Bamba SkinCare Depil-Action - Epilator CECOTEC - Free user manual and instructions

USER MANUAL Bamba SkinCare Depil-Action CECOTEC

White bamboo hair dryer with a circular button and beige filter, labeled 'BAMBA' (no additional text or symbols visible)

Safety instructions 9

1. Parts and components 39

2. Before use 39

3. Operation 39

4. Cleaning and Maintenance 43

5. Technical specifications 44

6. Disposal of old electrical appliances 44

7. Technical support and warranty 45

8. Copyright 50

SOMMAIRE

Read these instructions thoroughly before using the appliance. Keep this instruction manual for future reference or new users.

• Make sure that the mains voltage matches the voltage stated on the rating label of the appliance and that the wall outlet is grounded.
• This product is designed only for household use. Do not use for industrial or commercial purposes.
• For hygienic reasons, do not share this appliance with other people.

ENGLISH

• CAUTION: Do not use this appliance near bathtubs, showers, washbasins or other vessels containing water.
• Do not immerse the cord, plug, or any non-removable part of the appliance in water or any other liquid, nor expose electrical connections to water. Make sure your hands are completely dry before handling the plug or switching on the appliance.
• When switched on, the appliance must never come in contact with the hair on your head, eyelashes, ribbons, etc. to prevent any danger of injury as well as to prevent blockage or damage to the appliance. This appliance is provided with an

ENGLISH

integrated Safety Extra Low Voltage power supply.

- Do not exchange or manipulate any part of it. Otherwise there is risk of electric shock.

- Do not expose the device to temperatures below 5 °C or above 35 °C.

- People with reduced immunological response or that suffer from diabetes mellitus, haemophilia or immunodeficiency must consult their doctor before using the device.

- Use the device only for hair removal and following the instructions in this manual.

- Do not remove hair from areas with open wounds, cuts, burns, warts, moles, sun

ENGLISH

burnt skin or varicose veins.

• Do not use the device if you are suffering from a skin irritation, skin infections like psoriasis or eczema.
• Do not use the device for removing hair from your face, head, chest, eyebrows or eyelashes.
• This product may not be used by children under 8 years of age or by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge. Supervise young children to make sure that they do not play with the appliance. Use it only to remove hair from legs, arms, underarms and bikini line.

ENGLISH

- This appliance can be used by children aged 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children must not play with the appliance. Cleaning and user maintenance must not be carried out by unsupervised children.

SKINCARE DEPIL-ACTION

FRANÇAIS

INSTRUCTIONS DE SÉCURITÉ

1. Charger plug
2. Removable head (18 tweezers)
3. Shaving head
4. 2-speed switch
5. DC adapter
6. Overload protection
7. Indicator light
8. Protection cover
9. Cleaning brush

2. BEFORE USE

• Take the product out of the box.
• Remove all packaging material. Save the original box.
• Make sure all parts and components are included and in good conditions. If any visible signs of damage are observed, contact the Cecotec official Technical Support Service immediately.

3. OPERATION

Hair removal

- The electric epilator includes 18 tweezers that remove hair. For perfect efficiency, it is recommended to use it on fairly

SKINCARE DEPIL-ACTION

ENGLISH

short hair (2-5 mm).

• Before removing hair, take a warm shower. Warmth will help your pores dilate and thereby ease removal of the hair.
• To remove hair successfully, look closely at the direction in which hair grows in the area where hair is to be removed. Move the electric epilator in the direction opposite to that of the hair growth.

Note

If the device is moved in the same direction as the hair growth, hair could be simply cut or improperly pulled, causing it to grow back under the skin.

Warning

All methods of hair removal at the root can lead to ingrown hair and irritation (e.g. itching, discomfort and reddening of the skin) depending on the condition of the skin and hair. This is a normal reaction and should quickly disappear, but may be stronger when you are removing hair at the root for the first few times or if you have sensitive skin.

How to use the electric epilator

1. Connect the cord to the power supply and then to the device.
2. Fully charge the device.
3. Remove the protection cover.
4. Turn the device on and select speed:

ENGLISH

I: Fine hair
II: Thick hair
5. Hold the appliance at an angle of 90^ to the surface where hair is to be removed.

Fig. 2

Arms and legs

• Always work with both hands. Carefully stretch the skin with one hand while moving the appliance with the other.
• Only move your electric epilator against the direction of the growth of your hair. Do not use circular or back-and-forth motions.

- Slowly move the electric epilator, while pressing down lightly. Do not press the appliance down too hard against your skin; it might slow down and be less effective.

Underarms and bikini line

Recommendation

This zone is especially sensible, therefore it is recommended to use speed l.

• If hair is long (longer than 1 cm), it is suggested to cut it before using the device, preferably at speed l.
• Before operating the device in this area, clean it thoroughly to remove any residual remain such as deodorant. Once it is

ENGLISH

clean, dry it with a towel.

• Move the appliance using an upwards motion.
• After hair removal, use a moisturising milk to soften skin.

Apply the product and massage it in circular motions to help the skin absorb it.

Shaving head

Use this head to shave hair from sensible zones.

Indicator light

Red - Charging | Green - Charged | Red and green alternately- Low voltage

Overload protection

The electric epilator includes a protection system that will turn it automatically off to prevent risk of damage or danger.

