USER MANUAL COLIBRI 2000 POLTI

Aspirater Rechargeable

Aufladbarer Sauger

Aspirador recargable

ITALIANO

USO CORRECTO DEL PRODUCTO

This appliance must be used only for the use for which it is intended: as a vacuum cleaner for home use. Any other use is incorrect and therefore hazardous. Polti S.p.A. shall not be held liable for any damage resulting from incorrect or erroneous use.

This product is marked with the CE mark and produced in conformity with electromagnetic directive 89/336/EEC and low voltage directive 73/23/EEC.

POLTI S.p.A. reserves the right to modify technical features and construction as necessary without prior notification.

WARNING

• Read the instructions carefully before using the appliance and keep them for future reference.
• Check that your mains voltage corresponds to the voltage specified on the appliance plate and that the plug is of the right type before plugging in the recharger.
• Never touch the appliance if it is plugged in and your hands or feet are wet.
• Do not operate the appliance with bare feet.
• Do not use the appliance to suction up liquids (normal, inflammable or combustible) or toxic substances, and do not use in an environment where substances of these kinds are present.
• Do not leave the appliance outdoors where it will be exposed to the weather.
• Do not leave the appliance near a heat source.
• Do not use the appliance without the filter.
• Do not use the appliance to suction up burning or incandescent objects such as cigarette stubs, ash, or other burning material.
• It is normal for the recharger to heat up when recharging the appliance.
• Do not use the appliance in the presence of an explosion hazard.
• Do not submerge the appliance in water or other liquids. Do not use the appliance near a bathtub, shower or container full of water.
• Do not allow children or people unfamiliar with use of the appliance to use it.
• Do not use out of doors.

• Do not store the appliance in the trunk of a car or in another closed place subject to extremes of temperature.
• In the event of a fault or malfunctioning, turn off the appliance. Do not attempt to dismantle it, but take it to an authorised service centre.
• If the appliance is dropped, have it inspected by an authorised service centre. Internal malfunctioning could compromise product safety.
• Do not pull on the cord to unplug the recharger. Always grasp the recharger to unplug it.
• Do not handle the recharger roughly, pull the cord over blades or sharp corners, carry the recharger or base by the cord, close doors or place heavy objects on the power cord.
  Always check that the appliance is not connected to the recharger before performing any cleaning or maintenance operations.
• Use only original spare parts and accessories approved by the manufacturer to guarantee safe appliance use.
  Always dispose of used batteries in battery collection containers.
• Follow the manufacturer's installation instructions. The manufacturer may not be held liable for injury to people or animals or damage to objects if these instructions are not followed.

INSTALLATION

WARNING!!! Before drilling holes in walls, check that there are no gas or water pipes or electrical raceways in the surrounding area.

Assemble the bracket (M) upright on the wall using the plastic screw anchors provided, being sure to position it close to a power outlet.

Place the bracket on the wall and mark the points where the anchoring screws should be inserted. Drill holes in the wall at these points and insert the two screw anchors.

Screw in the upper screw, leaving it slightly protruding so as to mount the bracket (M) and the screw and press it downward to make sure it is hooked in place correctly.

Screw in the second screw and check that the bracket is firmly attached to the wall.

USE

WARNING!!! The first time you use the appliance, it must be charged for at least 24h to fully charge the batteries.

The first time you use the appliance, connect the recharger (I) to the recharging plug (A), plug in the recharger and wait for the amount of time specified above. The indicator light (C) will remain on for as long as the appliance is connected to the charger.

When the appliance has been charged, unplug the recharger from the power outlet and then remove the recharging plug from the appliance. Apply the accessory suited to the type of cleaning you intend to do and start the vacuum cleaner by setting the switch (B) to position 1. Once you have finished cleaning, put it back in its original position. (A fully charged battery will last about 10 minutes of operation).

USING ACCESSORIES

Removable motor-driven brush:

The motor-driven brush allows you to brush carpets, raising dust so that it is easily suctioned up by the appliance. This accessory is recommended for low pile carpets only.

Firmly apply the motor-driven brush to the dust container opening.

• Do not use the motor-driven brush to suction up hair, threads, etc. as these would obstruct the brush.
• Never touch the brush while in operation. It could be hazardous.

Lance:

Apply the appropriate nozzle for the surface area to be cleaned. The lance is useful for suctioning in hard to reach corners, and may be used with the hose if necessary.

• Apply the adapter to the dust container.
• Apply the lance and start suctioning.
• The flat lance (7) also has a brush attachment (8) for cleaning keyboards, etc.

Soft cleaning brush:

Useful for suctioning up dust off picture frames, shelves, etc. May be used with the hose if necessary.

• Apply the adapter to the dust container.
• Apply the soft cleaning brush and start suctioning.

Nozzle:

Useful for suctioning up dust and crumbs from tables, shelves, and other surfaces.

May be used with the hose if necessary.
- Apply the adapter to the dust container.
- Apply the nozzle and start suctioning.
The nozzle (10) also has a brush attachment (11).

