Product Type	Hi-Fi System
Brand	Blaupunkt
Model	BT03BK
Power Supply	DC 5V, 1A (via USB)
Battery	Built-in rechargeable lithium battery, 3.7V 1200mAh
Bluetooth Version	4.1 + EDR
Bluetooth Range	Up to 10 meters (no obstacles)
FM Frequency Range	87.5 – 108 MHz
Supported MicroSD Card	Up to 64GB (FAT32), MP3/WAV format
Audio Output Power	1 x 3W
Charging Time	Approximately 3 hours (with 5V/1A charger)
Playback Time	3–4 hours (depending on volume)
Standby Power Consumption	< 0.5W
Accessories Included	USB charging cable, 3.5mm audio cable
Key Features	Bluetooth audio streaming, FM radio with auto scan and presets, microSD card playback, AUX input, hands-free calling, built-in rechargeable battery
Cleaning	Unplug before cleaning. Wipe with a dry cloth. Do not use chemical solvents or spray directly on the unit.
Safety	Read all safety instructions. Do not expose to water, moisture, or heat sources. Do not open casing. Use only specified power source.
Maintenance	No user-serviceable parts inside. Refer all servicing to qualified personnel.
Environmental Conditions	Operating temperature up to 35°C. Do not dispose of with household waste; recycle electronics and batteries.
Automatic Standby	Switches to standby after 10 minutes of no audio input (ERP2 compliant).

Frequently Asked Questions - BT03BK BLAUPUNKT

How do I pair my Bluetooth device with the BT03BK?

Power on the speaker. Press and hold the play/pause button for 2 seconds to enter Bluetooth mode (blue LED flashes). On your device, enable Bluetooth and search for 'BP BT03'. Select it to pair. If prompted for a password, enter '0000'. Once paired, the blue LED becomes steady.

Why is there no sound in Bluetooth mode?

Ensure the speaker is paired and Bluetooth is enabled on your source device. Try turning off Bluetooth and re-pairing. Also, keep your device within 10 meters of the speaker. If the problem persists, check that volume is turned up on both devices.

How do I use the FM radio?

Insert the supplied 3.5mm audio cable into the AUX IN jack to use as an antenna. Power on and press the play/pause button for 2 seconds to enter FM mode. Short press the play/pause button to auto scan and save stations (up to 50 presets). Use volume +/- to select preset stations.

How do I play music from a microSD card?

Copy MP3/WAV files to a microSD card (up to 64GB). Insert the card into the slot on the rear panel. Power on and press the play/pause button for 2 seconds to enter microSD mode. Playback starts automatically. Use volume +/- to skip tracks.

How do I charge the speaker?

Use the supplied USB charging cable to connect the speaker's microUSB port to a USB charger (DC 5V, 1A or above). The red LED will light during charging and turn off when fully charged. First charge: at least 10 hours. Do not charge longer than 24 hours.

What should I do if the speaker automatically switches to standby mode?

This is normal after 10 minutes of no audio input (ERP2 standard). To resume, simply play audio again. If low volume causes it, increase the volume on your audio source. If the problem persists, contact service.

Can I use the speaker while it is charging?

Yes, the speaker can play music during charging. However, charging may take longer if the speaker is in use.

How do I reset the unit?

If the unit malfunctions due to electrostatic discharge or other issues, switch it off, disconnect the power, wait a few moments, then reconnect and power on. Alternatively, move the speaker to another location to avoid interference.

What is the maximum microSD card capacity supported?

The speaker supports microSD cards up to 64GB (FAT32 format). Only MP3 and WAV audio formats are supported. Not all cards are guaranteed to work due to brand differences.

How do I clean the speaker?

Always unplug the speaker before cleaning. Use a dry or slightly damp cloth to wipe the exterior. Do not use chemical solvents, aerosol sprays, or allow moisture to enter the openings. For the woofer, dust can be removed with a dry cloth.

