KM 160 Minimo Premio - Coffee grinder ECG - Free user manual and instructions

Product Type	Coffee grinder
Brand	ECG
Model	KM 160 Minimo Premio
Power Source	Built-in Li-Pol battery 3.7V / 1250 mAh
Power Consumption	13 W
Coffee Bean Container Capacity	Max 25 g
Ground Coffee Container Capacity	Max 120 ml
Charging Port	USB-C (USB-A to USB-C cable included)
Recommended Charger	Output DC 5V/1A (not included)
Grind Coarseness Adjustment	Yes, by dial on bottom of middle part (clockwise finer, anticlockwise coarser)
On/Off Button	Located on top of product
Auto Shut-Off	Yes, when grinding is completed
Battery Indicator	Button color: blue = on/fully charged; red = low battery/charging
Safety Features	Do not immerse in water; do not operate upside down; keep away from children
Maintenance	Wipe with damp cloth; use included brush to clean burrs; do not immerse top part
Included Accessories	USB-A to USB-C cable, cleaning brush
Intended Use	Household indoor use only, for grinding coffee beans
Disposal	Battery and electronics must be recycled separately

Frequently Asked Questions - KM 160 Minimo Premio ECG

How do I charge the coffee grinder?

Use the included USB-A to USB-C cable to connect the grinder to a 5V/1A USB charger (not included). The charging connector is on the top of the product. While charging, the button glows red; when fully charged, it turns blue.

How long does the battery last on a full charge?

The battery capacity is 1250 mAh. The grind time per charge depends on the coarseness setting and amount of beans. Typically, it can grind several batches before needing a recharge. The button turns red when the battery is low.

How do I adjust the grind coarseness?

Turn the grind coarseness dial located on the bottom of the middle part. Turning clockwise makes the grind finer, turning anticlockwise makes it coarser.

What is the maximum capacity for coffee beans?

The bean container can hold a maximum of 25 grams of coffee beans. Do not overfill; fill to about 80% of the middle part.

Can I grind other ingredients like spices or nuts?

No, this grinder is designed only for coffee beans. Grinding other items like legumes, grains, poppy seeds, or nuts may damage the device and void the warranty.

How do I clean the coffee grinder?

First, switch off the appliance. Wipe the exterior with a damp cloth, avoiding the charging connector. Use the included cleaning brush to clean the burrs. Do not immerse the top part in water.

Why is the button glowing red?

A red button indicates either the battery is low and needs charging, or the device is currently charging. A blue button means the grinder is on or fully charged.

The grinder won't turn on. What should I do?

Check if the battery is charged (button should be blue). If not, charge it. Also ensure no foreign body is stuck between the burrs. If moisture has entered the top part, let it dry completely. If the problem persists, contact support.

Can I use the grinder while it is charging?

It is recommended to use the grinder wirelessly. While charging, the button is red and the grinder may not operate. Use only after the battery is fully charged (blue button).

Is a charger included with the grinder?

No, a charger is not included. You need a standard USB charger with 5V/1A output. The grinder comes with a USB-A to USB-C cable for charging.

USER MANUAL KM 160 Minimo Premio ECG

Black ECG air purifier device with blue circular lens and control buttons (no visible text or symbols on body)

Black and white photo of a ECG-branded vacuum cleaner with blue LED head and digital display (no visible text or symbols)

KM 150 Minimo, KM 160 Minimo Premio

English

Deutsch

Čeština

Eesti keel

Hrvatski Bosanski

Latviešu valoda

Lietuvių kalba

Magyar

Polski

Română

Slovenčina

COFFEE GRINDER

INSTRUCTION MANUAL

AUTOMATISCHE KAFFEEMÜHLE

BEDIENUNGSANLEITUNG

MLÝNEK NA KÁVU

NÁVOD K OBSLUZE

KOHVIVESKI

KASUTUSJUHEND

MLINAC ZA KAVU

UPUTE ZA UPORABU

KAFIJAS DZIRNAVIÑAS

ROKASGRĀMATA

KAVAMALÉ

NAUDOTOJO VADOVAS

KÁVÉDARÁLÓ

HASZNÁLATI ÚTMUTATÓ

MŁYNEK DO KAWY

INSTRUKCJA OBSŁUGI

APARAT DE MĂCINAT CAFEA

INSTRUCTIUNI DE UTILIZARE

MLYNČEK NA KÁVU

NÁVOD NA OBSLUHU

MLINČEK ZA KAVO

NAVODILA

MLIN ZA KAFU

UPUTSTVO ZA UPOTREBU

ΜΥΛΟΣ ΚΑΦΕ

ΕΓΧΕΙΡΙΔΙΟ ΟΔΗΓΙΩΝ

КАВОМОЛКА

English

1. charging connector
2. on/off button
   *on the Minimo Premio model, the button is located on the top of the product
3. closing lock
4. middle part
5. container for grounds
6. grind coarseness indicator
7. coffee bean container
8. USB-A - USB-C cable
9. Cleaning brush

Deutsch

Read carefully and save for future use!

