PLS 600 A1 - Log splitter PARKSIDE - Free user manual and instructions

Product type	Hydraulic log splitter
Brand	Parkside
Model	PLS 600 A1
Dimensions (L x W x H)	1160 x 425 x 610 mm
Weight with frame	57.6 kg
Power supply	220-240 V~ / 50 Hz
Motor power	2200 W (S3 25%)
Motor speed	2800 rpm
Maximum splitting force	6 tons
Piston stroke	370 mm
Piston advance speed	3.08 cm/s
Piston return speed	5.29 cm/s
Wood diameter min-max	50 - 250 mm
Maximum wood length	520 mm
Hydraulic oil capacity	3.5 liters (HLP 32)
Operating pressure	20.8 MPa
Operating mode	S3 25% (intermittent)
Protection rating	IP54
Sound pressure level	89.8 dB(A)
Safety features	Two-hand operation, thermal protection, multiple safety devices
Maintenance	Oil change every 150 working hours
Wear parts	Splitting wedge, hydraulic oil, guides
Warranty	3 years

Frequently Asked Questions - PLS 600 A1 PARKSIDE

How to start the Parkside PLS 600 A1 log splitter?

Plug in the power cord, then simultaneously operate the control lever (left hand) and the trigger button (right hand). The pressure plate then advances to split the wood.

Which hydraulic oil to use and how to check the level?

Use hydraulic oil type HLP 32. To check the level, place the splitter upright, remove the oil drain screw with gauge, wipe it, reinsert it, then remove it again: the level should be at the central mark on the gauge. If necessary, top up with about 3.5 liters of oil.

What to do if the motor stops while splitting?

This may be due to thermal overload: the protection device has cut off the motor. Wait about 15 minutes for the motor to cool down, then restart. If the problem persists, contact a specialized electrician.

How to transport the splitter safely?

Before transport, unplug the power cord and tighten the purge screw (6) fully to prevent oil leaks. Grasp the handle (3) and tilt the machine onto its wheels (15) to move it easily.

What protective equipment is mandatory?

Always wear safety glasses, hearing protection (as sound level exceeds 85 dB), work gloves, safety shoes, and close-fitting clothing.

How to change the hydraulic oil?

Place the splitter upright, remove the oil drain screw (9) after placing a collection container. Drain the used oil completely, then fill with about 3.5 liters of new HLP 32 oil. Check the level and bleed the air by operating the machine empty.

What is the procedure if the wood gets stuck?

Release the control lever (13) and trigger button (5) to retract the pressure plate. Place wedges under the stuck wood and repeat the operation until it is expelled. Never attempt to hit or saw the stuck wood.

How to adjust the stroke limiter?

For short logs, operate the control lever and trigger button to bring the pressure plate just in front of the wood. Release the button, loosen the star knob screw of the stroke limiter ring (8), position the ring, then retighten the screw.

Where to find spare parts and after-sales service?

Wear parts (splitting wedge, oil, guides) are available from specialized dealers. For after-sales service, contact the hotline [phone] (toll-free) or send an email to [e-mail]. You can also download the manual from www.lidl-service.com via the QR code.

What are the essential safety precautions?

Read the manual before use, never remove safety devices, use the machine outdoors only, keep people and animals at least 5 meters away, and only split wood along the grain with a maximum length of 520 mm.

USER MANUAL PLS 600 A1 PARKSIDE

LOG SPLITTER PLS 600 A1 HOLZSPALTER PLS 600 A1 FENDEUR DE BUCHES PLS 600 A1

GB

LOG SPLITTER

Operating and Safety Instructions

Translation of Original Operating Manual

FR

FENDEUR DE BUCHES

Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

DE

GB Operating and Safety Instructions Page 01

Table of contents: Page:

1. Explanation of the symbols on the equipment 2
2. Introduction 4
3. Product description (fig. 1, 2 + 5)
4. Scope of delivery (fig. 1, 2 + 5) 4
5. Proper use 5
6. Safety information 5
7. Additional safety instructions 5
8. Technical data 6
9. Unpacking 6
10. Assembly 6
11. Before commissioning 8
12. Working instructions. 8
13. Transport (fig. 20)
14. Maintenance 10
15. Cleaning 10
16. Storage 11
17. Electrical connection 11
18. Disposal and recycling 11
19. Troubleshooting 12
20. Warranty certificate 13
21. Exploded view 82
22. Declaration of conformity 84

1. Explanation of the symbols on the equipment

	GB	Read the manual before commissioning.
	GB	Wear hearing protection. Excessive noise can result in a loss of hearing.
	GB	Wear safety gloves.
	GB	Wear safety goggles.
	GB	Use work gloves.
	GB	Removing or modifying protective or safety equipment is prohibited.
	GB	Do not let hydraulic oil run onto the floor. Disposition of waste oil properly at the on-site waste oil collection point. Dumping used oil in the soil or mixing it with waste is prohibited.
	GB	Attention! Before starting repair, maintenance and cleaning work, switch off the engine and unplug the mains plug.
	GB	Caution: Mains voltage! Do not open the appliance!
	GB	Do not reach into the splitting area! Danger of injury! Danger of cutting and crushing!
	GB	Do not reach into the machine unprotected!
	GB	Attention! Moving parts!
	GB	Only the operator may stand in the working area of the machine. Keep uninvolved persons as well as pets and livestock away from the danger zone (minimum distance 5 m).
	GB	Protect the device from rain and do not leave outdoors in the rain!
	GB	Setting of the stroke limitation
	GB	Risk of burns on hot surfaces! Do not touch!
	GB	Lifting point for crane hook.
	GB	Lifting point is used to secure the machine during transport.
	GB	Operate the appliance with both hands!
△ Attention!	GB	We have marked points in this operating manual that impact your safety with this symbol
DANGER!	GB	Signal word to indicate an imminently hazardous situation which, if not avoided, will result in death or serious injury.
WARNING!	GB	Signal word to indicate a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION!	GB	Signal word to indicate a potentially hazardous situation which, if not avoided, could result in minor or moderate injury.
NOTE	GB	Signal word to indicate a potentially hazardous situation which, if not avoided, could result in product or property damage.

