USER MANUAL GrandCooler Klarstein

COOKINGCO COOKINGCO KINGCOOKING KINGCOOKING COOKINGCO KINGCOOKING KINGCOOKING KINGCOOKING

KLARSTEIN

www.klarstein.com

QR code image containing encoded data, no visible human-readable text

INHALT

Labeled diagram of a refrigerator interior with numbered parts for identification

Name: Customer service

Website: https://www.elektronik-star.de/lnfo/Impressum/

E-Mail-Adresse: [e-mail]

Telefonnummer: [phone]

Anschrift:

Wallstraße 16

10179 berlin

Deutschland

Produktdatenblatt

Name: Customer service

Website: https://www.elektronik-star.de/Info/Impressum/

E-Mail-Adresse: [e-mail]

Telefonnummer: [phone]

Anschrift:

Wallstraße 16

10179 berlin

Deutschland

Symbol of a trash bin with crossed x and y axes, no text or labels present

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

Großbritannien

Dear Customer,

Congratulations on purchasing this device. Please read the following instructions carefully and follow them to prevent possible damages. We assume no liability for damage caused by disregard of the instructions and improper use. Scan the QR code to get access to the latest user manual and more product information.

QR code image containing encoded data, no visible human-readable text

CONTENTS

Safety Instructions 22

Product Overview 26

Operation 27

Care and Maintenance 28

Troubleshooting 29

Disposal Considerations 31

Manufacturer & Importer (UK) 31

TECHNICAL DATA

Item number 10046641, 10046642 10046643, 10046644
Power supply 220 - 240 V~ 50 Hz
Volume 270 L 307 L

SAFETY INSTRUCTIONS

Information on the safety of children and persons at risk

• This appliance may be used by children over 8 years of age and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, provided they are supervised during use or have received instruction in the safe use of the appliance and understand the risks involved.
  • Children aged 3 to 8 years may fill refrigerators with food and remove food.
• Ensure that children do not play with the appliance.
• Cleaning and maintenance of the appliance may only be carried out by children if they are at least 8 years old and supervised.
• Keep all packaging away from children. There is a danger of suffocation.
• When you dispose of the appliance, unplug it from the wall outlet, cut the power cord and remove the door. This will prevent children playing on the appliance from injuring themselves, getting hit or getting trapped.
• If this machine replaces an older machine with a spring lock and latch on the door or lid, disable the spring lock and latch before disposing of the old machine. This will prevent children from getting trapped and suffocating.

General advice

• This refrigerating appliance is not intended to be used as a built-in appliance.
• Do not use mechanical devices or other means to speed up the defrosting process.
• Do not damage the refrigerant circuit.
• Do not use other electrical appliances, such as ice machines, inside refrigeration appliances unless they are approved for this purpose by the manufacturer.
• If there is a light bulb inside the appliance, do not touch it. If it has been switched on for a long time, it can become very hot. The light bulb supplied with this unit is a special bulb that may only be used with the unit supplied. This light bulb is not suitable for household lighting. Do not use the unit without the light bulb.
• When setting up the appliance, take care not to pinch or damage the power cord.
• Do not store explosive substances such as spray cans containing a flammable propellant in this appliance.

• During transport and installation of the unit, take care not to damage any components of the refrigerant circuit.

• Avoid naked flames and sources of ignition near the unit.

• Thoroughly and regularly ventilate the room in which the unit is located.
• It is dangerous to modify this product in any way. Any damage to the cable may cause a short circuit, fire or electric shock.
• All electrical components such as the plug, power cord and compressor must be replaced by a certified service centre or by qualified service personnel.
• The power cord must not be extended.
• Be careful not to pinch or damage the power plug. A pinched or damaged power plug may overheat and cause a fire.
• Make sure that you can reach the power plug of the machine at any time.
• Do not pull on the power cord.
• If the power outlet is loose, do not plug in the power plug. There is a risk of electric shock or fire.
• This machine is heavy. Be careful when moving it.
• Do not place the unit in direct sunlight.

• This appliance is intended for use in the home and similar environments. These include:

• Staff kitchens in shops, offices and other working environments

• Farms, hotels, motels and other residential facilities
• Pensions that offer breakfast (Bed & Breakfasts)
• Catering and similar applications outside the retail trade

This appliance contains the coolant isobutane (R600a), a natural gas which is environmentally friendly. Although it is flammable, it does not damage the ozone layer and does not increase the greenhouse effect. The use of this coolant has, however, led to a slight increase in the noise level of the appliance. In addition to the noise of the compressor, you might be able to hear the coolant flowing around the system. This is unavoidable, and does not have any adverse effect on the performance of the appliance. Care must be taken during the transportation and setting up of the appliance that no parts of the cooling system are damaged. Leaking coolant can damage the eyes.

