USER MANUAL PPEKS 2500 B2 PARKSIDE

Black-and-white photo of a chainsaw with visible teeth and metal blades (no text or symbols)

Translation of the original instructions

NL BE

Elektrische kettingzaag

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

FR BE

Service-Center....24

Importeur.... 24

Two technical diagrams showing mechanical components and a tool interacting with a surface (no text or symbols present)

Scope of delivery/accessories......27

Overview.... 27

Description of functions....27

Technical data....27

Safety information....28

Meaning of the safety information...... 28

Pictograms and symbols.... 28

General Power Tool Safety

Warnings....29

Safety information for chainsaws...... 31

Additional safety instructions....31

Causes and Operator Prevention of Kickback.... 32

Residual risks....32

Preparation....33

Safety devices....33

Operation.... 33

Before operation.... 33

Switching on and off....34

Sawing techniques....34

Cleaning, maintenance and storage..... 36

Cleaning....37

Maintenance.... 37

Storage.... 40

Transport......41

Troubleshooting.... 41

Disposal/environmental protection......42

Service.... 42

Guarantee.... 42

Repair service.... 43

Service Centre.... 43

Importer.... 43

Spare parts and accessories.... 44

Translation of the original EU declaration of conformity.... 45

Exploded view.... 243

Introduction

Congratulations on purchasing your new electric chainsaw (hereafter referred to as device or power tool).

You have chosen a high-quality device. This device was quality-tested and subjected to a final inspection during production, therefore ensuring proper functioning of your device.

In some cases, residual amounts of lubricants may be present on or in the device. This is not a flaw or a defect and is no cause for concern.

The instruction manual forms part of this device. It contains important information on safety, use and disposal. Read the instruction manual carefully. Familiarise yourself with the controls and how to use the device correctly. Use the device only as described and for the stated fields of application. Store the instruction manual carefully and ensure that all documents are handed over in the event that the device is passed on to another user.

Proper use

This device is only intended for the following use:

- Sawing wood

The device is not intended for any other types of application. This typically includes cutting masonry, plastic, stone, metal, food or wood containing foreign objects (e.g. nails or screws).

The device is intended for use by adults.

Children under the age of 16 may not use the device, except under supervision.

The chainsaw may only be used by one person. The user must wear appropriate personal protective equipment (PPE). The chainsaw must be held with the right hand on the rear handgrip and the left hand on the front handgrip.

Before using the device, the user must read and understand all information and instructions in the instruction manual.

Any other use that is not expressly permitted in this instruction manual may pose a serious hazard to the user and result in damage to the device. The operator or user of the machine is responsible for any accidents or personal injury and/or material damage to third parties or their property. The machine is intended to be used by do-it-yourselfers. It was not designed for heavy commercial use.

The warranty is void in the case of commercial use. The manufacturer is not liable for damage caused by improper use or incorrect operation.

Scope of delivery/accessories

Unpack the device and check that everything is present.

Dispose of the packaging material properly.

• Electric Chainsaw
- Blade bar (pre-assembled)
- Saw chain (pre-assembled)
- Chain guard
- Carrier bag
- Oil bottle (130 ml Organic saw chain oil)
- Original instructions

Overview

The illustrations for the device can be found on the front and back fold-out page.

Fig. A

1 Rear handle
2 Chain brake lever/Front hand protection
3 Blade bar
4 Saw chain
5 Sprocket nose
6 Chain catcher (not visible)
7 Wing nut (Sprocket cover)
8 Chain tensioner screw
9 Sprocket cover
10 Cover (Carbon brush)
11 Rear hand protection
12 Strain relief
13 Power cord
14 Tank cover (Chain oil)
15 Front handle
16 Switch lock
17 On/Off switch
18 Sight line/Felling direction indicator
19 Minimum mark "MIN" (Oil level indicator)
20 Oil level indicator
21 Chain catch
22 Keyhole
23 Chain guard
24 Oil bottle
25 Carrier bag

Fig. B

26 Oil passage

27 Blade bar bolt

28 Sprocket

29 Lug

30 Chain tensioner pin

31 Receptacle (Chain tensioner pin)

Fig. D

32 Carbon brush

33 Holder (Carbon brush)

Description of functions

The chainsaw is powered by an electric motor.

The circulating saw chain is guided over a blade bar (guide rail). The chainsaw is equipped with a quick-stop chain brake.

An automatic oil system ensures continuous chain lubrication. The chainsaw is also equipped with a chain quick-tensioning system. The device is provided with various protective devices to protect the user.

Please refer to the descriptions below for information on how the operating elements work.

Technical data

Electric Chainsaw ......PPEKS 2500 B2

Rated voltage U ....230-240 V\~, 50 Hz

Rated input power P ....2500 W

Protection class ...... □ II (double insulation)

Protection type ......IPX0

Chain speed v0 16 m/s

Weight

– with blade bar and saw chain .... 5.5 kg

- without blade bar and saw chain ..... 4.7 kg

Tank capacity 130 cm ^4

Saw chain ....Kangxin ALP-50-62S

-Chain pitch 9.53 mm (0.375")

-Number of driving elements ......62

-Drive link thickness 1.3 mm

Blade bar ...... Kangxin 18" AP18-62-507P

-Blade bar type ....18"

-Blade bar length ....50 cm (500 mm)

-Cutting length ....45 cm (450 mm)

Chain sprocket pitch ..... 9.53 mm (0.375")

-Number of teeth (chain sprocket) 6

Sound pressure level ( L_pA ). 94 dB; K_pA=3 dB

Sound power level ( L_WA )

– Guaranteed ....109 dB

- Measured ....106.9 dB; K_WA=2.35 dB

Vibration ( a_h ) ..... 5.53 m/s ^2 ; K=1.5 m/s ^2

Notes on noise and vibration values

Levels of noise and vibration were determined according to the standards and regulations in the declaration of conformity.

⚠️ CAUTION! Hearing damage! Wear ear protection.

The specified total vibration values and the stated noise emission values have been measured according to a standardised test method and can be used to compare one power tool with another. The specified total vibration values and the stated specified noise emission values can also be used for a provisional assessment of the load.

