USER MANUAL KGS 1524 B Koenic

KOENIC Get ready for compliments Garment Steamer CE 2018 ■ I have the following: ■ I have manual: ■ I have de revoudrtes: ■ I have in line: ■ I have not in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: ■ I have the following: ■ I have manual: ■ I have de revoudrtes: ■ I have in line: ■ I have not in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: I have in line: ■ I have the following: ■ I have manual: ■ I have de revoudrtes: ■ I have in line: ■ I have not in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I has in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: ■ I have in line: □ I have the following: □ I have manual: □ I have de revoudrtes: □ I have in line: □ I have not in line: □ I have in line: □ I have in line: □ I have in line: □ I have in line: □ I have in line: □ I have in line:

Exploded view diagram of a hair dryer with labeled parts including covers, buttons, and accessories

Sicherheitshinweise

• The product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and/or knowledge if they have been given supervision or instruction concerning the use of the product in a safe way and understand the hazards involved.
  • Children must not play with the product.
• Cleaning and user maintenance must not be carried out by children unless they are older than 8 years and are supervised.
• The mains cable must be inspected regularly for signs of damage and if it is damaged, the product must not be used.
• To avoid hazards, a damaged mains cable may only be replaced by the manufacturer, a workshop authorised by the manufacturer or a similarly qualified person.
• The product must be connected to an earthed socket.
• The appliance must be disconnected from mains power during filling and cleaning.
• No water may be left in the water tank when the appliance is not in use.
• The product must be emptied and cleaned before storage. The product must be cleaned before the next use.
• Note that high humidity can promote the growth of biological organisms in the environment.

Safety instructions

- The environment around the garment steamer must not be allowed to become damp or wet. If moisture occurs, the output must be reduced. If the discharge cannot be reduced, the garment steamer may only be used periodically. Absorbent materials such as carpets, curtains, drapes or tablecloths must not be allowed to become damp.

- Observe the chapter Cleaning and care.

1. Read this user manual carefully before first use. It contains important information for your safety and for the use and care of the product. Keep the user manual for future reference and pass it on with the product. Observe all warnings on the product and in this user manual.
2. Only use the product for its intended purpose. Improper use can lead to hazards. If you do not use the product as intended or operate it incorrectly, no liability can be accepted for any resulting damage.
3. Never leave the product unattended while it is switched on.
4. Do not place any objects on the product.
5. Do not immerse electrical parts of the product in water or other liquids during cleaning or operation. Do not hold the product under running water.
6. Do not attempt to repair the product yourself. Return the product to a specialist dealer or a qualified customer service for maintenance and repair.
7. The mains voltage must match the specifications on the rating plate.

8. The mains plug serves as a disconnecting device. Ensure that it is always easily accessible and within reach. Only the mains plug can completely disconnect the product from mains power.

9. Avoid damaging the mains cable by kinking it or bringing it into contact with sharp edges.

10. Keep the product, including the mains cable and mains plug, away from heat sources such as radiators, ovens and other products that generate heat.
11. Only disconnect the mains plug from the socket by pulling on the plug itself. Do not pull on the mains cable.

12. Disconnect the mains plug ...

13. when the product is not in use,

14. if malfunctions occur,
15. before attaching / removing accessories and

16. before cleaning the product.

17. This product is not suitable for commercial use. It is designed for domestic use only.

18. Do not leave the product unsupervised.
19. The use of accessories and product parts not expressly recommended by the manufacturer may cause personal injury or damage and will invalidate the warranty.
20. If the mains cable or the housing of the product is damaged or the product has been dropped, it must not be used any further until it has been checked by a specialist.
21. Only use the product in dry indoor areas, never outdoors.

Safety instructions

1. Protect the product from

2. direct sunlight and dust,

3. fire (fireplace, barbecue, candles), water (splashes, vases, bathtub) and high humidity.

4. Do not use any chemical additives, fragrances or descaling agents. Failure to do so will invalidate the warranty.

5. To avoid hazards, a damaged mains cable may only be replaced by the manufacturer, a workshop authorised by the manufacturer or a similarly qualified person.

6. Warning! Only use clean tap water without any additives.

7. Clean the product and accessories after each use.

8. Do not leave the garment steamer near fabrics or flammable materials for long periods of time.

9. Do not leave the appliance plugged in unnecessarily. Unplug the appliance when it is not in use.

10. Do not touch the appliance with wet or damp hands.

11. Do not fill the water tank with water before unplugging the appliance.

12. Touching hot metal parts, hot water or steam can cause burns. Be careful when turning the garment steamer upside down - there may be hot water in the container.

13. If the power indicator flashes red, the steam brush is not working normally. Disconnect the appliance from power supply and have it repaired by an authorised customer service.

Congratulations!

Thank you for purchasing a KOENIC product. The garment steamer with its vertical steam for smoothing hanging textiles is intended exclusively for private household use. A steam output of up to 20 g/min is available, which can also be released constantly with a heating time of just 20 seconds using the snap-in function. The drip-stop function prevents unwanted water leaks and the automatic switch-off function ensures low power consumption. The removable water tank holds 250 ml. The attachments supplied ensure crease-free ironing and the long connection cable offers extra freedom of movement. Please read the user manual carefully and keep it for future reference.

