Product typeOven
BrandTomado
ModelTEO4500B
Power supply220-240 V ~ 50/60 Hz
Connected power1600 W
Capacity45 liters
External dimensions (L × P × H)568 × 421 × 356 mm
Internal dimensions (L × P × H)406 × 343 × 307 mm
Net weight10.7 kg
Timer120 minutes, with constant position for continuous operation
Cooking functionsBottom heat, top and bottom heat, top heat with fan, hot air, bottom heat with fan, top heat (grill)
Included accessoriesGrill rack, baking tray, handle
SafetyTempered safety glass, automatic shut-off with timer, audible signal at end of cooking
CleaningInterior with easy-to-clean coating, dishwasher-safe accessories
Warranty24 months
Intended useHousehold use only
Minimum clearance around for ventilation10 cm
Maximum load capacity of grid/tray2.5 kg

Frequently Asked Questions - TEO4500B Tomado

How to set the timer of the TEO4500B oven?
Turn the timer knob clockwise to the desired time (between 5 and 120 minutes). For continuous cooking, turn to the CONSTANT position. The oven automatically stops at the end of the set time with an audible signal.
What are the available cooking functions?
The oven has six functions: Bottom heat (for moist cakes), Top and bottom heat (even baking), Top heat with fan (crispy crust), Hot air (uniform cooking), Bottom heat with fan (crispy base), and Top heat (grill for meat, fish, bread).
How to clean the interior of the oven?
Before any cleaning, turn off the appliance and unplug it. Allow it to cool. Clean the interior with a damp cloth; for deep cleaning, use hot water and dish soap. Do not use abrasive products or metal scouring pads. The crumb tray can be removed from the bottom.
Can I use plastic or paper containers in the oven?
No, materials such as cardboard, paper, plastic or similar are not suitable for use in the oven. Use only heat-resistant dishes and plates.
What to do if the oven does not heat up?
Check that the plug is properly inserted and that the timer is set to a value other than 0. Make sure the circuit breaker has not tripped. If the problem persists, contact technical support. Never repair the appliance yourself.
How to use the grill function?
Turn the function selector to the top heat symbol (grill). Set the desired temperature (usually 200-220°C). Place food on the grill in the upper part of the oven. Monitor carefully as food can char quickly.
What is the maximum load capacity of the grid?
The maximum load capacity of the grid and baking tray is 2.5 kg. Do not exceed this limit.
Is it possible to cook without timer (continuous operation)?
Yes, turn the timer knob to the CONSTANT position. The oven will operate continuously. To stop it, turn the knob back to [0].
How to maintain the glass door?
The door is made of tempered safety glass. Clean it with a damp cloth. Never use a scraper, sharp/cutting or abrasive products to avoid scratches that could cause the glass to shatter.
Is the oven suitable for outdoor use?
No, the appliance must be used and stored indoors only. It is intended for indoor household use.