WARNING! The vibration and noise emissions may deviate from the specified value during actual use of the power tool, depending on how the power tool is being used and, in particular, what kind of material is being worked on. Safety measures for protection of the operator are to be determined that are based on an estimate of the vibration load under the real operating conditions. All parts of the operating cycle have to be considered while doing so – for example, times when the power tool is switched off and times when it is switched on but running without any load.

Safety information

This section deals with the basic safety instructions for using the device.

⚠ WARNING! A chainsaw is a dangerous piece of equipment that can cause serious or even fatal injuries if used incorrectly or carelessly. Therefore, for your safety and the safety of others, always observe the following safety instructions and ask an expert for advice if you are unsure.

Meaning of the safety information

⚠️ DANGER! If you do not observe this safety instruction, an accident will occur. The result of which is severe bodily injury or death.

⚠ WARNING! If you do not observe this safety instruction, an accident may occur.

The result of which is likely severe bodily injury or death.

⚠️ CAUTION! If you do not observe this safety instruction, an accident will occur. The result of which is likely minor or moderate bodily injury.

NOTICE! If you do not observe this safety instruction, an accident will occur. The result of which is possible damage to property.

Pictograms and symbols

Symbols on the device

NOTICE! Familiarise yourself with all operating elements before starting work. Practise using the chainsaw and have an expert explain the function, mode of operation and sawing techniques to you.

NOTICE! The saw chain does not rotate when the chain brake is locked into place. Release the chain brake by pulling the chain brake lever towards the front handle.

Attention!

Read the instruction manual

Use hearing protection

Use eye protection

Use head protection

Use protective gloves

Wear safety shoes with firm soles!

Wear protective clothing

Always work with both hands!

Use of the device in the rain or a damp environment is prohibited.

Attention! Kickback - be aware that you may experience kickback while working with the machine.

Pull out mains plug immediately, if the mains cable is damaged, entangled or severed.

Guaranteed sound power level LWA in dB(A)

Minimum mark "MIN" on oil level indicator

Saw chain oiling

AUTO STOP

Chain brake

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

Protection class II (double insulation)

Blade bar type

Graphical symbol beneath sprocket cover

Observe direction of travel of the saw chain. Attention! Read the instruction manual.

Graphical symbol on sprocket cover

Direction of travel of saw chain

Graphical symbol on blade bar

Blade bar type

Groove width

Chain pitch

Number of driving elements

Graphical symbol on chain brake lever

Chain brake activated

Chain brake deactivated

Graphical symbol on mounting screw of sprocket cover

OPEN

CLOSE

Symbol on screw for chain quick-tensioning system

loosen

tighten

Symbol on the oil bottle

Keep out of reach of children

General Power Tool Safety Warnings

⚠ WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference.

The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.

1. WORK AREA SAFETY

a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose control.

2. ELECTRICAL SAFETY

a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Un-

modified plugs and matching outlets will reduce risk of electric shock.

b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

3. PERSONAL SAFETY

a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating

part of the power tool may result in personal injury.

e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

4. POWER TOOL USE AND CARE

a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may affect the power tool's operation. If damaged, have the power tool repaired be-

fore use. Many accidents are caused by poorly maintained power tools.

f) Keep cutting tools sharp and clean.

Properly maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.

g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different from those intended could result in a hazardous situation.

h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.

1. SERVICE

a) Have your power tool serviced by a qualified repair person using only identical replacement parts. This will ensure that the safety of the power tool is maintained.

Safety information for chainsaws

a) When in operation, keep all body parts away from the saw chain. Before you start the saw, ensure that the saw chain is not touching anything. When using a chainsaw, losing concentration for just a moment can lead to clothing or body parts being caught up in the saw chain.

b) Always hold the chainsaw with your right hand on the rear grip and left hand on the front grip. Holding the chainsaw the other way around increases the risk of injuries and is not permitted.

c) Hold the chainsaw only by the insulated gripping surfaces, as the saw chain may come into contact with concealed power lines. Contact with a live wire by the saw chain can also cause a charge in metal parts of the device and result in an electric shock.

d) Wear eye protection. Further protective equipment for the ears, head, hands, legs and feet is recommended.

Appropriate protective clothing reduces the risk of injury from flying chip material and accidental contact with the saw chain.

e) Do not use the chainsaw to work from trees, ladders, a roof or other unstable surfaces. Operating the device in such a way poses a serious risk of injury.

f) Ensure you are standing firmly and only use the chainsaw if the ground beneath you is solid, secure and even. Slippery ground or unstable surfaces can lead to loss of balance or loss of control over the chainsaw.

g) If working on a branch under tension, be aware that it will spring back. Once the tension in the wood fibres has been released, the branch may hit the user and/or control over the chainsaw may be lost.

h) Be particularly careful when cutting brushwood and young trees. The thin material may become caught in the saw chain and hit you or cause you to lose balance.

i) Carry the chainsaw by the front grip when it is switched off with the saw chain pointing away from your body. Always place the protective cover onto the chainsaw when transporting or storing it. Careful handling of the chainsaw reduces the probability of accidentally coming into contact with the running saw chain.

j) Observe instructions for lubrication, chain tensioning and replacing the guide rail and chain. An improperly tensioned or lubricated chain may rip apart or increase the risk of kickback.

k) Only saw wood. Do not use the chainsaw for work for which it is not intended. Example: Do not use the chainsaw to saw through metal, plastic, masonry or construction materials not made from wood. Use of the chainsaw for unintended applications can lead to hazardous situations.

I) Do not attempt to fell a tree until you have a clear understanding of the risks and how to avoid them. The user or other persons can be seriously injured by a falling tree.

Additional safety instructions

- ⚠ WARNING! During operation, this power tool produces an electromagnetic field. Under certain circumstances, this field may negatively affect active or pass-

ive medical implants. In order to reduce the danger of serious or fatal injuries, we recommend that individuals who wear medical implants should consult their doctor and the manufacturer of the implant before operating the machine.