Intended use

This product is intended exclusively for vertical smoothing of hanging textiles for private household use. Any other use may result in damage to the appliance or personal injury. Imtron GmbH accepts no liability for damage to the product, damage to property or injury due to careless, improper, incorrect use of the product or use of the product for a purpose other than that specified by the manufacturer.

Before first time use

Carefully remove the product and accessories from the original packaging. It is advisable to keep the original packaging for later storage. Please observe the applicable legal regulations when disposing of the original packaging. If you have any questions about proper disposal, please contact your local authority. Check the delivery for completeness and damage. If anything is missing or damaged, contact your specialist dealer immediately. Clean the product after unpacking, see section Cleaning and care.

Content

1 x Garment steamer
1 x Brush attachment (removable)
1 x Steam protection attachment (removable)
1 x ironing glove
1 x Instruction manual

Technical data

Rated voltage : 220-240V\~ Power : 1370-1630W Rated frequency : 50/60Hz Protection class : I Water tank : 250ml Weight : 1.00kg (without accessories) Dimensions : 13.4x11.0x27.2cm

Controls and components

A Steam protection attachment
B Brush attachment
c Garment Steamer
D Steam button and steam lock button
Water tank
F Mains plug
G Main switch I/O
H Ironing glove

Operation

Note

When using the steam brush for the first time, you may notice a slight amount of smoke and hear some noises caused by the expanding plastics. This is completely normal and will subside after a short time. We also recommend running the garment steamer over a cloth before using it for the first time.

Ironing glove

The ironing glove could also be described as a “mobile mini ironing board” - and that is precisely its purpose. If you are right-handed, pull the ironing glove over your left hand while holding the garment steamer in your right hand. If you are left-handed, it works the other way round. Move the glove behind the garment to be ironed while ironing it with the garment steamer. The ironing glove is heat-resistant and protects you from burns.

Anti-scaling system

A special resin filter in the water tank softens the water and prevents limescale deposits on the heating element. The resin filter is permanent and does not need to be replaced. Only use tap water. Distilled and demineralised

water renders the anti-scaling system ineffective as it changes its physical and chemical properties.

Do not use any chemical additives, fragrances or descaling agents. Failure to do so will invalidate the guarantee.

Fig. 1 Press the water tank lock button and remove the water tank from the housing. Open the filler opening. Fill the tank with water, taking care not to exceed the maximum fill level of 250 ml. Close the filler opening again.

Fig. 2 Place the water tank back on the housing.

Fig. 3 Attach the brush attachment to the front of the appliance until you hear it click into place. Press the rear part of the brush and it will automatically detach from the housing.

Fig. 4 Attach the steam protection attachment to the front of the appliance until you hear it click into place. This allows you to achieve drier ironing effects. Press the rear part of the steam protection attachment and it will automatically detach from the housing.

Fig. 5 Insert the mains plug into a suitable socket.

Fig. 6 Set the main switch I/O to I. The garment steamer starts to heat up and the power LED flashes blue for about 20 seconds. When the heating process is complete, the power LED lights up blue.

Fig. 7 ① Press the steam button to iron with steam. ② If you require constant steam, press the steam lock button downwards.

Note

The power LED flashes blue during heating. If you press the steam button at this time, no steam can be generated. Steam will only be released by the electronic control once the heating process is complete.

Automatic switch-off

If the steam brush is switched on and the water pump does not work for more than 8 minutes, the appliance switches off automatically. In this case, the blue power LED goes out and flashes red instead. Press the steam button to allow the appliance to heat up again (the LED flashes blue) and to restart (the LED lights up blue).

Cleaning and care

Before cleaning the steam brush, you must disconnect it from mains power.

Deposits or starch residues on the heating element can be wiped off with a damp cloth or a non-abrasive liquid cleaner.

The plastic parts can be cleaned with a damp cloth and then wiped with a dry cloth.

You can wash the ironing glove carefully in warm soapy water. Allow it to dry completely afterwards. Do not dry it in direct sunlight.

Warning!

Do not immerse electrical parts of the product in water or other liquids during cleaning. Do not hold the product under running water.

Warning!

Never use solvents, abrasive cleaners, hard brushes, metal or sharp objects for cleaning. Solvents are harmful to health and attack the plastic parts; abrasive cleaners and aids scratch the surface.

Storage

Fill the tank with clean water and shake it carefully. Then pour the water out of the tank. Allow the steam brush to cool down completely. Roll up the power cable.

English

Ironing tips

To prevent silk, wool or synthetic garments from becoming shiny, iron them inside out. To prevent velvet garments from shining, iron only in the direction of the fibres. The more laundry is washed in the washing machine, the more creased the garments become. Many fabrics are easier to iron if they are not completely dry. Silk, for example, should always be ironed damp.

Troubleshooting

If faults occur during operation, switch the garment steamer off and on again. If the problems cannot be rectified, contact your specialist dealer.
