USER MANUAL Bianca Melchioni

Battery operated electric hand mixer

Batidora electrica con bateria

Melchioni Family thanks you for purchasing this blender.

The new range of cordless products for the kitchen uses the latest technologies available, to offer an innovative, simple and effective user experience, and is the result of a careful study and improvement of the features and functions available. The new products in the cordless range are practical, ergonomic and environmentally friendly: we are sure that the use of these tools will be extremely satisfying both for the occasional user and for the more demanding one.

To take advantage of the numerous functions of this product in the most effective way, we invite you to read the contents of this manual completely and carefully follow the instructions, as well as to keep it for future reference.

Melchioni is also at your complete disposal for clarifications, reports and suggestions regarding its cordless range for the kitchen.

2. IMPORTANT INSTRUCTIONS FOR THE SAFE USE OF THE PRODUCT

• Remove the appliance from the packaging and make sure it is intact. If you are unsure of its condition, contact your dealer. Keep plastic bags, paper clips and other packaging components out of the reach of children.
• Before connecting the charger to the mains, make sure that the voltage of your home system corresponds to that indicated on the charger.
• The charger must be connected to a compliant electrical system. The electrical system must have a nominal power equal to or greater than that of the charger.
• Use the device only for the purposes described in this manual. Any other use could cause injury to the user or damage to the product.
• The manufacturer and the distributor cannot be held responsible for any damage caused by using the appliance that does not comply with what is indicated in this manual.
• The product, including the charger, is designed for domestic and indoor use: it is not intended for intensive professional use or outdoor use.
• Do not expose the device to rain, solar radiation or the action of other atmospheric agents.
• During the charging phases, always place the device on a flat, stable and horizontal surface; also make sure that unpredictable environmental conditions (e.g. drafts, rain, etc.) cannot cause them to fall or move.
• When the appliance is not in operation, make sure that the activation switch is in the off position. Keep potentially dangerous parts of the appliance away from children.
• In the event of any damage to the appliance, contact an authorized Technical Assistance Center.

• This appliance is not to be used by persons with reduced sensitivity, physical or mental disabilities or persons who are unable to use the appliance, unless supervised or instructed by a person responsible for their safety.

• Make sure that children do not play with the appliance or the packaging.

• Do not connect the charger to extension leads or multiple sockets.
• Do not bend or damage the charging cable.
• The product is equipped with a circuit for maintaining the charge, therefore it can be left connected to the charger even after the end of charging; however, it is necessary to disconnect it during the assembly and disassembly of accessories, during use or if you plan not to use it for a long time.
• Do not use timers or other devices that independently control the power supply of the charger; unsupervised start-up of recharging could entail risks to safety and security, should unforeseeable environmental circumstances arise.
• Do not use the appliance (cable and power adapter included) in excessively hot or cold, dusty, humid environments, in the presence of atmospheres saturated with gas or chemical vapors.
• The appliance must not be used if it has obvious overheating or deformations, or if it emits smoke or bad smells: in this case, stop using it and contact a specialized technical service.
• Do not run continuously for more than 60 seconds at a time. After one minute of use, ensure at least three minutes of shutdown to ensure proper cooling of the moving parts.
• Do not disassemble the product, even after its disposal: any repairs or checks must be carried out by specialized technical personnel.
• The cleaning operations must be performed after the complete shutdown of the device, preferably in conditions of flat batteries: refer to the next chapter for the relevant requirements.
• Do not touch the end of the product while it is in operation.
• During operation, the appliance is subjected to minimal heating; if this should be clearly noticeable, stop using it and wait a few moments before restart.
• Work with quantities of food appreciably lower than the capacity of the container used, especially if the food is hot or boiling: this will avoid overflows, potentially dangerous, both by contact and by immersion of surrounding objects.
• The appliance is equipped with very sharp blades: pay close attention during use and cleaning, since a sudden start, due to clumsy operations, could result in injury or further dangerous situations for the user.
• Prevent water or other liquids from entering the appliance.
• Do not immerse the motor body of the appliance, the charger or the cable in water or other liquids, to avoid possible electric shocks.
• Do not let the cable come into contact with hot surfaces.
• Do not place the appliance near a gas stove or other heat sources.
• During operation, keep at least 50~cm of space around the appliance on all sides, to ensure the necessary maneuverability.
• During operation, pay particular attention that no objects come into contact with moving parts, especially hair, clothing, cutlery or other kitchen utensils.
• Do not clean with metal abrasive sponges, the residues of which can create situations of electrical risk or pass through food material during use.
• Do not use the appliance to shred materials other than food; the circumstance could pose a risk to the user, due to sudden damage, as well as jeopardizing the correct functioning and the cutting edge of the blade.

• Do not use the appliance to mix materials that are too hard; this could pose a risk to the user, due to sudden damage, as well as jeopardizing the correct functioning and the efficiency of the whips.