Notes on daily use

• Do not put hot food in the machine.
• Do not place food directly against the rear panel.
• Frozen food must not be refrozen after defrosting.
• Store packaged frozen food according to the instructions of the frozen food manufacturer.
• Open the door as rarely as possible.
• Do not leave the door open too long.
• Do not set the thermostat too low.
• To reduce energy consumption, leave all accessories, such as drawers, shelves or racks in the appliance.

Notes on installation

• Unpack the machine and check for damage. Do not connect the machine if it is damaged. Report any damage immediately to the manufacturer. Save the original packaging for possible return shipment.
• Wait at least four hours before connecting the unit to allow the coolant to distribute itself in the cooling circuit.
• Ensure that there is sufficient air circulation around the unit. Otherwise, the unit may overheat.
• If possible, the spacers on the unit should rest against the wall. This prevents burns caused by touching the hot compressor or condenser.
• The unit must not be installed near radiators or cookers.
• Make sure that the mains plug is always accessible after the unit has been installed.
• Install this unit in a location where the ambient temperature corresponds to the climate class indicated on the unit's nameplate:

SN Low		This cooling unit is designed for use at ambient temperatures of 10-32 °C.
N Moderate		This cooling unit is intended for use at ambient temperatures of 16-32 °C.
ST Subtropical		This cooling unit is intended for use at ambient temperatures of 16-38 °C.
T Tropical		This cooling unit is intended for use at ambient temperatures of 16-43 °C.

Notes on cleaning and maintenance

• Before cleaning and maintenance, switch the machine off and unplug the power cord from the wall outlet.
• Do not clean the machine with metal objects. Do not use sharp objects to remove frost from the machine. Use a plastic scraper.
• All electrical work required to service the unit should be performed by a qualified electrician or competent person.

To avoid contamination of food, please follow the instructions below:

• Prolonged opening of the door can cause a significant temperature rise in the compartments of the unit.
• Clean surfaces that may come into contact with food regularly. Clean the water drain regularly.
• Store raw meat and fish in suitable containers in the refrigerator so that meat and fish do not come into contact with or drip onto other foods.

WARNING

When using, servicing and disposing of the unit, pay attention to the left symbol on the rear of the unit or on the compressor. This symbol warns of possible fires. There are flammable substances in the refrigerant lines and in the compressor. Keep the appliance away from sources of fire during use, maintenance and disposal.t

PRODUCT OVERVIEW

Labeled diagram of a refrigerator interior with numbered compartments and storage racks

1 Light switch
2 Thermostat
3 Door seal
4 Handle
5 Right glass door
6 Front windshield
7 Universal casters with brake

8 Universal casters
9 Cabinet
10 Shelves
11 Evaporator
12 Inside LED light
13 Evaporator fan

Due to the product improvement, the product you get may not be completely consistent with the illustrations of this manual.

OPERATION

4 3 5 2 6 1 7 0

Temperature control knob

Light

Use

• Set the temperature controller knob according to your own needs.
• When the temperature controller knob is turned to the "0" position, the refrigeration system shuts down.
• The temperature controller has a range of 7 temperature adjustments. The setting "1" is the weakest cooling whereas "7" is being the strongest cooling. Generally, it is best to adjust the temperature knob to the middle position.
• The lighting switch turn the light on (Position "1") or off (Position "0").

CARE AND MAINTENANCE

Cleaning inside the fridge

After defrosting you should clean the fridge internally with a weak solution of bicarbonate of soda. Then rinse with warm water using a damp sponge or cloth and wipe dry. Wash the baskets in warm soapy water and ensure they are completely dry before replacing in the fridge.

Cleaning outside the fridge

Use standard non-abrasive detergent diluted in warm water to clean the fridge exterior. The grille of the condenser at the back of the fridge and the adjacent components can be vacuumed using a soft brush attachment.

Do not use harsh cleaners, scouring pads or solvents to clean any part of the fridge.

Moving the fridge

Location: Do not place your fridge/Freezer near a heat source, eg. Cooker, boiler or radiator. Also avoid direct sunlight in out-buildings or sun lounges.

Vacation time

• Turn off the refrigerator first and then unplug the unit from the wall outlet.
• Remove all the beverages.
• Clean the refrigerator.
• Leave the lid open slightly to avoid possible formation of condensation, mold, or odours.
• Use extreme caution in the case of children. The unit should not be accessible to child's play.
• Short vacations: Leave the refrigerator operating during vacations of less than three weeks.
• Long vacations: If the appliance will not be used for several months, remove all food and unplug the power cord. Clean and dry the interior thoroughly. To prevent odour and mold growth, leave the door open slightly: blocking it open if necessary or have the door removed.