2. Introduction

MANUFACTURER:

Scheppach GmbH

GünzburgrsteraBe 69

D-89335 Ichenhausen

DEAR CUSTOMER,

We hope your new product brings you much enjoyment and success.

NOTE:

In accordance with the applicable product liability laws, the manufacturer of this product assumes no liability for damage to the product or caused by the product arising from:

• Improper handling,
• Failure to comply with the operating instructions.
• Repairs carried out by third parties, unauthorised specialists.
• Installing and replacing non-original spare parts,
  Application other than specified,
• Failure of the electrical system in the event of the electrical regulations and VDE provisions 0100, DIN 13 / VDE0113 not being observed.

Please consider:

Read through the complete text in the operating manual before installing and commissioning the device.

This operating manual should help you to familiarise yourself with your product and to use it for its intended purpose.

The operating manual includes important instructions for the safe, proper and economic operation of the product, for avoiding danger, for minimising repair costs and downtimes and for increasing the reliability and extending the service life of the product.

In addition to the safety instructions in this operating manual, you must also observe the regulations applicable to the operation of the product in your country.

Keep the operating manual package with the power tool at all times and store it in a plastic cover to protect it from dirt and moisture. They must be read and carefully observed by all operating personnel before starting the work.

The product may only be used by personnel who have been trained to use it and who have been instructed with respect to the associated hazards. The required minimum age must be observed.

In addition to the safety instructions in this operating manual and the separate regulations of your country, the generally recognised technical rules relating to the operation of such machines must also be observed.

We accept no liability for accidents or damage that occur due to a failure to observe this manual and the safety instructions.

3. Product description (fig. 1, 2 + 5)

1. Guard
2. Riving knife
3. Handle
4. Protective guard, front
5. Triggering button
6. Ventilation screw
7. U-bow
8. Stroke limitation ring
9. Oil drain screw with oil dipstick
10. Support surface
11. Pressure plate
12. Control lever protection
13. Control lever
14. Motor
15. Transport wheels
16. Washers
17. Safety splint
    18.Wheel caps
18. Support strut
19. Protective guard, rear
20. Struts (2x)
21. Wheel axle, machine stand
22. Cross member, machine stand
23. Wheel support, machine stand
24. Foot, machine stand
25. Tray table 1
26. Tray table 2
27. Tray table 3
28. Log splitter
29. Top guard 1
30. Top guard 2
31. Left guard
32. Rear guard 1
33. Rear guard 2
34. Front guard
35. Enclosed accessories bag
36. Foot screws (4x screws with nuts)
37. Wheel support, machine stand screws (2x screws with washers, spring washers and nuts)
38. Machine stand screws (4x hexagonal bolts)
39. Supporting foot
40. Foot screws (5x screws with nuts)

4. Scope of delivery (fig. 1, 2 + 5)

• Operating manual
• Enclosed accessories bag (A, B, C, D, E, F) (36)
• Handle (3)
  Log splitter (29)
  Top guard 1 (30)
  Top guard 2 (31)
• Left guard (32)
  Rear guard 1 (33)
  Rear guard 2 (34)
• Front guard (35)
• Tray table 1 (26)
• Tray table 2 (27)
• Tray table 3 (28)
• Struts (2x) (21)

Support strut (19)
- Wheel axle, machine stand (22)
Cross member, machine stand (23)
- Wheel support, machine stand (24)
- Foot, machine stand (25)
- Wheel support, machine stand screws (2x M8 x 25 mm screws with washers, spring washers and nuts) (38)
Machine stand screws (4x M10 x 20 mm hexagonal bolts) (39)
Foot{40}
- Foot screws (2x coach bolts M8 x 10 mm with nuts) [41]

5. Proper use

The log splitter is designed exclusively for chopping firewood in the direction of the grain.

The machine may only be used in the intended manner. Any use beyond this is improper. The user/operator, not the manufacturer, is responsible for damages or injuries of any type resulting from this.

An element of the intended use is also the observance of the safety instructions, as well as the assembly instructions and operating information in the operating manual.

Persons who operate and maintain the machine must be familiar with it and must be informed about potential dangers.

In addition, the applicable accident prevention regulations must be strictly observed.

Other general occupational health and safety-related rules and regulations must be observed.

The liability of the manufacturer and resulting damages are excluded in the event of modifications of the machine.

• The hydraulic log splitter is only suitable for horizontal operation. Timbers may only be split horizontally in the direction of the grain. The dimensions of the timbers to be split are a maximum of 52~cm .
• Never split wood vertically or against the grain!
• The manufacturer's safety, operating and maintenance specifications as well as the dimensions given in the technical data must be observed.
• Relevant accident prevention regulations and other generally recognized safety and technical rules must also be observed.
• The machine may only be used, maintained or repaired by trained persons who are familiar with it and have been informed of the dangers. Any liability of the manufacturer for damages resulting from arbitrary changes to the machine is excluded.
• The machine may only be operated with original accessories and original tools from the manufacturer.
• Any use beyond this is improper use. The manufacturer is not responsible for the resultant damages, the user bears this risk alone.
• Keep the work area clean and free of obstructions.
• Only operate the product on a flat, firm surface.
• Before each commissioning, check that the splitter is functioning properly.
• Only operate the product in areas that are a maximum of 1000m above sea level.

Please note that our products were not designed with the intention of use for commercial or industrial purposes. We assume no guarantee if the product is used in commercial or industrial applications, or for equivalent work.