• Lay the power cord so that it is not caught by branches or similar during sawing.
• Use a residual current device (RCD) with a rated residual current of 30 mA or less.
• Only use approved mains cables of the type H07RN-Fwhich at most 75 m long and intended for outdoor use. The wire cross section of the mains cable must be at least 2.5 mm ^2 . Always roll out the cable drum completely before use. Check the mains cable for damages.
• Follow the maintenance, control and service instructions in this instruction manual carefully. Damaged safety equipment and parts must be repaired or replaced professionally by our service centre, unless otherwise indicated in the instruction manual.
• Do not use the chainsaw without lubrication. Only use recommended lubricants for this purpose.
• Practise cutting logs on a sawhorse or frame if you are a first-time user.
• If the cord of the power tool is damaged, it must be replaced with a specially prepared cord, which is available from the customer service organisation.
• If the cord needs to be replaced, we recommend that this be done by the manufacturer or their representative (e.g. authorised specialist workshop, customer service, etc.).

Causes and Operator Prevention of Kickback

Two diagrams showing a mechanical component (a) and a lever mechanism (b), both without any text or symbols.

- Kickback may occur when the nose or tip of the guide bar touches an object, or when the wood closes in and pinches the saw chain in the cut (Fig. b).

• Tip contact in some cases may cause a sudden reverse reaction, kicking the guide bar up and back towards the operator (Fig. a).
• Pinching the saw chain along the top of the guide bar may push the guide bar rapidly back towards the operator.
• Either of these reactions may cause you to lose control of the saw which could result in serious personal injury. Do not rely exclusively upon the safety devices built into your saw. As a chain saw user, you should take several steps to keep your cutting jobs free from accident or injury.

Kickback is the result of chain saw misuse and/or incorrect operating procedures or conditions and can be avoided by taking proper precautions as given below:

• Maintain a firm grip, with thumbs and fingers encircling the chain saw handles, with both hands on the saw and position your body and arm to allow you to resist kickback forces. Kickback forces can be controlled by the operator, if proper precautions are taken. Do not let go of the chain saw.
• Do not overreach and do not cut above shoulder height. This helps prevent unintended tip contact and enables better control of the chain saw in unexpected situations.
• Only use replacement guide bars and saw chains specified by the manufacturer. Incorrect replacement guide bars and saw chains may cause chain breakage and/or kickback.
• Follow the manufacturer's sharpening and maintenance instructions for the saw chain. Decreasing the depth gauge height can lead to increased kickback.

Residual risks

There will always be residual risks even if you operate this device according to the instructions. The following hazards may occur in connection with the type and design of this device:

• Hearing damage if suitable ear protection is not worn.
• Health injuries resulting from the effect of hand/arm vibration in the event that the tool is used over a longer period of time or is not used and maintained properly.
• Cutting injuries

WARNING! Danger due to electromagnetic field generated while the tool is in operation. Under certain circumstances, this field may negatively affect active or passive medical implants. In order to reduce the danger of serious or fatal injuries, we recommend that individuals who wear medical implants should consult their doctor and the manufacturer of the implant before operating the tool.

Preparation

WARNING! Risk of injury due to unintentional start-up. Do not insert the plug into the outlet until the device is fully prepared for use.

Safety devices

The following safety devices are provided to protect the user and the device:

Rear handle (1) with rear hand guard (11)

- Protects the hand from branches, twigs and if the saw chain jumps off.

Chain brake lever/front hand protection (2)

• The saw chain does not run when the chain brake is locked into place.
• Stops the saw chain immediately in the event of a kickback.
• Lever can also be operated manually.
• Protects the operator's left hand if it slips off the front handle.

Saw chain (4) with low kickback

- Helps to absorb kickbacks thanks to specially developed safety devices.

Chain catcher (6)

- Reduces the risk of injury if the saw chain jumps off or breaks.

Switch lock (16)

- The switch lock must be unlocked in order to switch on the device.

On/Off switch (17) with immediate chain stop

- The device switches off immediately once the on/off switch is released.

Chain catch (21)

• Increases stability when making vertical cuts.
• Makes sawing easier.

Operation

Before operation

⚠ WARNING! Risk of injury! Always wear protective gloves while working with the saw chain and use only original parts. Always remove the mains plug before working on the chainsaw.

Carry out the following steps before operating the chainsaw:

• if necessary, Installing the saw chain and blade bar, p. 38
  • Tensioning the saw chain, p. 38
• Pouring in chain oil, p. 34
• Checking the chain brake, p. 33
• Checking the oil automation

Checking the chain brake

Notes

• The saw chain will not run when the chain brake is locked into place.
• RANGER! Risk of injury from the trailing saw chain. Do not use the chainsaw if the chain brake does not work properly. Contact the service centre.

Procedure

1. Place the tool on a level surface.
2. Connect the tool to the power supply.
3. Release the chain brake by pulling the chain brake lever (2) against the front grip (15).
4. Hold the tool firmly with both hands, with your right hand on the rear grip (1) and your left hand on the front grip (15). Your thumb and fingers must tightly clasp the grips.
5. Switch on the tool.
6. With the engine running, operate the chain brake lever (2) with your left hand. To do so, push the chain brake lever (2) away from the front grip (15).

The saw chain should stop abruptly.

1. If the chain brake is working properly, release the on/off switch (17) and release the chain brake.

Checking chain lubrication

NOTICE! If the chainsaw is used with too little oil, the cutting performance and lifespan of the saw chain will decrease as the saw chain will become blunt more quickly. You can recognise insufficient oil by the smoke development or discolouration of the blade

bar. Make sure that there is always oil flowing onto the chain.

Notes

• Before starting work, check the oil level.
• You can check the chain lubrication at any time during operation.

Procedure

1. While the saw chain is running: Hold the chainsaw above clear ground. Observe the trace of oil. The chainsaw must not touch the ground!

• Significant trace of oil: The chainsaw is working properly
- Slight trace of oil: Adjust the oil flow
- No trace of oil: Clean the oil passage

Pouring in chain oil

⚠ WARNING! Risk of fire! Always turn off the device and let the engine cool down before filling with chain oil.

NOTICE! If the chainsaw is used with too little oil, the cutting performance and lifespan of the saw chain will decrease as the saw chain will become blunt more quickly. You can recognise insufficient oil by the smoke development or discolouration of the blade bar. Make sure that there is always oil flowing onto the chain.

The oil flows to the blade bar (3) as soon as the chain starts running.

