USER MANUAL ES90212MS Atag

1. As a cooker hood connected to an exhaust duct.

The cooking fumes are drawn into the cooking hood, filtered, and exhausted outdoors. This is the best way!

2. As a recirculation cooker hood.

The cooking fumes are drawn into the cooking hood and the grease droplets and odours are filtered out. The filtered air is not exhausted outdoors, but is returned to the kitchen. You then need to fit an odour/fine particle filter. Note! The recirculation set including filter must be ordered separately.

4. Speed setting 3 and intensive setting

7. Switching on/off and dimming the lighting

Note! If you have a cooker hood with an odour/fine particle filter, you should activate the recirculation filter cleaning indicator as described in the ‘Cleaning filters’ paragraph. Operation Switching the extraction on and off

1. Touch the on/off key.

The cooker hood is switched on at the lowest setting.

2. Select the desired extraction setting by touching the appropriate

speed setting key. The speed setting key lights up. The cooker hood switches to the selected speed setting.

3. Touch the on/off key.

The on/off key is lit for 5 seconds and a double beep sounds. The cooker hood is switched off.EN 6 OPERATION Switching to intensive setting A timer function is automatically used for the intensive setting. The duration is 4 minutes, after which the cooker hood switches to speed setting 3.

1. Touch the on/off key.

The cooker hood switches on at speed setting 1.

2. Touch speed setting key 3.

Speed setting key 3 lights up.

3. Touch speed setting key 3 again.

Speed setting key 3 flashes. The intensive setting is switched on. Touch the on/off key or any other key to stop the intensive setting at any time. Switching on the timer

1. Switch on the cooker hood at speed 1, 2 or 3.

2. Touch the timer key.

The timer key flashes and a single beep sounds. The timer for the motor is activated; after 10 minutes the cooker hood switches off. Touch the timer key to stop the timer at any time. Switching on Clean Air function

1. Touch the on/off key and the desired speed setting key 2, 3 or the

timer key (for speed 1) at the same time. The corresponding key lights up.

2. Then, within 5 seconds, touch the on/off key again.

The Clean Air function is activated. The cooker hood will be switched on for 10 minutes every hour for the next 24 hours. The speed setting key flashes while the extraction is active. After 10 minutes, the cooker hood switches off automatically. The Clean Air function cannot be used when the intensive setting is selected.EN 7 Switching the lighting on and off

1. Briefly touch the lighting key.

The lighting is switched on at maximum brightness.

2. Touch the lighting key for 3 seconds to dim the lighting.

3. Briefly touch the lighting key to return to maximum brightness.

4. To switch the dimmed lighting off, touch the lighting key for about

5. If you want to switch off the lighting at the maximum setting, briefly

touch the lighting key. Cleaning filters Grease filter cleaning indicator After 100 hours of use of the cooker hood, a beep sounds periodically during operation. The on/off key flashes continuously when the cooker hood is switched off. The grease filter must be cleaned.

• To reset the cleaning indicator, touch the filter indicator key with the cooker hood switched off. You can also touch the on/off key twice. You will hear a confirmation beep for 3 seconds. After 20 hours, the filter cleaning indicator automatically resets. Carbon filter cleaning indicator After 200 hours of use of the cooker hood, a beep sounds periodically during use if the carbon filter contamination indicator is activated. The lighting key flashes continuously when the cooker hood is switched off. The odour/fine particle filter must be replaced.

• To reset the cleaning indicator, touch the filter indicator key with the cooker hood switched off. You can also touch the lighting key twice. You will hear a confirmation beep for 3 seconds. After 20 hours, the filter cleaning indicator automatically resets. OPERATIONEN 8 Activation of the carbon filter cleaning indicator In standard mode, the carbon filter cleaning indicator is not active. If the cooker hood is used as a recirculation hood, the carbon filter cleaning indicator must be activated.

1. Switch off the cooker hood and the lighting.

2. Touch the timer key for 5 seconds.

The lighting key lights up for 5 seconds as confirmation. Switching off the carbon filter cleaning indicator:

