| Product type | WiFi Endoscope |
| Brand | Voltcraft |
| Model | BS-27+IP |
| Dimensions (L x W x H) | 197 x 49 x 32 mm |
| Weight | Approx. 258 g (with battery) |
| Power supply | Lithium-ion battery 2600 mAh, charging via micro-USB (5 V / 1 A) |
| Battery life | Approx. 3.5 hours |
| Camera resolution | Front and side camera: 1280 x 720 px |
| LED lighting | Front camera: 6 white LEDs (550 lux at 20 mm), side camera: 1 white LED, adjustable brightness |
| Viewing angle | 68° |
| Gooseneck length | 1 m |
| Camera head diameter | 5.5 mm |
| Protection rating | IP67 (gooseneck only) |
| Connectivity | Wi-Fi IEEE 802.11 b/g/n, max. range 20 m |
| Recording formats | Video: MOV, Photo: JPG |
| Functions | Front and side camera, adjustable LED lighting, video/photo recording, playback, sharing and deletion via app |
| App | Voltcraft BS-26 BS-27 (iOS and Android) |
| Cleaning and maintenance | Clean with a dry, lint-free cloth. Do not use harsh chemicals. Do not immerse the base unit. |
| Safety | Do not look directly at the LED. Use only on de-energized installations. Keep out of reach of children. |
| Package contents | Endoscope, carrying bag, hanging hook, micro-USB cable, instruction manual |
