Product Type	Canister Vacuum Cleaner
Brand	Polti
Model	PBGB0014
Dimensions (L x W x H)	40 cm x 25 cm x 25 cm
Weight	5.2 kg
Power Supply	220-240 V, 50/60 Hz
Power Consumption	1200 W
Cord Length	5 m
Dust Capacity	1.5 L (bagless)
Filtration System	HEPA washable filter
Noise Level	75 dB
Main Functions	Dry vacuum cleaning with adjustable suction power
Floor Nozzle	Combination floor brush for hard floors and carpets
Accessories	Crevice tool, upholstery brush, dusting brush
Maintenance	Empty dust container, wash filter every 3 months
Safety Features	Thermal overload protection, double insulation
Spare Parts Available	Replacement HEPA filter, foam filter, brush head
Repairability Index	7.5/10 (easy access to main components)
Warranty	2 years

Frequently Asked Questions - PBGB0014 POLTI

How do I change the filter on my Polti PBGB0014 vacuum cleaner?

To change the filter, first unplug the vacuum. Open the dust container lid and remove the HEPA filter assembly. Replace with a new Polti-approved filter, ensuring it is securely seated. Wash the foam pre-filter if present and let it dry completely before reinserting.

What should I do if the suction power decreases?

A decrease in suction is often due to a blocked hose or filter. Check the hose for obstructions, empty the dust container, and clean the filter. Also inspect the floor nozzle for tangled hair or debris.

Can I use my Polti PBGB0014 to vacuum liquids?

No, this model is designed for dry vacuum cleaning only. Using it to pick up liquids can damage the motor and void the warranty.

How often should I clean the filter?

It is recommended to clean the foam filter every 3 months and replace the HEPA filter annually or when visibly dirty. Frequency may increase with heavy use.

The vacuum turns off during use. What could be the cause?

This is likely due to the thermal overload protection activating. The vacuum may have overheated. Turn it off, unplug, and let it cool for 30 minutes. Ensure the filter is clean and no blockages exist.

How do I empty the dust container?

Press the release button on the dust container lid, lift it off, and empty into a trash bin. Tap the container to remove fine dust. For thorough cleaning, wash with mild soap and water and dry completely before reattaching.

Are replacement parts compatible with other Polti models?

Replacement parts for the PBGB0014 are model-specific. While some filters may be shared with similar Polti canister vacuums, it is best to use genuine Polti parts for optimal performance and safety.

What does the 'max' button on the handle do?

The 'max' button provides maximum suction power for deep cleaning carpets or stubborn debris. Release it to revert to standard suction for everyday use.

My vacuum makes a rattling noise. Should I be concerned?

A rattling noise may indicate a loose part or a foreign object in the hose or brush head. Turn off the vacuum, inspect the hose and nozzle for obstructions, and ensure all attachments are securely fitted.

How do I clean the brush roll?

Unplug the vacuum. Remove the floor nozzle and use scissors or a seam ripper to cut away hair and threads wrapped around the brush roll. Wipe the brush with a damp cloth and let it dry before reattaching.

USER MANUAL PBGB0014 POLTI

Black and white photo of a high-tech vacuum cleaner with attached hose and control panel (no visible text or symbols)

REGISTER YOUR PRODUCT REGISTRA IL TUO PRODOTTO ENREGISTREZ VOTRE PRODUIT REGISTRA TU PRODUCTO GERÄTREGISTRIERUNG REGISTE O SEU PRODUTO

www.polti.com

POLTI

NATURAL HOME FEELING

FORZASPIRA MC330 TURBO

KEEP THESE INSTRUCTIONS

• Read these instructions carefully before using the appliance.
• Any use which does not comply with these instructions will invalidate the warranty.
• If this instruction manual is lost, it is possible to review it and/or download it from the web site www.polti.com
• Unpack the product and make sure it is intact as well as all the accessories listed in the key. If in doubt, do not use the product and contact an Authorized Service Centre.
• This appliance has been designed only for domestic use.
• This appliance can be used by children over 8 years old, by people with reduced physical, sensory or mental abilities or by inexperienced persons provided they are instructed in advance on its safe use and only if informed of the dangers inherent to the product.
  • Children must not play with the appliance.
• The cleaning and maintenance of the appliance may not be done by children without the supervision of an adult.
• In case the appliance is accidentally dropped, it is necessary to have it checked by an authorized Service Centre as the internal safety features may have been affected.
• Keep all the parts of the packaging out of the reach of children, they are not a toy. Keep the plastic bag out of the reach of children: danger of suffocation.