• The appliance must only be started up if it is already immersed in the bowl containing the food material: operation in free air must be avoided; this occurrence causes unnecessary wear, deterioration of performance and energy waste.
  Periodically check the integrity of the appliance and in any case at the end of each use: if any damage or lack of parts is detected, discard the food and never proceed with its consumption.

• Do not use outdoor.
• Once it reaches the end of its life, the device must be disposed of in accordance with the requirements of the local authority on environmental protection; in any case, the utmost attention must be paid to ensure that the disposal of the product results in the lowest possible environmental impact.

3. PACKAGE CONTENTS

When unpacking for the first time, check that the package is complete and includes:

• Blender motor body
• Stainless steel whisks (2)
• Charger for mains voltage
• Charging cable type USB-C
  This manual

If one or more parts are missing or damaged, contact the dealer for reinstatement.

4. PARTS IDENTIFICATION

A = Whisks ejection button

B = Speed selector

C = Charging indication

D = Motor body

E = Whisks

On the opposite side, in the lateral part of the motor body, it is also possible to identify the connector for recharging the battery, equipped with a USB-C socket.

F = USB-C charging cable

G = Battery charger

5. USE

Battery charging: The blender is supplied with a not fully charged battery: for best performance it is advisable to fully charge it before use. Recharging is carried out, strictly with speed selector in position 0, connecting the charging cable to the appropriate socket provided with the charger, then connecting the USB-C connector to the charging socket located on the side of the motor body, taking care to disconnect and slightly move the protective rubber gasket. The insertion must be carried out gently and thoroughly, until a click is heard in correspondence with the total insertion; the connector is reversible, therefore it can also be inserted upside down. Once you have verified the correct insertion of the plug, insert the charger into the wall socket and check that the recharge starts with the sequential lighting of the LEDs of the indicator, with a number of LEDs gradually increasing until fully recharged, that is when all the LEDs are on steady. This operation must be performed every time the charging indicator lights up with a single LED; the charging time is approximately 4 hours. When charging is complete, disconnect the USB cable from the motor body and the charger from the wall socket and replace the rubber gasket on the charging connector. During recharging, the start of rotation is electronically prevented.

Whisks application: Before first use, it is advisable to wash the whisks with normal dish detergent: avoid washing in the dishwasher. Before use, the whisks must be connected to the motor body: insert the kingpin of the first whip into one of the two holes on the lower part of the motor body. Rotate the whip by pressing it towards the motor body, until you hear a further insertion with the relative double click; carry out the same operations with the second whip. The blender is ready for use.

Whisks disconnection: The whips are removed by gripping the mixer with the selector in position 0 and pressing the eject button located above the selector itself: the whips will be automatically ejected. Pay attention that the whisks, when ejected, cannot fall into uncontrollable areas, creating situations of potential danger or damage. During rotation, pressing the eject button is mechanically prevented.

Food preparation: The food material must have a fluid consistency, in order to avoid that the operation is difficult or that the engine can be damaged; the treatment of too dense material will be difficult, ineffective and potentially dangerous, also due to the excessive torsion that must be

physically opposed by the user. It is advisable to slightly hydrate the food if it is too dry, compatibly with the expected result. Avoid overloading the container in which you intend to perform the mince, in order to prevent it from overflowing with rotation.

Using the blender: The appliance must be strictly started only if immersed in the bowl containing the food material: operation in free air must be avoided. To start the operation, move the selector progressively from position 1 to 5, alternating each speed change by a few seconds, in order to make the rotation more docile and manageable, up to the ideal speed for the preparation in progress. To obtain the best result, it is advisable to keep the blender at a distance of a few millimeters from the bottom of the container and favor a circular movement around its perimeter, as well as tilt it slightly to facilitate the blending of the parts; lifting and slightly re-immersing the blender in the bowl can be further useful. Ensure at least ten minutes of shutdown after three minutes of continuous operation, in order to ensure the cooling of the moving parts: this precaution avoids damage and improves the reliability and life of the appliance. Avoid contact of any object unrelated to the food material or part of the body with the moving parts.

At the end of use: Disconnect the whips as described above and wash them as soon as possible, in order to prevent the food material from forming encrustations that are difficult to remove: use running water and, if necessary, common degreasing liquid soap for dishes. During cleaning it is always advisable to wear kitchen gloves; do not wash in the dishwasher. The motor body can be cleaned with a simple damp cloth; in all cases avoid immersing it or putting it under running water and wait for it to dry completely before putting it back into service.

