Product Type Rechargeable lithium-ion battery
Brand Fuxtec
Model FX-E1B2AH
Nominal Voltage 20 V (max), 18 V (min)
Capacity 2000 mAh
Cell Type Lithium-ion
Charging Time Approximately 60 minutes with 2.4 A fast charger
Compatible Charger Fuxtec 1 A charger, 2.4 A fast charger, dual charger 2×2.4 A
Charge Level Indicator LED indicators (4 LEDs) with push button
Intended Use Powering Fuxtec 20 V series power tools
Charging Temperature Respect the range indicated in the manual (not specified, charge at room temperature)
Safety Protection Protection against short circuits, overcharge, deep discharge
Recycling TRIMAN logo, to be disposed of at store or recycling center
Available Accessories 4 Ah battery, single and dual chargers

Frequently Asked Questions - FX-E1B2AH Fuxtec

How to charge the Fuxtec FX-E1B2AH battery for the first time?
Before first use, fully charge the battery. Remove it from the device by pressing the lock button, insert it into the appropriate charger, then plug in the charger. The LEDs indicate the progress. Once fully charged, insert it into the tool until it clicks.
Which charger should I use with this battery?
Use only chargers recommended by Fuxtec: 1 A charger, 2.4 A fast charger or dual charger 2×2.4 A. Using another charger may pose a fire risk.
How long does it take to charge the battery?
With the 2.4 A fast charger, charging time is about 60 minutes. With the 1 A charger, the time is longer (about 2 hours).
How to check the remaining charge level?
Press the button on the battery (mark 2). The LED indicators (mark 1) show the remaining capacity: 4 LEDs = full, 1 LED = low.
Can I use this battery with other tool brands?
No, this battery is designed exclusively for Fuxtec 20 V series power tools. Using it with other brands may cause injury or fire.
What to do if the battery is damaged or leaks?
Do not use a damaged battery. In case of liquid leakage, avoid contact. Rinse thoroughly with water if skin contact occurs, and consult a doctor if the liquid gets into eyes.
What safety precautions should be taken?
Do not expose the battery to fire or temperatures above 130°C. Avoid short circuits by keeping the battery away from metal objects. Only charge within the temperatures specified in the manual.
How to maintain the battery to prolong its life?
Store the battery in a cool, dry place away from moisture. Avoid frequent deep discharges. Clean the contacts with a dry cloth.
Is this battery recyclable?
Yes, it bears the TRIMAN logo. Dispose of it at a store (collection point) or recycling center. Do not throw the battery in household waste.
Where can I buy accessories or a replacement battery?
Accessories (4 Ah battery, chargers) are available on the website www.fuxtec.fr. You can also contact Fuxtec customer service.
