Product type	Electric instantaneous water heater
Brand	Kospel
Model	EPS2
Nominal power	3.5 / 4.4 / 5.5 kW (depending on version)
Power supply	230 V~ single-phase
Amperage	15.2 / 19.1 / 23.9 A (depending on version)
Dimensions (without tap)	195 x 135 x 69 mm
Weight (with tap)	~1.4 kg
Water connection	G 1/2"
Minimum water pressure	0.12 MPa
Water flow rate (ΔT 30°C)	1.7 / 2.1 / 2.6 l/min (depending on version)
Ingress protection rating	IP25
Minimum cable cross-section	3x1.5 / 3x2.5 mm² (depending on version)
Recommended fuse	16 / 20 / 25 A (depending on version)
Maximum grid impedance	0.34 / 0.31 Ω (depending on version)
Minimum water resistivity (15°C)	1100 Ωcm
Power cable length	1.2 m
Power switch (5.5 kW model)	Two positions: reduced and full power
Operation indicator	Yes (indicator light)
Freeze protection	Do not install below 0°C
Strainer filter	Included, clean periodically
Recycling	Do not dispose of with household waste

Frequently Asked Questions - EPS2 KOSPEL

How to install the EPS2 water heater?

Installation must be carried out by a professional. Connect the supplied tap to the water inlet pipe (1/2" thread). Attach the water heater to the tap with the nuts, gaskets, and filter. Connect the water supply, check for leaks, bleed, then connect the power supply.

What to do if the device does not heat?

First check the fuses of the electrical installation. Then verify that the water flow is sufficient: clean the filter or the aerator if necessary. If the problem persists, contact customer service.

How to bleed the water heater?

Turn off the power supply, open the hot water tap until flow is steady, then close the tap and restore power. Bleed after each water shut-off.

What is the minimum water flow rate?

The minimum flow rate to trigger heating is 1.1 l/min for the 3.5 kW version, 1.7 l/min for 4.4 kW, and 2.0 l/min for 5.5 kW. Below this, the device may not turn on.

Can the device be used with water pressure below 0.12 MPa?

No, the minimum water supply pressure is 0.12 MPa. Insufficient pressure may prevent the water heater from functioning properly.

How to clean the filter?

Turn off the power supply and water supply. Disconnect the water heater from the tap, remove the strainer filter on the cold water inlet, clean it, then put it back. Check for leaks after reassembly.

What to do in case of a leak?

Immediately shut off the water supply and turn off the power supply. Check the connections and gaskets. If the leak persists, contact a professional. Do not use the device until the leak is repaired.

What is the maximum power?

The 5.5 kW version offers a maximum power of 5.5 kW in full power position. It can also operate at reduced power (4.4 kW) using the switch.

Can the device be used by children?

Yes, from 3 years old under adult supervision. Children must not play with the device. Warning: water at 40°C can cause burns, especially in children.

How to recycle the device at the end of its life?

Do not dispose of with household waste. Take the disassembled device to an appropriate recycling point for electrical and electronic waste. Contact the local council or the retailer for more information.

USER MANUAL EPS2 KOSPEL

Line drawings of two KOSPEL water purifiers mounted on a flexible hose, no text or symbols present

Warning symbol image with exclamation mark inside triangle

This appliance may be used by children at the min. age of 3 years and by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge about the product, provided that they have been given supervision or instruction concerning safe usage of the appliance and that they are aware of potential dangers that might result from usage of the appliance. Children should not play with the device. Children without supervision should not complete any cleaning nor maintenance procedures.

Technical diagram showing assembly of a device with labeled parts and a close-up view of the component.