TROUBLESHOOTING

Problem Cause Solution
No cooling	There is no electricity on the socket	Check whether the socket is connectedCheck whether the voltage is stable Check the voltage on the socket is normal.No cooling.
	Unstable voltage Check the voltage on the socket is normal.
	The refrigeration switch is not turned on or damaged.	Check whether the refrigeration switch is turned on. If the switch is damaged, needs to be replaced.
	The temperature control knob is not set in place.	Check that the temperature control knob is in the right position.
	Refrigeration system failure.	Inform professionals to repair the refrigeration system.
The cooling performance is poor.	Insufficient ventilation and heat dissipation of the refrigeration system.	Check that the air vents are blocked.
	The product is exposed directly to the sunlight.	Place the appliance in a less sunny place.
	The door seat of the product is not sealed after aging.	Replace the door seal.
	The indoor ambient temperature is too high.	Use indoor ventilation to keep the indoor temperature below 32 °C.
	Excessive air traffic blockage in the cabinet.	Ensure that the air duct of the product is unobstructed and not blocked.
	The fan does not turn. Inform the professional personnel to replace the fan.
Problem Cause	Solution
The compressor does not stop	The product is exposed directly to the sunlight.	Place the display case in a less sunny place.
	The thermostat selling temperature is too low	Reduce the thermostat setting temperature.
	Insufficient ventilation and heat dissipation of the refrigeration system	Ensure the surrounding ventilation distance.
	Refrigeration system failure.	Inform professionals to repair the refrigeration system.
There is a peculiar smell in the cabinet.	There is a newly purchased product insulation material taste.	Place the product in the ventilated place, and open the cabinet door for ventilation.
	Items in the cabinet have expired and deteriorated.	Regularly check and clean up spoiled items.
	The cabinet did not produce water accumulation on the horizontal surface.	Move the cabinet to the level to ensure the water is drained.
	Pollution in the cabinet Clean the water and pollutants in the cabinet regularly to ensure clean and tidy.

DISPOSAL CONSIDERATIONS

Symbol of a trash bin with crossed lines and a horizontal bar below (no text or labels)

If there is a legal regulation for the disposal of electrical and electronic devices in your country, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of it in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. For information about the recycling and disposal of this product, please contact your local authority or your household waste disposal service.

MANUFACTURER & IMPORTER (UK)

Manufacturer:

Chal-Tec GmbH, Wallstrasse 16, 10179 Berlin, Germany.

Importer for Great Britain:

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

London, W8 6ND

United Kingdom

Product Information Sheet

COMMISSION DELEGATED REGULATION (EU) 2019/2016 with regard to energy labelling of refrigerating appliances

Supplier's name or trade mark: KLARSTEIN

Supplier's address: Customer service, Wallstraße 16, 10179 berlin, DE

Model identifier: 10046441, 10046442

Type of refrigerating appliance:

Low-noise appliance: No Design type: freestanding

Wine storage appliance: Yes

Other refrigerating appli- ance:

General product parameters:

Parameter Value Parameter Value

Overall dimensions (millimetre) Height 800 Width 510 Depth 450

EEI 169

Airborne acoustical noise emissions (dB(A) re 1 pW)

Annual energy consumption (kWh/a)

Minimum ambient temperature (°C), for which the refrigerating appliance is suitable

Winter setting No

Compartment Parameters:

Total volume (dm ^3 or l) 65

Energy efficiency class

Airborne acoustical noise emission class

Climate class:

Maximum ambient temperature (°C), for which the refrigerating appliance is suitable

G

D

temperate

32

Compartment type		Compartment parameters and values
		Compartment Volume (dm3 or l)	Recommended temperature setting for optimised food storage (oC)These settings shall not contradict the storage conditions set out in Annex IV, Table 3	Freezing capacity (kg/24h)	Defrosting type (auto-defrost=A, manual defrost=M)
Pantry	No	-	-	-	-

Product Information Sheet

COMMISSION DELEGATED REGULATION (EU) 2019/2016 with regard to energy labelling of refrigerating appliances

Supplier's name or trade mark: KLARSTEIN

Supplier's address: Customer service, Wallstraße 16, 10179 berlin, DE

Model identifier: 10046443, 10046444

Type of refrigerating appliance:

Low-noise appliance: No Design type: freestanding
Wine storage appliance: Yes		Other refrigerating appli-ance:	No

General product parameters:

