or once a

month, the soleplate should be cleaned as

- Fill half the water reservoir with water

and place it on its base stand.

- Leave the iron to heat on the highest

temperature setting until the indicator

- Unplug the appliance, activate the

steam function and shake the iron to

and fro horizontally over a sink.

- Hot water and steam will be emitted by

the holes in the soleplate. This will

result in the removal of dust particles

- Pour out any remaining water, let the

iron heat up again and pass the

soleplate over an old, clean cotton

cloth. The remaining water trapped in

Do not dispose of old or defective

appliances in domestic garbage;

this should only be done through

public collection points.

This product is guaranteed against defects in

materials and workmanship for a period of

two years from the date of purchase. Under

this guarantee the manufacturer undertakes

to repair or replace any parts found to be

defective, providing the product is returned

to one of our authorised service centres. This

guarantee is only valid if the appliance has

been used in accordance with the

instructions, and provided that it has not

been modified, repaired or interfered with

by any unauthorised person, or damaged

This guarantee naturally does not cover

wear and tear, nor breakables such as glass

and ceramic items, bulbs etc. If the product

fails to operate and needs to be returned,

pack it carefully, enclosing your name and

address and the reason for return. If within

the guarantee period, please also provide the

guarantee card and proof of purchase.