• Check the oil level regularly and top up with oil if the level is low. Tank capacity: 130 cm^3
• Use bio chain oil containing additives to reduce friction and wear. Alternatively, use chain lubricating oil with a low proportion of adhesion additives.
• Empty the oil tank if it will not be used for a prolonged period of time (6–8 weeks).

Procedure

1. Place the device on its side with the tank cover (14) facing upwards.
2. Unscrew the tank cover (14).
3. Pour the bio chain oil into the tank.
4. Wipe away any spilt oil.
5. Screw on the tank cover (14).

Switching on and off

Requirements

- The blade bar (3), saw chain (4) and sprocket cover (9) are correctly fitted.

• Sufficient chain oil in the tank. Top up with chain oil if necessary (Pouring in chain oil, p. 34).
• The voltage of the mains connection matches that indicated on the tool's type plate.

Procedure (Fig. C)

1. Form a loop from the end of the extension cable and hook it into the strain relief (12) on the rear handle (1).
2. Connect the machine to the power supply.
3. Release the chain brake by pulling the chain brake lever (2) towards the front handle (15).
4. Hold the chainsaw firmly with both hands, with your right hand on the rear handle (1) and your left hand on the front handle (15). Your thumb and fingers must tightly clasp the handles.
5. Before starting, make sure that the chain-saw is not touching any objects.
6. To switch on, press the switch lock (16) with your right thumb and then press the on/off switch (17). The chainsaw runs at maximum speed. Release the switch lock (16) again.
7. Release the on/off switch (17) to switch off the chainsaw. Continuous switching is not possible.

Sawing techniques

⚠ WARNING! Risk of injury! If the saw chain is jammed, do not try to pull the chainsaw out by force. Switch off the motor and use a lever arm or wedge to release the chainsaw.

• Always stand above the tree trunk when sawing on slopes.
• Remove dirt, stones, loose bark, nails, clips and wires from the tree.
• The saw chain must not touch the ground or any object while sawing through the material or thereafter.
• You will have better control over the device if you saw using the lower edge of the blade bar (saw chain in pulling direction) and not using the upper edge of the blade bar (saw chain in pushing direction).
• Ensure that the saw chain does not get stuck while sawing. The log must not break or splinter.
• Please observe the precautionary measures to protect against kickback (Causes

and Operator Prevention of Kickback, p. 32)

• Reduce the contact pressure towards the end of the cut without loosening the firm grip on the chainsaw handles in order to maintain full control at the moment of 'sawing through'.
• The chainsaw may slip unexpectedly while cutting. This happens in particular when the guide bar cannot find a firm grip on round, smooth, or hard surfaces, or when sawing with the tip of the guide bar.? Always hold the saw firmly with both hands, stand securely, and avoid using only the tip of the guide bar.
• After completing the cut, wait until the chainsaw has come to a standstill before removing it.
• Always switch off the chainsaw motor before moving from tree to tree.

Felling trees

⚠ WARNING! A lot of experience is needed to fell trees. Only fell trees if you know how to use the chainsaw safely. Never use the chainsaw if you feel unsafe.

CAUTION! Do not cut down a tree if there is a strong or changing wind, if there is a risk of damage to property or if the tree could hit power lines. When felling trees, ensure that no other persons are subject to hazards and that no material damage is caused. If a tree should come into contact with a power line, the supply company must be informed immediately.

⚠️ CAUTION! For safety reasons, we advise inexperienced users against felling a tree trunk with a blade bar length that is smaller than the trunk diameter.

• Please make sure that no other persons or animals are present in your work area. The safety distance between the tree to be felled and the nearest workplace must be 2 ½ tree lengths.
• Pay attention to the felling direction. The user must be able to move around safely near the felled tree so that he can cut the tree to size and cut off all branches easily. The falling tree must be prevented from becoming entangled in another tree.
• Please note that the natural falling direction depends on the pitch and crookedness of the tree trunk, the wind direction,

position of larger branches and the number of branches.

• Stay above the tree to be felled when sawing on a slope. The tree will probably roll or slide downhill after felling.
• Small trees with a diameter of 15-18 cm can usually be sawn off with one cut.
• For trees with a larger diameter, notch cuts and a felling cut must be applied (Fig. L).
• If cutting and felling is being carried out by two or more persons simultaneously, the distance between the felling and cutting persons must be at least twice the height of the tree to be felled.

Fold up the hearing protection immediately after finishing the sawing process so that you can hear sounds and warning signals.

Procedure

1. Limbing (Fig. J)

Remove branches hanging downwards by sawing from the top of the branch. Never saw off branches higher than shoulder height.

2. Escape area (Fig. I)

Remove the undergrowth around the tree to ensure an easy retreat. The escape area (1) should be offset by about 45^ behind the planned felling direction (2).

3. Cut drop notch (A) (Fig. L)

Place a drop notch in the direction in which you want the tree to fall. Start with the lower, horizontal cut. The cutting depth should be about 1/3 of the trunk diameter. Now make an oblique saw cut with a cutting angle of approximately 45^ from above, which meets the lower saw cut exactly. This prevents the saw chain or guide rail from jamming when the second notch cut is made.

⚠ WARNING! Never step in front of a tree that is notched.

4. Felling cut (B) (Fig. L)

Make the felling cut from the other side of the trunk. Stand to the left of the tree trunk and saw with the saw chain pulling (with the underside of the blade bar). The felling cut must be at least 5 cm above the horizontal notch section. It should be deep enough so that the distance to the notch cutting line is at least 1/10 of the trunk diameter. The part of the log that has not been sawn through is called the

hinge (felling bar). The hinge prevents the tree from turning and falling in the wrong direction. Do not cut through this hinge. When the felling cut nears the hinge, the tree should begin to fall. If it becomes apparent that the tree will not fall in the desired direction or if it bends back, and if the saw chain is stuck, discontinue the felling cut. Use wooden, plastic or aluminium wedges to open the cut and fell the tree to fall into the desired fall line.

1. Slide a cutting wedge into the felling cut as soon as the cutting depth so permits, in order to prevent the blade bar from getting jammed (Fig. M).
2. If the trunk diameter is greater than the length of the blade bar, make two cuts (Fig. N).
3. Once the felling cut has been made, the tree falls by itself or with the help of the felling wedge.