USER MANUAL BT03BK BLAUPUNKT

Close-up of a black square speaker with a mesh grille (no visible text or symbols)

Enjoy it.

IMPORTANT SAFETY INSTRUCTIONS

The marking plate is located at the bottom of the apparatus.

Important Safety Instructions

Caution:

To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel.

Explanation of Graphical Symbols:

The lightning flash within an equilateral triangle is intended to alert you to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute an electric shock to a person or persons.

The exclamation point within an equilateral triangle is intended to alert you to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.

To achieve the utmost in enjoyment and performance, and in order to become familiar with its features, please read this manual carefully before attempting to operate this product. This will assure you years of trouble free performance and listening pleasure.

Important Notes

• This safety and operating instruction should be retained for future reference.
• The apparatus should not be exposed to dripping or splashing or placed in a humid atmosphere such as a bathroom.
Do not install the product in the following areas:
- Places exposed to direct sunlight or close to radiators.
On top of other stereo equipment that radiate too much heat.
○ Blocking ventilation or in a dusty area.
- Areas where there is constant vibration.
○ Humid or moist places.
• Do not place near candles or other naked flames.
• Operate the product only as instructed in this manual.
• Before turning on the power for the first time, make sure the power adaptor is properly connected.
- Plug-in the USB stick directly or use an USB-extension cable which is not longer than 25 cm.

For safety reasons, do not remove any covers or attempt to gain access to the inside of the product. Refer any servicing to qualified personnel.

Do not attempt to remove any screws, or open the casing of the unit; there are no user serviceable parts inside. Refer all servicing to qualified service personnel.

SAFETY INSTRUCTIONS

1. Read Instructions - All the safety and operating instructions must be read before

the product is operated.

1. Retain Instructions - The safety and operating instructions should be kept with the product for future reference.

2. Heed warnings - All warnings on the product and in the operating instructions should be adhered to.

3. Follow instructions - All operating and users' instructions should be followed.

4. Installation - Install in accordance with the manufacturer's instructions.

5. Power sources - This product should be operated only from the type of power source indicated by the marking adjacent to the power cord entry. If you are not sure of the type of power supply to your home, consult your product dealer or local power company.

6. Grounding or polarization - the product is not required to be grounded. Ensure that the plug is fully inserted into the wall outlet or extension cord receptacle to prevent blade or pin exposure. Some versions of the product are equipped with a power cord fitted with a polarized alternating line plug (a plug having one blade wider than the other). This plug will fit onto the power outlet only one way. This is a safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug. When using an extension power-supply cord or a power-supply cord other than that supplied with the appliance, it should be fitted with the appropriate molded plugs and carry safety approval appropriate to the country of use.

7. Power cord protection - Power-supply cords should be routed so that they are not likely to be walked on, kinked or pinched by items placed on or against them, paying particular attention to cords from plugs, receptacles and the point where they exit from the product.

8. Overloading - Do not overload wall outlets, extension cords, or multiple sockets, as this can result in a risk of fire or electric shock.

9. Ventilation - The product must be properly ventilated. Do not place the product on a bed, sofa, or other similar surface. Do not cover the product with any items such as tablecloths, newspapers, etc.

10. Heat - The product should be situated away from heat sources such as radiators, heat registers, stoves, or other products, including amplifiers that produce heat. No naked flame sources, such as lighted candles, should be placed on the apparatus.

11. Water and moisture - To reduce the risk of fire or electric shock, do not expose the product to train, dripping, splashing or excessive moisture such as in a sauna or bathroom. Do not use this product near water, for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool (or similar).

12. Object and Liquid Entry - Never push objects of any kind into this product through openings, as they may touch dangerous voltage points or short-circuit parts that could result in a fire or electric shock. Never spill liquid of any kind on the product. Do not place any object containing liquid on top of the product.

