Product Type	Wireless Bluetooth Headphones
Bluetooth Version	BT v5.3
Operating Range	Up to 10 m
Driver Size	40 mm
Impedance	32 Ω ± 15%
Frequency Band	2.4 GHz (Bluetooth)
Sensitivity (Switchable)	85 dB / 94 dB ± 3 dB
Battery Type	Built-in rechargeable Li-ion, 3.7 V / 300 mAh
Input Voltage	DC 5 V / 300 mA
Charging Time	2 to 3 hours
Playback Time	Up to 35 hours at 50% volume
Box Contents	Headphones, USB-C charging cable, AUX cable, User Guide
Controls	Power/Play/Pause/Answer/End call (0 button), Volume +/-, Next/Previous track (hold), Mobile assistant (double-click 0)
Pairing Password	0000
Age Recommendation	Not suitable for children under 36 months; use by children 10+ with supervision
Maintenance	Wipe with soft, lint-free cloth; do not use chemicals; turn off before cleaning
Safety Precautions	Do not use damaged headphones; avoid heat/water; charge under supervision; do not use fast charger
Warranty	24 months on device; 24 months on battery, 6 months on capacity
Manufacturer	LAMAX by elem6 s.r.o.
Compliance	CE, RoHS, EU Declaration of Conformity (2014/53/EU, 2014/30/EU)

Frequently Asked Questions - Base Kid1 Lamax

How do I turn on the LAMAX Base Kid1 headphones?

To turn on, press and hold the 0 button for 2 seconds. The indicator light will flash red and blue.

How do I pair the headphones with my phone?

Turn on the headphones; they enter pairing mode automatically. Enable Bluetooth on your phone, select LAMAX BaseKid1 from the list. If prompted, enter the password 0000.

How long does the battery last and how do I charge it?

Playback time is up to 35 hours at 50% volume. Charging takes 2–3 hours via USB-C. The charging light is red while charging and turns off when fully charged.

Can I use the headphones with a cable?

Yes, you can connect the included AUX cable to the AUX IN jack for wired use. Controls (volume, playback) work the same as in Bluetooth mode.

How do I switch between 85 dB and 94 dB sensitivity?

In Bluetooth mode, press the 0 button three times quickly. With the AUX cable, use the switch on the cable. A beep confirms the change.

Is the LAMAX Base Kid1 suitable for young children?

The headphones are not suitable for children under 36 months. Children aged 10+ can use them under adult supervision. Keep small parts away from young children to avoid choking.

How do I clean the headphones?

Turn off the headphones. Use a soft, lint-free cloth to wipe the exterior. Do not use cleaning chemicals, solvents, or water.

What should I do if the headphones are damaged?

Do not use damaged headphones. Do not attempt to repair them yourself. Contact the dealer or manufacturer for service. Unauthorized repairs void the warranty.

Can I use a fast charger to charge the headphones?

No, do not use a power adapter with fast charging support. Only use the supplied USB-C cable and a standard 5V/300mA adapter or a computer USB port.

How do I activate the voice assistant?

Double-click the 0 button to activate the mobile assistant (e.g., Siri or Google Assistant). Ensure your phone is paired and the assistant is enabled.

USER MANUAL Base Kid1 Lamax

LAMAX BaseKid1 Downloads

BOX CONTENT

Headphones
USB-C charging cable
AUX cable
User Guide

DESCRIPTION

1. Button + to increase volume
2. Button 0 button to turn on/off; start/stop playback; answer/end call (in Bluetooth mode)
3. Button - to decrease volume
4. AUX IN jack
5. USB-C cable connector

OPERATION

Power on Hold the 0 button for 2 seconds.
Power off Hold the 0 button for 5 seconds.
Play/Pause Press shortly the button 0.
Increase the volume Press shortly the button +.
Decrease the volume Press shortly the button -.
Next track Hold the + button.
Previous track Hold the - button.
Answer call Press shortly the button 0.
End call Press shortly the button 0.
Reject call Hold the 0 button for 2 seconds.
Activate the mobile assistant Double click the 0 button.

PAIRING PROCESS

1. The headphones will automatically switch to pairing mode when you turn them on. The indicator light will flash alternately red and blue.
2. Turn on the Bluetooth function on your device (e.g. phone, music player, etc.) and start searching for available devices.
3. Select "LAMAX BaseKid1" from the list of searched devices and the headphones will be paired with the device. You may be prompted to enter a password, which is "0000".

After successful pairing, the indicator light will flash slowly in blue.

If the headphones do not switch to pairing mode when switched on or if you need to disconnect the headphones from the device, press and hold the + and - buttons simultaneously for 2 seconds.

CHARGING

The headphones must be fully charged before first use.

1. Plug one end of the charging cable into the socket at the bottom of the headphones. Plug the other end into your computer's USB-A port or a suitable AC adapter.
2. The charging light will turn red to indicate that the headphones are charging.
3. When the light turns off, the headphones are charged. Disconnect the charging cable.

Charging time is usually 2 to 3 hours.

When the charging light flashes during use, the headphones need to be charged.

During charging, the headphones and charging cable may become warm. This is a normal phenomenon.

Warning: Do not use a power adapter with fast charging support for charging.

MUSIC PLAYBACK

You can play music both when paired with a Bluetooth device and when you connect the audio cable to the AUX IN jack. The principle of music control is the same in both ways.

Warning: Loud listening can seriously damage your hearing and even cause hearing loss.

SENSITIVITY SWITCHING

Bluetooth mode: after turning on the headphones, press the O button three times in short succession to switch the sensitivity from 85 dB to 94 dB and vice versa. A short beep will sound to indicate the change in sensitivity.

