USER MANUAL 4-LD5882 AURIOL

23:450 1.5 V AA 1.5 V AA 1.5 V AA ... 1.5 V AAA 1.5 V AAA

www.lidl-service.com

384583_2107

MODE HISTORY CITY CH

MODE - Basic setting

HISTORY - MAX-/MIN-value

CITY - Location table

CH - Channel setting

AL 1 - ALARM 1 - ON/OFF

AL 2 - ALARM 2 - ON/OFF

AL 1 - ALARM 1 - ON/OFF

AL 2 - ALARM 2 - ON/OFF

2 Seconds

1. CH → 2. ( ) 3-10 Minuten, Minutes, Minutes

Basic setting Grundeinstellung Réglage de base
3 Seconds MODE 9 x MODE

$$ 24Hr^{\phi_{\mathrm{tot}}} \rightarrow \phi C^{\phi_{\mathrm{tot}}} \rightarrow hPR^{\phi_{\mathrm{tot}}} \rightarrow 00^{\phi_{\mathrm{tot}}} \rightarrow $$

10:00 → 18:00 → 20:21 →

DATE MONTH DAY 38/10 → DATE MONTH DAY 10/18 → DATE MONTH DAY 10/10 GE

3 Second

AL 1 + AL 2
→

DST

GB IE NI CY MT Usage and safety instructions.... - 1 -

GB IE Usage and safety instructions

Table of contents

Table of contents....- 1 -

Introduction - 2 -

Intended use....- 3 -

Explanation of symbols....- 3 -

Important safety information important safety information....- 5 -

Important safety information for users .... - 5 -

Important safety information for the batteries ....- 6 -

Simplified EU declaration of conformity....-7 -

Disposal....- 8 -

Disposal of the electronic device ....- 8 -

Battery disposal....-9-

Recycling....- 11 -

Waste disposal....- 11 -

-1-

GB IE NI CY MT

RADIO-CONTROLLED WEATHER STATION

This document is a shorter printed version of the complete instruction manual. By scanning the QR code, you will be taken straight to the Lidl service website (www.lidl-service.com) where you can view and download the complete instruction manual by entering the article number (IAN) 384583_2107.

WARNING! Observe the complete instruction manual and safety notes to prevent personal injury and property damage. The short guide forms an integral part of this product. Prior to using the product, familiarize yourself with all operation and safety notes. Keep the short guide well preserved and if you hand the product on to third parties, all documentation should be passed on as well.

Visit www.lidl-service.com to download this and many other manuals, product videos and software.

PDF ONLINE www.1idl-service.com

With this QR-Code you can reach the Lidl-Service-Site (www.lidl-service.com) directly and you can open your manual by entering the article number (384583_2107).

Introduction

Congratulations on purchasing your new radio-controlled weather station

(hereinafter referred to simply as "device"). You have chosen a high-quality device. The quick-start guide is part of this device. It contains important information pertaining to

-2-

GB IE NI CY MT

safety, and to using and disposing of the device. Please familiarise yourself with all the operating and safety instructions before using this device. Use the device only as described and for the purposes indicated. All documents must be included if the device is passed on to third parties. Please keep the packaging and the quick-start guide for future queries.

Intended use

This device is suitable for displaying the time and for using the additional functions described. Any other use or modification of the device is considered to be improper use. The manufacturer is not liable for damage caused by improper use or incorrect operation. The device is not intended for commercial use.

Explanation of symbols

	WARNING!	This symbol/word indicates a hazard with a medium level of risk, which may result in death or serious injury if the hazard is not avoided.
	Note:	This signal word indicates additional information.
		Improper use of disposable/rechargeable batteries may cause an explosion and/or leakage of battery fluid.
		Alkaline batteries included
		Radio-controlled weather station batteries: 3 x 1.5 V AA R6/LR6

GB IE NI CY MT

		External sensor batteries:2 x 1.5 V AAA R03/LR03, (UM-4)
		Symbol for DC voltage
		Quick-start guide
		Please read the operating instructions!
		By using the CE symbol, digi-tech gmbH declares conformity with the applicable EU directives.
		With the UKCA marking, digi-tech gmbh declares that the product is in conformity with the relevant statutory requirements applicable to the product.
		Temperature indoors/outdoors
		Humidity
		Frost warning
		Range of external sensor: max. 100 mTransmission frequency: 433.92 MHzTransmission power: 0.024 W

GB IE NI CY MT

		DCF77 radio signal
		Radio waves/radio symbol
		Time
		Alarm
		Snooze
		Protection rating provided by the housing (external sensor only): IPX4 (protection from splashing water according to IEC 60529 standard)

Important safety information

Important safety information for users

WARNING! RISK OF INJURY!

This device may be used by persons (including children over 8 years of age) with reduced physical, sensory or mental abilities or lack of experience and knowledge, if they are supervised or instructed regarding the safe use of the device and understand the

-5-

GB IE NI CY MT

dangers that may arise. Children may not play with the device.

Cleaning and user maintenance of the device may not be performed by children without supervision.

Keep packaging films out of the hands of children. There is a danger of suffocation.