Parameter Value Parameter Value
Overall dimensions (millimetre)	Height	827	Total volume (dm3 or l) 111
	Width	696
	Depth	481
EEI		171	Energy efficiency class	G
Airborne acoustical noise emissions (dB(A) re 1 pW)		39	Airborne acoustical noise emission class	C
Annual energy consumption (kWh/a)		142	Climate class:	temperate
Minimum ambient temperature (oC), for which the refrigerating appliance is suitable		16	Maximum ambient temperature (oC), for which the refrigerating appliance is suitable	32
Winter setting		No

Compartment Parameters:

Compartment type		Compartment parameters and values
		Compartment Volume (dm3 or l)	Recommended temperature setting for optimised food storage (°C)These settings shall not contradict the storage conditions set out in Annex IV, Table 3	Freezing capacity (kg/24h)	Defrosting type (auto-defrost=A, manual defrost=M)
Pantry	No	-	-	-	-

Product Information Sheet

COMMISSION DELEGATED REGULATION (EU) 2019/2016 with regard to energy labelling of refrigerating appliances

Supplier's name or trade mark: KLARSTEIN

Supplier's address: Customer service, Wallstraße 16, 10179 berlin, DE

Model identifier: 10046443, 10046444

Type of refrigerating appliance:

Low-noise appliance: No Design type: freestanding

Wine storage appliance: Yes

Other refrigerating appli- ance:

General product parameters:

Parameter Value Parameter Value

Overall dimensions (millimetre) Height 827 Width 696 Depth 481

EEI 171

Airborne acoustical noise emissions (dB(A) re 1 pW)

Annual energy consumption (kWh/a)

Minimum ambient temperature (°C), for which the refrigerating appliance is suitable

Winter setting No

Compartment Parameters:

Total volume (dm ^3 or l) 111

Energy efficiency class

Airborne acoustical noise emission class

Climate class:

Maximum ambient temperature (°C), for which the refrigerating appliance is suitable

G

C

temperate

32

Compartment type		Compartment parameters and values
		Compartment Volume (dm3 or l)	Recommended temperature setting for optimised food storage (oC)These settings shall not contradict the storage conditions set out in Annex IV, Table 3	Freezing capacity (kg/24h)	Defrosting type (auto-defrost=A, manual defrost=M)
Pantry	No	-	-	-	-

Wine storage Yes 111,0 12 - A
Cellar No - - - -
Fresh food No - - - -
Chill No - - - -
0-star or ice-making No - - - -
1-star No - - - -
2-star No - - - -
3-star No - - - -
4-star No - - - -
2-star section No - - - -
Variable temperature compartment	-	- - - -
For wine storage appliances
Number of standard wine bottles 36
Light source parameters:
Type of light source -
Energy efficiency class -
Minimum duration of the guarantee offered by the manufacturer: 24 months
Additional information:
Weblink to the supplier's website, where the information in point 4 of Annex II of Commission Regulation (EU) 2019/2019 is found: https://www.electronic-star.com/

Model placed on the Union market from 01/08/2024.

EPREL registration number: 2082516

https://eprel.ec.europa.eu/qr/2082516

Supplier: Chal-Tec GmbH (Authorised representative)

Website:

Customer care service:

Name: Customer service

Website: https://www.elektronik-star.de/lnfo/Impressum/

Email: [e-mail]

Phone: [phone]

Address:

Wallstraße 16

10179 berlin

Germany

Chère cliente, cher client,

QR code image containing encoded data, no visible human-readable text

SOMMAIRE

Labeled diagram of a refrigerator interior with numbered compartments and storage racks

Nom: Customer service

Site web: https://www.elektronik-star.de/lnfo/Impressum/

Courriel: [e-mail]

Téléphone: [phone]

Adresse:

Wallstraße 16

10179 berlin

Allemagne

INFORMATIONS POUR LE RECYCLAGE

Symbol of a trash bin with crossed lines and a horizontal bar below (no text or labels)

Berlin Brands Group UK Limited

Boîte postale 42

272 Kensington High Street

Londres, W8 6ND

Royaume-Uni

Gentile cliente,

QR code image containing encoded data, no visible human-readable text

INDICE

Labeled diagram of a refrigerator interior with numbered parts for identification

Nome: Customer service

Sito web: https://www.elektronik-star.de/lnfo/Impressum/

E-mail: [e-mail]

Symbol of a trash bin with crossed lines and a horizontal bar below (no text or labels)

Berlin Brands Group UK Limited

PO Box 42

272 Kensington High Street

Londra, W8 6ND

Regno Unito

Estimado cliente:

QR code image containing encoded data, no visible human-readable text

ÍNDICE

Labeled diagram of a refrigerator interior with numbered compartments and doors

Symbol of a trash bin with crossed lines indicating no waste, and a solid rectangle below (no text or labels)

Berlin Brands Group UK Limited

272 Kensington High Street

Londres, W8 6ND

Reino Unido

KLARSTEIN