⚠ WARNING! As soon as the tree starts to fall, pull the chainsaw out of the cut, stop the engine, put the chainsaw down and leave the workplace via the retreat path. Pay attention to falling branches and do not stumble.

Limbing

Limbing is the term for removing branches and twigs from a felled tree.

⚠️ CAUTION! Risk of injury! Never saw off branches when you are standing on the tree trunk. Keep an eye on the kickback area when branches are under tension.

(Fig. J)

• Only remove support branches after cutting to length.
• Saw branches under tension from the bottom upwards to prevent the tool from jamming.
• Use the same technique as for Cutting to length, p. 36 when sawing off thicker branches.
• Work to the left of the trunk and as close as possible to the tool. If possible, the weight of the tool should rest on the trunk.
• Change location to saw off branches beyond the trunk.
• Cut branched branches to length individually. Leave larger branches pointing downwards and supporting the tree for the time being.
• Separate smaller branches with one cut.

Cutting to length

Cutting to length means sawing felled tree trunks into small sections.

• Ensure that you have a secure footing and balance your body weight evenly on both feet.
• Support the trunk if possible. The trunk should be underpinned and supported by branches, beams or wedges.
• Make sure that the saw chain does not touch the ground when sawing.
• Stand above the trunk on sloping terrain.

Techniques for cutting to length

Trunk lying on the ground (Fig. E)

Saw all the way through the trunk from above, taking care not to touch the ground at the end of the cut. If it is possible to turn the trunk, saw through 2/3 of it. Then turn the trunk over and saw through the rest of the trunk from above.

Trunk is supported at one end (Fig. F)

First saw through 1/3 of the trunk diameter from bottom to top (with the top of the blade bar) to avoid splintering. Then saw from top to bottom (with the underside of the blade bar) towards the first cut to avoid jamming.

Trunk is supported at both ends (Fig. G)

First saw through 1/3 of the trunk diameter from top to bottom (with the underside of the blade bar). Then saw from bottom to top (with the top of the blade bar) until the cuts meet.

Sawing on a sawhorse (Fig. H)

Hold the chainsaw firmly with both hands and guide the machine in front of your body while sawing. When the log is cut, guide the machine past the body on the right (1). Keep your left arm as straight as possible (2). Watch out for the falling trunk. Position yourself so that the severed trunk does not pose a hazard. Pay attention to your feet. The severed trunk could cause injuries if it falls. Keep your balance (3).

Cleaning, maintenance and storage

⚠ WARNING! Electric shock! Risk of injury due to unintentional start-up. Protect yourself when performing maintenance or cleaning work. Switch off the device and disconnect the plug from the power outlet.

You should have any repair and maintenance work that is not described in these instructions carried out by our Service Centre. Only use original replacement parts.

CAUTION! Please be aware that the chainsaw may leak oil after use if it is stored on its side or head. This is a normal occurrence and is caused by the ventilation opening on the top edge of the tank which is a necessary component; this is not grounds for complaint. Since every chainsaw is inspected and tested using oil during manufacture, a small amount of oil may remain in the tank after emptying, which may slightly dirty the housing during transport. Please clean the housing with a cloth.

Cleaning

⚠ WARNING! Electric shock! Never spray down the device with water.

CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

NOTICE! Risk of damage. Chemical substances may attack the plastic parts of the machine. Do not use any cleaning agents or solvents.

Clean the machine thoroughly. This will extend the life of the machine and prevent accidents.

Cleaning after every use

• Keep the handles free of oil or grease. If necessary, clean the handles with a damp cloth washed in soapy water.
• Clean the saw chain. Do not use any liquids to clean the saw chain. Lightly oil the saw chain with chain oil after cleaning.
• For cleaning, also remove the sprocket cover (9) so that this area can also be cleaned.
• Clean the blade bar (3).
• Clean the ventilation slits and the surface of the machine with a paintbrush or dry cloth.
• Clean the oil passage (26) to ensure fault-free, automatic oiling of the saw chain during operation. Use a brush or a cloth to help remove residues from the oil passage.

Maintenance

Service intervals

Carefully perform the maintenance tasks listed in the following table on a regular basis. Regular servicing of your device will extend its life. Additionally, you will achieve optimum cutting performance and prevent accidents.

Machine part Action Before		each use	After 10 hours of use	After each use
Chain brake components	Visual inspection, re-place as needed	√
Sprocket (28) Visual inspection, re-place as needed		√
Saw chain (4) Check saw chain, oil, reg-rind or replace if necessary		√
Saw chain (4) Clean and oil the saw chain √
Blade bar (3) Servicing the blade bar, p. 40 √ √
Blade bar (3) Turning the blade bar, p. 40 √
Automatic oil system	Check, clean oil pas-sage if necessary	√

Removing the blade bar and saw chain

CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

Procedure (Fig. B)

1. Pull out the mains plug.
2. Place the tool on a level surface.
3. Deactivate the chain brake: Pull the chain brake lever (2) back towards the front handle (15).

You can only refit the sprocket cover (9) when the chain brake band has been released.

1. Loosen the chain tension: Turn the chain tensioner screw (8) ⭕.

2. Remove the sprocket cover (9): Turn the wing nut (7) ⬆.

3. Push the blade bar (3) towards the chain sprocket (28).

You can remove the saw chain (4) and blade bar (3).

1. Clean the groove of the blade bar. If dirt deposits are present, the saw chain (4) may jump out of the bar.

2. Check the chain sprocket (28) for wear or damage. If worn or damaged:

Contact the service centre.

Changing the saw chain and blade bar

Prior to changing the saw chain, the groove of the guide rail must be cleaned of dirt because dirt deposits available can cause the saw chain to break out of the rail. The deposits can also absorb the chain oil. So the consequence would be that the chain oil would not or only a small part of it would reach the underside of the rail and the lubrication would be reduced.