6. PROBLEM E POSSIBILI SOLUZIONI

Problem Possible cause	Use Probable solution
The blender does not start The battery is dead Recharge the battery as described in chap. 5
The blender has not started Start the mixer by carefully following the instructions in chap. 5
The blender stops suddenly Excessive effort was required from the engine		Decrease the density of the food material, move the selector to 0 and start again
The blender does not mix effectively	The selected rotation speed is too low	Increase the rotation speed as indicated in chap. 5
	The food is too dry Increase the food hydration
The whips do not disengage The release button was not pressed hard enough		Press the button harder; it may be helpful to lean on a flat, solid surface
The whips remain stuck in the motor body		Exert a slight pull on the whips to extract them

Any further cases of malfunction may in any case occur, as well as those indicated could depend on other causes and require further treatments; in these cases, however, it is not possible to work effectively for the solution and it is necessary to contact an authorized service center.

7. TECHNICAL DATA

Model: BIANCA-Cod.118420040

Working voltage: 7,4 V DC

Motor power : 150 Watt

Maximum rotation speed: 16.500 giri/min

Batteries : 2 lithium ion elements 3,7 Volts DC 2000 mAh

Battery charger : 5 Volts DC 2000 mA

Charging duration: Approximately 4 hours for full charge

Autonomy : Up to 30 minutes depending on the treated material

1.PRODUCT CONFORMITY

The producer Melchioni Spa declares that the product Battery operated electric hand mixer-Model BIANCA (cod. 118420040) is in compliance with Directive 2014/30/EU of the European Parliament and of the Council, of 26 february 2014, on the harmonisation of the laws of the Member States relating to electromagnetic compatibility.

The producer Melchioni Spa declares that the product Battery operated electric hand mixer-Model BIANCA (cod. 118420040) is in compliance with Directive 2009/125/EC of the European Parliament and of the Council, of 21 octber 2009, establishing a framework for the setting of ecodesign requirements for energy-related products.

The producer Melchioni Spa declares that the product Battery operated electric hand mixer-Model BIANCA (cod. 118420040) is in compliance with Directive 2011/65/EU of the European Parliament and of the Council, of 8 June 2011 and subsequent Commission Delegated Directive 2015/863, on the restriction of the use of certain hazardous substances in electrical and electronic equipment.

According to Directive 2012/19/EU of the European Parliament and of the Council, of 4 July 2012, on waste electrical and electronic equipment (WEEE), the presence of the crossed-out bin symbol indicates that this appliance is not to be considered as urban waste: its disposal must therefore be carried out by separate

collection. Disposal in a non-separate manner may constitute a potential harm to the environment and health. This product can be returned to the distributor when purchasing a new device. Improper disposal of the appliance constitutes misconduct and is subject to sanctions by the Public Security Authority. For further information, contact the local administration responsible for environmental matters.

2. WARRANTY

Melchioni Spa, based in Milan (Italy), via Colletta 37, recognizes a conventional guarantee on the product for a period of two years from the date of the first purchase by the consumer. This guarantee does not affect the validity of the legislation in force concerning consumer goods (Legislative Decree 6 September 2005 n. 206 art. 128 and following), of which the consumer remains the owner. This guarantee applies to the entire territory of the European Union.

The components or parts that are found to be defective for ascertained manufacturing causes will be repaired or replaced free of charge through the dealer, during the above warranty period. Melchioni Spa reserves the right to make a complete replacement of the device, if repairability is impossible or excessively expensive, with another device of similar characteristics (Legislative Decree 6 September 2005 no. 206 art. 130) during the warranty period. In this case, the validity of the warranty remains that of the original purchase: the service provided under warranty does not extend the warranty period.

In any case, this appliance will not be considered defective in terms of materials or manufacture should it be adapted, changed or adjusted, in order to comply with national or local safety and / or technical standards, in force in a country other than that for which it is was originally designed and manufactured. This appliance has been designed and built for domestic use only: any other use will invalidate the benefits of the guarantee.

The warranty does not cover:

• parts subject to wear or tear, nor those parts that require periodic replacement and / or maintenance
• professional use of the product
• malfunctions or any defects due to incorrect installation, configuration, software / BIOS / firmware update not performed by authorized Melchioni Spa
• repairs or interventions carried out by persons not authorized by Melchioni Spa
• manipulation of assembly components or, where applicable, of the software
• defects caused by fall or transport, lightning, voltage fluctuations, liquid infiltration, opening of the appliance, bad weather, fire, public disturbances, inadequate ventilation or incorrect power supply
• any accessories, for example: boxes, bags, batteries, etc. used with this product
• home interventions for convenience checks or presumed defects

The recognition of the guarantee by Melchioni Ready S.r.l. is subject to the presentation of a tax document that proves the actual date of purchase. The same must not show any tampering or deletions, in the presence of which Melchioni Spa reserves the right to refuse the provision of treatment under warranty.

The warranty will not be recognized if the serial number or model of the appliance is non-existent, abraded or modified.

This warranty does not include any right to compensation for direct or indirect damage, of any nature, to people or things, caused by any inefficiency of the appliance. Any extensions, promises or services in this regard, insured by the retailer, will be borne by the latter.
