Sicherheitshinweise

Electronic Appliance

Co., Ltd.

Warning! Do not use the charger in the vicinity of water or high levels of

humidity, for example in a damp cellar or close to a swimming pool or bathtub.

• This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they are being supervised or have been instructed concerning use of the product in a safe way and understand the hazards involved.
• Children shall not play with the product.
• Cleaning and user maintenance shall not be carried out by children unless they are supervised.
• Warning! For the purposes of recharging the battery, only Detachable adaptor use the detachable supply unit KH6-050100EUL provided with this appliance.

English

Safety instructions

e power supply unit shall not be used, if pins of the plug part are damaged.

• Never expose rechargeable batteries to excessive heat (e.g. bright sun, fire), and never throw them into fire. The rechargeable batteries could explode.

• The rechargeable battery is permanently built into the product and cannot be replaced.

• When disposing of the product, please consult an electrician or your retailer to remove and dispose of the built-in batteries in an environmentally friendly manner.

• Never short-circuit the contacts of the rechargeable battery. Do not throw the rechargeable battery or the product into fire. There is a danger of fire and explosion!

Safety instructions

• Never charge the rechargeable battery of the product unattended.

• Read this user manual thoroughly before first use and pass it on with the product. Pay attention to the warnings on the product and in this user manual. It contains important information for your safety as well as for the use and maintenance of the equipment.

• Use the product only for its intended purpose and with recommended accessories and components. Improper use or wrong operation may lead to hazards.
• Never leave the product unsupervised while it is switched on.
• Do not under any circumstances attempt (e.g. damage in power cord, product has been dropped, etc.) to repair the product yourself. For servicing and repairs, please consult an authorised service agent.
• Use this product in indoor areas only and never outdoors.
• Never use, expose or put the product near to: direct sunlight and dust; fire (fireplace, grill, candles), water (water splashes, vases, ponds, bath tube) or heavy moisture (this is applicable, for all non water-proof components).
• This product is not intended for commercial use. It is designed for household use only.
• Clean the product and all other accessories after each use.
• Follow the instructions in the chapter Cleaning and care.

• The shaver is suitable for being cleaned under running water.

• Attention! The handheld part must be disconnected from the connection line before being cleaned with water.

• Important! Check to ensure that the product is in a serviceable condition before use. The product shall not be used if it shows any signs of damage or if it's suspected to be defect.

English

Congratulations!

Thank you for your purchase of KOENIC product Please read this manual carefully and keep it for future reference.

Intended use

This product is only suitable for trimming body hairs, with or without shaving cream, as well as for trimming beards and sideburns. This product is not intended for commercial use. It is designed for household use only. Any other use may result in damage to product or injuries.

The Imtron GmbH assumes no liability for damage to the product, for property damage or for personal injury due to careless or improper usage of the product, or usage of the product which does not meet the manufacturer's specified purpose.

Before first time use

Remove the product and accessories carefully from the original packaging. Inspect the delivery contents for completeness and damages. Should the delivery contents be incomplete or damaged, contact your sales outlet immediately.

Note

• For first time use, charge the product for at least 1.5 hours. The general charging time is about 1.5 hours which also depends on the condition of the battery.
• When the battery is fully charged, the product can be used for 60 minutes. The time may vary (depending on the battery condition).

Content

1 x Body Trimmer
1xUSB charger
1xUSB cord
2 × Replacement trimmer head
3 × Trimmer combs
1 x Cleaning brush
1 x Storage bag
1 × User manual

Controls and Components

A Storage bag
B Charger with USB cable
C Trimmer attachment 5 mm
D Trimmer attachment 3 mm
E Trimmer attachment 1 mm
F Cleaning brush
USB C charging socket with indicator light
H Replacement trimmer head (x2)
1 On/Off button
1 Shaving head

Technical Data

Shaver

Battery operated (motor): 3.0 V---

Rated input voltage/ :5V=1A

current

IP code: IPX7

Re-chargeable battery: Li-lon, 3.7 V
600 mAh

Charger

Manufacturer: Ningbo KAM HOI

Electronic Appliance

Co., Ltd.

Imported by: Imtron GmbH,

Media-Saturn-Strasse 1,

85053 Ingolstadt,

Germany.