Requirements

- Removing the blade bar and saw chain, p. 37

Procedure (Fig. B)

1. Replace the blade bar (3)/ the saw chain (4).

2. Fit the blade bar (3) and saw chain (4) as described under Installing the saw chain and blade bar, p. 38.

Installing the saw chain and blade bar

⚠️ CAUTION! Risk of injury due to unintentional start-up. Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop

⚠️ CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

Procedure (Fig. B)

1. Place the device on a level surface.

2. Remove the sprocket cover (9): Turn the wing nut (7) ⬆.

3. Spread out the saw chain (4) in a loop so that the cutting edges are aligned in a

clockwise direction. Use the symbol below the sprocket (28) as a guide for aligning the saw chain (4).

Direction of travel by saw chain

1. Place the blade bar (3) on the blade bar bolt (27) and slide it onto the chain sprocket (28).

2. Thread the saw chain (4) over the chain sprocket (28).

3. Place the saw chain (4) on the top of the blade bar (3) in the blade bar groove. Start at the chain sprocket (28). It is normal for the saw chain (4) to sag.

4. Pull the blade bar (3) forwards to tension the saw chain (4).

5. Fit the sprocket cover (9). To do this, first insert the lug (29) on the sprocket cover (9) into the holder provided on the tool. Ensure that the chain tensioner pin (30) engages in the receptacle (31).

6. Tighten the wing nut (7) with moderate force ⬇.

7. Tension the saw chain: Turn the chain tensioner screw (8) ⬇.

8. Tighten the wing nut (7) ↻.

Tensioning the saw chain

NOTICE! Do not re-tension or change the saw chain when it is hot because it shrinks slightly once it has cooled down. If this is not observed it can lead to damage on the guide rail or the engine because the saw chain is now too taut on the blade bar.

Regularly tightening the saw chain provides safety for the user and reduces and/or prevents wear and chain damage. We recommend that the user check the chain tension before starting work and at intervals of approx. 10 minutes and correct it if necessary. The saw chain warms up when working with the saw and thus expands slightly. These “expansions” can be expected especially from newer saw chains.

Chain tension and chain lubrication have a significant impact on the service life of the saw chain. The chain tension of a new saw chain must be readjusted after a maximum of 5 cuts.

The saw chain is properly tensioned when it does not hang from the underside of the blade bar and cannot be moved around by a gloved hand. When pulling on the saw chain with 9 N (approx. 1 kg) of force, the saw

chain and blade bar should not be separated by a distance of more than 2 mm.

10 min 9N max. 2 mm

⚠️ CAUTION! Risk of injury due to unintentional start-up. Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop

Procedure

1. Make sure that the chain brake is released, i.e. the chain brake lever (2) is pulled against the front handle (15).

2. Undo the wing nut (7) ⭕.

3. To tension the saw chain, turn the chain tensioner screw (8) ⬇.

To loosen the tension, turn the chain tensioner screw (8) ⭕.

1. Retighten the wing nut (7) ⬇.

The chain tension of a new saw chain must be readjusted after a maximum of 5 cuts.

Sharpening the cutting teeth

CAUTION! Risk of injury! An incorrectly sharpened saw chain increases the danger of kickback! Use cut-resistant gloves when working with the saw chain or with the blade bar.

A sharp saw chain ensures optimum cutting performance. It effortlessly eats through the wood and leaves behind large, long wood chips. A saw chain is dull when you have to push the cutting equipment through the wood and the wood chips are very small. With a very blunt saw chain, no chips are produced, only wood dust.

Special tools are required for sharpening the saw chain to ensure that the chain is sharpened at the correct angle and to the correct depth. For inexperienced chain-saw users, we recommend having the saw chain sharpened by an expert or a specialist workshop. If you are confident that you can sharpen the chain, proceed according to the instructions for your saw chain sharpener (e.g. Parkside PSG 85 B2).

- The sawing parts of the saw chain are the cutting links, which consist of a cutting

tooth and a depth gauge lug. The height distance between these two determines the sharpening depth.

- The saw chain is worn and must be replaced with a new saw chain when only approx. 4 mm of the cutting tooth is left.

- The following values must be taken into account when sharpening the cutting teeth (Fig. K):

• Sharpening angle (30°)

- Front angle (85°)

• Sharpening depth (0.65 mm)

• Round file diameter (4.0 mm)

⚠ WARNING! Risk of accident! Deviations from the dimensions of the cutting edge geometry can lead to an increased tendency of kickback by the machine.

Tools and aids required

- Round file

- Flat file

Procedure (Fig. K)

1. Switch off the device and unplug the mains plug.
2. Ensure that the saw chain is tightly tensioned to enable correct sharpening.
3. Only sharpen from the inside out. Guide the round file from the inside of the cutting tooth to the outside. Lift off the file when you pull it back.
4. Sharpen the teeth on one side first. Then turn the saw chain over and sharpen the teeth on the other side.
5. Check the length of the cutting links. After sharpening, all the cutting links must have the same length and width.
6. After every third sharpening, check the sharpening depth (depth gauge) and re-file the height using a flat file. The depth gauge should be set back by approx. 0.65 mm from the cutting tooth.
7. After resetting, round off the depth gauge slightly towards the front.

Adjusting the chain tension

Adjusting the chain tension is described in section Tensioning the saw chain, p. 38.

Running in a new saw chain

The tensioning force of a new saw chain decreases after some time. You must therefore retighten the saw chain after the first 5 cuts or after 10 minutes of sawing at the latest (Tensioning the saw chain, p. 38).

⚠ WARNING! Risk of injury! Never attach a new saw chain to a worn chain sprocket or to a damaged or worn blade bar. The saw chain could jump off or break.

Servicing the blade bar

CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

Tools and aids required

- Flat file

Procedure (Fig. B)

1. Switch off the device and unplug the mains plug.
2. Remove the sprocket cover (9), saw chain (4) and blade bar (3).
3. Check the blade bar (3) for wear.
4. Remove burrs and straighten the guide surfaces with a flat file.
5. Clean the oil passage (26) to ensure fault-free, automatic oiling of the saw chain during operation.
6. Mount the blade bar (3), saw chain (4) and sprocket cover (9) and tighten the chainsaw.

When in an optimal condition, the oil passages will automatically spray the saw chain with a little oil a few seconds after starting the chainsaw.

Turning the blade bar

CAUTION! Cutting injuries! Wear cut-resistant gloves when working with the saw chain or with the blade bar.