Tips

Scrubbing is a necessary step for successful hair removal. Done regularly, it:

• Prevents hair from growing back under the skin.
• Removes dead cells and refines the texture of your skin.
• Prepares your skin to help it absorb skin care products.
• Scrubbing done once or twice a week maintains a healthy and fresh skin.

It is suggested to scrub skin ideally the day before hair removal. The scrubbing will straighten the hair thereby helping you to remove it.

ENGLISH

Warning

Avoid scrubbing just after hair removal.

4. CLEANING AND MAINTENANCE

Fig. 3

• Turn off and disconnect the device from the mains supply before cleaning, maintaining it or assembling or disassembling any of its parts.
• Pull out the head cover by hand.

• Do not use compressed air, abrasive cleaners or scouring pads to clean the product.

• Do not immerse the appliance in water or any other liquid or place it under running water.

• Press both buttons on the sides and pull the epilation head out with the other hand.
• Use the cleaning brush dipped into alcohol to clean the tweezers. Clean the tweezers with the brush from the rear side of the epilation head while turning the barrel manually.
• It is recommended to regularly disinfect the heads with alcohol.
• After cleaning, place the protection cover and epilation head back on the appliance.
• Use a soft damp cloth with some water to clean the product's surface.
• Dry thoroughly the device with tissue paper after cleaning it.

ENGLISH

5. TECHNICAL SPECIFICATIONS

Product: Bamba SkinCare Depil-action

Product reference: 04334

Charger: Input: 100 V-240 V \~, 50 Hz/60 Hz

Output: 4.5 V DC, 1000 mA, 4.5 W

Epilator: Input: 4,5 V DC, 1000 mA

Battery: 3.7 V, 700 mAh, 2.59 Wh

Made in China | Designed in Spain

6. DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE) specifies that old household electrical appliances must not be disposed of with the normal unsorted municipal waste. Old appliances must be collected separately, in

order to optimise the recovery and recycling of the materials they contain and reduce the impact on human health and the environment.

The crossed out "wheeled bin" symbol on the product reminds you of your obligation to dispose of the appliance correctly.

ENGLISH

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

7. TECHNICAL SUPPORT AND WARRANTY

This product is under warranty for 2 years from the date of purchase, as long as the proof of purchase is submitted, the product is in perfect physical condition, and it has been given proper use, as explained in this instruction manual.

The warranty will not cover the following situations:

- The product has been used for purposes other than those intended for it, misused, beaten, exposed to moisture,

immersed in liquid or corrosive substances, as well as any other fault attributable to the customer.

• The product has been disassembled, modified, or repaired by persons, not authorised by the Cecotec official Technical Support Service.
• Faults deriving from the normal wear and tear of its parts, due to use.

The warranty service covers every manufacturing defect of your appliance for 2 years, based on current legislation, except consumable parts. In the event of misuse, the warranty will not apply.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact Cecotec official Technical Support Service at [phone].

ENGLISH

Information requirement for external power supplies
Information published Value	and precision Unit Notes
Manufacturer's name or trademark, commercial registration number and address	E-TEK Electronics Manufactory Co. LTD. B, 3 Bldg, Tangwupu Industrial Park, Yanchuan, Songgang Subdistrict, Bao'an District, 518105, Shenzhen, Guangdong, China	---
Model identifier ZDJ0451006	U --- --

ENGLISH

Input voltage	100-240	V	Specified by the manufacturer. Shall be a value or a range.
Input AC frequency	50-60	Hz	Specified by the manufacturer. Shall be a value or a range.
Output voltage 4.5 V Nameplate output voltage. Shall indicate w	indicate w	whether is AC or DC.In cases where more than one physical output or more than one output voltage at load condition 1 are measured, the sets of available Output voltage — Output current – Output power shall be published.
Output current 1.0 A Nameplate output current. In cases where m	more than one physicaloutput or more than one output voltage at load condition 1 are measured, the sets of available Output voltage — Output current – Output power shall be published.

ENGLISH

Output power 4.5 W Nameplate output power.		In cases where more than one physical output or more than one output voltage at load condition 1 are measured, the sets of available Output voltage — Output current – Output power shall be published.
Average active efficiency 77.68 (for 115V, 60 Hz); 76.28 (for 230 V, 50 Hz)	% Declared by the manufacturer based on the value calculated as arithmetical mean of efficiency at load conditions 1-4. In cases where multiple average active efficiencies are declared for multiple output voltages available at load condition 1, the value published shall be the average active efficiency declared for the lowest output voltage.

ENGLISH

Efficiency at low load (10 %)	-- % Declared by the manufacturer	based on the value calculated at load condition 5.External power supplies with a nameplate output power of 10 W or less shall be exempted from this requirement.In cases where multiple average active efficiencies are declared for multiple output voltages available at load condition 1, the value published shall be the value declared for the lowest output voltage.
No-load power consumption	0.05 (for 115V, 60 Hz);0.07 (for 230V, 50 Hz)	W Declared by the manufacturer based on the value measured for load condition 6.

ENGLISH

8. COPYRIGHT

The intellectual property rights over the texts, designs, photographs and illustrations in this manual belong to CECOTEC INNOVACIONES, S.L. All rights reserved. The contents of this publication may not, in whole or in part, be reproduced, stored in a retrieval system, transmitted or distributed by any means (electronic, mechanical, photocopying, recording or similar) without the prior authorization of CECOTEC INNOVACIONES, S.L.