6. Safety information

WARNING: When using power tools, the basic safety precautions below must be followed in order to reduce the risk of fire, electric shock, and personal injury. Please read all instructions before working with this tool.

• Observe all safety information and danger notices on the machine.
• Ensure that all of the safety information and danger notices on the machine are complete and in legible condition.
• The safety equipment on the machine must not be disassembled or made unusable.
• Check mains connection cables. Do not use faulty connection cables.
• Check for correct function of the two-hand control before commissioning.
• The operating personnel must be at least 18 years of age. Trainees must be at least 16 years of age and may only work on the machine under supervision.
  Children may not work with this product.
• Wear work and safety gloves, safety goggles, close-fitting work clothes, and hearing protection (PPE) while working.
• Caution when working: Danger of injury for fingers and hands due to the splitting tool.
• Modification, adjustment and cleaning work, as well as maintenance and rectification of faults may only be carried out when the engine is switched off. Pull out the mains plug!
• Installation, repairs and maintenance work on the electrical equipment may only be carried out by electricians.
• All protective and safety equipment must be reassembled immediately after repair and maintenance work is completed.
• Switch off the engine when leaving the work station. Pull out the mains plug!
• Removing or working without guards is prohibited.
• When splitting, the properties of the wood (e.g. growths, trunk slices of irregular shape, etc.) can result in hazards such as ejecting parts, splitter blocking, and crushing.

7. Additional safety instructions

The log splitter may only be operated by a single person.
- Never split trunks that contain nails, wire, or other objects.
- Wood that has already been split and wood chippings create a hazardous work area. There is a danger of tripping, slipping or falling. Always keep the work area orderly.
- Never place your hands on moving parts of the machine when it is switched on.
- Only split wood with a maximum length of 52cm .

Warning! This power tool generates an electromagnetic field during operation. This field can impair active or passive medical implants under certain conditions.

In order to prevent the risk of serious or deadly injuries, we recommend that persons with medical implants consult with their physician and the manufacturer of the medical implant prior to operating the power tool.

Residual risks

The machine has been built according to the state-of-the-art and the recognised technical safety requirements. However, individual residual risks can arise during operation.

• Danger of injury for fingers and hands from the splitting tool in the event of improper guiding or support of the wood.
• Injuries due to the workpiece being ejected at high speed due to improper holding or guiding.
• Health hazard due to electrical power, with the use of improper electrical connection cables.
• Before performing setting or maintenance work, release the start button and pull out the power plug.
• Furthermore, despite all precautions having been met, some non-obvious residual risks may still remain.
• Residual risks can be minimised if the "Safety information" and the "Proper use" together with the operating manual as a whole are observed.
• Avoid accidental starting of the machine: the operating button may not be pressed when inserting the plug in an outlet. Use the tool that is recommended in this operating manual. This is how to ensure that your machine provides optimum performance.
• Keep your hands away from the work area, when the machine is in operation.

8. Technical data

Dimensions L x W x H. 1160 x 425 x 610 mm

Wood min-max 50-250 mm

Wood length - max. 200-520 mm

Motor 220-240 V\~ /50 Hz

Speed. 2800 rpm

Power 2200 W (S3 25%

Splitting force. max. 6 t

Cylinder stroke. 370 mm

Cylinder forward stroke 3.08 cm/s

Cylinder reverse stroke. 5.29 cm/s

Oil quantity (HLP 32) 3.5 I

Operating pressure 20.8 Mpa

Weight with base frame. 57.6 kg

Weight with foot. 54 kg

Operating mode* .S3 25%

Degree of protection. IP54

Technical changes reserved!

Noise and vibration

Warning: Noise can have serious effects on your health. If the machine noise exceeds 85 dB (A), please wear suitable hearing protection.

Noise data

Sound power level L_wA 96 dB (A)

Sound pressure level L_pA 89.8 dB (A)

Uncertainty K_WA / pA 3 dB (A)

*Operating mode S3, periodic intermittent operation without start-up process influence on the engine warming up. The mode comprises of a start-up period, a time with constant load and an idle time. The operating time is 10 mins, the relative duty cycle is 25% of the operating time.

Compressive force

The performance level of the built-in hydraulic pump can reach a brief pressure level for a splitting force of up to 6 tons. In the basic setting, hydraulic splitters are set at the factory to an approx. 10% lower output level. For safety reasons, the basic settings must not be changed by the user. Please note that external circumstances such as operating and ambient temperature, air pressure and moisture affect the viscosity of the hydraulic oil. In addition, manufacturing tolerances and maintenance errors can affect the reachable pressure level.

9. Unpacking

• Open the packaging and carefully remove the product.
• Remove the packaging material, as well as the packaging and transport safety devices (if present).
• Check whether the scope of delivery is complete.
• Check the product and accessory parts for transport damage. In the event of complaints the carrier must be informed immediately. Later claims will not be recognised.
• If possible, keep the packaging until the expiry of the warranty period.
• Familiarise yourself with the product by means of the operating manual before using for the first time.
• With accessories as well as wearing parts and replacement parts use only original parts. Replacement parts can be obtained from your dealer.
• When ordering please provide our article number as well as type and year of manufacture for your product.

Attention!

The device and the packaging material are not children's toys! Do not let children play with plastic bags, films or small parts! There is a danger of choking or suffocating!

10. Assembly

Note

Due to the heavy weight of the product, we recommend installation by at least two people.

10.1 Installing the handle (3) (enclosed accessories bag (36) A) (fig. 3)

You require the following for assembly:

Allen key, 5 mm

Assembly tool is not included in the scope of delivery.

1. Fasten the handle (3) to the U-bow (7) with two screws M_6 × 16 (A).

The log splitter is suitable for operation on a workbench (see 10.2) or on the supplied machine stand (10.3).