The blade bar (3) needs to be reversed regularly after a working time of about 10 hours in order to ensure even wear.

Procedure (Fig. B)

1. Switch off the device and unplug the mains plug.
2. Remove the sprocket cover (9), saw chain (4) and blade bar (3).
3. Turn the blade bar around its horizontal axis and install the blade bar and saw chain as described under Installing the saw chain and blade bar, p. 38. Pay attention to the correct rotation direction of the saw chain while doing so!

Direction of travel of saw chain

1. To align the saw chain (4), use the symbol below the sprocket cover (9) as a guide when turning the blade bar.

Replacing the carbon brushes

CAUTION! Risk of injury due to unintentional start-up. Switch off the device and disconnect the plug from the power outlet. Make sure that all moving parts have come to a complete stop

Notes

• Always replace the carbon brushes on both sides.

Tools and aids required

- Slotted screwdriver

Procedure (Fig. D)

1. Loosen the carbon brush cover (10) with a slotted screwdriver.
2. Remove the carbon brush cover (10).
3. Remove the carbon brush (32) from the holder (33).
4. Slide a new carbon brush into the holder (33).

Pay attention to the installation position.

1. Place the carbon brush cover (10) on the tool.
2. Fasten the carbon brush cover (10) with a slotted screwdriver.

Storage

• Clean and maintain the tool prior to storage.
• Attach the chain guard (23).
• Empty the oil tank prior to longer periods of non-use. Dispose of waste oil environmentally correctly (Disposal/environmental protection, p. 42).

There may still be oil residues within hoses and in the tool that could leak out during storage. Place the tool on a suitable base/oil pan for storage.

- Store the tool in a dry and dustproof location and out of reach of children.

Wall mounting

You can hang it on the wall with the keyhole bore (22) on the bottom of the tool.

WARNING! Personal injury or damage to property during drilling. Contact with electric cables can lead to fire and electric shock. Damage to a gas pipe can cause an explosion. Penetration into a water line causes property damage. Use suitable detectors in

order to find hidden supply lines or consult the local utility company.

Tools and aids required

• Screw (screw head ∅: 7-10 mm)
  • Corresponding screwdriver
• Dowels, if necessary

Procedure (Fig. A)

• Using dowels, place one screw at the desired position on a wall.
• Let the screw head protrude with approx. 10 mm distance to the wall.
  • Make sure that the suspension system is designed for the weight of the tool.
• You can place the tool with the keyhole (22) against the screw and pull the tool down as far as it will go.

Transport

• Cover the blade bar and saw chain with the chain guard (23) when you transport the tool.
• Short distances at the place of work: Carry the tool by the front handle (15) with the blade bar pointing backwards.
• Switch off the tool each time before transport. Secure the tool against tipping over during transport (including in vehicles) to prevent injury, damage or loss of fuel.
• Longer distances or in vehicles: Transport the tool in the provided carrier bag (25).

Troubleshooting

The following table will assist you in fixing faults:

Problem Possible cause Error correction
Device does not start	Chain brake locked into place	Checking the chain brake,p. 33
	No mains power supply Check	the socket, mains connection cable, plug and fuse and have them repaired by a qualified electrician if necessary.
	On/Off switch (17) defective	contact the service centre.
	Worn out carbon brushes
	Defective motor
Saw chain not running Chain brake blocks saw chain(4)		Checking the chain brake,p. 33
Poor cutting performance	Saw chain (4) incorrectly fitted	Installing the saw chain and blade bar, p. 38
	Saw chain (4) blunt • Sharpening	the cutting teeth, p. 39Changing the saw chain and blade bar, p. 38
	Insufficient chain tension Tensioning the saw chain,p. 38
Device has difficulties running,saw chain jumps off	Insufficient chain tension Tensioning the saw chain,p. 38
Saw chain gets hot, smoke development when sawing, dis-colouration of the rail	Not enough chain oil • Checking	the oil level and oil automationPouring in chain oil,p. 34Cleaning the oil passagecontact the service centre.
Problem Possible cause Error	correction
Sparking	Carbon brushes worn outReplacing the carbon brushes, p. 40
Irregular operation
Reduced performance

Disposal/environmental protection

Empty the oil tank carefully.

Do not dispose of used oil residues in the sewage system or down the drain. Dispose of waste oil in an environmentally friendly way – take them to your local recycling centre.

The device, accessories and packaging should be properly recycled.

Waste electrical and electronic equipment (WEEE) must not be disposed of with domestic waste.

The symbol of the crossed-out wheeled bin means that this product must not be disposed of as unsorted municipal waste at the end of its useful life.

Directive 2012/19/EU on waste electrical and electronic equipment:

Consumers are legally obliged to recycle electrical and electronic equipment in an environmentally sound manner at the end of its life. In this way, environmentally friendly and resource-saving recycling is ensured. Depending on the implementation in national law, you may have the following options:

• Return to a shop,
• Hand over to an official collection point,
• Return to the manufacturer/distributor.

This does not affect accessories enclosed with the old devices or tools without any electrical components.

Service

Guarantee

Dear Customer,

This product is provided with a 5 year guarantee from the date of purchase. In case of defects, you have statutory rights against the seller of the product. These statutory rights are not restricted by our guarantee presented below.

Terms of Guarantee

The guarantee period begins on the date of purchase. Please retain the original receipt. This document is required as proof of purchase. If a material or manufacturing defect occurs within five years of the date of purchase of this product, we will repair or replace – at our choice – the product for you free of charge. This guarantee requires the defective product and proof of purchase to be presented within the five-year period with a brief written description of what constitutes the defect and when it occurred.

If the defect is covered by our guarantee, you will receive either the repaired product or a new product. No new guarantee period begins on repair or replacement of the product.

Guarantee Period and Statutory Claims for Defects

The guarantee period is not extended by the guarantee service. This also applies for replaced or repaired parts. Any damages and defects already present at the time of purchase must be reported immediately after unpacking. Repairs arising after expiry of the guarantee period are chargeable.

Guarantee Cover

The product has been carefully produced in accordance with strict quality guidelines and conscientiously checked prior to delivery.

The guarantee applies for all material and manufacturing defects. This guarantee does not extend to cover product parts that are subject to normal wear and may therefore be considered as wearing parts (e.g. Saw chain) or to cover damage to breakable parts.

