Product type Battery charger
Brand Fuxtec
Model FX-E1LG2A
Input voltage 230 V~, 50 Hz
Output voltage 20.9 V=
Output current 2.4 A
Rated power 70 W
Compatible battery type FUXTEC 20 V Li-Ion series
Protection class II
Charge indicators Indicator lights (4)
Short-circuit protection Yes
Overload protection Yes
Over-temperature protection Yes
Recommended charging temperature 0 °C to 45 °C
Fast charge function Yes, 2.4 A
Approximate weight 0.4 kg
Dimensions (L x W x H) 150 x 80 x 60 mm
Included accessories None (charger only)
User manual Included (32 pages, multilingual)
Intended use Charging FUXTEC 20 V batteries
Maintenance Clean with a dry cloth, do not immerse
Safety Do not expose to water, do not charge incompatible batteries
Disposal Recyclable, TRIMAN logo, take to a store or recycling center

Frequently Asked Questions - FX-E1LG2A Fuxtec

What types of batteries can I charge with this charger?
This charger is exclusively intended for charging FUXTEC 20 V Li-Ion batteries. Only use batteries recommended by the manufacturer.
How do I know when the battery is fully charged?
The indicator lights (4) on the charger show the charging progress. When the battery is fully charged, the corresponding light stays on or turns off depending on the model.
What should I do if the charger does not turn on?
Check that the charger is properly plugged into a 230 V~ power outlet. If the problem persists, try another outlet. If the charger still does not work, contact FUXTEC customer service.
Can I charge batteries of other brands?
No, this charger is designed only for FUXTEC 20 V batteries. Using other batteries can cause injuries and fires.
Can I leave the battery charging overnight?
It is recommended not to exceed the indicated charging time and to remove the battery once fully charged. Do not leave the battery charging unattended to avoid any risk of overheating.
What to do in case of battery liquid leakage?
In case of contact with the liquid, rinse immediately with water. If liquid gets into eyes, consult a doctor. The liquid can cause irritation or burns.
How to clean the charger?
Unplug the charger before cleaning. Use a dry cloth to wipe the surface. Never immerse the charger in water or any other liquid.
Where should I dispose of the charger at the end of its life?
Do not dispose of the charger with household waste. Follow the sorting instructions (TRIMAN logo) and take it to a store or recycling center. Prefer repair or donation.
Is the charger compatible with a 4 Ah battery?
Yes, the charger can charge 2 Ah or 4 Ah batteries of the FUXTEC 20 V series. The charging time is proportional to the capacity.
What is the output voltage of the charger?
The charging voltage is 20.9 V= with a current of 2.4 A, corresponding to a power of 70 W.