13. Cleaning - Unplug the product from the wall outlet before cleaning. Dust in the woofer may be cleaned with a dry cloth. If you wish to use an aerosol cleaning spray, do not spray directly on the cabinet; spray onto the cloth. Be careful not to damage the drive units.

14. Attachments - Do not use attachments not recommended by the product manufacturer, as they may cause hazards.

15. Accessories - Do not place this product on an unstable cart, stand, tripod, bracket or table. The product may fall, causing serious injury to a child or adult, and serious

damage to the product. Use only with a cart, stand, tripod, bracket or table recommended by the manufacturer or sold with the product. Any mounting of the product should follow the manufacturer's instructions and should use a mounting accessory recommended by the manufacturer.

1. Moving the product - A product and cart combination should be moved with care. Quick stops, excessive force and uneven surfaces may cause the product and cart combination to overturn.

2. Unused periods - The power cord of the appliance should be unplugged from the outlet during lightning storms or when the apparatus is left unused for a long period of time.

3. Servicing - Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.

4. Please remove the power plug form the main power source or wall power source when not in use. When plugged in to a power source, the system is in standby mode, so the power is not entirely cut off.

5. Replacement parts - When replacement parts are required, ensure that the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock or other hazards.

6. Mains fuses - For continued protection against fire hazard, use fuses only of the correct type and rating.

7. Do not turn up the volume while listening to a section with very low level inputs or no audio signals. If you do, the speaker may be damaged when a peak level section is suddenly played.

8. The only means of completely disconnecting the product from the power supply is by removing the power cord from the wall outlet or the product. The wall outlet or the power cord entry to the product must remain freely accessible at all times while the product is in use.

9. Try to install the product near a wall socket or extension cord and shall be easily accessible.

10. The highest environmental temperature suitable for this product is 35^ C.

11. ESD hints - If the product maybe reset or not reset to operation of control due to electrostatic discharge, just switch off and reconnect again, or move the product to another location.

28. Battery

1. The batteries must not be exposed to excessive heat such as sunshine, fire or the like.

2. The batteries should be drawn to the environmental aspects of battery disposal.

3. Battery usage CAUTION-to prevent battery leakage which may result in body injuries, property damage, or damage to the apparatus:

- Install all batteries correctly, + and - as marked on the apparatus.

- Do not mix batteries (old and new or carbon and alkaline, etc.)

- Remove batteries when the unit is not used for a long time.

ERP2 (Energy Related Products) note

This product with ecodesign complies with the stage 2 requirements of Commission Regulation (EC) NO. 1275/2008 implementing Directive 2009/125/EC regard to standby and off mode electric power consumption of electronic household and office equipment. After 10 minutes without any audio input, the device will automatically switch into

standby mode. Follow up the instruction manual to resume the operation.

Important note:

This device is equipped with an energy saving mode: if no signal is given during 10 minutes the device will switch automatically into standby mode in order to save energy (ERP 2 standard). Please note that low volume setting in the audio source may be recognized as "no audio signal": this will affect the capability of signal detection from the device and can also originate an automatic switch into standby mode. If this happens please reactivate the audio signal transmission or increase the volume setting on the audio source player (MP3 player, etc.), in order to resume playback. Please contact the local service center if the problem remains.

WARNING

This appliance is not intended for use by persons (including children) with reduced physical sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