1. Read and strictly follow the installation and operating instructions to ensure a long life and reliable unit operation.
2. The unit can only be used when in perfect technical condition and correctly assembled.
3. The unit should always be vented before initial start-up. Vent the unit each time after the water has been emptied from the heater or pipes (e.g. when water supply system has been repaired or maintained). Follow the procedure provided in section "Venting".
4. The unit should be connected to electrical system and the reliability of fire protection system should be tested by a qualified person.
5. The unit has to be earthed or neutrally grounded.
6. The unit must be permanently connected to the mains.
7. Electric installation should be equipped with residual current protective devices and other solutions which will ensure disconnecting the heater from the source of power (intervals between all their poles should not be less than 3 mm).
8. The unit must not be installed in the place which is exposed to the danger of explosion and place in which the temperature may go down below 0^ C.
9. The unit must be connected to the cold water supplies only.
10. The water inlet of this appliance shall not be connected to inlet water obtained from any other water heating system.
11. Do not use when the water has been emptied from the unit or pipes (e.g. when water supply system has been repaired or maintained). Turn off the tap immediately when you notice the water supply interruption. Vent the unit when the water is once again supplied to the piping system. Follow the procedure provided in section „Venting”.
12. Unit's cover must not be taken off while power is on.
13. This unit can work only with the tap set included in the product box.
14. The tap set works as an air vent and therefore, cannot be connected to any valve or a connector that is not recommended by the manufacturer.
15. Failure to install the filter on water supply pipe can cause unit damage.
16. The filter should be cleaned after repair or maintenance work of the water supply system, when the water get dirty or after 1 year of use.
17. Appropriate precaution must be taken when using hot water. Temperature of water over 40^ C may cause hot feeling and can be dangerous for children.
18. If the inseparable supply cord will become damage, it should be replaced at the manufacturer or in special repair shop or by a qualified person in order to avoid all risks.

Technical diagram showing a device with labeled parts and an inset view of a cylindrical component with circular holes.

1. Fix the mixer tap set on water supply pipe.
2. Connect the heater to the tap body with nuts, gaskets and the flow reducer which is positioned in the filter (see picture).
3. Allow water mains pressure gets to the tap.
4. Open the tap and check for leaks. Do it without the spray- head on. Some impurities which come from the installation may appear.
5. Vent the water installation.
6. Put the spray-head on.
7. Connect the heater to the power source (through the installation cable box).

Venting

1. Shut off electric supplies.
2. Turn the flow on (turn the hot water tap on) in order to vent the installation until the flow of water becomes constant and even.
3. Shut off the flow.
4. Switch on the electric supplies.

Vent the appliance every time after a decay of water.

1. Cut off water and electric supply to the heater.

2. Disconnect the heater from the tap set.

3. Take the filter out from the fittings at cold water inlet.

4. Clean the filter and install the filter into the former position.

5. Fix the heater on the tap set.

6. Turn the flow on and check for leaks.

7. Vent the installation (see „Venting“ section).

Operation

The heater is produced in 2 versions: EPS2-3,5 and EPS2 4,4 that is without power changing knob, EPS2-5,5 that is equipped with a power changing knob which is placed on the front cover. There are 2 possible positions that the knob can be situated. In „(” position the appliance uses lower power than in a position „))“ – in that case the maximum power is used. The knob is easily turned in both directions. There is a heating „on” indicator near the knob.

Faults

In case the appliance does not heat water, check for possible reasons:

- a failure of the mains supplies (e.g. fuses),

- insufficient flow rate through the heater (e.g. dirty filter, incorrect setting of the hot water tap).

The guarantee does not cover the above repairs.

If there is a fault in the appliance (the heater does not work and all the above reasons do not occur), contact the nearest authorised service point or the seller.

EPS2 water heater 3,5 4,4 5,5R
Rated power kW 3,5 4,4 5,5/4,4
Rated voltage 230V~
Rated current A 15,2 19,1 23,9/19,1
Rated voltage 220V~
Rated current A 15,9 20 25/20
Min. supply water pressure MPa 0,12
Operating point l/min 1,1 1,7 2,0
Efficiency (at Δt = 30°C)	l/min	1,7	2,1	2,6/2,1
Overall dimension (length without a tap x width x depth)	mm	195 x 135 x 69
Weight (with a tap)	kg	~1,4
Conductor to connect with electrical installation (1.2m long)		with assembly terminals
Min. water resistivity at 15°C	Ωcm	1100
Min. connecting wires section	mm2	3 x 1,5	3 x 2,5
The maximum allowed network impedance	Ω		0,34 0,31
Water supply pipe section		G1/2"
Safety class		IP 25

Technical diagram showing a mechanical assembly with labeled parts and a magnified view of a cylindrical component.

Technical diagram showing a mechanical assembly with labeled parts and an inset view of a cylindrical component.

Symbol of a trash bin with crossed lines indicating no waste or restriction, plus a solid black rectangle below (no text or labels)

Used product can't be treated as general communal waste. Disassembled appliance has to be delivered to the collection point of electrical and electronic equipment for recycling. Appropriate utilisation of used product prevents potential negative environmental influences that may occur as a result of inappropriate handling of waste. In order to get more detailed information about recycling this product you should contact the local government unit, waste management service or the shop where this product has been purchased.
