Product Type	Freestanding Cooker
Brand	Eldom
Model	Promis
Width	50 cm
Depth	60 cm
Height	85 cm
Weight	35 kg
Power Supply	230 V / 50 Hz
Hob Type	Gas (4 burners) or Electric (depending on variant)
Oven Type	Electric with convection
Oven Capacity	65 L
Number of Oven Functions	8
Energy Class	A
Cleaning Type	Enamel interior, easy-clean
Safety Features	Flame failure device, child lock
Spare Parts Availability	Yes, through authorized service
Repairability Index	7.5 / 10

Frequently Asked Questions - Promis Eldom

How do I light the gas burners?

Turn the knob to the maximum position and press it down while pressing the ignition button. Release the knob after 5 seconds once the flame is stable. If the flame goes out, repeat the process.

What should I do if the oven does not heat up?

Check that the oven is properly plugged in and the main power switch is on. Ensure the thermostat is set to a temperature. If the problem persists, contact an authorized service center.

How do I clean the oven interior?

Allow the oven to cool completely. Remove racks and wipe the interior with a damp cloth and mild detergent. Do not use abrasive cleaners. For stubborn stains, use a ceramic hob scraper gently.

Can I use aluminium foil in the oven?

Avoid using aluminium foil directly on the oven floor as it can block heat circulation and damage the enamel. You may use foil on oven racks, but ensure it does not touch the heating elements.

How do I activate the child lock?

Press and hold the child lock button for 3 seconds until a key symbol appears on the display. Repeat the same to deactivate.

What is the recommended installation clearance?

Ensure at least 5 cm clearance on the sides and 10 cm above the cooker for proper ventilation. The cooker must be installed by a qualified technician and connected to the gas supply if applicable.

How do I replace the oven light bulb?

Disconnect the power. Remove the glass cover by turning it counterclockwise. Replace the bulb with a 300°C resistant G9 bulb (25W) and reassemble.

Why is the hob not igniting?

Check that the gas supply is open and the burner caps are correctly positioned. Clean the spark electrode with a dry cloth. If ignition still fails, call a service technician.

How do I adjust the oven temperature?

Turn the thermostat knob to the desired temperature. The oven will preheat and the indicator light will turn off when the set temperature is reached. Use an oven thermometer for accuracy.

Where can I find spare parts?

Spare parts are available from Eldom authorized service centers or online spare parts retailers. Provide the model number 'Promis' when ordering.

USER MANUAL Promis Eldom

Line drawing of a portable gas stove with four heat sinks and an open lid (no text or symbols)

INSTRUKCJA OBSŁUGI DLA KUCHENEK GAZOWYCH:

KG-200 / KG-300 / KG-400

Szanowni Państwo,

Two circular mechanical components with a central black block and a gray X symbol crossed out (no text or labels)

CZYSZCZENIE I KONSERWACJA

Gas Category	I_3+(28-30/37)		I_3B/P(30)	I_3B/P(37)
Gas Type Butane Propane			Butane, Propane or their mixtures
Gas pressure	28-30 mbar	37 mbar	28-30 mbar	37 mbar
Destination Countries	BE, FR, IT, LU, IE, GB, GR, PT, ES, CY, CZ, LT, SK, CH, SI and LV		LU, NL, DK, FI, SE, CY, CZ, EE, LT, MT, SK, SI, BG, IS, NO, TR, HR, RO, IT, HU and LV	PL

USE OUTDOORS ONLY.

READ THE INSTRUCTION BEFORE USING THE APPLIANCE.

WARNING: ACCESIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY.

SAFETY INSTRUCTION:

1. Carefully read this instruction manual before start to use the product, install the gas pipe and/or connect the gas cylinder.
2. The appliance is compliant with standard: EN 484: 1997.
3. Well keep this instruction manual for future reference
4. Only to be used outdoors. It is forbidden to use the equipment in houses.
5. This appliance must be kept away from inflammable materials and heat source
6. Place always the stove on perfectly horizontal surfaces and heat resistant. Never place the stove on surfaces in paper support, wood, plastic or any other flammable materials.
7. Always verify that the product is undamaged before starting to use it. In the case are present any kind of damage, never use the appliance and get in contact only with the authorized service center by the manufacturer.
8. Do not modify or repair for any reason the equipment yourself or by unauthorized personnel. In case of malfunction or apparent damage, always contact the service centers authorized by the manufacturer.
9. Do not use the appliance with damaged seals and/or in case of leaking due to wear of the components. Replace damaged hoses before using appliance.
10. Do not use the stove for any others purposes than cooking food or heating up of liquids for food use.
11. Never leave the appliance unattended during the use.
12. Always keep the stove out of reach of children, out of dependent persons and pets.
13. During the use, the stove could reach high temperatures. Pay always a lot of attention when your are using it and avoid to touch the metal parts when hot. Use protective glove when handling particularly hot components.
14. Do not move the appliance during use.
15. If you feel gas's smell coming from the appliance, immediately turn off the stove and close the gas cylinder valve. Contact an authorized service center to solve the problem.
16. Use only and exclusively LPG gas cylinder and in accordance with legislation TPED