1. Never use the device unsupervised! Switch off the device whenever you are not using it, even if this only for a short while.
2. The appliance is not intended to be operated by means of an external timer or separate remote control system.
3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
4. Before operating this system, check the voltage of this system to see if it is identical to the voltage of your local power supply.
5. The unit should not be impeded by covering the ventilation opening with items such as newspaper, table-cloths, curtains etc. Make sure that there are at least 20 cm of space above and at least 5 cm of space on each side of the unit.
6. The apparatus must not be exposed to dripping or splashing and that objects filled with liquids, such as vases, must not be placed on the apparatus.
7. To prevent fire or shock hazard, do not expose this equipment to hot places, rain, moisture or dust.
8. Do not locate this unit near any water sources e.g. taps, bathtubs, washing machines or swimming pools. Ensure that you place the unit on a dry, stable surface.
9. Do not place this unit close to a strong magnetic field.
10. Do not place the unit on a amplifier or receiver.
11. Do not place this unit in a damp area as the moisture will affect the life of electric components.
12. If the system is brought directly from a cold to a warm location, or is placed in a very damp room, moisture may condense on the lens inside the player. If this occurs, the system will not operate properly. Please leave the system turned on for about an hour until the moisture evaporates.
13. Do not attempt to clean the unit with chemical solvents as this might damage the finish. Wipe with a clean, dry or slightly damp cloth.
14. When removing the power plug from the wall outlet, always pull directly on the plug, never pull on the cord.

15. Depending on the electromagnetic waves used by a television broadcast, if a TV is turned on near this unit while it is also on, lines might appear on the TV screen.

16. Neither this unit nor the TV is malfunctioning. If you see such lines, keep this unit well away from the TV set.

17. The mains plug is used as the disconnect device, the disconnect device must remain readily operable.
18. To prevent possible hearing damage, do not listen at high volume levels for long periods.

NOTICE

Conformity

Hereby, Blaupunkt Competence Center 2N-Everpol Sp. z o.o., declares that this equipment is in compliance with the essential requirement and other relevant provisions of Directive 2014/53/EU. Declaration of conformity can be obtained from the product page at www.blaupunkt.com.

Responsible party: 2N-Everpol Sp. z o.o, Puławska 403A, 02-801 Warsaw, Poland, Phone:

[phone], E-mail: [e-mail]

Your products is designed an manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/EC. Please inform yourself about the local separate collection system for electrical and electronic products. Please cat according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the European Directive 2013/56/EU, which cannot be dispose with normal household waste. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard(box), polystyrene foam(buffer) and polyethylene (bags, protective foam sheet). Your system consists of material which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Recording and playback of material might require consent. See Copyright Act 1956 and The Performer's Protection Acts 1958 to 1972.

Bluetooth™

The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by us is under license. Other trademarks and trade names are those of their respective owners.

Many thanks to buy our product. This model includes below main features.

1. Bluetooth function for audio streaming playback.
2. PLL FM radio with station memory.
3. MicroSD card playback (max supported device up to 64GB).
4. Aux in.
5. Built-in rechargeable battery power.

Location of controls:

1. Play/pause button

a. Long press it 2 seconds to switch the play mode between Bluetooth/FM/microSD and AUX IN mode.
b. In Bluetooth and microSD card playback mode, short press it to play pause or resume music playback.
c. In FM radio mode, short press it to scan and save the available station automatically.

2,3.Volume +/- button

a. Press and hold it to adjust the output volume level.
b. In Bluetooth and microSD card playback mode, short press it to skip the playback track.
c. In FM radio mode, short press it to pick up the preset station.

4. LED Indicator and microphone hole.

a) Blue color: Bluetooth mode.
b) Flare red color: microSD card playback mode.
c) Steady red color: FM radio mode or AUX in mode.

5. Power on/off switch.

6. AUX IN jack.

1. MicroUSB DC 5V power jack and charging LED indicator.

2. microSD card slot.

Battery charging

This unit had built-in rechargeable lithium battery inside. Before start the playing, please follow up below step for charging.

1. Using the supplied USB to microUSB type charging cable connects the speaker with your USB charger (USB adaptor or USB output port
   like on PC, USB rating output: 5V/1A, other USB charger with current equal or above 1A). The microUSB connector should connect with the

DC 5V power jack on the rear panel of speaker, and the another terminal connect with USB charger. Then plug your USB charger into the

household AC power.

1. The charging LED will light on in red color during charging, and the red color LED will off when the battery is fully charged.