SAFETY WARNINGS:

Risk of electric shock and/or short circuit:

• The wiring system to which the appliance is connected must always comply with the laws in force.
• Before connecting the appliance, make sure that the mains voltage is the same as the voltage indicated on the data label of the appliance and that the power outlet is connected to earth.
• Always turn off the appliance at the on/off switch before unplugging it.

FORZASPIRA MC330 TURBO

• If the appliance is left unused, always disconnect it from the mains. Never leave the appliance unattended with the cable plugged into the mains.
• Always make sure the appliance is unplugged before performing maintenance work of any kind.
• Do not pull the power cable out of the socket, but grasp the plug itself to avoid damage to the socket.
• Do not allow the power cable to be twisted, crushed, stretched, or come into contact with sharp or hot surfaces.
• Do not use the appliance if the power cable or other important parts of the appliance are damaged. Instead, contact an authorised service centre.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• Do not use electric extension leads that are not authorized by the manufacturer, as they may cause damage or fire.
• Never touch the appliance with wet hands or feet with the cable plugged into the mains.
• Do not use the appliance when barefoot.
• Do not use the appliance near washbasins, bathtubs, showers or containers full of water.
• Never immerse the appliance, the cable or the plugs in water or another liquid.

SAFETY WARNINGS:

Risk of injuries and/or burns when using the appliance:

• Use of the appliance in places where there is a danger of explosions is prohibited.
• Do not use the product with toxic substances.
• In case of breakdown or malfunction switch off the appliance and never attempt to disassemble it, but refer to an authorized Polti Service Centre.
• This appliance is equipped with safety devices which are to be replaced only by a suitably qualified technician.
• Do not use if the appliance has been dropped and has visible signs of damage.

FORZASPIRA MC330 TURBO

SAFETY WARNINGS:

using the appliance:

• Never leave the appliance exposed to the weather.
• Do not place the appliance near a live element, an electric stove or any other source of heat.
• Do not expose the appliance to temperatures under 0° C or over 40° C
• Press the buttons only with a finger, without excessive force and avoid using a pointed object such as a pen.
• Do not wind the power cable around the appliance, especially when the appliance is still hot.
• To avoid prejudicing the safety of the appliance when repairing or replacing accessories, use only original spare parts.
• It is necessary to keep the unit in horizontal position during operation.
• Always rest the appliance on a stable surface.
• Do not vacuum up liquids
• Do not use the appliance to suck up acids or solvents, as these might cause serious damage to the appliance and above all do not suck in explosive dust or liquids, as these could cause explosions on coming into contact with the inside components of the appliance.
• Do not vacuum up toxic substances.
• Do not suck up burning or incandescent objects such as embers, ash or other material in which combustion is taking place.

Read these instructions carefully before using the appliance.

Congratulations on your purchase and welcome to the Polti world of cleaning.

We know how important it is to be able to depend on a reliable appliance for every day cleaning, that is why your vacuum cleaner has been designed to let you experience efficient as well as quick, fast cleaning. Powerful suction, easy and intuitive use and a wealth of accessories make your vacuum cleaner the ideal assistant.

Please also visit our website www.polti.com, where you can find all the information and advice necessary to better use the product, and where you can register your newly purchased product to receive exclusive benefits.

KEY

1) Power Supply cable
2) Parking housing
3) Dust container release lever
4) Cable winder button
5) Control panel
5a) STOP indicator light
5b) Suction levels indicator lights
5c) Remote control receiver
5d) Container full indicator light

6) Dust container

6a) Dust container cover
6b) Container filter
6c) Filter unit
6d) Container
6e) Dirt removal door
6f ) Dust container opening button

7) Connector hose

8) HEPA filter grill

9) HEPA filter

10) ON/OFF switch

11) Small nozzle storage

12) Lance storage

13) Cap for cleaning vacuum cleaner hoses

ACCESSORIES

A) Hose
A1) Hose handle
A2) Flexible hose control panel
A2a) Remote control operation indicator light
A2b) Maximum power button
A2c) Reduce power button
A2d) Increase power button
A2e) Pause button

A3) Tube lock-in button

B) Telescopic tube locking button B1) Telescopic tube release button

C) Bristled frame for small nozzle

D) Parquet brush

E) Lance

F) Small nozzle

G) Universal Brush

G1) Hook for attaching to accessories holder

G2) Brush selector for carpets / floors

H) Mini turbo-brush

I) Turbo-brush

I1) Surface type selector

This unit conforms with EC-directives 2004/108/CE (EMC) and 2006/95/CE (low voltage).

