USER MANUAL CGGNR3PL FAR

Black and white photo of a modern kitchen grater with a control knob (no visible text or symbols)

Model CGGNR3PL G

MANUEL D'UTILISATION

Technical diagram showing exploded and assembled views of a robotic vacuum cleaner with labeled components

Thank you to have chosen the FAR quality. This product has been created by our professional team and according to the European regulation. For a better use of your new device, we recommend you to read carefully this user manual and keep it for record.

TABLE OF CONTENTS

SAFETY INSTRUCTIONS GB-2

PRODUCT INTRODUCTION ....GB-6

ASSEMBLY GB-6

BEFORE FIRST USE ....GB-7

OPERATION GB-8

CLEANING AND CARE GB-12

STORAGE GB-13

TROUBLESHOOTING GB-14

TECHNICAL SPECIFICATION ....GB-14

DISPOSAL OF OLD ELECTRICAL APPLIANCES ....GB-15

CUSTOMER SERVICE GB-16

PURCHASE PRODUCT AT CONFORAMA STORE ....GB-16

PURCHASE PRODUCT AT BUT STORE ....GB-17

SAFETY INSTRUCTIONS

Read these safety instructions carefully before using your appliance and keep them safe for future reference.

• This appliance is intended to be used in household and similar applications such as:
• staff kitchen areas in shops, offices and other working environments;
• farm houses;
• by clients in hotels, motels and other residential type environments;
• bed and breakfast type environments.

- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

- Keep the appliance and its cord out of reach of children less than 8 years.

- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

- The appliance is not intended to be operated by means of an external timer or separate remote-control system.

- CAUTION: Hot surface. The temperature of surfaces may be high when the appliance is operating.

- The outer surface may get hot when the appliance is operating.

- Regarding the instructions for cleaning surfaces in contact with food thanks to refer to the below paragraph of the manual.

- Never leave children unsupervised with the packaging materials. The packaging materials pose a danger of suffocation. Children frequently underestimate the dangers. Always keep children away from the packaging materials.

- Close supervision is necessary when the product is used by or near children.

- Misuse may lead to injury. Use this product solely in accordance with these instructions. Do not attempt to modify the product in any way.

- Risk of burns! During use, the product gets hot. Do not touch the product while in use nor immediately after use.

- Risk of electric shock! Never attempt to repair the

ENGLISH

ENGLISH

product yourself. In case of malfunction, repairs are to be conducted by qualified personnel only.

• Risk of electric shock! Do not immerse the product, the power cord or the power plug in water or other liquids. Never hold the product under running water.
• Unplug from the outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the product.
• Risk of electric shock! Never use a damaged product. Disconnect the product from the power supply and contact your retailer if it is damaged.
• The product may not be used if it has been dropped or if there are visible signs of damage.
• The product is powered at all times while it is connected to the power supply.
• Before connecting the product to the power supply, check that the voltage and current rating corresponds with the power supply details shown on the product's rating label.

• Regularly check the power plug and the power cord for damages. Do not operate the product with a damaged cord or plug or after the product malfunctions or has been damaged in any manner. Return the product to the nearest authorized service facility for examination, repair or adjustment.

• Protect the power cord against damages. Do not let it hang over sharp edges, e.g. edge of table or counter, do not squeeze or bend it. Keep the power cord away from hot surfaces and open flames.

• The use of accessory attachments not recommended by the product manufacturer may result in injuries.
• Do not use it outdoors.
• Do not touch hot surfaces. Use handles or knobs.
• Do not place on or near a hot gas or electric burner or in a heated oven.
• Extreme caution must be used when moving a product containing hot oil or other hot liquids.
• Do not use the product for any use other than the intended.
• Do not pull the power plug out of the electrical outlet by the power cord.
• The product must not be left unattended while it is connected to the power supply.
• Do not move the product while it is in operation.
• Operate the product on a level, stable, clean, heat resistant and dry surface.
• Do not cover the product while it is in use or shortly after use when it is still hot.