2. The speaker will off automatically when the battery power exhausted, please arrange recharge for playing.

Important: We recommend connect the USB charger with rating output spec at DC 5V/1A, or equal or above 1A output current USB power. The general USB output on PC (personal computer) is 5V/1A (please reference your PC spec for checking). There may have some charging noise or abnormal function from speaker if the charging current is too low. If it happened, please remove the charging power and put the speaker in a while, then the speaker will reset the function in normal. Please kindly note this is not malfunction.

Notes:

Your battery lifetime will last longer if you follow up below simple guidelines for charging and storing.

a. For charging first time, charge it at least 10 hours.
b. Recharge and store the unit within the temperature range of 5°C\~35°C (40°F\~95°F).
c. Do not charge longer than 24 hours. Excessive charging or discharging may shorten the battery's life.

d. Battery life naturally shortens slowly over time.

e. Please turn off the speaker if long time not to use.

f. The speaker can play music during charging.

g.Due to prolong charging and discharging, the unit battery life will be affected and playback time will also be shortened. We cannot gua

Bluetooth operation

The speaker includes Bluetooth function which allows you to wireless playback the audio with other Bluetooth device like smart phone etc. Please follow up below for the operation.

1. Push the power on/off switch to power on the unit, press play/pause button 2 seconds to switch the play source and enter to the Bluetooth mode. The blue color LED will flare which means the speaker is ready to pair with other device.
2. Enable the Bluetooth function on your Bluetooth device, and search the available Bluetooth device( please reference your device manual for the operation).
3. Check the available Bluetooth device on the menu list of your device, and select "BP BT03" in order to start pairing. Please key-in "0000" (4 zero) in case of a POP password required during pairing. The blue LED will become stable when the pairing is successful.
4. Select and play the music on your Bluetooth device. Then the sound will output from speaker.
5. During Bluetooth playback, you can short press the play/pause button to play or pause the music; short press the volume +/- button to select last or next track; press and hold volume +/- button to decrease or increase the volume.

Phone call hands free: when the cell phone was paired with speaker in Bluetooth mode, and an incoming call is arriving; short press the play/pause button can pick up the call; answer the phone call and talk aim to the microphone hole within 30cm(suggested distance) in order get better conversation sound quality; short press the play/pause button again can end the phone call and resume the music playback.

Notes:

a. All Bluetooth devices are not guaranteed to pair successfully due to different design and brand.
b. Please do not put your cell phone very close to the speaker during phone call hands free conversation, in order to avoid interference which will impact the conversation sound quality.
c. The Bluetooth best working distance is within 10 meters without any obstacle in between.
d. The speaker can broadcast the incoming phone call number smartly in Bluetooth mode.
e. In case the speaker does not pair with other device successfully and no further operation, the speaker auto off after about 10 minutes, please power on the unit again for operation.

FM radio operation

Before listen to the radio, please try to move the unit next to the window as you can, and insert the supplied 3.5mm to 3.5mm stereo audio cable into the AUX IN jack as an external antenna in order to get better reception.

1. Power on the unit, press the play/pause button 2 seconds to switch and enter FM radio mode.
2. Short press the play/pause button to auto scan and save the available FM station( max support up to 50 preset station ); short press the volume +/- button to select the last or next preset station; press and hold the volume +/- button to decrease or increase the volume.

TF/MicroSD card playback

Please copy the MP3 format music into the TF or MicroSD card device (max supported 64GB) before start the playing, and then insert the card into the slot on the rear panel of unit. Power on the unit, press the play/pause button 2 seconds to switch and enter the MicroSD playback mode; the speaker will read out the card device automatically, and get the music output after few seconds.

In TF/MicroSD card playback mode, short press the volume+/- button to select the last or next track; press and hold the volume +/- button to decrease or increase the volume. Short press the play/pause button to play or pause the music.