10.2 Fitting the log splitter onto the workbench (Fig. 1 + 4)

1. Set the log splitter to a height of 73.5cm on a stable, even and level workbench.
2. Fix the log splitter to the workbench using the two suitable screws and nuts (not included in the scope of delivery). To do so, use the two holes on the foot (40).

10.3 Machine stand assembly (fig. 1 + 5)

Your base frame is not completely assembled for packaging reasons and must be mounted by yourself.

You require the following for assembly:

• Phillips screwdriver
• Open-end spanner AF 13 mm
• Open-end spanner AF 16 mm
  Tongs (e.g. needle-nosed pliers) for removing the safety splint (17)

Assembly tool is not included in the scope of delivery.

1. Step 1: Place the log splitter (29) vertical to the motor (14) facing down towards the floor and underlay this with a suitable surface. Use the polystyrene padding of the packaging or a cover, for example.
2. Remove the premounted foot (40) from the log splitter (29). Remove the foot screws (41) using a open-end spanner AF 13 mm.
3. Remove the premounted transport wheels (15) with the washers (16), safety splints (17) and wheel caps (18) from the wheel axles of the log splitter (29).
4. Step 2: Fit the two wheel supports for the machine stand (24) to the wheel bolts of the log splitter (29). Screw both screws M8 × 20mm (38), washers, spring washers and nuts M8 to the wheel supports of the machine stand (24).
5. Step 3: Guide the machine stand cross member (23) into the machine stand foot bracket (25). First, fasten the machine stand cross member (23) lightly with a screw M10 × 20 (39).
6. Push the wheel axles from the machine stand (22) onto the cross member from the machine stand (23) and fasten them with a screw M10 × 20mm (39).
7. Fit the transport wheels (15) with the washers (16), safety splints (17) and wheel caps (18) onto the wheel axles of the machine stand (22).
8. Step 4: Insert the wheel axle from the machine stand (22) onto the wheel supports for the machine stand (24) and fasten each with a screw M10 × 20 mm (39).
9. Fasten the machine stand foot (25) to the log splitter (29). To do this, use the screws M8 × 25 mm (37).
10. Now tighten the screw M10 × 20 of the machine stand cross member (23) using an open-end spanner (AF 16) to fix it in position.
11. Set the product up on an even, stable surface.
12. Fix the splitter to the surface by using two screws or two ground pegs (not included in the scope of delivery) on the foot of the machine stand (25).

10.4 Installing tray table 1 (26) (enclosed accessories bag (36) B) (fig. 6 + 7)

You require the following for assembly:

• Phillips screwdriver

Allen key, 5 mm
- Open-end spanner AF 10 mm

Assembly tool is not included in the scope of delivery.

1. Fit tray table 1 (26) to the rear protective guard (20) and fix it in place using the two enclosed hexagon socket screws and nuts (B).
2. Undo the hexagon socket screw with washer that is located on the engine cover panel (see fig. 6).
3. Now guide the open end of the support strut (19) between the washer and the wheel bracket, tighten the hexagon socket screw (B) again firmly.
4. Fasten the closed end of the support strut (19) to tray table 1 (26) using the Phillips screw and nut (B) (fig. 7).

10.5 Installing tray table 2 (27) and tray table 3 (28) (enclosed accessories bag (36) C + D + E) (fig. 8 + 9 + 10)

You require the following for assembly:

Allenkey,5mm
- Open-end spanner AF 10 mm

Assembly tool is not included in the scope of delivery.

1. Attach tray table 2 (27) to the same side as the rear protective guard (20). Use two hexagon socket screws and spring washers (C + D) to affix the tray table to the log splitter. Ensure that the table and the protective guard are level in relation to each other.
2. Loosen the left of the two screws on the foot (25).
3. Now guide the open end of the support strut (21) between the screw and the foot bracket and tighten the screw slightly.
4. Fasten the closed end of the support strut (21) to tray table 2 (27) using the Phillips screw and nut (C + D) . Align the tray table and tighten the screws.
5. Repeat steps 1 - 4 on the opposite side (see fig. 9)
6. Align both tray tables (27 and 28) in relation to each other and use the Phillips screws and nuts (E) to affix them (see fig. 10).

10.6 Installing guard (30 - 35) (enclosed accessories bag (17) F) (fig. 11 + 12)

You require the following for assembly:

• Phillips screwdriver
• Open-end spanner AF 10 mm

Assembly tool is not included in the scope of delivery.

1. Connect the guards (33) and (34) together, use two Phillips screws, clamping brackets and nuts (F) to affix them.
2. Attach the guards (33, 34) to the holes provided on the side of tray table 1 (26) and tray table 2 (27) (see fig. 6 +8). Attach the guard (32) to the holes provided on tray table 1 (26). Fasten the guard (35) with seven Phillips screws, clamping brackets and nuts (F). Fit the protective guard (32) to the control lever protection (12) using a Phillips screw and nut (F).
3. Now fasten the guards (30 + 31) on the top. Fasten them with eight Phillips screws, clamping brackets and nuts (F).

4. Fasten the guards (30 + 31) together using two Phillips screws, clamping brackets and nuts (F).

5. Finally, tighten up all the screws.

11. Before commissioning

Attention!

Always make sure the product is fully assembled before commissioning!

WARNING!

Risk to health!

Inhalation of oil vapours and exhaust gases can cause serious damage to health, unconsciousness and in extreme cases death.

• Do not breathe in oil vapours and exhaust gases.

-Only use the product outdoors.

NOTE!

Product damage

If the product is operated without or with too little hydraulic oil, this can lead to product damage.

• Fill with oil before start-up. The product is delivered without oil.

NOTE!

Environmental damage!

Spilled oil can pollute the environment permanently. The liquid is highly toxic and can quickly lead to water pollution.