Polti S.p.A. reserves the right to change equipment or accessory specification without prior notice.

CORRECT USE OF THE PRODUCT

This appliance is intended for home use for vacuuming solids as described and in accordance with the instructions provided in this manual. Please read these instructions carefully and keep them, as you may find them useful in future.

Polti declines liability for any damage or accident derived from any use of this appliance which does not comply with the instructions contained in this booklet.

ATTENTION

Directive 2002/96/EC (Waste Electrical and Electronic Equipment - WEEE): information for users.

This product complies with EU Directive 2002/96/EC.

The crossed-out wastebasket symbol on the appliance means that at the end of its useful lifespan, the product must be disposed of separately from ordinary household wastes.

The user is responsible for delivering the appliance to an appropriate collection facility at the end of its useful lifespan.

Appropriate separate collection to permit recycling, treatment and environmentally compatible disposal helps prevent negative impact on the environment and human health and promotes recycling of the materials making up the product.

For more information on available collection facilities, contact your local waste collection service or the shop where you bought this appliance.

PREPARATION

• Remove the appliance from the packaging, checking that the product is whole and that all the parts are there.
  ♦ Insert the suction opening of the flexible tube (A) into the connector (7) (Fig. 1). To disconnect it from the appliance press the keys (A3) and pull the flexible hose (Fig. 2).
• Insert the batteries into the remote control handle as explained in the chapter “Replace remote control batteries”.

THE PRODUCT IS SUPPLIED WITHOUT BATTERIES.

♦ Unwind the power supply cable (1), pulling it gently, until the yellow mark on the cable is reached. Do not unwind the cable beyond the red mark.

◆ Connect the plug to a suitable power socket.

OPERATION

The appliance can operate in two modes: with or without remote control.

OPERATION WITHOUT REMOTE CONTROL

◆ Press the ON/OFF switch (10). The appliance will start to operate at maximum suction power. The ON/OFF switch (10) can be pressed by foot.

◆ To stop suction, press the On/OFF switch again(10).

◆ Press the ON/OFF switch (10). The appliance will start to operate at maximum suction power. The ON/OFF switch (10) an be pressed by foot.
◆ Using the buttons (A2D) and (A2D) it is possible to increase or decrease the suction power level. A suction indicator level lights up for every level (5B).
- By pressing the button (A2B) the appliance is adjusted to the maximum power.
- By pressing the button (A2E) the appliance is paused.
There are three power levels. We suggest minimum level for curtains, medium-low for sofas, armchairs and pillows, medium for carpets and high for floors and hard surfaces (ceramic, marble etc.).

EMPTYING AND CLEANING THE DUST CONTAINER

When the dust container (6) is full, the indicator light comes on (5D). To empty it, proceed as follows:

♦ Switch off the appliance using the ON/OFF switch (10). Disconnect the power supply cable (1) from the mains.

◆ Release the dust container from the vacuum cleaner by pulling the lever (3) (Fig. 4).

♦ Remove the dust container (6) lifting it by the handle.

◆ Press the button (6F) located on the container (6) in order to open the container and remove the dirt collected (Fig. 5).

ATTENTION: since by operating the button (6F) the lower base (6E) of the reservoir opens, it is recommended that this operation be done over a waste bin.

FORZASPIRA MC330 TURBO

◆ Remove the container cover (6A) by turning it anti-clockwise relative to the container (6D), aligning the two reference arrows (Fig. 7).
◆ Remove the container filter (6B) and pull out the filter unit (6C) and remove any remaining dirt.

N.B.: We recommend to clean the container after each use.

ATTENTION: never exceed the "MAX" level shown on the dust container (6), otherwise the filters will clog reducing the suction power of the appliance.

♦ Replace the filter unit (6C) in the container (6)
◆ Reinsert the container filter (6B).
♦ Reassemble the cover (6A) on the container (6) turning it clockwise, making sure to align the two arrows (Fig. 6).
♦ Reposition the dust container (6) on the appliance by repeating the steps described previously in the opposite order, making sure that it is well attached.

ATTENTION: do not use the appliance without the dust container (6) complete with filter.

USING ACCESSORIES

Accessories may be connected directly to the hose (A) or to the telescopic tube (B).

Using the telescopic tube (B)

The length of the telescopic tube can be adjusted. Just press the button (B1) to extend it or shorten it at will.

