PCFW 3058 - Foot bath ProfiCare - Free user manual and instructions

USER MANUAL PCFW 3058 ProfiCare

Coiled black-and-white product with white fur covering, connected to a digital thermometer (no text or symbols visible)

Thank you for choosing our product. We hope you will enjoy using the appliance.

Read the operating instructions carefully before putting the appliance into operation and keep the instructions including the warranty, the receipt and, if possible, the box with the internal packing. If you give this appliance to other people, please also pass on the operating instructions.

Symbols in this Instruction Manual

Important information for your safety is specially marked. It is essential to comply with these instructions in order to avoid accidents and prevent damage to the appliance:

WARNING:

This warns you of dangers to your health and indicates possible injury risks.

CAUTION:

This refers to possible hazards to the appliance or other objects.

NOTE:

This highlights tips and information.

Contents

Important Instructions! 34

Symbols on the Product....34

General Notes......37

Notes for Use....37

Operation....37

Electrical Connection ....37

Switching On 37

Step Switch 38

Switching Off 38

Cleaning 38

Inner Lining....38

Foot Warmers and Step Switches....38

Storage....39

Technical Data....39

Disposal 39

Meaning of the "Dustbin" Symbol ....39

Important Instructions!

Keep for Subsequent Use!

Symbols on the Product

On the products you will find symbols that indicate warnings or provide information:

Read the instructions!

Do not insert pins!

Do not use foot warmer if it is folded or pushed together.

Must not be used by very young children (0 – 3 years).

Symbols on the Product

On the products you will find symbols that indicate warnings or provide information:

Inner lining can be washed on delicate programme at a maximum of 40 °C.

Do not wash the body part.

Inner lining can be dried using the delicate programme.

Do not dry the outer cover in a tumble dryer.

Do not iron.

Do not bleach.

Do not dry-clean.

The instructions in the chapter "Cleaning" must be complied with.

WARNING:

• This appliance is not intended for use in hospitals.
- The product may not be used by infants, people who are unable to help themselves or people who are not sensitive to heat.
- The appliance may not be used by young children (under the age of eight) unless the step switch has been preset by a parent or guardian or the child has been sufficiently instructed on how to operate the step switch safely.

WARNING:

• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  • Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children without supervision.
• Do not use the product wet or in rooms with high humidity such as bathrooms etc.
• In the case of continuous use, the step switch may only be set to step "1".
• If there is a possibility that the user will fall asleep using the appliance, the appliance may only be set to step "1".
• Long, continuous use can cause burns.
• When the appliance is not being used, it must be stored as indicated in the chapter “Storage”.
• People with certain diseases (varicose veins, thrombosis etc.) should consult their doctor before using the appliance.
• The appliance may not be used on open wounds, burns, bruises, swelling or injuries.
• The appliance must not be used to keep animals warm.
  • Shoes must be removed before using the appliance.
• The appliance must not be used if signs of damage are present. If the product has these signs or if the appliance is used incorrectly, it must be taken to the dealer or service centre before being used again.

WARNING:

• Do not use a damaged appliance and disconnect it from the power supply immediately.
• If the appliance is not working because a fuse in it has been triggered, send the product to our service centre.
• Do not repair the appliance by yourself. Always contact an authorized technician. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

General Notes

• The appliance is designed exclusively for private use and for the envisaged purpose. This appliance is not fit for commercial use.
• Do not use it outdoors. Keep it away from sources of heat, direct sunlight, humidity (never dip it into any liquid) and sharp edges. Do not use the appliance with wet hands. If the appliance is humid or wet, unplug it immediately.
• When cleaning or putting it away, switch off the appliance and always pull out the plug from the socket (pull the plug itself, not the lead) if the appliance is not being used and remove the attached accessories.
• Do not operate the appliance without supervision. If you leave the room you should always turn the appliance off. Remove the plug from the socket.
• The appliance and the mains lead have to be checked regularly for signs of damage. If damage is found the appliance must not be used.
• Use only original spare parts.
• In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

WARNING:

Do not allow small children to play with the plastic foil. There is a danger of suffocation!

Notes for Use

Operation

The product keeps your feet nice and warm and relaxes them.

WARNING:

Always use the foot warmer with the inner lining. This creates a minimum distance which protects against overheating.

CAUTION:

Do not cover the step switch. This can lead to malfunctions.

Electrical Connection

1. Ensure that the appliance voltage (see label) and the mains voltage are the same.
2. Insert the plug into a properly installed socket.

Switching On

• Move the step switch on the controller to the desired setting.
• If the appliance has switched itself off after 90 minutes of use, you can switch it back on my setting the step switch to 0 (off) and then setting the desired temperature level again.

NOTE:

Unusual smells may occur during the first use. These are harmless and disappear the more the appliance is used.

Step Switch

You can choose the following settings:

Settings Function
0Off
1Low. Light heat.
2Medium
3High

NOTE:

You can identify the setting using the temperature level controller.

Switching Off

1. Set the step switch to 0 (off).
2. Only then pull the plug out of the wall socket.

NOTE:

The appliance will switch itself off after 90 minutes. This saves energy and provides additional safety as the foot warmer is never used without supervision.

Cleaning

WARNING:

• Pull the plug out of the socket before each time you clean the appliance.
• Only clean the appliance when it is cool. Risk of burns!
• Do not submerge the foot warmer with the step switch in water! This could lead to an electric shock or a fire.

CAUTION:

• Do not use any strong cleaning agents or solvents.
• Please note the care instructions on the labels!

Inner Lining

1. Take the inner lining out of the foot warmer.
2. You can wash the inner lining in the washing machine on a delicate programme at 40 °C.
   Use a mild detergent and follow the instructions of the manufacturer on amount of detergent.

CAUTION:

• Please note that the inner lining may not be chemically cleaned, wrung out, dried in a tumble dryer or ironed.

• Please note that high stress is placed on the inner lining by frequent washing. The inner lining should be washed in a washing machine a maximum of five times during its service life. We therefore recommend that you wash the appliance exclusively by hand.

• Immediately after washing, pull the inner lining into its original shape and leave it to dry lying flat over a washing stand.

CAUTION:

Do not use any clothes pegs or similar to attach the inner lining of the foot warmer to the washing stand. Otherwise this may damage the inner lining.

1. Let the inner lining dry completely before you put it back into the foot warmer. Otherwise this may damage the foot warmer.

WARNING:

Never switch the foot warmer on to dry it! This may cause an electric shock.

Foot Warmer and Step Switch

• You can brush off the foot warmers using a soft brush.
• Only clean the step switch with a dry cloth.

Storage

Let the appliance cool down completely before storing it away.

CAUTION:

• Store the product in a dry place.
• Avoid bending the appliance being bent sharply by items being placed on it during storage.

Technical Data

Model: PC-FW 3058

Power supply: 220–240 V\~, 50 Hz

Power consumption: 100 W

Protection class:...... II

Net weight: .... approx. 0.6 kg

The right to make technical and design modifications in the course of continuous product development remains reserved.

This appliance has been tested according to all relevant current CE guidelines, such as electromagnetic compatibility and low voltage directives, and is manufactured according to the latest safety regulations.

Disposal

Meaning of the "Dustbin" Symbol

Protect our environment: do not dispose of electrical equipment in the domestic waste.

Please return any electrical equipment that you will no longer use to the collection points provided for their disposal.

This helps avoid the potential effects of incorrect disposal on the environment and human health.

This will contribute to the recycling and other forms of re-utilisation of electrical and electronic equipment.

Information concerning where the equipment can be disposed of can be obtained from your local authority.