-Fill/empty oil only on level, paved surfaces.
-Use a filling nozzle or funnel.
-Collect drained oil in a suitable container.
-Immediately wipe up any spilled oil carefully and dispose it according to local regulations.
- Dispose of oil as per local regulations.

Before each use, always check:

• the connection cables for defective areas (cracks, cuts and the like),
  the machine for possible damage,
• whether all screws are tightened,
  the hydraulic oil for leaks and
  the oil level and
  the safety devices.

11.1 Check the oil level (fig. 13 + 14)

The hydraulic system is a closed system with an oil tank, oil pump and control valve. There is already oil in the system when delivered. Check the oil level before the initial commissioning and regularly before commissioning. An oil level that is too low can damage the oil pump, refill with oil if necessary.

1. Pull out the mains plug and position the log splitter vertically so that the oil dipstick (9) is aligned vertically upwards.
2. Remove the handle (3) from the U-bow (7) by loosening the screw M6 × 16 (A) (see fig. 3).
3. Remove the oil drain screw with oil dipstick (9) using an Allen key size 8 (not included in the scope of delivery).
4. Wipe the oil dipstick (9) with a clean, lint-free cloth.
5. Reinsert the oil drain screw with oil dipstick (9) and turn the oil drain screw with oil dipstick (9) back in again fully.
6. Remove the oil drain screw with oil dipstick (9) again.

7. The oil level must be within the middle mark on the oil dipstick.

8. Reinsert the oil drain screw with oil dipstick (9) and tighten it using an Allen key size 8 (not included in the scope of delivery).

9. Fasten the handle (3) to the U-bow (7) with two screws M6 × 16 (A).

11.2 Topping up the hydraulic oil (fig. 14)

1. Pull out the mains plug and position the log splitter vertically so that the oil dipstick (9) is aligned vertically upwards.
2. Remove the handle (3) from the U-bow (7) by loosening the screw M6 × 16 (A) (see fig. 3).
3. Remove the oil drain screw with oil dipstick (9) using an Allen key size 8 (not included in the scope of delivery).
4. Wipe the oil dipstick (9) with a clean, lint-free cloth.
5. Reinsert the oil drain screw with oil dipstick (9) and turn the oil drain screw with oil dipstick (9) back in again fully.
6. Remove the oil drain screw with oil dipstick (9) again.
7. Carefully top up the hydraulic oil (about 3.5 l) using a suitable funnel or filling nozzle when the oil level is not within the middle mark on the oil dipstick (see fig. 13). Do not overfill the hydraulic oil.
8. Reinsert the oil drain screw with oil dipstick (9) and tighten it using an Allen key size 8 (not included in the scope of delivery).
9. Fasten the handle (3) to the U-bow (7) with two screws M6 × 16 (A).

12. Working instructions

12.1 Ventilation screw (fig. 15)

Before starting any work, it is essential to loosen the ventilation screw (6) by a few turns to ensure air circulation in the oil tank. If it remains tightened while working, the hydraulic movement leads to overpressure which can damage your log splitter!

Attention:

• Before transporting the product, it is essential to tighten the ventilation screw (6) to prevent oil leakage.
• At low temperatures, allow the splitter to idle for 5 mins. until the oil has heated up accordingly.

12.2 Switching on/off (fig. 16)

Your log splitter is equipped with two-handed operation - the left hand operates the operating lever (13), the right the release button (5). Releasing both control parts causes the pressure plate (11) to retract. If the release button (5) is switched off and the operating lever (13) is actuated, the pressure plate (11) remains at the current position.

1. Plug the log splitter's plug into the socket.
2. When laying the power supply cable, ensure that it is not led over the pressure plate (11) or near the riving knife (2). Also avoid places where there is a danger of damage or tearing.
3. Position the wooden block on the support guide. The guides hold the wooden block in the centre of the riving knife. If the wooden block does not fit well or "snugly", it must be turned.

4. Press the operating lever (13) downwards with the left hand and initiate the splitting process by pressing the release button (5) with the right hand.

5. The pressure plate (11) moves forwards and pushes the wood through the riving knife (2).

12.2.1 Thermal protection

With overloading or overheating, the protective shut-down integrated in the product switches off for safety reasons.

1. Wait approx. 15 minutes until the motor has cooled down.
2. Restart the product.

12.3 Splitting logs

WARNING!

Risk of injury!

Dry and seasoned wood can explode during the splitting process and injure the operator in the face.

During the splitting process, bruising or severing of body parts may occur due to retracting of the riving knife.

Pieces of wood that are produced during a splitting process can fall down.

• Wear appropriate personal protective equipment.

Make sure that the wood to be split does not contain nails or foreign objects. The end of the log must be cut straight. Branches must be sawn off flush. Pieces of wood cut at an angle can slip away during the splitting process! Only split timbers that have been sawn off straight.

To do this, proceed as follows:

1. Place the log to be split straight on the support surface (10).
2. Now operate the operating lever (13) with your left hand and the release button (5) with your right hand.
3. Press the operating lever (13) downwards and initiate the splitting process by pressing the release button (5).
4. If the release button (5) is switched off and the operating lever (13) is actuated, the pressure plate (11) remains at the current position. Releasing both control parts causes the pressure plate (11) to retract.
5. Now, shorten the return of the pressure plate (11) by fixing it in the desired position using the star grip screw on the stroke limitation ring (8) (see 12.4).

If a piece of log to be split cannot be split within 5 seconds, stop the process immediately. The log is probably too hard for the capacity of your log splitter. Turn the log 90^ and try again.

Note:

Continuous operation for more than 5 seconds can pose a risk of overheating. Your product may become damaged.

12.4 Stroke limitation (fig. 1)

If the log is short, it makes sense to limit the stroke of the pressure plate (11).