PRODUCT INTRODUCTION

Technical diagram of a robotic vacuum cleaner with labeled components and internal structure

1 Lock

2 Red indicator (power)
3 Green indicator (ready)
4 Power cord with power plug
5 Power cord retainer
6 Heating element
7 Large hook catches
8 Release lever

9 Outer catch (small)
10 Inner catch (large)
11 Sandwich plate (upper and lower plate)
12 Grill plate (upper and lower plate)
13 Waffle plate (upper and lower plate)

ASSEMBLY

• Risk of electric shock. Before installing/removing the plates [1203], disconnect the power plug [4] from the wall outlet.
• Risk of burns. Do not install/remove the plates 111213 right after operation.

Let the product cool first.

Installing the plates

• Open the lock ^1 . Open the product.
• Place the inner catch 10 of the chosen plate into the large hook catches 7.
• Push down the plate until it clicks into place.
• Repeat on the other side of the product.
  NOTICE: Install only plates of the same type.

Removing the plates

• Open the lock ^1 . Open the product.
• Pull the release levers 8. Remove the plate.
• Repeat on the other side of the product.

BEFORE FIRST USE

• Remove the packaging. Check if all parts are complete.
• During production, some parts are covered with a thin oil film for their protection. Before first use, operate the product without any food so that any potential residues may evaporate.
• Clean the product and its accessories (see the "Cleaning and care" section).

NOTICE: The first few times the product is heated up, a faint odor may be present. Ensure sufficient

ventilation in the area.

NOTICE: The first food should not be consumed.

OPERATION

Preparation

• Grease the upper and lower exchangeable plates with suitable cooking oil.
• Turning the product on: Connect the power plug to a suitable wall outlet. The red indicator lights up.
• Turning the product off: Disconnect the power plug from the wall outlet. The red indicator goes off.
• Keep the product locked while preheating.
• Preheat until the green indicator lights up.
• This product is designed for making waffles and sandwiches and for grilling food (see the following sections).

Light indicator Status
Red indicator on	Product on.
Red indicator off	Product off.
Green indicator off	Product is preheating/reheating.
Green indicator on	The baking temperature has been reached.

NOTICE: During operation, the green indicator goes on and off from time to time. This indicates that the product is reheating up to the baking temperature.

Suggested baking/grilling times
Sandwiches	3 to 4 minutes
Grilling sausages	4 to 9 minutes (check the degree ofbrowning from time to time)
Waffles (sweet/savory)	5 to 15 minutes

Grilling sandwiches

Suitable for: Sandwich pockets with sweet or savory filling

• Plates: Sandwich plates (upper and lower plate).
• Open the lock. Open the product.
• Place 2 prepared sandwiches onto the lower sandwich plate.
• Close the product. Close the lock. The sandwiches are now being grilled.

NOTICE: Grilling takes approx. 3 to 4 minutes. Depending on how crunchy you want your sandwiches to be, the baking time may be shortened or increased.

• Removing sandwiches: Use a plastic/wooden spatula (or other suitable nonmetallic tools) to avoid damaging the product's non-stick coating.
• While the sandwiches are being grilled, the green indicator will turn off and on again. This is to regulate the required operating temperature.
• When you are done with grilling: Disconnect the power plug from the wall outlet.

Grilling

Suitable for: Grilling smaller meat chunks, sausages or vegetables.

• Plates: Grill plates (upper and lower plate).
• Open the lock. Open the product.
• Place the food to be grilled onto the lower grill plate.
• Close the product. Close the lock. The food is now being grilled.

CAUTION! Danger of splashes. Do not use wet food for grilling. Fat splashes and rising steam will occur when opening the product.

NOTICE: Grilling takes approx. 4 to 9 minutes. Check the degree of browning from time to time.

• Removing the grilled food: Use a plastic/wooden spatula (or other suitable non-metallic tools) to avoid damaging the product's non-stick coating.
• While the food is being grilled, the green indicator will turn off and on again. This is to regulate the required operating temperature.
• When you are done with grilling: Disconnect the power plug from the wall outlet.

