Fast&Furious 5040 Absolute - Iron CECOTEC - Free user manual and instructions

Product type	Steam iron
Brand	Cecotec
Model	Fast&Furious 5040 Absolute
Reference	05523
Power supply	220-240 V~, 50/60 Hz
Power	3000 W
Water tank capacity	Approximately 300 ml (estimated)
Soleplate	Smooth soleplate (material not specified)
Anti-scale function	Yes, permanent system with recommended cleaning
Anti-drip function	Yes
Automatic shut-off	Yes: 30 seconds horizontally, 8 minutes vertically
Steam burst	Yes, up to 3 consecutive bursts
Water spray	Yes
Steam selector	Variable
Temperature control	Adjustable thermostat (MIN to MAX)
Power cord	360° swivel
Ironing type	Dry, steam, spray, steam burst
Self-cleaning	Yes, recommended once a month
Maintenance	Clean the soleplate with a damp cloth, do not use abrasive products
Safety	Automatic shut-off, grounded cord, overheat protection
Approximate weight	Approximately 1.5 kg
Dimensions (L x W x H)	Approximately 30 x 15 x 20 cm (estimated)
Warranty	2 years
Country of manufacture	China (designed in Spain)

Frequently Asked Questions - Fast&Furious 5040 Absolute CECOTEC

How to fill the water tank of the Cecotec Fast&Furious 5040 Absolute iron?

Make sure the iron is off and unplugged. Turn the steam selector to '0'. Open the tank cap and fill up to the 'MAX' mark. The level is visible through the transparent part. Use only tap water, without additives.

What is the power of this iron?

The Cecotec Fast&Furious 5040 Absolute iron has a power of 3000 W at a voltage of 220-240 V~, 50/60 Hz.

How to use the steam function?

Fill the tank, plug in the iron, place it in vertical position and set the temperature selector to the steam zone (usually high, towards MAX). Preheat until the indicator light goes off. Turn the steam selector to the desired level. Steam ironing is only possible at high temperature to avoid dripping.

What to do if the iron does not produce steam?

Check that the tank has enough water and that the temperature selector is set to a high position (steam zone). Make sure the steam selector is not on '0'. If the problem persists, use the self-cleaning function to remove limescale deposits.

How to clean the soleplate of the iron?

Unplug the iron and let it cool completely. Clean the soleplate with a damp cloth. For stubborn residues, you can use a cotton cloth on a warm soleplate (but not hot). Never use abrasive products or hard sponges.

How does the automatic safety shut-off work?

The iron automatically turns off if it remains in horizontal position for 30 seconds or in vertical position for 8 minutes. It emits 5 beeps and the light flashes. To turn it back on, simply lift or move it slightly.

What water to use in the tank?

It is recommended to use tap water. If the water is very hard, mix equal parts with demineralized water. Do not use scented water or additives, as they may stain clothes or damage the iron.

How to perform the self-cleaning of the iron?

Fill the tank halfway, set the steam selector to 'off'. Place the iron in vertical position, turn it on and set the temperature to MAX. Preheat until the light goes off, then unplug. Hold the iron horizontally over the sink and turn the steam selector to maximum or press the self-cleaning button. Boiling water and steam will come out of the soleplate. Then clean the cooled soleplate.

Can the iron be used without water (dry ironing)?

Yes, dry ironing is possible. Simply set the temperature selector to the desired position (MIN for delicate fabrics) and wait for the indicator light to go off. You can also use the water spray or steam burst even in dry mode.

What to do if the iron drips water on clothes?

This can happen if the temperature is too low for steam. Make sure the temperature selector is on a high position (steam zone, towards MAX). The anti-drip function normally prevents leakage at low temperature. If it persists, check that the tank is not too full and that the steam selector is correctly set.

USER MANUAL Fast&Furious 5040 Absolute CECOTEC

Exterior view of a precision electric iron with 'cecotec' branding and 'AntiCalc' branding (no text-heavy elements)

Safety instructions 10

1. Parts and components 35
2. Before use 35
3. Operation 36
4. Cleaning and maintenance 38
5. Technical specifications 38
6. Disposal of old electrical appliances 39
7. Technical support and warranty 39

SOMMARIE

Read these instructions thoroughly before using the appliance. Keep this instruction manual for future reference or new users. All safety instructions should be closely followed when using the appliance.

Make sure that the mains voltage matches the voltage stated on the rating label of the appliance and that the wall outlet is grounded.

Do not immerse the cord, plug, or any non-removable part of the appliance in water or any other liquid. nor expose the electrical connections to water. Make sure your hands are dry before handling the plug or switching on the appliance.

Never immerse the appliance in water. Do not reach into the water!

Do not twist, bend, strain, or damage the power cord in any way.

Protect it from sharp edges and heat sources. Do not let it touch hot surfaces. Do not let the cord hang over the edge of the working surface or countertop.

The appliance is not intended to be operated by means of an external timer or separate remote-control system.

Turn off and unplug the appliance from the mains supply when not in use and before cleaning it.

Pull from the plug, not the cord, to disconnect it from the outlet. This device is designed to iron fabrics. This product is designed only for household use.