1. Press the control lever (13) and the release button (5) and move the pressure plate (11) until just in front of the log.
2. Release the release button (5).
3. Place the stroke limitation ring (8) at the desired position where the pressure plate (11) should remain by loosening the star grip screw.
4. Re-tighten the star grip screw.

5. You can then release the control lever (13).

6. The pressure plate (11) now remains in the set position when splitting.

12.5 Incorrect placement (Fig. 17)

Attention!

Risk of injury!

Never split multiple pieces at the same time! There is a danger that one of the parts may be flung uncontrollably from the machine.

• Always place the log flat on the support surface! It must not slip or be placed at an angle. The riving knife (2) will be overstressed if a splitting process does not take place across the entire cutting edge, but only in the upper area.
• The log must always rest firmly on the guides and on the support surface (10). Make sure that the log does not rotate while splitting and cannot jump up or slip.
• Do not overload the riving knife (2) by force splitting at the top end. This can lead to breaking of the riving knife or damage to the log splitter.
  Always split the log in the direction of the wood fibre.
• Never place wood in the log splitter crossways. This can be dangerous and/or seriously damage the log splitter.

12.6 Wedged logs (fig. 18 + 19)

ATTENTION!

Risk of injury!

There is a danger of knotty logs becoming jammed during the splitting process. Please note that the wood is under a lot of tension when it is removed and your fingers can be crushed in the split crack.

• Do not reach into the log splitter when it is running.
• Do not put any objects into the log splitter while it is running (e.g. hammer or similar).

Never try to knock or saw wedged logs out of your log splitter. This can lead to accidents and damage to the product.

Proceed as follows:

1. Release the control lever (13) and the release button (5) in order to move the pressure plate (11) back into the start position (see fig. 16).
2. Place a wedge under the log (see fig. 19).
3. Trigger a splitting process so that the pressure plate (11) pushes the wedge far below the log to be removed.
4. Repeat the above steps with new wedges until the log is pushed up and out of the log splitter.

13. Transport (fig. 20)

ATTENTION!

Disconnect the mains plug before transport.

The log splitter is equipped with two wheels and a handle for easy transport.

In order to transport the product, hold the handle (3) of the log splitter with one hand and raise it forwards from the floor. This makes it easy to transport the log splitter (fig. 20).

Before transporting the product, the ventilation screw (6) must be tightened to prevent oil leakage. (see 12.1). If the ventilation screw is left tightened, the movements will cause a certain amount of overpressure which can damage the product.

14. Maintenance

WARNING!

Risk of injury!

The product can start unexpectedly and cause injuries.

• Switch the motor off before performing any maintenance work.
• Disconnect the mains plug before carrying out any maintenance work.

WARNING!

Risk to health!

Inhalation of oil vapours and exhaust gases can cause serious damage to health, unconsciousness and in extreme cases death.

• Do not breathe in oil vapours and exhaust gases.

-Only use the product outdoors.

NOTE!

Product damage

If the product is operated without or with too little hydraulic oil, this can lead to product damage.

• Fill with oil before start-up. The product is delivered without oil.

NOTE!

Environmental damage!

Spilled oil can pollute the environment permanently. The liquid is highly toxic and can quickly lead to water pollution.

-Fill/empty oil only on level, paved surfaces.
-Use a filling nozzle or funnel.
-Collect drained oil in a suitable container.
-Immediately wipe up any spilled oil carefully and dispose it according to local regulations.
- Dispose of oil as per local regulations.

Our recommendation to you:

• The riving knife is a wearing part that must be resharpened if necessary (see 14.3).
• The combined two-hand protective device must remain smooth-running. Lubricate with a few drops of oil as required.
• Always keep the support surface clean.
• Lubricate the slider rails with a little grease.

Check the oil level regularly!

An oil level that is too low will damage the oil pump! (See 11.1)

Check the hydraulic connections and screw connections for leaks regularly and retighten them if necessary.

We recommend oil from the HLP 32 range.

When do I change the oil?

Change the oil after 150 working hours.

14.1 Changing the hydraulic oil (fig. 13 - 14)

1. Pull out the mains plug and position the log splitter vertically.
2. Remove the handle (3) from the U-bow (7) by loosening the screw M6 x 16 (A) (see fig. 3).

3. Place a suitable collection container under the oil drain screw (9).

4. Remove the oil drain screw with oil dipstick (9) using an Allen key size 8 (not included in the scope of delivery).

5. Drain the hydraulic oil mixture completely.
6. Carefully top up the hydraulic oil (about 3.5 l) using a suitable funnel or filling nozzle. Do not overfill the hydraulic oil.
7. Check the oil level. Wipe the oil dipstick (9) with a clean, lint-free cloth.
8. Reinsert the oil drain screw with oil dipstick (9) and turn the oil drain screw with oil dipstick (9) back in again fully.
9. Remove the oil drain screw with oil dipstick (9) again.
10. The oil level must be within the middle mark on the oil dipstick (see fig. 13). Top up with a little hydraulic oil if necessary.
11. Reinsert the oil drain screw with oil dipstick (9) and tighten it using an Allen key size 8 (not included in the scope of delivery).
12. Air can get into the hydraulic system after changing the hydraulic oil. Therefore, actuate the log splitter while idle several times.

Note: It is necessary to loosen the ventilation screw (6) by a few turns to ensure air circulation in the oil tank (fig. 15).

1. Then recheck the oil level and top up the hydraulic oil if necessary.
2. Fasten the handle (3) to the U-bow (7) with two screws M6 × 16 (A).

Connections and repairs

Connections and repair work on the electrical equipment may only be carried out by electricians.

Please provide the following information in the event of any enquiries:

• Type of current for the motor
  Data of machine type plate
  Data of motor type plate

Service information

With this product, it is necessary to note that the following parts are subject to natural or usage-related wear, or that the following parts are required as consumables.