Audio cable: after plugging in the audio cable, switch the control on the cable from 85 dB to 94 dB and vice versa. The default sensitivity is set to 85 dB.

SPECIFICATIONS

Input voltage DC 5 V / 300 mA
Built-in battery 3.7 V / 300 mA
Distance 10 m
Bluetooth version BT v5.3
Impedance 32 Ω ± 15 %
Converter size 40 mm
Charging time 2 to 3 hours
Playback time Up to 35 hours at 50% volume
Sensitivity 85 dB/ 94 dB ± 3 dB

SAFETY PRECAUTIONS

Before first use, the consumer is obliged to familiarize himself with the principles of safe use of the product.

Security precautions

Warning: Not suitable for children under 36 months.

- The headphones can be used by children aged 10 years and older and by people with reduced physical, sensory or mental capabilities or a lack of experience and knowledge, if they are supervised or have been instructed in the safe use of the appliance and understand the possible dangers.

- Children are not allowed to play with the headphones. Keep the headphones and accessories out of the reach of children. The bags or the many parts they contain can cause suffocation if swallowed or applied to the head.

- Cleaning and user maintenance must not be carried out by children.

- If the charging cable is damaged, it must be replaced by the manufacturer, its service technician or a similarly qualified person in order to avoid a hazardous situation.

- Keep the charging cable out of the reach of children so that they cannot play with it. There is a risk of strangulation.

- Do not use the headphones in highly humid or dusty environments. Never touch them with wet hands or when standing in water.

- Loud listening can seriously damage your hearing and even cause hearing loss.

- Do not use damaged headphones. If the device is damaged, do not repair it yourself!

- In case of excessive heating, immediately disconnect the headphones from the power supply.

- Charge the headphones under supervision.

- Do not place the headphones on heat sources (e.g. heaters or stoves). Keep away from them.

- Do not expose the headphones to dripping or splashing water. Do not place any containers filled with water, such as vases, on the headphones.

- Avoid contact with open flame, e.g. a burning candle.

Safety precautions when charging

- Only use the supplied charging cable for charging.

- Do not use any damaged charging cable or mains adapter.

- Charge at room temperature, never charge below 0°C or above 40°C.

- Before charging the headphones, check the parameters with the charger. The voltage data is indicated on the product casing or on its packaging.

- Leave enough space for air circulation when charging. Do not cover the headphones or the cable with papers or other objects that could impair its cooling.

- Do not place the headphones or the charging cable on or near flammable objects while charging. Pay attention to curtains, carpets, tablecloths, etc.

Caring for your device

- Proper maintenance of the headphones will ensure trouble-free operation and reduce the risk of damage.

- Keep the headphones away from extreme humidity and temperatures and do not expose the device to direct sunlight or ultraviolet radiation for a long time.

- Do not drop the headset or subject it to strong impacts.

- Do not expose the headphones to sudden and sudden changes in temperature. This could cause moisture to condense inside, which could damage the device. In the event that moisture condenses, allow them to dry completely before further use.

- Turn off the headphones before cleaning.

- Use a soft, lint-free cloth to clean the exterior surface. Do not use any cleaning or chemical preparations, solvents, thinners, etc.

- As a matter of principle, do not attempt to disassemble, repair or modify the headphones in any way. Disassembly, modification or any attempted repair will void the warranty and may result in damage or even personal injury or property damage.

- Do not store or transport flammable liquids, gases or explosive materials together with the device, its parts or accessories.

- Store the headphones in a dry and well-ventilated place.

Other information

1) For households: This marking (crossed recycle bin) indicates that this product should not be disposed with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. In case of incorrect disposal of this kind of wastes user can be fined according to national laws. User information for disposal of electric and electronic devices in countries outside the EU: The symbol stated above (crossed recycle bin) is valid only in countries in Europe—an Union. For correct disposal of electric and electronic devices ask your city hall or distributor of these devices. Everything is expressed by the symbol of crossed recycle bin on product, cover or printed materials.

2) You can determine a warranty service at the place of purchase. In case of technical problems or queries contact

your dealer who will inform you about the following procedure. Follow the rules for work with electric devices. User is not allowed to disassembly the device neither replace any of its components. To reduce the risk of electric shock, do not remove or open the cover. In case of incorrect setup and plug in of device you will expose yourself risk of electric shock.

The warranty period for the products is 24 months unless otherwise stated. The warranty does not cover damage caused by non-standard use, mechanical damage, exposure to aggressive conditions, handling contrary to the manual and normal wear and tear. The warranty period for the battery is 24 months and 6 months for its capacity. For more warranty information, go to www.elem6.com/warranty.

Neither the manufacturer, the importer nor the distributor assumes any responsibility for any damage caused by installation or misuse of the product.

EU Declaration of Conformity

elem6 s.r.o. hereby declares that LAMAX BaseKid1 is in compliance with the requirements and other relevant provisions of Directive 2014/53/EU and 2014/30/EU. The all LAMAX products are intended for sale without restrictions in Germany, the Czech Republic, Slovakia, Poland, Hungary and other EU member states. The declaration of conformity can be downloaded from www.lamax-electronics.com/support/doc

Frequency band(s) in which the radio equipment operates:

Maximum radio-frequency power transmitted in the frequency band(s) in which the radio equipment operates:

MANUFACTURER

The LAMAX® brand is a registered trademark and its products are protected by an industrial design.

All rights reserved.

Typographical errors and changes are reserved.

CE

LAMAX

ELECTRONICS

BaseKid1
