USER MANUAL HRA9D+BT ROADSTAR

Press (5) on remote repeatedly to select DAB / FM / BT / CD / USB / AUX mode. POWER SUPPLY This unit operates from a main supply of 100-240V ~ 50/60Hz. Connect the AC power cord to the AC household main outlet. Ensure that the voltage is as indicated3

14 152 English on the rating plate on the rear of the unit. This unit has two working modes: STANDBY MODE: The display shows the current time and the speakers and ba- cklight are off. PLAYBACK MODE: The blue backlight is on and you can listen to music. When no sound is produced, the unit will switch to STANDBY MODE automatically after 15 minutes. To switch between PLAYBACK MODE and STANDBY MODE, press VOLUME KNOB (3) or press ON/OFF (1) on remote control.

Press SKIP+/- (7/8) (12/13 on remote) repeatedly to set the correct hour. Press STOP (11) (6 on remote) again to confirm.

2. The hour digits will flash on the display. Press SKIP+/- (7/8) (12/13 on remote)

repeatedly to set the correct hour. Press STOP (11) (6 on remote) again to con- firm.

3. The minute digits will flash on the display. Press SKIP+/- (7/8) (12/13 on remote)

repeatedly to set the correct minute. Press STOP (11) (6 on remote) again to confirm.

4. The year digits will flash on the display. Press SKIP+/- (7/8) (12/13 on remote)

repeatedly to set the correct year. Press STOP (11) (6 on remote) again to con- firm.

5. The month digits will flash on the display. Press SKIP+/- (7/8) (12/13 on remote)

repeatedly to set the correct month. Press STOP (11) (6 on remote) again to confirm.

6. The day digits will flash on the display. Press SKIP+/- (7/8) (12/13 on remote) re-

peatedly to set the correct day. Press STOP (11) (6 on remote) again to confirm. SETTING TIMER In STANDBY mode:

1. Press and hold TIMER (20 on remote). The hour digits will flash on the display.

Press SKIP+/- (7/8) (12/13 on remote) repeatedly to set the correct hour. Press TIMER (20 on remote) again to confirm.

2. The minute digits will flash on the display. Press SKIP+/- (7/8) (12/13 on remote)

repeatedly to set the correct minute. Press TIMER (20 on remote) again to con- firm.

3. Press SKIP+/- (7/8) (12/13 on remote) repeatedly to choose the alarm mode:

DAB/FM/CD/USB. Press TIMER (20 on remote) again to confirm.

4. Press TIMER (20 on remote) to activate the alarm. The alarm icon will appear on

display. Once the alarm hour is reached the unit will start playing in the chosen mode.

5. Press TIMER (20 on remote) in standby mode to deactivate the alarm. The a-3 English

larm icon will disappear from the display. SLEEP

1. This function enables you to go to sleep listening to the Radio.

2. While listening to music, press TIMER (20 on remote) repeatedly to select be-

tween OFF/15/30/45/60/75/90.

3. The Radio turns on and will turn off automatically after the selected sleep timer.

In FM/DAB mode there is an option menu.

1. Press MENU (6) (17 on remote) to access to the options.

2. Press SKIP+/- (7/8) (12/13 on remote) to search the options.

3. Press STOP (11) (16 on remote) to select the options.

4. Press MENU (6) (17 on remote) to exit the menu.

SYSTEM SETTINGS In FM/DAB mode, press MENU (6) (17 on remote) and select SYSTEM: Language: select this option to change the system language. Factory Reset: select this option to reset the device to factory settings. Software Upgrade: select this option if a new software version is released. SW version: select this oprion to see the current software version. DAB MODE Press MODE (3) (5 on remote) repeatedly to select DAB mode. Press SKIP+/- (7/8) (12/13 on remote) to search the program. DAB MENU Press MENU (6) (17 on remote) to access to the options. Full Scan: select this option to perform a full scan of the available DAB programs. You can press SCAN (9) to perform the same action. Manual Tune: select this option to select manually the DAB frequence. DRC: select this option to choose between DRC low, DRC high and DRC off. Prune: select this option to choose between PRUNE stations on or off. DAB PRESET You can program a maximum of 20 preset radio stations. Press and hold PRESET (12) (19 on remote). PRESET STORE will appear on display. Press SKIP+/- (7/8) (12/13 on remote) to select the preset number. Press STOP (11) (16 on remote) to confirm. Press PRESET (12) (19 on remote) to navigate through the presets. DAB INFO Repeatedly press INFO (5) (18 on remote) to see the following informations: NA-4 English ME / KBPS / DATE / TIME. FM MODE Press MODE (3) (5 on remote) repeatedly to select FM mode. Select a station using one of the following methods: AUTO: Long pressing SKIP+/- (8/9) (12/13 on remote) for 2 seconds or more, the frequency changes down or up automatically until a station is found. MANUAL: Repeatedly press SKIP+/- (8/9) (12/13 on remote) to change the fre- quency until you find the station you want. FM MENU Press MENU (6) (17 on remote) to access to the options. Scan Setting: select this option to choose between scanning all stations or only the strong stations. Audio Setting: select this option to choose between forcing mono audio or allowing stereo sound. FM PRESET See DAB PRESET instructions. FM INFO Repeatedly press INFO (5) (18 on remote) to see the following informations: KIND OF PROGRAM / FREQUENCE / AUDIO / DATE / TIME.

