KI6750.0SR - Cooker Küppersbusch - Free user manual and instructions
Find the device manual for free KI6750.0SR Küppersbusch in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Induction Hob |
| Brand | Küppersbusch |
| Model | KI6750.0SR |
| Number of Cooking Zones | 4 zones (2 Flex zones) |
| Control Type | Touch with slide control |
| Power Supply | 230 V ~ / 400 V 2N~ / 400 V 3N~ (depending on connection) |
| Maximum Total Power | Approx. 7,200 W (limitless via power management function) |
| Special Functions | Power Boost, Stop&Go, Lock, Timer, Power Management, Chef Functions (Keep Warm, Melt, Boil, Rapid Boil, Grill, Pan Frying, Deep Frying) |
| Flex Zone Function | Combination of two cooking zones for large cookware |
| Flex Complete Function | Combination of four cooking zones |
| Pan Detection | Yes, automatic shut-off if absent or unsuitable cookware |
| Display | Digital indicators with LED lights |
| Timer | Countdown timer (1 to 99 minutes) for each zone |
| Safety | Child lock, automatic safety shut-off, overheat detection, automatic disconnect |
| Cooking Surface | Ceramic glass |
| Cleaning and Maintenance | Ceramic glass cleaner, scraper, no steam cleaner, avoid hot sugar |
| Installation | Separation panel if drawer under hob (20 mm between bottom and hob) |
| Warranty | Refer to the provided warranty certificate |
| Weight (estimate) | Approx. 10-15 kg |
| Dimensions (estimate) | Approx. 77 cm width, 52 cm depth (typical cut-out) |
Frequently Asked Questions - KI6750.0SR Küppersbusch
How to turn the induction hob on and off?
Press the On/Off key (1) for one second. To turn off all zones, press this key again. To turn off a single zone, set its power level to 0 using the slider (2).
What types of cookware to use on an induction hob?
Use cookware with a ferromagnetic base (attracted by a magnet) and flat bottom. Minimum diameter is 8 cm for one zone, 19 cm for two spots, 24 cm for four spots. Avoid glass, aluminum, or copper cookware without a magnetic base.
How to activate the Power Boost function?
Select a zone, slide the slider to level 9 and hold for one second, or press + (11) for one second. The indicator shows 'P'. The function lasts a limited time (10 minutes) then returns to level 9.
How to use the timer?
After selecting a zone, press - (10) or + (11). Set the time (1-99 min) with these keys. The timer counts down automatically. At the end, the zone turns off and an audible signal sounds.
What does the display 'H' on a zone mean?
The 'H' symbol indicates residual heat: the zone is still hot after being turned off. Do not touch it. It disappears when the temperature drops.
How to lock the hob for child safety?
Press the Lock key (6) for one second. The indicator (7) lights up. To unlock, press the same key again. The On/Off key remains functional.
What to do if an error code C81, C82, or C90 appears?
C81/C82: excessive temperature. Let the hob cool down or remove the cookware. C90: the On/Off key is covered. Clean and dry the touch area.
How to clean the ceramic glass surface?
Clean after cooling with a damp cloth and mild detergent. For stubborn stains, use a special ceramic glass cleaner and a scraper. Remove melted sugar immediately while hot.
How to set the power limitation?
Within one minute of connecting to power, press + (11) for 3 seconds. 'PL' appears. Press Lock (6), choose the value with + or -, confirm with Lock.
Can I use large diameter cookware?
Yes, thanks to the Flex Zone (combination of two zones) and Flex Complete (four zones) functions. Activate the corresponding sensor (14 or 15) to merge the zones and use cookware up to 24 cm or larger.