Baking waffles

Suitable for: Sweet and savory waffles

• Plates: Waffle plates (upper and lower plate).
• Open the lock. Open the product.
• Use a wooden or heat-resistant plastic ladle to pour batter onto the lower waffle plate. Do not use metal ladles, as this could damage the non-stick surface of the plates.
• Do not overfill the lower waffle plate with batter.
• Close the product. Close the lock. The batter is now being baked.

NOTICE: The baking process takes approx. 5 minutes. Depending on how brown you want your waffles to be, the baking time may be shortened or increased.

• Removing waffles: Use a plastic/wooden spatula (or other suitable non-metallic tools) to avoid damaging the product's non-stick coating.
• While the waffles are baking, the green indicator will turn off and on again. This is to regulate the required operating temperature.
• When you are done with cooking: Disconnect the power plug from the wall outlet.

CLEANING AND CARE

• Risk of electric shock! Before cleaning: Always disconnect the product from the wall outlet.
• Risk of burns! Do not clean the product right after operation. Let the product cool first.
• Do not immerse the product's electrical components in water or other liquids. Never hold the product under running water.
• Clean the product right after it has cooled. Once food residue has dried, it is not easy to remove.
• Do not use any abrasive, aggressive cleaners or hard brushes to clean the product or its accessories.
  • After cleaning: Let all parts dry completely.

Cleaning method

Sandwich maker

• Wipe down the housing with a slightly damp cloth.
• Do not let any water or other liquids enter the product interior.

Sandwich, grill, waffle plates

- Rinse the plates in water and/or mild detergent.

- You can also clean the plates in the dishwasher.

Spaces underneath the plates, heating element, lock

- Removing fat and liquids: Use a piece of kitchen paper.

- Removing stuck-on burnt residue: Use a wooden spatula or small wooden skewers.

STORAGE

• CAUTION! Risk of burns! Do not store the product right after operation. Let the product cool first. Clean the product before storage.
• Do not store the hot product in a cupboard or in the packaging.
• Wind the power cord around the power cord retainer on the bottom of the product.
• Store the product in the original packaging when it is not in use.
• Protect the product, its power cord and power plug against dust, direct sunlight, dripping and splashing water.
• Store the product in a cool, dry place, protected from moisture and out of the reach of children.
• Protect the product against heat. Do not place the product close to open flames or heat sources such as stoves or heating appliances.

TROUBLESHOOTING

Problem Solution
The product is not working.	Connect the power cord to an appropriate wall outlet.
The waffles/sandwiches are too dark.	Shorten the baking time.
The waffles/sandwiches are too light.	Extend the baking time.
The finished waffles/sandwiches are difficult to remove from the product.	Lightly grease the plates before baking. Try using a different batter recipe.

TECHNICAL SPECIFICATION

Voltage/Frequency: 220-240V\~50-60Hz

Power: 750W

DISPOSAL OF OLD ELECTRICAL APPLIANCES

European directive 2012/19/EU on Waste from Electrical and Electronic Equipment (WEEE), requires that used household appliances are not thrown into the normal municipal waste stream. Used appliances must be collected separately in order to optimize the rate of recovery and recycling of materials that compose them, and to reduce the impact on human health and on the environment. The crossed bin symbol is affixed to all the products to remind you of the obligations of separated collection.

CE

Customer service

We decline liability for any damage or accident derived from any use of this appliance which is not in conformity with the instructions contained in this manual.

In accordance with Article L. 217 of the Consumer Code, your product benefits from a legal guarantee of conformity of 2 years.

Purchase product at Conforama store:

This instruction book is also available on our website: www.conforama.fr

If you have a problem with your product, before going to your Conforama store, please get in touch with our aftersales services for electrical household appliances:

http://sav-client.conforama.fr / or call :09 69 32 05 05 from Monday to Saturday, 08:30 to 19:00 price of a local call.

Purchase product at BUT store:

This instruction book is also available on our website: www.but.fr

To contact our After-Sales Service, before going to your BUT store, call 09 78 97 97 97

From Monday to Friday from 9:00 to 19:00,

Saturday from 9:00 to 18:00 (local call price).

CONFORAMA FRANCE