It is not suitable for commercial or industrial use. Do not use outdoors.

To protect against burns or injuries to persons, do not iron textiles while being worn on the body.

Do not use any accessory that has not been recommended by Cecotec, as they might cause injuries or damage.

Place the appliance on a dry, stable, flat, heat-resistant surface. The temperature of accessible surfaces may be high while in use and could cause burns. Do not touch hot surfaces while in use or immediately after.

Unplug the appliance immediately if fire or smoke is observed. Do not leave the appliance unattended while in use.

Unplug it from the power supply when you finish using it and before leaving the room.

The appliance must not be plugged in when filling or emptying the water tank.

The tank cap must not be open when the appliance is switched on.

The use of tap water is recommended. If the lime content of the tap water is too high, use a mix composed of 50 % of tap water and 50 % of water with low mineral content. Do not use only water with low mineral content.

Burns can occur when touching hot metal parts, hot water, or steam. Hot water may leak from the iron. Be careful when filling or turning the steam iron upside down.

To protect against burns or injuries, do not direct steam toward persons or animals when ironing.

The iron must be used and placed on a stable surface. When placing the iron on its stand, make sure that the surface is stable.

Keeping the iron at maximum temperature for too long may cause discolouration, which will not affect the performance of the appliance.

Do not try to repair the product by yourself. Contact the official Technical Support Service of Cecotec.

To ensure the correct operating of the device, cleaning and maintenance tasks must be carried out according to this instruction manual. Turn off and unplug the appliance before moving and cleaning it. Allow it to completely cool down before

cleaning or storing it.

Cleaning and maintenance tasks must not be carried out by children.

Store the appliance and its instruction manual in a safe and dry place when not in use.

Cecotec takes no responsibility for any damage caused by misuse of the appliance. Any misuse or non-compliance with these instructions renders the warranty and the manufacturer's liability null and void.

If the power cord is damaged, it must be replaced by the Technical Support Service of Cecotec or similar qualified personnel to avoid risks.

The appliance is not intended to be used by children under the age of 8.

It can be used by children over the age of 8, as long as they are given continuous supervision.

This appliance can be used by children aged 8 and above, and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, as long as they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.

Supervise children, they shall not play with the appliance. Close supervision is necessary when the appliance is being used by or near children.

Keep this appliance and its power cord out of reach of children under the age of 8.

Warning: All our ironing range's products have undergone quality control tests previous to their commercialisation. These tests consist of filling the water tank in order to check tightness and to ensure correct operating of the device. Once the test has been carried out, the tank is emptied and dried, but there is a slight probability that water could remain inside it.

INSTRUCTIONS DE SÉCURITÉ

1. Steam selector
2. Steam burst button
3. Spray button
4. Temperature indicator light
5. 360° swiveling cord
6. Temperature control dial
7. Water tank
   B. Soleplate
8. Spraying mouth
9. Water tank cap
10. Auto-clean button

2. BEFORE USE

Remove all packaging elements.

Inspect all parts of the appliance for visual damage. Unwind the power cord completely and inspect it for damage. Do not use the product if it or its cord have been damaged or are not working properly. In case of damage, contact the official Technical Support Service of Cecotec for advice, repairs or returns.

Make sure you have read and understood all instructions and warnings in this instruction manual. Pay particular attention to the safety instructions on previous pages.

Place the appliance on an even, heat-resistant surface. Do not place the appliance near heat sources, places with high humidity levels, or combustible materials.

Plug the appliance into an appropriate wall outlet. The plug must be accessible so that, in case of an emergency, it can be easily unplugged.

Note: You may notice a slight burning smell or smoke when using the appliance for the first time, caused by the excess of lubricants from the manufacturing process. Ensure good ventilation and let the appliance work until no odour or smoke can be noticed. Fig. 2.

How to fill the water tank

Make sure the iron is turned off and unplugged from the mains supply before following the below instructions:

Turn the steam dial to position '0' before filling the tank with water.

Open the cap of the tank and fill it up to the 'MAX' mark on the tank. The water level can be seen through the transparent side of the tank when the iron is placed in an upright position.

ENGLISHENGLISH

Pour out the remaining water after use.

Note: Tap water can be used in this iron. Do not use water additives or substitute water, such as linen or scented water in the steam iron. They can stain fabrics or damage the iron. Do not exceed the 'MAX' mark on the tank.

3. OPERATION

Anti-calc function

The anti-calc function is a permanent system located inside the water tank to eliminate impurities in water and reduce the problems derived from limescale build-up. To prolong the efficiency of this system, follow these steps regularly:

Unplug the iron and allow it to cool down.

FILL 3/4 of the measuring cup provided with the iron with water. Add 1 teaspoon of salt and fill the water tank with this mix.

Leave the mix in the water tank for 15 minutes, shake it occasionally, and empty it. Repeat this process twice.

Fill the tank with fresh water to rinse it and empty it.

Anti-drip function

This system controls the water flow emitted to the soleplate at all times. Below a certain temperature, the anti-drip function cuts off the water flow and prevents the iron from dripping water onto the fabric.