Warning: The safety measures and instructions contained in this manual do not include all conditions and situations possible. The user must understand that common sense, caution and care are factors that cannot be integrated into any product. Therefore, these factors must be ensure by the user/s using and operating this appliance. We are not liable for damage caused during transportation, improper use, voltage fluctuation any change or modification of any part of the appliance. To protect against the risk of fire or electric shock, basic precautions must be take while using electrical appliances, including the following: NOTE: The charger for this appliance is not included. If you want to purchase one, the recommended parameters are: Input: 100-240 V 50/60 Hz, Output DC 5V/1A. Use only a charger with these technical parameters for charging. Li-F BATTERIES ● Built-in Li-Pol batteries are used in this

appliance. Do not attempt to replace them your sites - If a fluid leaks from the batteries, prevent contact with the eyes, mucous membranes and skin. Do not breathe in fumes. The affected area must be rinsed immediately with copious amounts of clean water. Seek a doctor in every case. DANGER of fire and explosion - Do not leave the appliance unattended when the power cord is plugged in. - Do not expose the appliance to direct sunlight, proximity heat source or fire or high temperatures. The cells could catch fire and explode. In case of fire use a specific suitable extinguisher (powder fire extinguisher ABC, CO2 or extinguisher for putting out Li-Pol batteries). NEVER USE WATER. - Store the appliance in a dry environment with low humidity, without corrosive gases, and at a safe distance from flammable materials, at a temperature ranging from 5 to 35 °C. GENERAL SAFETY INSTRUCTIONS - Use the appliance only for the purpose for which it is intended. This appliance is intended only for grinding coffee beans. Do not use it to grind, for example, legumes, grain

poppy seeds nuts, seeds etc. ● Before grind make sure that there are no foreign bodies in the beans. ● Never cover the appliance during operation. ● Never switch on the appliance when is empty, and do not remove the coffee container or motor body until it has come to a complete sto ● It is forbidden to switch on the appliance until has been fully assembled. ● Do not touch the moving parts. ● Always use the appliance on a flat, stable surface. ● Do not use equipment not recommended by the manufacturer, otherwise you run the risk of the warranty being voided. ● Only use the appliance in compliance with the direction given in these instructions. Incorrect use may result in injury or damage to the appliance. ● This appliance is intended only for home use in an indoor environment. It is not intended for commercial use. ● The manufacturer is not responsible for damage caused by incorrect use of this appliance. ● Switch off the appliance before maintenance, installation, assembly, disassembly cleaning. WARNING: do not switch on the coffee

grinder if it is upside down. DANGER FOR

CHILDREN ●Pay extra attention when using the grinder near children. ● Do not leave the grinder unattended when in operation. ● Children must not use this appliance. Keep the appliance and its lead out of the reach of children. ● The appliance may be used by persons with reduced physical, sensorial or mental capacities or lack of experience and knowledge if they are supervised or if they were instructed how to use the appliance safely a understand the potential dangers. ● Children must not play with the appliance. ● Children must not play with the packaging. Do not let children play with plastic bags. Suffocation danger.

Do not immerse in water!

BEFORE FIRST USE

Clean the coffee grinder according to the instructions in the chapter “Maintenance and Cleaning” and assemble.

USE OF PRODUCT

1. Press the start button. If the button is blue, the appliance is switched on. If the button is red, the appliance's battery is flat.
2. The grinder switches off automatically when the grinding is completed. You can switch off the grinder manually by pressing the button.
3. The connector for the charger is on the top of the product. If the appliance is charging, the button is red. If it is fully charged, the button is blue.
4. You can charge the grinder using the supplied USB-C cable.

Filling the grinder

1. Twist the top part of the grinder clockwise and separate it from the middle part.
2. Fill the middle part to the level of approximately 80% with coffee beans.
3. Connect the top and middle part, and twist them anticlockwise to the "locked" position.

Setting the grind coarseness

You can set the grind coarseness by turning the grind coarseness dial. This is on the bottom of the middle part. Turning the dial clockwise makes the grind finer. Turning it anticlockwise makes it coarser.

MAINTENANCE

1. Switch off the appliance before maintenance. Be extra careful to prevent injury caused by the burrs.
2. Wipe the outside of the coffee grinder with a damp cloth. Make sure that no water or moisture gets into the charging connector.
3. Do not immerse the top part in water.
4. Store the grinder in a dry environment.
5. Use the included brush to clean the burrs

Troubleshooting:

The appliance is not charging	1. make sure that the charging cable is correctly connected and connected to the mains
The device does not switch on	1. the device is not charged2. a foreign body has got in between the burrs3. moisture has got into the top part
The device switches off	1. fully charge the device (the button is blue)

TECHNICAL DATA

Power source – built-in Li-Pol battery 3.7V/1250 mAh

Power 13W

Coffee bean container capacity: max 25 g

Ground coffee container capacity: max 120 ml

USE AND DISPOSAL OF WASTE

Wrapping paper and corrugated paperboard – deliver to dump or paper recycling bins. Packing film, PE bags, plastic packaging or elements – dispose of in plastic recycling bins.

DISPOSAL OF PRODUCTS AT END OF LIFETIME

Disposal of electric and electronic equipment (valid in EU member countries and other European countries with an implemented recycling system)

The depicted symbol on the product or package means the product should not be treated as household waste. Hand over the product to place intended for recycling of electric and electronic equipment. Prevent negative impacts on human health and the environment by properly disposing of the product. Recycling contributes to preserving natural resources. For more information on the recycling of this product, refer to your local authority, domestic waste processing organization or store where you purchased the product. Incorrect liquidation of this type of waste can result in a fine according to the law.

The Li-Pol battery used in this appliance must not be disposed of in mixed household waste. The battery must be disposed of properly. You can get more information from battery distributors or at waste disposal sites.

This product complies with EU directive requirements on electromagnetic compatibility and electrical safety and heavy metals in electric and electronic equipment. It also meets the relevant requirements for energy performance and direct contact with food.

The instruction manual is available at website www.ecg-electro.eu.

Changes in text and technical parameters reserved.