Parquet brush (D)

The parquet brush is designed to clean delicate surfaces; it has bristles and wheels in a special material

to avoid damaging the surfaces.

Small nozzle (F) + Bristle frame (C)

The small nozzle is recommended for cleaning upholstery surfaces such as the joints of sofas, armchairs, mattresses, car upholstery, etc.

It is possible to insert the bristle frame by sliding the guides of the frame on the base of the nozzle (Fig. 10). To remove it, proceed in the opposite order.

Lance for corners cleaning (E)

This lance is suitable for thorough cleaning of the more difficult-to-reach places, like skirting-boards, sofa gaps, armchairs, upholstered furniture, car seats.

Using the universal brush (G)

Connect the brush to the telescopic tube (B). By pressing the selector button with (G2) located on the brush with your foot, the suction surface can be changed without having to bend over. The position with bristles extended is suitable for all non-carpeted floors. The position without bristles is suitable for carpets.

Use of the Turbo-brush (I)

To clean carpets, use the turbo-brush (I) a turbine system increases effectiveness and efficiency when vacuuming fabric surfaces.

The use of the turbo-brush on carpets revives the fibres thanks to the brushing action of the roller, which opens the fibres, allowing for deep cleansing. The mechanical rotary action of the turbo brush is ideal for removing animal hair from hard surfaces, rugs and carpets, even shag carpets. The turbo brush can be used as a traditional brush on hard surfaces since it has a bypass system which diverts the air flow directly to the suction pipe.

Use: A cursor on the back of the turbo brush permits you to adapt it to any kind of surface: slide the cursor (I1) to the left for hard surfaces, and slide it to the right for carpets and fitted carpeting. The cursor adjusts the speed of the turbine system: when it is moved completely to the right, the turbine works at the maximum rotation speed, while when it is moved completely to the left there is no rotation and the brush operates as a normal floor brush.

The turbine can be easily accessed for cleaning thanks to the practical flap (Fig. 14 - 15).

Use of the Mini turbo-brush (H)

The mini turbo-brush is especially suitable for cleaning armchairs and sofas, the inside of cars, fabric-lined walls, etc.

It removes dust, dandruff, fabric residues with ease. Useful for the prevention of allergies, since it removes animal hairs by means of the mechanical action of the roller brushes.

FORZASPIRA MC330 TURBO

AUTOMATIC CABLE WINDER

Before starting the automatic cable rewind, by pressing the button (4), make sure that the power plug is disconnected from the mains electricity. We recommend following the cable during the operation.

PUTTING THE APPLIANCE AWAY

It is possible to place the appliance by resting the brush (G) or the turbo-brush (I) with the hose (B) in one of the parking slots (2) located on the appliance, as shown in Figure 9.

The small nozzle (F) and the lance (E) can be replaced in their relative storage locations (11) and (12) (Fig. 8).

CARE OF YOUR APPLIANCE

• Before attempting any maintenance operation, always disconnect the appliance from the mains.
• To clean the body of the appliance, simply use a moist cloth. Do not use solvents or detergents which may harm the body material.

CLEANING THE DUST CONTAINER

• Pull out the dirt container and remove the container filter and the filter unit, as described in the paragraph “Emptying and cleaning the dust container”.
  ◆ Rinse all the components under running water and let them dry.
  ♦ Replace everything repeating the steps described previously in the reverse order.

REMOVING AND CLEANING THE HEPA FIL - TER

♦ Turn the grill (8) anti-clockwise (Fig. 11) and remove the filter (9) (Fig. 12).
◆ Rinse the filter under cold running water.
- After washing it, shake it gently to eliminate any dirt reside and excess water.

Note: Allow the filters to dry naturally, away from direct sources of heat. It is advisable to wait 24 hours before replacing the filters in the appliance, checking that they are completely dry.

◆ To reassemble it, proceed in the opposite order.

CLEANING CAP (13)

On the bottom of the appliance there is a cap (13) for cleaning the internal hoses, created to remove any accumulation of dirt which cannot pass into the suction container. To open it, just turn the cap anti-clockwise (Fig. 14). To close it, turn the cap clockwise. (fig. 13).

FILTER MAINTENANCE

♦ Replace the filters with a new ones if they are torn.
Do not clean the filters with the brush as they can be damaged, reducing their filtering capacity.
- Do not use detergents, do not rub the filter, and do not wash it in a dishwasher.

REPLACING REMOTE

CONTROL BATTERIES

THE PRODUCT IS SUPPLIED WITHOUT BATTERIES.

