HLC01 - Cooker Eldom - Free user manual and instructions

Product Type	Electric Cooker
Brand	Eldom
Model	HLC01
Dimensions (approx.)	30 x 30 x 10 cm
Weight	2.5 kg
Power Supply	230 V ~ 50 Hz
Power Consumption	1500 W
Number of Cooking Zones	1
Cooking Zone Type	Radiant / Solid Plate
Heating Indicator Light	Yes
Temperature Control	Stepless / Infinite
Non-slip Feet	Yes
Overheat Protection	Yes
Cool-Touch Handle	Yes
Cleaning	Wipe with damp cloth, do not immerse
Safety Features	Automatic shut-off, overheating protection
Spare Parts Availability	Contact authorized service centers
Warranty	2 years
Certifications	CE, RoHS

Frequently Asked Questions - HLC01 Eldom

How do I turn on the Eldom HLC01 cooker?

Plug the cooker into a mains socket and turn the knob to the desired heat setting. The indicator light will show that the plate is heating.

Can I use metal utensils on the cooking plate?

It is recommended to use wooden or silicone utensils to avoid scratching the surface. Metal utensils may damage the plate.

How do I clean the cooker?

Unplug the device and let it cool completely. Wipe the surface with a damp cloth and mild detergent. Do not immerse in water or use abrasive cleaners.

What is the maximum power consumption?

The maximum power consumption is 1500 W. Ensure the electrical circuit can handle this load.

Does the cooker have automatic shut-off?

Yes, the cooker is equipped with overheating protection that will automatically shut it off if it gets too hot.

Can I use the cooker on a glass surface?

It is safe to use on a heat-resistant surface. Ensure the surface can withstand high temperatures and place the cooker on a flat, stable area.

What should I do if the indicator light does not come on?

Check that the power cord is properly connected and the socket is working. If the problem persists, contact authorized service.

Is the handle heat-resistant?

Yes, the handle is designed to stay cool to the touch during normal use. However, avoid touching the housing near the cooking zone.

Can I leave the cooker unattended while cooking?

Never leave the cooker unattended while in use. Always monitor cooking to prevent fire hazards.

Where can I find spare parts?

Spare parts are available through Eldom authorized service centers. Refer to the manual for contact information.

USER MANUAL HLC01 Eldom

Black portable air conditioner unit with glowing red flames and smoke, no visible text or symbols

OPIS OGÓLNY

Close-up of a black industrial fan grille with a white number '5' on the side (no text or symbols beyond the number)

UŻYTKOWANIE URZĄDZENIA

1. ON/OFF switch (operation mode)
2. Indicator light
3. Carrying handle
4. Air blowing opening
5. Air inlet
6. The flame effect

TECHNICAL DATA

• power: 1500W
• supply voltage: 230V \~ 50Hz

HOW TO USE THE APPLIANCE

HLC01 ceramic heater has many advantages, with the major ones being: the state-of-the-art ceramic heating element and the insert imitating a genuine fireplace hearth. The ceramic technology increases the operational efficiency of the device so that it heats up quickly and evenly. The "FLAME" function, which can be activated independently of the heating function can be used to obtain a cosy fireplace effect.

• After unpacking the appliance, make sure it has not been damaged during transport. In case of any doubts, do not use the appliance until consulting a service centre. Put the appliance onto a flat, stable and high temperature resistant ground.
• Turn the switch (1) to position "O" (appliance turned off).
• Connect the appliance to a power source with parameters in accordance with the Instructions for Use.
• choose operation mode by turning the knob (1):

FLAME

LOW - hot air

HIGH - very hot air

- The appliance work is signaled by control lamps (2)

When used for the first time, the heating elements and insulation can emit characteristic smell. It is a normal phenomenon.

In the base of the appliance there is a switch which cuts off power supply in case of overturning.

Do not cover outlets when the appliance is in operation.

CLEANING AND PRESERVATION

• Before cleaning remove the power cable from the socket
• The appliance cannot be submersed in water
• Do not use any cleansing agents which are strong and damage the surface
• Wipe the housing with a moistened cloth

SAFETY INSTRUCTIONS

- before first use familiarise with the whole instruction manual

- the device should be plugged in the socket with the working parameters described on the shell

- the device works only in vertical setting

- the device should be unplugged before cleaning and maintenance and in case of improper working or after using the device

- the device should be unplugged by pulling the plug not the cable

- do not use close to shower, bath, washbasin, pool, etc.

- do not use close to combustible materials such as furniture, bedding, paper, clothes, curtains, carpets, etc.

- do not operate in with high risk of gas explosion or when flammable solvents, lacquers or adhesives are used

- do not use outdoors

- do not touch with wet or moistened hands or feet

- do not immerse in water or sprinkle

- move only using the handle (4)

- do not let children or animals to have access to the device. While operating the device the surface temperature may be high.

- do not use for drying clothes

- do not cover outlets while operating the device

- do not direct the cord over the heater and outlets

- the device should not be used by people (including children) with limited physical, sensory and mental abilities unless they are under supervision of a person responsible for their safety

- do not leave working device without supervision

- let heater cool down before putting it to a hide

- check regularly whether the device or the cord have any damages. Do not operate if any damages are noticed.

- do not use if the cord is damaged, when the device fell over or was otherwise damaged. Any mending of the device should be let to authorised service providers. List of service providers can be found in the annex or on website www.eldom.eu

- Any mending of the device should be held by authorised service providers. Any modernisations or using spare parts or other elements other than original is forbidden and dangerous.

- Eldom sp.z o.o. shall not be responsible for any damages occurring as a result of improper usage

ENVIRONMENTAL PROTECTION

- the device is made of materials which can be reused or recycled

- the device should be handled to a special point which deals with collecting and recycling of electric and electronic equipment

GUARANTEE

• the device is designed to be used in households
• not for professional use
• the guarantee expires when device is used improperly

Detailed warranty description in the annex.

POPIS HLAVNÍCH ČÁSTÍ

Close-up of a black industrial fan grille with a white label showing the number 5 (no text or symbols on the grille itself)

POUŽIVANÍ ZAŘÍZENÍ

Close-up of a black industrial fan grille with a white number 5 on the side (no text or symbols beyond the number)

GEBRAUCH DES GERÄTES

Close-up of a black industrial fan grille with a white label showing the number 5 (no text or symbols on the grille itself)