Automatic shut-off function

The iron will automatically turn off when placed in horizontal position for 30 seconds, or in an upright position for 8 minutes. To indicate that the iron has been turned off, the unit will beep 6 times and the auto shut-off indicator light will blink. The iron can take up to 45-60 minutes to completely cool down.

To heat up the iron again:

Pick up the iron or slightly move it.

The auto shut-off light indicator will stop blinking.

The auto shut-off light indicator will remain on and the iron will be ready for use.

ECO mode

Use this mode for optimal results when steam ironing any type of fabric. This position guarantees good results saving energy.

Dry ironing

Place the iron in vertical position.

Plug the iron.

Set the temperature control dial to position 'MIN'.

Preheat the iron until the indicator light turns off.

The iron is ready for use.

Steam ironing

Fig. 3.

Fig. 4.

Fill the iron as described in 'How to fill with water'.

Plug the appliance into the mains supply.

Place the iron vertically and turn the temperature control dial to the steam position.

Steam ironing is only possible when the temperature control dial is set at higher temperature settings, signaled with the mark 'MAX'; otherwise, the water will leak from the soleplate.

Preheat the iron until the indicator light turns off.

Turn the steam selector to the required setting, according to the different types of fabric.

The iron is ready for use.

How to use the water spray

Before using the spray function, check the fabric label for ironing instructions, as some fabrics may be spotted or stained with moisture. The spray function is particularly helpful to remove stubborn wrinkles and whenever extra moisture is needed. The spray may be used both with steam or dry ironing. Simply press the spray mist button when desired.

How to use the steam burst

The steam burst feature provides additional steam to remove stubborn wrinkles. It maybe used both with steam or dry ironing. Press the power steam button to release a steam burst. Pressing the button several times may be necessary to build up the steam burst. Wait a few seconds for the steam to penetrate the fabric before pressing the button again for more steam.

Note: For optimal results, do not apply more than three successive bursts after the indicator light turns off.

After use

Turn off and unplug the iron.

Empty the iron immediately after use. Do not store the iron with water in its tank.

Allow the iron to completely cool down before cleaning or storing it. Let it rest on its base in vertical position to protect the soleplate from scratches, corrosion, or stains.

ENGLISHENGLISH

4. CLEANING AND MAINTENANCE

Outside surface of the iron

After unplugging and letting the iron cool down, wipe its exterior surface with a damp cloth and, if necessary, a mild detergent.

Warning: Do not use any abrasive cleaning agent.

Soleplate

Starch and other types of residue may be easily removed from the soleplate with a damp cloth. To avoid scratches on its finish, do not use metallic scouring pads to clean the soleplate and never place the iron on a rough surface.

If synthetic fabrics are ironed at high temperature, both the fabric and the soleplate of the iron could be damaged. The best way to remove synthetic residue from the soleplate is to heat it up and iron over an old cotton rag.

Warning: Do not use steam iron cleaners in this iron, since they could damage its parts.

Auto-cleaning

Note: In order to perform best results, use the auto-clean function once per month, or more if required according to the use.

Fill half of the water tank with water and leave the steam selector in off position.

Place the iron in vertical position.

Plug the iron.

Set the temperature control dial to position 'MAX'.

Allow the iron to heat up until the indicator light turns off.

Unplug the iron from the mains supply and keep it in a horizontal position over the sink.

Turn the steam selector to the maximum position or hold the Auto-clean button. Boiling water and steam will be elected through the holes on the soleplate.

Clean the soleplate with a clean cloth once it has cooled down.

5. TECHNICAL SPECIFICATIONS

Model: Fast&Furious 5040 Absolute

Product reference: 05523

3000 W, 220-240 V\~, 50/60 Hz

Made in China | Designed in Spain

6. DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), specifies that old household electrical appliances must not be disposed of with the normal unsorted municipal waste. Old appliances must be collected separately, in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment.

The crossed out "wheeled bin" symbol on the product reminds you of your

obligation to dispose of the appliance correctly. If the product has a built-in battery or uses batteries, they should be removed from the appliance and disposed of appropriately.

Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

7. TECHNICAL SUPPORT AND WARRANTY

This product is under warranty for 2 years from the date of purchase, as long as the proof of purchase is submitted, the product is in perfect physical condition. and it has been given proper use, as explained in this instruction manual.

The warranty will not cover the following situations:

The product has been used for purposes other than those intended for it, misused, beaten, exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault attributable to the customer.

The product has been disassembled, modified, or repaired by persons, not authorised by the official Technical Support Service of Cecotec.

Faults deriving from the normal wear and tear of its parts, due to use.

The warranty service covers every manufacturing defects of your appliance for 2 years, based on current legislation, except consumable parts. In the event of misuse, the warranty will not apply.

If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact Cecolec Technical Support Service at [phone].

FRANÇAISFRANÇAIS

1. PIÈCES ET COMPOSANTS

Img. 1.

Fig./img./Abb.1

Fig./img./Abb.2

Fig./Img./Abb. 3

Fig./Img./Abb. 4

www.cecotec.es

Quart de Poblet, Valencia (Spain)

YV02200519