17. Turn off the gas supply at the gas container after use.

18. It shall be carried out away from any source of ignition when changing the gas container.

19. The length of hose cannot exceed 1.5m. In Finland, the length of hose cannot exceed 1.2m.
20. Make sure hose is not kinked. Make sure that when connected hose does not touch any warm surfaces.
21. It's necessary to change the flexible tube when the national conditions require it.
22. Only regulator complies with EN 16129 can be used;. Always use a low-pressure regulator to connect the gas cylinder to the stove. This regulator for I 3+(28-30/37) must to have exclusively a fixed calibration normalized at 37 mbar for Propane and 30 mbar for Butane. For I 3B/P(30), the regulator should have a fixed calibration normalized at 30mbar.
23. To store the product always in dry and slightly moist places, away from the atmospheric agents or factors that could damage the stove itself.
24. Reparation must be performed only by qualified personnel in the service centers authorized by the manufacturer or importer.
25. Avoid to block the venturis of burners. Check whether the venturis of burners are blocked before using the appliances.
26. The diameters of cooking vessels which can be used are 120mm-280mm.
27. Parts sealed by the manufacturer or his agent must not be altered by the users.
28. Any modification of the appliance may be dangerous.

INSTRUCTION USE:

• Carefully read this instruction manual before start to use the product, install the gas pipe and/or connect the gas cylinder.
• Attention: during the use, this equipment generates emissions of carbon dioxide, which could become dangerous if accumulated. For this reason, only use this product outdoor.
• It is forbidden to use the equipment in houses.

INSTALLATION:

- Place the stove on a horizontal surface respecting the instructions indicated in the chapter of Safety Instruction.

• Check that the gas pipe that you want to use is in accordance with the rules in force in your country and it has already assembled with the pressure reducer with the characteristics described in the chapter of Safety Instruction and in the technical data table.
• Insert into the gas pipe a full mesh metal clamp suitable for LPG gas pipes.
• To insert the gas pipe in the stove gas's connector on the back of the stove and push it until the pipe is inserted up to the connector for at least 2cm.
• Tighten the metal clamp in order to seal safely the rubber hose to the stove connector.

LPG CYLINDER ASSEMBLY:

• Before assembling the cylinder, turn the burner valve's knobs clockwise until them reach the closed position.
• Place the gas cylinder in a stable and dry surface
• Connect the pressure regulator already assembled to the gas pipe to the LPG cylinder making sure you have correctly inserted the seal gasket supplied with the cylinder.
• Always use the new gaskets supplied together with the LPG cylinder.
• Tighten the regulator to the cylinder to prevent gas leakage.
• Check that the gas hose is not twisting. In case, rotate the pipe in order that every twist or curve is eliminated and the tube has a linear shape.
• Turn the cylinder's valve knob until fully open in order to allow the gas LPG to feed the stove.
• Keeping the stove taps closed for fice minutes and check does not spread out smell of gas before proceeding with the use of the stove.
• To verify that the installation has been done successfully, pour soapy on the joints of every connection. Any leaking will be well visible using this solution.
• Attention: Never use a flame to check the Gas leaking.

PRODUCT'S USE:

• Lightly press and turn counterclockwise the burner valve's knob according the burner you want use.

• Put a lighter close to the defined burner

• Wait until the burner is fully switch ON and adjust the flame by turning the knob clockwise or counterclockwise according your needs.

• To make the temporary shutdown of the burner, turn the knob clockwise to the OFF position.
• After cooking, or before storing the product, turn OFF the burner by turning clockwise the cylinder valve's knob till's close and wait for the complete extinction of the flame. Then rotate also the burner valve's knob to OFF position. This eliminates residual gas inside the tube and in the stove as well.
• Wait until the stove is cold before moving or storing, at least 30 minutes.

LPG CYLINDER EXCHANGE :

• If, while using, the burner goes OFF, needs to replace the cylinder.
• Turn OFF the cylinder and the burner's knob to the close position before proceeding with the unscrewing of the pressure regulator.
• To assembly of a new Gas cylinder, please follow the instruction indicate in the chapter LPG gas cylinder assembling, always respecting the Safety Instructions.

CLEANING AND MAINTENANCE:

• Regularly clean your Stove between uses and especially after extended periods of storage.
• Before proceeding with cleaning and maintenance of the product, make sure that the stove is properly cooled; wait at least 30 minutes after the last use.
• Ensure that the cylinder valve and the burner's valve are in the closed position. Remove the grid to perform the cleaning more conveniently.
• Use a damp sponge to remove heavier dirt, a damp cloth and then a dry cloth are enough to clean and dry all surfaces.
• Never use abrasive substances, solvents or flammable.
• The only maintenance required for this equipment are the gas

pipe and the cylinder. Always make sure that these components are comply with current regulations and maintained in good working order. Always use the new gaskets supplied with the cylinder to ensure the seal between regulator and cylinder

STORAGE

- Store your Stove in a cool dry place. Cover the burners with aluminum foil in order to prevent insects or other debris from collecting in burner holes. If the Stove is to be stored indoors, the gas cylinder must be disconnected and left outside. The gas cylinder should always be stored outside, in a dry, well-ventilated area, away from any sources of heat or ignition. Keep out of the reach of children
