USER MANUAL HS 0706 SEVERIN

GB Instructions for use

F Mode d'emploi

Before using the appliance, please read the following instructions carefully and keep this manual for future reference. The appliance must only be used by persons familiar with these instructions.

Connection to the mains supply

Make sure that the supply voltage corresponds with the voltage marked on the rating label of the adaptor.

This product complies with all binding CE labelling directives.

Familiarisation

1. Push-on comb 24-40 mm
2. Push-on comb 4-20 mm
3. Push-on comb 2 mm
4. Push-on comb 1 mm
5. Scissors
6. Adaptor
7. Connecting plug
8. Comb
9. Oil
10. Cleaning brush
11. Sensor touch controls
12. Cutting length indicator at the rear of trimming head
13. Main power switch ①
14. Rating label (at the rear)
15. Cutting/thinning selector switch
16. Adjustment slide tracks
17. Trimming blade
18. Trimming comb

Important safety instructions

This appliance is not intended for use by any persons (including children) with reduced physical, sensory or mental capabilities, or lacking experience and

knowledge, unless they have been given supervision or instruction concerning the use of the appliance by a person responsible for their safety.

Children must not be permitted to play with the appliance.

Caution: Keep any packaging materials well away from children - such materials are a potential source of danger, e.g. of suffocation.

• Do not use the appliance in the vicinity of a bath, shower or swimming-pool, over a washbasin filled with water or any other receptacle containing water. Additional protection is afforded by fitting an earthquake circuit-breaker with a rated tripping current not exceeding 30mA into your home installation. Please consult a qualified electrician.

• Protect the appliance from moisture and splashing water and do not operate it with wet hands.

Before the appliance is used, the main body as well as any attachment fitted should be checked thoroughly for any defects. Should the appliance, for instance, have been dropped onto a hard surface, it must no longer be used: even invisible damage may have adverse effects on the operational safety of the appliance.

The power cord should be regularly examined for any signs of damage. In the event of such damage being found, the appliance must no longer be used.

- Switch off and remove the adaptor from the wall socket

• after use,
  -in case of any malfunction during use,
• before cleaning the appliance.

Do not leave the appliance unattended while switched on.
When removing the adaptor from the wall socket, never pull on the power cord; always grip the adaptor itself.
Caution: the trimming blade is extremely sharp; to prevent injuries, ensure that at all

times during use the blade does not touch the skin.

The trimmer must only be used with the adaptor and accessories included.
No responsibility is accepted if damage results from improper use, or if these instructions are not complied with.
- Do not use the appliance on pets or other animals.
This appliance is intended for domestic or similar applications, such as

• in shops, offi ces and other similar working environments,
  -in agricultural areas,
• by customers in hotels, motels etc. and similar establishments,
• in bed-and breakfast type environments.

In order to comply with safety regulations and to avoid hazards, repairs of electrical appliances must be carried out by qualified personnel, including the replacement of the power cord. If repairs are needed, please send the appliance to one of our customer service departments. The address can be found in the appendix to this manual.

Charging process

Before using the appliance for the first time the battery must be fully charged, which will take about 3 hours. The appliance can remain on charge for a longer period without damage or danger, but this should generally be avoided. With a fully charged battery, the appliance can be operated for around 100 minutes.
- As the capacity of the rechargeable battery-pack becomes low, the touch controls () will start fl ashing. The trimmer can now be used for only a few more minutes until the deep-discharge protection device switches the appliance off. Recharging is now necessary.
- Insert the connecting plug of the adaptor into the corresponding jack on the appliance.
- Insert the adaptor itself into a suitable wall socket. The charging process begins

automatically. The touch controls are flashing alternately while the batteries are being recharged.

Once the charging process is complete, the touch controls stay lit. To disconnect the adaptor, always remove it from the wall socket first before taking the jack out of the appliance.

The appliance remains in standby mode for around 10 seconds before it can be switched on again with the touch controls, or switched off with the main power switch (①). (see 'Using the main power switch/touch controls to turn the trimmer on/off').

• While charging, the transformer within the adaptor will become warm. This is perfectly normal and safe and does not indicate a malfunction of any kind.
• If the appliance has not been used for a long period, the capacity of the battery may decrease by a certain amount. However, full capacity will be restored after several charge/discharge cycles.

Mains operation

The appliance may also be used when the adaptor is connected. In this case, use the touch controls to turn the trimmer on and allow the batteries to be briefly charged for approximately 5 minutes, before the trimmer can be operated.

Use

Fitting the push-on combs

• The push-on comb attachments allow for cutting length adjustment from 1 to 40~mm . The range of the cutting lengths is indicated on the inside of each push-on comb.
• When fitting a push-on comb, place it on the silver slide tracks on the sides. To fit one of the variable-length (4-20 or 24-40 mm) push-on combs, the locking buttons must be slightly depressed.