This guarantee shall be invalid if the product has been damaged, used incorrectly or not maintained. Precise adherence to all of the instructions specified in the operating manual is required for proper use of the product. Intended uses and actions against which the operating manual advises or warns must be categorically avoided.

The product is designed only for private and not commercial use. The guarantee will be invalidated in case of misuse or improp-

er handling, use of force, or interventions not undertaken by our authorised service branch.

Processing in Case of Guarantee

To ensure efficient handling of your query, please follow the directions below:

• Please have the receipt and product number (IAN 495711_2504) ready as proof of purchase for all enquiries.
• Please refer for the product number to the type plate on the product, an engraving on the product, the title page of the operating instructions (bottom left) or the sticker on the back or underside of the product.

- Should functional errors or other defects occur, please initially contact the service centre specified below by telephone or use the contact form available on parkside-diy.com in the category Service.

- After consultation with our customer service, a product recorded as defective can be sent postage paid to the service address communicated to you, with the proof of purchase (receipt) and specification of what constitutes the defect and when it occurred. In order to avoid acceptance problems and additional costs, please be sure to use only the address communicated to you. Ensure that the consignment is not sent carriage forward or by bulky goods, express or other special freight. Please send the appliance inc. all accessories supplied at the time of purchase and ensure adequate, safe transport packaging.

PDF ONLINE parkside-diy.com

You can view and download these and many other manuals on parkside-diy.com.

This QR code will take you directly to parkside-diy.com. Select your country and search for the operating instructions via the search mask. You can open your operating instructions by entering the article number (IAN) 495711_2504.

Repair service

For repairs that are not covered by warranty, contact the service centre. They will gladly create a cost estimate for you.

• We can only work on devices which are sent in properly packed and with postage paid.
  Note: Please send your device cleaned and with an indication of the defect to the address named for the service centre.
• The following are not accepted: devices sent in without prepaid postage, sent as bulky goods, sent as an Express shipment, or devices sent as any other form of special freight.
• We will dispose of defective devices you ship to us free of charge.

Service Centre

Service Great Britain

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 495711_2504

Service Malta

Tel.: [phone]

Contact form on

parkside-diy.com

IAN 495711_2504

Importer

Please note that the address below is not a service address. Contact the service centre named above first.

Spare parts and accessories

You can get spare parts and accessories from www.grizzlytools.shop. If you have any problems with your order, contact us via our online shop. If you have any other questions, contact: Service Centre, p. 43

Pos. nr. Name Order No.
21 Chain catch 91120416
14 Tank cover (Chain oil) 91120418
3 Blade bar 91120149
4 Saw chain 91120150
23 Chain guard 91120419
9 Sprocket cover 91120420

⚠ WARNING! Safe use of the chainsaw is only possible with approved saw chains and guide rails. The use of unapproved combinations can cause serious or even fatal injuries.

- Blade bar:

• 18"AP18-62-507P (Kangxin)
• 18"180SDEA041 (Oregon)
• M1501862-1041TL (Trilink)

- Saw chain:

• ALP-50-62S (Kangxin)
- 91PX062X (Oregon)
- CL15062TL (Trilink)

Translation of the original EU declaration of conformity

Product: Electric Chainsaw

Model: PPEKS 2500 B2

Serial number: 000001-016700

The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:

2006/42/EC • 2014/30/EU • 2000/14/EC & 2005/88/EC • 2011/65/EU & (EU) 2015/863

The object of the declaration described above is in conformity with Directive 2011/65/EU of the European Parliament and of the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

To ensure conformity, the following harmonised standards and national standards and regulations have been applied:

EN 62841-1:2015/A11:2022 • EN 62841-4-1:2020 • EN ISO 12100:2010

EN IEC 55014-1:2021 • EN IEC 55014-2:2021

EN IEC 61000-3-2:2019/A2:2024 • EN 61000-3-3:2013/A2:2021

EN IEC 63000:2018

In accordance with the Directive 2000/14/EC relating to noise emission, the following is confirmed: Sound power level ( L_WA )

- Measured: 106.9 dB;

- Guaranteed: 109 dB

Followed conformity assessment procedure according to 2000/14/EC, Annex VI.

EC type-examination certificate

• Number: M6A 036607 2324 Rev.00

- Notified body: TÜV SÜD Product Service GmbH • Ridlerstraße 65 80339 München • Deutschland, NB: 0123

This declaration of conformity is issued under the sole responsibility of the manufacturer:

Authorised representative of documentation

Sommaire

Introduction...... 46

Garantie (France)......66

Service-Center....68

Importateur.... 68

Two diagrams showing a tracked vehicle and a mechanical device with arrows indicating motion (no text or symbols)

Service-Center....89

Importeur.... 89

Two technical diagrams showing mechanical components: (a) a gear-like structure with motion arrows, and (b) a tool interacting with a surface (no text or symbols)

Service-Center....112

Importador.... 112

Diagram of a mechanical or physical setup with an arrow indicating direction, no visible text or symbols

Service-Center....133

Importatore.... 133

Ricambi e accessori.... 134

Two technical diagrams showing mechanical components and a tool interacting with a surface (no text or symbols present)

Service-Center....153

Dovozce....154

Two diagrams showing mechanical components: (a) a gear-like structure with angular motion, and (b) a lever mechanism with force arrow (no text or symbols)

Service-Center....174

Importér.... 174

Two technical diagrams showing mechanical components and a robotic arm (no text or symbols present)

Two diagrams showing mechanical components: (a) a gear-like structure with motion arrows, and (b) a tool interacting with a tree branch (no text or symbols)

Two diagrams showing a mechanical component (a) and a tool interacting with a surface (b), both without any text or symbols.

QR code image containing encoded data, with a central logo or watermark

PDF ONLINE parkside-diy.com

Service-Center....236

Importør...... 237

Two technical diagrams showing mechanical components and a tool interacting with a surface (no text or symbols present)

QR code image containing encoded data, with a central logo or watermark

PDF ONLINE parkside-diy.com

FSC www.fsc.org MIX From responsible sources FSC® C142784

IAN 495711_2504

8=