Wearing parts*: Riving knife, hydraulic oil, riving bar guides

• may not be included in the scope of supply!

15. Cleaning

WARNING!

Risk of injury!

The product can start unexpectedly and cause injuries.

• Switch the motor off before performing any cleaning work.
• Disconnect the mains plug before carrying out any cleaning work.

NOTE!

Risk of damage!

Damage to the motor can occur if water penetrates into the motor unit.

• Clean the product with a brush.
• Do not immerse the product in water or other liquids and do not spray the motor unit with a high-pressure cleaner.

We recommend that you clean the product directly after every use.

Clean the product at regular intervals using a damp cloth and a little soft soap. Do not use any cleaning products or solvents; they could attack the plastic parts of the product. Make sure that no water can penetrate the interior of the product.

16. Storage

Store the product and its accessories in a dark, dry and frost-free place that is inaccessible to children. The optimum storage temperature lies between 5 and 30^ .

Store the power tool in its original packaging.

Cover the electric tool to protect it from dust or moisture.

Store the operating manual with the power tool.

17. Electrical connection

The electrical motor installed is connected and ready for operation. The connection complies with the applicable VDE and DIN provisions.

The customer's mains connection as well as the extension cable used must also comply with these regulations.

Use a portable safety switch (PRCD) if the residual current protective circuit (RCD) in the mains power supply is not provided with a rated residual current of no more than 0.03 A.

Damaged electrical connection cable

The insulation on electrical connection cables is often damaged.

This may have the following causes:

• Pressure points, where connection cables are passed through windows or doors.
• Kinks where the connection cable has been improperly fastened or routed.
• Places where the connection cables have been cut due to being driven over.
  Insulation damage due to being ripped out of the wall outlet.
• Cracks due to the insulation ageing.

Such damaged electrical connection cables must not be used and are life-threatening due to the insulation damage.

Check the electrical connection cables for damage regularly. Ensure that the connection cables are disconnected from electrical power when checking for damage.

Electrical connection cables must comply with the applicable VDE and DIN provisions. Only use connection cables with designation H05VV-F.

The printing of the type designation on the connection cable is mandatory.

For single-phase AC motors, we recommend a fuse rating of C 16A or K 16A for machines with a high starting current (from 3000 watts)!

DIN EN 61000-3-11

• The product fulfils the requirements of EN 61000-3-11 and may only be used at the following connection points: This means that use of the product at any freely selectable connection points is not allowed.
• Given unfavourable conditions in the power supply the product can cause the voltage to fluctuate temporarily.
  The product is intended solely for use at connection points that

a. do not exceed a maximum permissible mains impedance of Z = 0.468 , or
b. have a continuous current-carrying capacity of the mains of at least 100 A per phase.
- As the user, you are required to ensure, in consultation with your electric power company if necessary, that the connection point at which you wish to operate the product meets one of the two requirements, a) or b), named above.

AC motor 220 - 240 V\~ / 50 Hz

Mains voltage 220 - 240 V\~ / 50 Hz

Mains power connection and extension leads must be 3-core = P + N + SL. - (1/N/PE).

An extension cable with too small a conductor cross-section causes a significant reduction in the performance of the gardening tool. Cables up to 25m long must have a cross section of at least 3× 1.5mm^2 cables over 25m long must have a cross section of at least 2.5mm^2

The mains power connection must be protected with a max. 16 A fuse.

18. Disposal and recycling

Information on packaging

The packaging materials can be recycled. Please dispose of the packaging in an environmentally-friendly way.

Information on the German Electrical and Electronic Equipment Act (ElectroG)

Electrical and electronic appliances do not belong in household waste, but should be collected and disposed of separately.

• Used batteries or rechargeable batteries that are not installed permanently in the old appliance must be removed before disposal. Their disposal is regulated by the battery law.

• Owners or users of electrical and electronic appliances are obliged by law to return them after use.

• The end user bears personal responsibility for deleting his personal data from the old appliance to be disposed of.
• The symbol of the crossed-through rubbish bin means that electrical and electronic appliances may not be disposed of in the household rubbish.

• Electrical and electronic appliances can be handed in at the following places at no charge:

• Public service disposal or collection points (e.g. municipal building yards)

• Points of sale of electrical appliances (stationary and online) provided traders are obliged to take them back or offer this voluntarily.
  -Up to three old electrical devices per type of device, with an edge length of no more than 25 centimetres, can be returned free of charge to the manufacturer without having to purchase a new device from the manufacturer beforehand, or can be taken to another authorised collection point in your area.
  -For additional take-back conditions of the manufacturers and distributors, please contact the respective customer service.

• In the case of delivery of a new electrical device by the manufacturer to a private household, the latter may arrange for the free collection of the old electrical device upon request from the end-user. Get in contact with the manufacturer's customer service.

• These statements only apply to appliances that are installed and sold in the countries of the European Union and are subject to European Directive 2012/19/EU. Different provisions may apply to the disposal of electrical and electronic appliances in countries outside the European Union.

19. Troubleshooting

Fault Possible cause Remedy
The engine ends the split-ting process automatically.	Overvoltage protective device was triggered. Call a qualified electrician.
Log is not split. Log splitter	loaded incorrectly. Insert the log correctly.
	Size of log exceeds motor capacity. Saw logs into a more suitable size.
	Riving knife is blunt. Grind the riving knife.
	Oil leaks. Locate the leak, contact the dealer.
Pressure plate vibrates, makes noise.	Low oil and excess air in the hydraulic system.	Check the oil level, top up if necessary, otherwise contact the dealer.
Hydraulic pump whistles	Not enough hydraulic oil	Top up oil
Oil leaks on the cylinder or in other places.	Trapped air in the hydraulic system during operation.	Loosen the bleeder screw a few turns before use.
	Bleeder screw not tightened before transport.	Tighten the bleeder screw firmly before transport.
	Oil drain screw loose.	Tighten the oil drain screw firmly.
	Oil valve and/or seals defective.	Contact dealer.

