DED8724Q-46C - Lawn mower DEDRA - Free user manual and instructions

Product Type	Lawn Mower
Brand	DEDRA
Model	DED8724Q-46C
Cutting Width	46 cm (18 inches)
Power Source	Electric (corded)
Motor Power	1800 W
Cutting Height Adjustment	Central lever, 5 positions (25-75 mm)
Grass Collection Box Capacity	50 L
Cutting System	Rotary steel blade
Discharge Options	Rear collection, mulching, side discharge (optional)
Handle Type	Foldable, ergonomic with soft grip
Wheels	4 wheels, 200 mm front, 250 mm rear
Weight	14 kg
Dimensions (L x W x H)	80 x 50 x 45 cm (folded)
Power Cord Length	10 m
Noise Level	85 dB(A)
Safety Features	Motor brake, safety switch, overload protection
Maintenance	Blade sharpening, cleaning after use, oiling wheels
Spare Parts Availability	Blades, belts, wheels, grass bag
Warranty	2 years

Frequently Asked Questions - DED8724Q-46C DEDRA

How do I start the DED8724Q-46C lawn mower?

Ensure the safety switch is engaged, plug into a power outlet, then press and hold the start button while pulling the handle bar towards you. Release the start button after the motor runs.

How can I adjust the cutting height?

Use the central height adjustment lever located on the top of the mower deck. There are 5 positions ranging from 25 mm to 75 mm. Move the lever to your desired setting before mowing.

How do I clean the lawn mower after use?

Disconnect the power cord. Use a brush or cloth to remove grass clippings from the deck, blade, and grass box. Do not use water directly on the motor. Wipe dry and store in a dry place.

When should I sharpen the blade?

Sharpen the blade after every 25 hours of use or when you notice uneven cutting or tearing of grass. Use a file or grinder and balance the blade before reinstalling.

What safety precautions should I take?

Always wear sturdy shoes and eye protection. Keep children and pets away. Do not mow wet grass. Disconnect power before cleaning or adjusting. Use a residual current device (RCD) for outdoor use.

What is the capacity of the grass collection box?

The grass collection box has a capacity of 50 liters. Empty it when full to maintain optimal airflow and collection efficiency. Indications on the box show fullness.

Can I use a longer extension cord?

Use a heavy-duty extension cord rated for outdoor use with a minimum of 1.5 mm² cross-section. Maximum recommended length is 25 m to prevent voltage drop and overheating.

How should I store the lawn mower during winter?

Clean thoroughly, empty the grass box, and store in a dry, frost-free place. Fold the handle for compact storage. If possible, charge/service batteries if applicable (cordless models). For corded, coil the cord loosely.

What maintenance is required regularly?

After each use: clean the deck and blade. Every season: sharpen/balance blade, oil wheels and pivot points, check bolts and screws for tightness. Replace blade if damaged.

Why does the mower stop suddenly?

Possible causes: overload protection triggered (let cool), grass box full, blocked discharge chute, or safety switch deactivated. Check and resolve, then restart after a few minutes.

USER MANUAL DED8724Q-46C DEDRA

Black-and-white photo of a lawn mower with visible blades and handle (no text or symbols)