Commercial registration : HRB 4580

number

Model: KH6-050100EUL

Input voltage:100-240V~

Input AC frequency : 50/60 Hz

Output voltage: 5 V

Output current:1.0A

Output power: 5.0 W

Average active efficiency : 74.63 %

Efficiency at low load : NA

(10%)

No-load power : 0.06 W

consumption

Protection class : II

Preparation

Fig.1 Connect the USB C plug with the USB C charging socket, the USB A plug with the charger and the charger with a suitable socket outlet. The charging indicator light shines red while charging and blue when the battery is fully charged. Charge the battery for at least 1.5 hours before first use.

Low battery warning:

When the battery is less than 10% the indicator light keeps on flashing red.

Operation

Fig 2 Switch on the hair trimmer

• Switch on the device by pressing the on/off button.
  To switch off the device press the on/off button again.

Fig. 3 Hair / beard trim and cut

Note

Do not use the product with:

• Skin wounds
• Inflamed skin
• Sunburn
• Pimples and blisters

The hair to be cut should be clean.

Longer hair should be shortened before using the hair clipper.

1. Choose a trimmer attachment (1 mm, 3 mm, 5 mm), depending on the desired hair or beard length and push it on the shaving head until it clicks into place.
2. Follow the point Switch on hair trimmer.
3. If necessary shorten the hair gradually.
4. Guide the hair trimmer slowly through the hair. Hold the hair and beard trimmer in such a way that the trimmer attachment rests as flat as possible.

Note

Depending on the position and angle of the trimmer, the cutting lengths may differ.

1. Without a trimmer attachment hair can be completely cut off.

Body trimmer

Fig 4 Remove trimmer attachment

1. Use moderate force to pull off the trimmer attachment with your thumb and forefinger.
2. Remove the trimmer attachment.
3. Without trimmer attachment the hair is shaved down to the skin.

Shaving legs

• Hold the trimmer in such a way that the long hair trimmer and the shaving blade touch the skin with the same amount of pressure.
• Slowly guide the trimmer along the skin in the opposite direction of the hair growth, applying a slight pressure.

Shaving armpits

It is particularly important that the skin is tautened. This can easily be achieved in the armpit area by holding the arm high above the head.
Armpit hair grows in different directions. For this reason it is necessary to shave several times and in different directions in this area.

Trimming bikini area

To trim the hair to a specific length, you can use a trimming attachment.
- Slowly guide the device with the trimmer in the opposite direction of the hair growth.

Wet shaving

Wet your skin and apply a thin layer shaving foam to the parts which shall be shaved.
- Follow steps as given above in chapter Shaving

Note

Only proper shaving foam may be used with the razor, as shaving gel will gum up the shaving head and impair the result.

English

Travel lock

Activate: Press the on/off button for 3 seconds to activate the travel lock. The indicator light flashes in blue.

Deactivate: If the indicator light flashes in blue when you want to switch on the product, then the travel lock is activated. Press the on/off button for 3 seconds to deactivate the travel lock. The product turns on.

Cleaning and care

Warning

When cleaning, never use solvents or abrasive materials, hard brushes, metallic or sharp objects. Solvents are harmful to human health and can attack plastic parts, while abrasive cleaning mechanisms and tools may scratch the surface(s).

Fig. 5 After every use, please use the cleaning brush to thoroughly brush and blow out hair.

• Danger! Be carefully when removing and inserting the shaving head to avoid injury.
  Clean the outside of the product with a slightly damp cloth and dry well.
• Remove the shaving head by turning it to the left (as seen from above). Take it off.
  Clean the shaving head and the holder with the provided brush. If necessary, blow out the corresponding parts.
• Put the shaving head back on the holder so that both arrows are aligned and lock it by turning it to the right (seen from above).
  The shaver is suitable for being cleaned under running water.
• Keep the product in a dry, cool location which is protected against moisture and direct sunlight. Keep this product out of the reach of children.

Troubleshooting

If there are any problems during operation, please refer to the following table. If the problems cannot be solved as indicated under Solution, please contact your sales agent.

Problem Possible causes Solution
Product does not work • Interrupted power supply • Batteries empty • Travel lock is activated	Check the power supply Re-charge batteries Deactivate the travel lock
LED indicator does not light on during charging batteries	No power supply Charging cord is not connected to product	Check the power supply Check the charging cord connection
Shaving head not moving smoothly	Impurities accumulated on the shaving head	Clean the shaving head