Important safety information for the batteries

WARNING!

HEALTH HAZARD!

RISK OF EXPLOSION!

Keep new and old batteries/rechargeable batteries out of reach of small children. If a battery/rechargeable battery is swallowed, medical help must be obtained immediately.

The batteries/rechargeable batteries must always be inserted with the correct polarity. Clean the battery and device contacts

beforehand if necessary. Do not attempt to recharge, short-circuit, or open the batteries/rechargeable batteries.

Never heat the batteries/rechargeable batteries to

recharge them. Do not expose the batteries to excessive heat such as sunshine, fire or the like. There is an increased risk of leakage!

Never throw batteries/rechargeable batteries into fire, as they can

GB IE NI CY MT

explode. Improper use of the batteries/rechargeable batteries poses a risk of explosion and leakage of the battery fluid. If the batteries/rechargeable batteries should leak, avoid contact with skin, eyes and mucous membranes. Use gloves. In the event of contact with battery fluid, immediately rinse the affected areas with plenty of clean water and consult a doctor immediately. Remove exhausted batteries/rechargeable batteries from the device immediately, there is an increased risk of leakage.

Note:

• Non-rechargeable batteries must not be recharged.
- Different battery types or new and used batteries must not be used together!
- Do not short-circuit the supply terminals.
- Empty batteries / rechargeable batteries must be removed from the device and safely disposed of (see Disposal of batteries)!
- If the device is stored unused for a longer period of time, the batteries / rechargeable batteries should be removed.

Simplified EU declaration of conformity

Hereby, digi-tech gmbh declares that the radio-controlled weather station 4-LD5882 is in compliance with the RED 2014/53/EU, article 10 (8) directive.

-7-

GB IE NI CY MT

Note:

You can download your instruction manual and declaration of conformity here: www.diqi-tech-qmbh.com/downloads

Then click on the magnifying glass and enter the IAN 384583_2107

Disposal

This device and all the packaging materials are recyclable. Please dispose of them separately for better waste handling. You can find out about disposal options for your product by contacting your municipality.

Please take note of the marking of packaging material when separating waste materials. They are marked with abbreviations (a) and numbers (b) with the following meanings:

1-7: plastics

20-22: paper and cardboard

80-98: composite materials.

Disposal of the electronic device

Remove the batteries before disposal and dispose of them separately (see Disposal of the batteries). This device and the outdoor sensor are subjects to the European Directive 2012/19/EU. The symbol of the crossed-out wheelie bin indicates that the product must be disposed of separately in the European Union. Labelled products cannot be disposed of with normal household waste, but must be handed in at a collection point for the recycling of electrical and electronic equipment.

In the interest of the environment, when your device has reached the end of its usefulness, do no throw it in the normal household trash. Dispose of it in the proper and correct way. You can find out about collection sites and their business hours from your public administration. Please adhere to applicable requirements.

GB IE NI CY MT

Battery disposal

The accompanying symbol indicates that batteries and rechargeable batteries must not be disposed of with normal household waste. Defective or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Consumers are legally obliged to dispose of all batteries and rechargeable batteries, regardless of whether the contain harmful substances such as: Cd = cadmium, Hg = mercury, Pb = lead lithium or not, at a collection point in their municipality/district or at a retail or for environmentally friendly disposal and for the recovery of valuable raw materials such as cobalt, nickel or copper.

The return of batteries and accumulators is free of charge.

WARNING!

Environmental damage through incorrect disposal of batteries / rechargeable batteries!

Some of the possible materials such as mercury, cadmium and lead are poisonous and, if not disposed of properly, endanger the environment. For example, heavy metals can have harmful effects on the health of humans, animals and plants and accumulate in the environment and in the food chain, and can then enter the body indirectly via food.

-9-

GB IE NI CY MT

WARNING!

Danger of explosion!

With used batteries containing lithium (Li = lithium) there is a high risk of fire. Therefore, special attention must be paid to the proper disposal of used batteries and rechargeable batteries containing lithium. Incorrect disposal can also lead to internal and external short circuits due to thermal effects (heat) or mechanical damage. A short circuit can lead to a fire or an explosion and have serious consequences for humans and the environment.

For this reason, tape off the poles of lithium-based batteries and rechargeable batteries prior to disposal in order to avoid an external short circuit.

Batteries and rechargeable batteries that are not permanently installed in the device must be removed and disposed of separately before disposal of the device.

Please return batteries and rechargeable batteries only when they have been discharged!

Use rechargeable batteries instead of disposable batteries whenever possible.

Recycling

The product packaging consists of recyclable materials. Please dispose of them properly at the available collection sites.

Waste disposal

Dispose of the packaging in an environmentally responsible fashion. Please note the marking of the different packaging materials and separate them if applicable.

GB IE NI CY MT

DRAADLOOS WEERSTATION

www.digi-tech-gmbh.com/downloads

Imported for GB market by:

Lidl Great Britain Ltd,

Lidl House,

14 Kingston Road,

Surbiton, KT5 9NU

PDF ONLINE www.1idl-service.com

digi-tech gmbh

Valterweg 27A

65817 Eppstein

GERMANY