RECHARGING

If you find that several recharges are not sufficient to permit optimal functioning at first, this does not mean that the appliance is detective.

It is normal for batteries to require a number of recharges before they offer optimum performance. The first time you use the appliance, it is a good idea to operate it until the battery is flat.

MAINTENANCE

Cleaning the dust container

Make sure the appliance has been unplugged before removing dirt.

• Remove dirt collected in the dust container after each use.
• Hold the appliance upright with the tip downwards so you will not spill dirt.
• Press the container fixing hook (D) to release the container (E).
• Remove the filter (F) and shake it out. If it is very dirty, rinse it under running water. If the filter is torn, replace it with an original Polti filter.
  Empty the dust container, wash it and dry it.
• Put the filter (F) back in the container (E), first checking that both components are perfectly dry.
• Connect the container (E) to the body of the appliance, raising the hook (D) a little until the two parts are firmly in place.

Precautions when cleaning the appliance and the filter

Do not attempt to clean the appliance with paint thiners or other chemical solutions which could damage its outer shell.

Clean with neutral soap and a damp cloth only.

Clean plastic parts with a damp cloth only.

Make sure that the dust container and filter (F) are perfectly dry before using them again.

Check that the motor-driven brush is not obstructed by hair or threads before using it.

Contact an authorised Polti service centre if you need repair work.

Disposing of batteries:

Precautions when handling nickel cadmium batteries:

When you need to replace the appliance's batteries, remove old nickel cadmium batteries carefully and take them to an authorised collection facility.

• Do not burn batteries or expose them to high temperatures, as they could explode.
• Do not put batteries or the appliance in a place where temperatures are high. Do not throw them onto a fire.
• Do not short circuit terminals. Cover battery terminals with insulating tape. DO NOT dismantle and reassemble the battery pack.
• Do not attempt to clean the battery pack with paint solvents or other chemical solutions which could damage the batteries' outer covering.
  Always take the battery pack and the appliance to authorised service centres only.
• Battery leakage:

Under extreme environmental conditions batteries may leak. Battery fluid is a 20 - 35% potassium hydroxide solution.

If battery fluid comes into contact with the skin:
- Wash immediately with water and neutral soap, or neutralise the affected area with lemon juice or vinegar.
If the fluid comes into contact with the eyes:
- Rinse the eyes immediately with clean running water for at least 10 minutes and seek medical attention without delay.
- To keep batteries properly charged, keep the appliance connected to its recharging base with the adapter plugged in at all times.
Always store the battery pack and the appliance together in a cool place with the battery pack fully charged.
- Do not remove the battery pack from the appliance except for maintenance work or replacement of the battery pack.

IMPORTANT

• This appliance is manufactured in compliance with current recycling regulations.
• Do not dispose of protective packaging material with household waste, but take it to a collection facility.
• Use only original Polti spare parts.

ELECTRICAL SAFETY

No earth required.

Ensure the mains voltage suits your appliance.

Fitting the mains plug important

The wires in the mains lead are coloured in accordance with the following code:

• Blue: Neutral
• Brown: Live

The wire which is coloured BLUE must be connected to the Terminal which is marked with the letter "N" or coloured BLACK.

The wire which is coloured BROWN must be connected to the Terminal which is marked with the letter "L" or coloured RED.

It is important that the outer sheath is clamped correctly into the-3-pin plug.

If in doubt consuot your local Service Dealer or qualified electrician before the machine is used.

A 13 AMP FUSE MUST BE FITTED TO THE MAINS PLUG.

GARANZIA / GARANTIA / GARANTIE / GARANTIEKAART / GUARANTEE

ITALIANO

Polti products are guaranteed to the original purchaser for two years from the date of purchase as shown on a valid receipt issued by the seller.

This guarantee does not affect the consumer's rights under European Directive 99/44/CE regarding certain aspects of the sale and guarantee of consumer goods; consumers should address claims under these provisions to the retailer where they purchased the goods.

This guarantee is effective in countries where European Directive 99/44/CE has been implemented. Local guarantee legislation applies in all other countries.

During the guarantee period, Polti will repair products with defects in workmanship or materials at no charge to the customer for either labour or materials.

To have work performed under this guarantee, consumers must contact an Authorised Polti Technical Assistance Centre. A list of these

centres and their addresses is attached. The consumer must present a valid receipt issued by the seller at the time of purchase as evidence of the date of purchase.

The guarantee does not cover defects due to incorrect use or use other than that identified in the instruction booklet, which is an integral part of the contract of sale for the product. The guarantee does not cover defects resulting from chance (fire, short circuit) or attributable to a third party (tampering with the product).

The guarantee does not cover parts that are damaged by wear or subject to normal wear (consumables such as filters, brushes, etc.).

Polti will accept no responsibility for any injury to people or animals or damage to objects directly or indirectly resulting from failure to follow the instructions provided in the instruction booklet, in particular the warnings and product maintenance instructions.