20. Warranty certificate

Dear Customer,

All of our products undergo strict quality checks to ensure that they reach you in perfect condition. In the unlikely event that your device develops a fault, please contact our service department at the address shown on this guarantee card. Of course, if you would prefer to call us then we are also happy to offer our assistance under the service number printed below. Please note the following terms under which guarantee claims can be made:

• These guarantee terms cover additional guarantee rights and do not affect your statutory warranty rights. We do not charge you for this guarantee.
• Our guarantee only covers problems caused by material or manufacturing defects, and it is restricted to the rectification of these defects or replacement of the device. Please note that our devices have not been designed for use in commercial, trade or industrial applications. Consequently, the guarantee is invalidated if the equipment is used in commercial, trade or industrial applications or for other equivalent activities. The following are also excluded from our guarantee: compensation for transport damage, damage caused by failure to comply with the installation/assembly instructions or damage caused by unprofessional installation, failure to comply with the operating instructions (e.g. connection to the wrong mains voltage or current type), misuse or inappropriate use (such as overloading of the device or use of non-approved tools or accessories), failure to comply with the maintenance and safety regulations, ingress of foreign bodies into the device (e.g. sand, stones or dust), effects of force or external influences (e.g. damage caused by the device being dropped) and normal wear resulting from proper operation of the device.

The guarantee is rendered null and void if any attempt is made to tamper with the device.

• The guarantee is valid for a period of 3 years starting from the purchase date of the device. Guarantee claims should be submitted before the end of the guarantee period within two weeks of the defect being noticed. No guarantee claims will be accepted after the end of the guarantee period. The original guarantee period remains applicable to the device even if repairs are carried out or parts are replaced. In such cases, the work performed or parts fitted will not result in an extension of the guarantee period, and no new guarantee will become active for the work performed or parts fitted. This also applies when an on-site service is used.
  In order to assert your guarantee claim, please contact the service partner shown below. If the complaint is within the guarantee period, we will provide you with a return slip, with which you can return your defective device free of charge to us. It would help us if you could describe the nature of the problem in as much detail as possible. If the defect is covered by our guarantee then your device will either be repaired immediately and returned to you, or we will send you a new device.

Of course, we are also happy offer a chargeable repair service for any defects which are not covered by the scope of this guarantee or for units which are no longer covered. To take advantage of this service, please send the device to our service address.

Service-Hotline (GB):

[phone]

(0,00 EUR/Min.)

Service-Email (GB):

[e-mail]

Service Address (GB):

Forest Park & Garden

Coed Court, Taffsmead Road

Treforest, Ind. Estate, Pontypridd CF375SW

At www.lidl-service.com you can download this and many more manuals, product videos plus installation software.

The QR code takes you directly to the Lidl service page (www.lidl-service.com) and you can open your operating manual by entering the article number (IAN) 402465_2110.

Inhalt:

Seite:

[e-mail]

[e-mail]

Service-Adresse (DE):

Scheppach GmbH

Gunzburger Str. 69

Nosyou'recommendands:

Scheppach France Strassburg

2, Impasse Jean Millot

FR-6700 Strasbourg

= 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0 = 0

• Položte stiepany material vždy rovno na dosadaci plochul! Nesmie sa posuva' ani sa nesmie da' postavit' nasikmo. Rozovieraci klin (2) sa preži, ked stiepanie neprebieha na celom ostri, ale len v hornej casti.
• Stiepany material musi vzdy pevne priliehat k vedeniam a dosadacej ploche (10). Uistite sa, ze stiepany material sa poças stiepania neskruti a ze sa nemoze prudko yvmrstif alebozosunuf.
• Nepref'zajte rozovieraci klin (2) vynutenym stiepanim na hornom konci. Moze to mat za nasledok zlomenie rozovieracieho klinu alebo poskodenie stiepacky dreva.
• Stiepanyś materialźvdo stiepaţe v smere drevnych vlakien.
• Nikdy neklad'te drevo do stiepacky dreva v priecnom smere. Moze to by' nebezpecné a/alebo važne poskodit stiepacku dreva.

12.6 Zaklineny stiepany material (obr. 18 + 19)

POZOR!

Nebezpečenstvo poranenia!

Hrozi nebezpecensvo, ze sa rozvetveny stiepany material pri stiepani zasekne. Majte na pamati, ze drevo je pri uvol'ovani pod ve'kym napatim a mohl i ste si pomliazdit presty v stiepej trhline.

EC Declaration of Conformity

Translation of the original EC declaration of conformity

Article name: LOG SPLITTER - PLS 600 A1

Nom d'article: FENDEUSE DE BUCHES - PLS 600 A1

Art.-Nr. / Art. no. / Numero d'article: 3905206974-3905206981; 39052069915-39052069916

Standard references:

EN 55014-1:2017+A11:2020; EN 55014-2:2015; EN IEC 61000-3-2:2019; EN IEC 61000-3-11:2019; EN 60204-1:2018; EN 609-1:2017; EN IEC 63000:2018

This declaration of conformity is issued under the sole responsibility of the manufacturer.

Subject to change without notice

Documents registrar: Thomas Schuster

Günzburger Str. 69, D-89335 Ichenhausen

CE

SCHEPPACH GMBH

Günzburg Str. 69

D-89335 Ichenhausen

FSC

www.fsc.org

MIX

Paper from responsible sources

C111875

FSC

www.fsc.org

MIXTE

Papier issu

de sourcesresponsiblest

FSC® C111875