PLAYING COMPACT DISC

1. Press MODE (3) (5 on remote) repeatedly to select CD mode.

2. Press CD DOOR OPEN/CLOSE BUTTON (12) (2 on remote) to open the cd do-

or. Place a cd with the printed side facing up inside the tray, then close the cd door. The first track will start playback. Press SKIP -/+ (7/8) (12/13 on remote) to select your favorite tunes. If you hold SKIP -/+ (7/8) (10/11 on remote), the playing track will go fast backward or forward until you release the button. Press PLAY/PAUSE (9) (9 on remote) to pause the playback. The track number will start blinking. Press PLAY/PAUSE (9) (9 on remote) again to resume the playback. Press STOP (11) (6 on remote) to stop the playback. REPEAT MODE During playback, repeatedly press (7) on remote on the remote control to select: Repeat1: The current track is played repeatedly. RepeatFolder: The current folder is played repeatedly. RepeatAll: All tracks are played repeatedly. CD PROGRAMMING5 English You can program up to 99 tracks to play in any desired order.

1. Insert a disc and press STOP (11) (6 on remote) when it starts playing.

2. Press (8) on remote. “P01” will be shown on the display.

3. Press SKIP -/+ (7/8) (12/13 on remote) to select your favorite tunes.

4. Press (8) on remote to store the track in the program memory. “P02” will be

shown on the display.

5. Repeat steps 3-4 to select and store all desired tracks.

6. Press PLAY/PAUSE (9) (9 on remote) to start program play.

7. Press STOP (11) (6 on remote) once to stop the program play. Press STOP (11)

(6 on remote) twice to clear programme. AUX-IN This unit provides an auxiliary audio input jack for connecting external audio device like MP3 players, CD players and allow playback of your external source through the system speakers.

1. Use an audio cable (not included) with a RCA stereo plugs on one end of the ca-

ble. Plug one end into the AUX-IN jack on the main unit and plug the other end of the cable into the LINE OUT or HEADPHONE Jack of your external audio de- vice.

2. Turn ON the unit and your external audio device. Press MODE (3) (5 on remote)

repeatedly to select CD mode.

3. Start to play the external device (see the user manual of the external device).

1. Press MODE (3) (5 on remote) repeatedly to select BT mode.

2. Select from your portable device (Smartphone, Tablet...) the ID Bluetooth tagged

as HRA-9D+BT, then confirm connection.

3. When the pairing is successful the LED will stop blinking.

4. Now you can transfer the music to the HRA-9D+BT and all operations can only

be operated from your mobile device.

1. Insert the USB device's plug into the USB socket.

2. Press MODE (3) (5 on remote) repeatedly to select USB mode.

3. The unit will start reading the device automatically after the connection.

4. Use the same procedure as CD to listen to your USB device.

1. During playback, press and hold REC (10) (4 on remote). “DEL” will be shown

2. Press SKIP -/+ (7/8) (12/13 on remote) repeatedly to select between ONE/

3. Press REC (10) (4 on remote) again to confirm.6 English

1. While listening to PHONO/TAPE/BLUETOOTH/AUX-IN/DAB, press REC (10) (4

on remote). “REC” will be shown on the display. The REC indicator will light up. Encoding is performing now. Note that the encoding speed is 1:1.

2. Press STOP (11) (6 on remote) to stop recording.

3. The unit will create a folder in the USB device, that contain all recorded tracks.

2. Press SKIP -/+ (7/8) (12/13 on remote) repeatedly to select between ONE/

3. Press REC (10) (3 on remote) once more to start recording.

EQ OPERATIONS In any mode, you may press EQ button (18 on remote) repeatedly to select between FLAT / POP / CLASSIC / ROCK / JAZZ. SPECIFICATIONS This marking shown on the product or its literature, indicates that it should not be disposed with o-ther household wastes at the end of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users should contact the retailer where they purchased this product, or their local government office, for details of where and how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms and conditions of the purchase contract. This pro-duct should not be mixed with other commercial wastes for disposal.

CORRECT DISPOSAL OF THIS PRODUCT

(Waste Electrical & Electronic Equipment) WARNINGS The exclamation point within the triangle is a warning sign alerting the user of important instruc- tions accompanying the product. The lightening flash with arrowhead symbol within the triangle is a warning sign alerting the user of “dangerous voltage” inside the unit. To reduce the risk of electric shock, do not remove the cover. No user serviceable parts inside the unit. Refer all servicing to qualified personnel. This unit operates on 100-240V ~ 50/60Hz. If the unit is not used for a long period of time, remo- ve the plug from the AC mains. Ensure all connections are properly made before operating the unit. This unit must not be exposed to moisture or rain. This unit should be positioned so that it is properly ventilated. Avoid placing it, for example, close to curtains, on the carpet or in a built-in installation such as a bookcase. Do not expose this unit to direct sunlight or heat radiating sources.7 Deutsch