Notes:

a. The TF/MicroSD card playback mode is only available when there have card device installed on the speaker successfully.
b. The supported audio format is MP3/WAV in TF/MicroSD playback mode, but not guarantee all mentioned audio file.
c. Not all TF/MicroSD card devices are supported due to different design and brand, the max supported storage is 64GB.
d. Please kindly insert the TF or MicroSD card into the slot properly.

AUX IN/ MP3 link mode

Using the supplied 3.5mm to 3.5mm stereo audio cable connect the AUX jack on the speaker rear panel with the line out or headphone jack on any other external audio player like mp3 player etc. Power on the speaker, press the play/pause button 2 seconds to switch and enter the AUX IN playback mode; select and play the music from your external audio player, then the sound will output from the speaker.

Notes:

a. In AUX IN mode, the main control is on your external audio player side. But you still can increase or decrease the volume on the speaker side.
b. Please kindly note the AUX in mode is only available when the audio cable was plugged in. The unit will switch to AUX IN mode automatically when you connect it with audio cable.

Specification:

Power source: DC5V, 1A; (or DC 5V, rating current above 1A) Bluetooth version: 4.1 +EDR, best working distance within 10 meters FM Frequency: 87.5\~108.00MHz TF/MicroSD card supported device till to 64GB max, support audio format MP3/WAV Rated power: 1 x 3W Battery power: 3.7V/1200 mAH rechargeable lithium battery Charging time: approximately 3 hours base on DC5V, 1A input. Music playback time: 3\~4 hours around. Power consumption: 3 Watt Standby power consumption: < 0.5Watt Accessory: 1 pcs x USB charging cable, 1 pcs x 3.5mm to 3.5mm audio cable (The above spec may revise without prior notice)

Trouble shooting

1. The unit cannot power on.

a. Please charge the unit and try again.
b. Please contact the service center in case of issue remains.

1. There is no or intermittent sound output in Bluetooth mode.

a. Please turn off the Bluetooth, and repair with the speaker.
b. Please put your Bluetooth device closer with the speaker.

1. No available FM station or background noise in FM.

a. Please plug on the 3.5mm stereo audio cable and re-scan the available FM station.
b. Please tune to another FM station for listening.
c.Please try to move the unit next to the window in order to get better reception.

1. The speaker cannot read out the music in TF or microSD card.

a. Please check if you insert the TF or microSD card into the slot properly.
b. Please check if the audio format is in MP3/WAV.

WAŻNE INSTRUKCJE DOTYCZĄCE BEZPIECZEŃSTWA

PRZESTROGA

ZAGROŻENIE PORAŻENIEM ELEKTRYCZNYM NIE OTWIERAĆ

1. Przycisk odtwarzania / pauzy

DÔLEŽITÉ BEZPEČNOSTNÉ POKYNY

VAŽNE SIGURNOSNE UPUTE

UGROŽENJE OD ELEKTRIČNOG

UDARA NEMOJTE OTVARATI

Važne sigurnosne upute

Oprez:

Kako bi se smanjila opasnost od električnog udara, nemojte skidati poklopac niti stražnj dio uređaja. Unutar uređaja ne postoje komponente za popravak od strane korisnika. Održavanje i popravak opreme izvršava isključivo kvalificirano servisno osoblje.

Objašnjenje grafičkih simbola:

Simbol munje sa sa strelicom koji se nalazi u jednakostraničnom trokutu upozorava na prisutnost neizoliranog „opasnog napona“ unutar kućišta uređaja koja može postići veličinu uzrokujuću strujni udar.

Uskličnik unutar jednakostraničnog trokuta upozorava korisnika da ovdje su prezentirane važne poruke za rad i održavanje opreme u dokumentaciji priloženoj uređaju.

1. Esituse / pausi nupp

02-801 Warsaw, Poland

phone: [phone]

e-mail: [e-mail]

www.blaupunkt.com

In case of questions or problems

please contact our service.

Tel. [phone]

E-mail: [e-mail]

All rights reserved. All brand names are registered trademarks of their

respective owners. Specifications are subject to change without prior notice.