1. Switch off the cooker hood and the lighting.

2. Touch the timer key for 5 seconds.

The on/off key lights up for 5 seconds as confirmation. OPERATIONEN 9 Cleaning Important! For all maintenance first switch off the mains power to the cooker hood by pulling the plug out of the socket or by turning off the home’s master switch. The hood needs to be cleaned regularly, both inside as well as outside (at least in the same frequency as the grease filter cleaning). Do not use abrasive cleaning products. Do not use alcohol! Important! If the instructions regarding cleaning the appliance or replacing the filters are not followed, this can cause a fire. These instructions should be followed! The manufacturer is not liable for damage to the hood or fire damage resulting from incompetent maintenance or from non- adherence to the above safety instructions. Cooker hood Clean the cooker hood with soapy water and a soft cloth. Then wash off with clean water. Do not use aggressive cleaning agents such as caustic soda. The cooker hood finish stays in good condition if it is buffed periodically following the application of wax. Stainless steel cooker hoods Do not use scouring pads or other abrasive cleaners on stainless steel cooker hoods. Finish with a non-abrasive, non-polishing agent and buff the stainless steel in the direction of the grain. Metal grease filters Metal grease filters should be cleaned once a month (or when indicated by the filter saturation indication system, if present on your model), using a neutral cleaning agent, preferably by hand or in the dishwasher on a short, low-temperature program. Place the grease filters with the openings facing downwards in the dishwasher so the water can drain out of the filter. Aluminum-colored and black grease filters become dull as a result of dishwasher cleaning agents. This is normal and does not effect the working. MAINTENANCEEN 10 Grease filters Remove the filters by pulling on their release handles. Odour/fine particle filter Use an odour/fine particle filter when the cooker hood is not connected to an exhaust duct. The functioning:

• More noise is produced when carbon filters are used than when the cooker hood is used with an exhaust vent.

• Carbon filters function optimally at a lower motor speed. For this reason, avoid the intensive setting. Replacing the odour/fine particle filter The odour/fine particle filter must be replaced annually. To replace the filter, follow the instructions supplied with the new filter. The recirculation set HR0014 must be ordered for the first installation.

1. Remove the grease filter.

2. Remove the filter holder by loosening the screw and removing the

holder at an angle from the appliance.

3. Remove the filter and place a new filter back in the holder. Note the

arrow on the filter for correct placement!

4. Place the filter holder back in the appliance and tighten the screw.

5. Install the grease filter.

MAINTENANCEEN 11 Important:

• The saturation of the filter depends on the intensity of use, the manner of cooking and the regularity with which the grease filters are cleaned. It is important that the grease filters are properly dried before installation. Lighting

• The cooker hood is fitted with LED lighting.

• LED lamps guarantee you optimum lighting, a service life of up to 10 times longer than conventional lamps and energy savings of as much as 90%. This hood is fitted with a light system. This light system has to be replaced by an authorized technician. Do not attempt to replace it by yourself. The lamp in this household appliance is only suitable for illumination of this appliance. The lamp is not suitable for household room illumination. MAINTENANCEEN 12 General This appliance must be connected to the power supply by a recognized installer who is familiar with and works in accordance with the applicable safety regulations. This appliance conforms to the European directives. Important information:

• The lowest part of the cooker hood must be at least 65 cm above a gas hob. The lowest part of the cooker hood must be at least 55 cm above an electric, ceramic or induction hob.

• The cooker hood may only be connected to an existing exhaust duct to which no other appliances are connected (such as a geyser or heater).

• Gas appliances must be vented in accordance with the local regulations.

• The cooker hood works best when connected to an exhaust duct that is as short and as straight as possible.

• Before drilling any holes, always check to make sure that there are no wires in the area.

• The hood’s connection pipe has a diameter of 120 or 150 mm. The exhaust duct should preferably be of the same diameter.

• The installation materials supplied with this cooker hood are suitable for reinforced concrete and masonry walls. You will need special plugs and screws to fasten the appliance to some other types of wall. INSTALLATIONEN 13 Connection Electrical connections This appliance is a Class II appliance and must be earthed. Check to make sure that the voltage specified on the type plate matches the mains voltage. The appliance must be connected to the mains as follows: BROWN = L (live) BLUE = N (neutral) This cooker hood is fitted with a plug. Install the cooker hood so that the plug is accessible. It is preferable to fit the wall socket out of sight, behind the chimney cover. Note: When you make a fixed connection to the mains you must make sure that the live wire is connected to an omnipolar switch with a break contact distance of at least 3 mm. Max. 125 cm Mounting the cooker hood The installation instructions are included separate. INSTALLATIONEN 14 ENVIRONMENTAL ASPECTS Disposal of packaging and appliance This appliance is made from sustainable materials. This appliance must be disposed of in a responsible manner at the end of its service life. Contact the local authorities for information about the method. The packaging of the appliance is recyclable. The following materials may have been used:

• CFC-free polystyrene (hard PS foam). These materials must be disposed of in a responsible manner and in accordance with government regulations. The appliance is marked with a crossed out wheeled bin symbol to draw your attention to the requirement for the separate disposal of domestic electrical appliances. This means that the appliance may not be disposed of in unsorted household waste at the end of its service life. The appliance must be taken to a special municipal waste processing location for separated waste or to a dealer who provides this service. Collecting and disposing of domestic appliances separately avoids detrimental consequences for humans and the environment. This ensures that the materials used to make the appliance can be recovered and that substantial savings in the use of energy and raw materials can be achieved. Declaration of conformity We hereby declare that our products conform to the applicable European Directives, Regulations and requirements, as well as all requirements in the standards to which reference is made.EN 15880435 / VER 1 / 08-03-2022