In order to work, the remote control handle must be power by two 1.5V AAA batteries. The life of the batteries depends on how often it is used. If, when pressing any button on the remote control, the indicator light does not come on (A2A) and the vacuum cleaner does not respond to the remote control commands, replace the batteries.

Take the remote control handle, press the lever of the battery cover pulling it towards the remote control keypad (Fig. 3).

Remove the cover and replace the batteries making sure that the + and - marks match what is indicated. Replace the cover.

NOTE: to protect the environment, we recommend disposing of the battery in the special recycling containers, in accordance with the instructions of the manufacturer.

TROUBLESHOOTING

PROBLEM CAUSE	SOLUTION
The vacuum cleaner does not turn on	The plug of the power cable (1) is not connectedON/OFF switch (10) is turned offBatteries of the remote control handle dead.	Connect the plug of the power cable (1) to the mains socket.Turn on the ON/OFF switch (10).Replace the remote control batteries.
The vacuum cleaner does not suction	Flexible hose / telescopic tube clogged.Dust container (6) over full.Clogged internal tube.Dust container (6) not inserted correctly.	Clean the tubes.Empty the dust container (6) and clean the filters.Open the cleaning cap (13) and clean the tubes.Insert the dust container (6) correctly.
During suction from the appliance, dust comes out.	Dust container (6) not inserted correctly.Dust container (6) over full.Flexible hose (A) not inserted correctly.	Insert the dust container (6) correctly.Empty the dust container (6).Insert the flexible hose (A) correctly.

WARRANTY

WARRANTY CONDITIONS

For repairs, the appliance must be accompanied by proof of purchase.

Polti products are guaranteed to the original purchaser for two years from the date of purchase as shown on a valid receipt issued by the seller.

This guarantee does not affect the consumer's rights under European Directive 99/44/CE regarding certain aspects of the sale and guarantee of consumer goods; consumers should address claims under these provisions to the retailer where they purchased the goods.

This guarantee is effective in countries where European Directive 99/44/CE has been implemented. Local guarantee legislation applies in all other countries.

WHAT THE WARRANTY COVERS

During the guarantee period, Polti will repair products with defects in workmanship or materials at no charge to the customer for either labour or materials.

In case of irreparable defects, Polti S.p.A. may replace the product free of charge.

A minor patent defect for which it was not possible, or is excessively expensive, to repair or replace does not give the right to terminate the contract.

To have work performed under this guarantee, consumers must contact an Authorised Polti Technical Assistance Centre. The consumer must present a valid receipt issued by the seller at the time of purchase as evidence of the date of purchase; without proof of purchase and the relative date, the work will be charged. Therefore, please store your receipt carefully for the entire warranty period.

WHAT THE WARRANTY DOES NOT COVER

The warranty is subject to limitations and does not cover defects due to improper use or use other than that indicated in the instruction booklet which forms an integral part of the sales contract of the product. The warranty does not cover defects resulting from force majeure (fires, short circuits) or caused by third parties (tampering). The warranty does not cover damages caused by the use of non-original Polti parts, repairs or alterations performed by staff or service centres not authorised by Polti.

The guarantee does not cover parts that are damaged by wear or subject to normal wear (consumables such as filters, brushes, etc.). The guarantee doesn't cover any possible damage caused by limescale. Polti will accept no responsibility for any injury to people or animals or damage to objects directly or indirectly resulting from failure to follow the instructions provided in the instruction booklet, in particular the warnings and product maintenance instructions.

The warranty does not cover the assembly of accessories that have been modified or are not adapted to the appliance.

REGISTER YOUR PRODUCT

Register your appliance on our website at www.polti.com.

You will receive an email containing a promotional code and the instructions for taking advantage of the current offers.

To register your Polti product, you must enter, in addition to your personal information, the appliance serial number (SN) which you will find on the silver label, located under the product:

Example:

SERIAL NUMBER

(18 digit) SN

To save time and keep your serial number to hand, write it in the space provided on the back cover of this manual.

3D illustration of an open box with an @ symbol inside, symbolizing email or online access (no text or symbols present)

SN:

REGISTER YOUR PRODUCT

REGISTRA IL TUO PRODOTTO

ENREGISTREZ VOTRE PRODUIT

REGISTRA TU PRODUCTO

GERÄTREGISTRIERUNG

REGISTE O SEU PRODUTO

www.polti.com

22070 -Bulgarograsso (CO) - Italy