Selecting the cutting length

• With the 4-20 mm and 24-40 mm variable-length push-on combs, the cutting length

can be variably adjusted.

• A scale for the cutting lengths adjustment is indicated on the rear of the trimming head. The arrow markings on the push-on combs correspond with the cutting length on the scale.
• In its lowest position, the cutting length of the 4 - 20mm push-on comb is 4mm , and 24mm on the 24 - 40mm push-on comb.
• Fit the desired push-on comb, select the appropriate cutting length at the rear and release the locking buttons to ensure that the push-on comb locks into place.
• When cutting hair, always start with a longer cutting length and reduce it gradually until the desired length has been reached.

Using the main power switch (①) to turn the trimmer on

Use the main power switch to turn the appliance on. The motor starts running and the touch controls light up.

Using the touch controls (/) to turn the trimmer on/off

• Once the trimmer has been turned on with the main power switch, it may be switched off, or on again, by using the touch controls. By sliding the finger rapidly from ① to ⑦ the trimmer is turned off and remains in standby mode. It can be switched on again by doing the reverse, from ⑨ to ④
• After two minutes in standby mode, the trimmer switches off automatically.

Adjusting the operating speed:

• The operating speed can be adjusted: keeping the touch control pressed decreases the speed, while keeping the touch control pressed increases it. Two short beeps indicate that the min or max speed settings have been reached. The selected setting is saved during standby mode.

Cutting/thinning function

The cutting/thinning selector switch allows

selecting between cutting and thinning of hair. For cutting, select the switch setting 'CUT'. If a trendy short-hair style should require that the hair is thinned by about one third, select the setting 'THIN'. In this mode, always cut the hair against its natural direction of growth.

Operation

Before each use, always put a few drops of acid-free oil between the trimming comb and the blade.

Cutting hair:

• For longer hair, one of the push-on combs provided may be used. We recommend that you start with the large comb.
• Switch the appliance on.
• The hair should first be combed, and then generally cut against its natural direction.
• Always cut from bottom to top with the shaving head lying against the head; lead the appliance upwards through the hair, moving it gradually away from the head at the same time
• For a shaped cut, reverse the appliance and shorten the hair from top to bottom without a push-on comb.

Care and Cleaning

It is essential to switch off the appliance and then remove the adaptor from the wall socket before cleaning and oiling. To avoid the risk of electric shock, the appliance and the adaptor must not be immersed in liquid or allowed to come into any contact with liquid.
- If necessary, the exterior surfaces of the appliance and the adaptor may be wiped with a dry, lint-free cloth.

Trimming comb and trimming blade

• After each use, use the cleaning brush to remove hair from between the trimming comb and the blade. The trimming head can be removed for cleaning by using the thumbs to push it away and down towards the base.

• Caution: The trimming comb and blade are very sharp.
  Before use, and again after every 15 minutes' operation, put a few drops of acid-free oil between the trimming comb and the trimming blade and then switch the appliance on briefly to ensure that the oil is evenly distributed. Regular oiling will guarantee good cutting performance over a long period and a long service life.

Battery pack disposal

This appliance contains a nickel-metal hydride (Ni-MH) rechargeable battery pack, which must be removed for disposal. To remove, first disconnect the appliance from the mains. Use a suitable screwdriver to remove the small screw on the rear of the appliance. Then take off the trimming head and remove the two small screws from the metal plate. Use a screwdriver to lift out first the plate, and then the housing element along the silver slide tracks. Remove the two screws above the large circuit-board. Now the whole circuitboard assembly can be lifted out. Cut the three connecting wires one by one, but take special care not to short-circuit the batteries. Lift the batteries up and use a pair of pliers to cut the metal connectors one at a time, again taking care not to cause a short-circuit. Dispose of the batteries properly.

Do not dispose of the rechargeable Ni-MH battery pack in your domestic garbage. All batteries must be disposed of through the proper local

'special garbage collection points'.

Disposal

Do not dispose of old or defective appliances in domestic garbage; this should only be done through public collection points.

Guarantee

This product is guaranteed against defects in materials and workmanship for a period of two years from the date of purchase. Under this guarantee the manufacturer undertakes to repair or replace any parts found to be defective, providing the product is returned to one of our authorised service centres. This guarantee is only valid if the appliance has been used in accordance with the instructions, and provided that it has not been modified, repaired or interfered with by any unauthorised person, or damaged through misuse.

This guarantee naturally does not cover wear and tear, nor breakables such as glass and ceramic items, bulbs etc. This guarantee does not affect your statutory rights, nor any legal rights you may have as a consumer under applicable national legislation governing the purchase of goods. If the product fails to operate and needs to be returned, pack it carefully, enclosing your name and address and the reason for return. If within the guarantee period, please also provide the guarantee card and proof of purchase.
