Nina - Aroma diffuser STADLERFORM - Free user manual and instructions

Product Type	Aroma Diffuser
Brand	STADLERFORM
Model	Nina
Dimensions	100 × 160 mm (diameter × height)
Weight	360 g
Power Supply	100-240 V ~ 50/60 Hz, 3.5 W via mains adapter or USB (2A min.)
Battery Type	Rechargeable lithium (PN103040), autonomy up to 50 h
Noise level	< 26 dB(A)
Diffusion principle	Natural evaporation by fan blowing on scent oil-impregnated beads
Diffusion levels	2 levels (level 1 and 2)
LED lighting	3 modes: normal, dimmed, off
Scented globe included	White Amber
Available fragrance range	White Amber, Orange Bergamot, Red Jasmine, Blue Rosewood, Black Orchid, Yellow Vanilla
Usage	Indoor only, protected from water splashes
Safety	Do not use near a heat source, water, or ignition; handle lithium battery with care
Exterior cleaning	Damp cloth, then dry
Interior cleaning	Remove the globe, clean with a drop of dish soap on a damp sponge, dry thoroughly
Repairs	By a qualified electrician only; warranty void if non-compliant repair
Warranty	2 years, covers material and manufacturing defects, excludes wear parts and maintenance defects
Standards	CE / RoHS / EAC

Frequently Asked Questions - Nina STADLERFORM

How to turn the Nina diffuser on and off?

Press the On/Off button (6) to turn on the device (power level 2 by default). Press a second time to switch to level 1, a third time to turn off.

How to adjust the LED brightness?

Use the dimmer switch (7): press once for dimmed mode, twice to turn off the LED, once more to return to normal mode.

What is the battery life and how to charge it?

The lithium battery offers up to 50 hours of autonomy. Charge via USB port with the mains adapter or a 2A source (computer, power bank). The battery indicator LED (10) flashes when charge is below 10% and stays on solid during charging.

How to replace the scented globe?

Lift the upper part (4), remove the used globe, place the new globe (available in 6 fragrances: White Amber, Orange Bergamot, etc.) and put the upper part back in place.

Can I use the diffuser without plugging it into the mains?

Yes, once the battery is fully charged, you can unplug the USB cable and use the device on battery for up to 50 hours.

How to clean the inside of the diffuser?

Turn off and unplug the device. Remove the scented globe. Clean the upper and lower parts with a damp cloth containing a drop of dish soap, then dry thoroughly. Never immerse the device in water.

What to do in case of battery leakage?

Avoid any contact with eyes and skin. Collect the spilled liquid with a cloth and dispose of it according to local regulations. Consult a professional if necessary.

Where can I buy replacement scented globes?

Scented globes are available from the retailer where you purchased the Nina. Six fragrances are offered: White Amber, Orange Bergamot, Red Jasmine, Blue Rosewood, Black Orchid and Yellow Vanilla.

Does the diffuser make noise?

The noise level is below 26 dB(A), making it very quiet, ideal for use in a bedroom or office.

What is the product warranty?

The warranty is 2 years and covers material, construction and manufacturing defects. It excludes normal wear parts and damage due to neglected maintenance.

USER MANUAL Nina STADLERFORM

Subscribe to our newsletter!

www.stadlerform.com/Newsletter

You Tube

Stadler Form Aktiengesellschaft, Chamerstrasse 174, 6300 Zug, Switzerland
Phone [phone], Fax [phone], www.stadlerform.com/contact

English

Congratulations! You have just purchased the exceptional aroma diffuser lady NINA. It will bring you a great deal of pleasure and improve the ambient air for you.

As with all domestic electrical appliances, particular care is needed with this model also, in order to avoid injury, fire damage or damage to the appliance. Please study these operating instructions carefully before using the appliance for the first time and follow the safety advice on the appliance itself.

Description of the appliance

The appliance consists of the following main components:

1. USB cable
2. Power adapter for power supply
3. Connection for USB cable
4. Upper part
5. Lower part
6. On/Off button & button for selection of output level
7. Button for LED dimmer (normal, dimmed, lights-out)
8. Fragrance outlet
9. Fragrance Globe „White Amber"
10. Battery status display

How your product works

The way that your aroma diffuser works is based on the natural principle of evaporation. A fan blows air across the beads in the fragrance globe which are filled with fragrance oil so that the fragrance is emitted into the room.

Important safety instructions

Please read through the operating instructions carefully before you use the appliance for the first time and keep them safely for later reference; if necessary pass them on to the next owner.

• Stadler Form refuses all liability for loss or damage which arises as a result of failure to follow these operating instructions.
• The appliance is only to be used in the home for the purposes described in these instructions. Unauthorised use and technical modifications to the appliance can lead to danger to life and health.
• Use and keep the device and fragrance globe out of reach of children.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
• Only connect the cable to alternating current. Observe the voltage information given on the appliance.

• Do not use damaged extension cords.

• Do not run the power cord over sharp edges and make sure that it does not get trapped.

• Do not pull the plug from the socket with wet hands or by holding on to the power cord.
• Do not use the appliance in immediate vicinity of a bath tub, a shower or a swimming pool (observe a minimum distance of 0.7m ). Place the appliance such that a person in the bath tub cannot touch the appliance.
• Keep the device and fragrance globe away from heat sources.
• This device contains a lithium battery.
• In case of battery leakage: Avoid contact with human eyes and skin. Collect spillage.
• Do not place the appliance near a heat source. Do not subject the power cord to direct heat (such as a heated hotplate, open flames, hot iron sole plates or heaters for example). Protect power cords from oil.
• Do not drop the device. Otherwise the battery may overheat, cause a fire or malfunction and reduce service life.
• See to it that the appliance is properly positioned to ensure a high stability during its operation and make sure that no one can trip over the power cord.
  The appliance is not splash-proof.
• For indoor use only.
• Do not store the appliance outdoors.
• Store the appliance in a dry place inaccessible to children (pack the appliance).

• If the power cord is damaged, it must be replaced by the manufacturer or a repair shop authorized by the manufacturer or by similarly qualified persons in order to avoid a hazard.

• Prior to any maintenance, cleaning and after each use, switch off the appliance and unplug the mains cable from the socket.

• Repairs to electrical appliances must only be carried out by a qualified electrical technician.
• Only use the adapter provided by the manufacturer.
• Fragrance globe: Harmful if swallowed. May cause an allergic skin reaction. Very toxic to aquatic life. Toxic to aquatic life with long lasting effects. Do not eat, drink or smoke when using this product. Avoid release to the environment.
• To prolong the life of your fragrance globe, please keep it in the airtight blister pack when it is not being used. The fragrance gloce may decrease in size if it is used over a period of several weeks.

Setting up / operation

1. Place Nina in the desired position on a flat surface. Connect the USB cable (1) to the power adapter (2) and to the appliance (3) and insert the adapter into a suitable socket. Alternatively, you can also connect the USB cable to another power source such as a PC or an external battery (battery pack/power bank) with min. 2A. The device is equipped with a battery. When fully charged, it allows Nina to operate for up to 50 hours without having to be plugged into the mains.
2. Take off the top part (4). Remove the fragrance globe (9) provided from the plastic bag and place the globe back in the device. Then put the top part back on the bottom part (5).
3. Then switch Nina on by pressing her on/off button (6). The LED underneath the globe will now light up and create a soft glow. Each fragrance globe creates

a unique atmosphere.

1. When you switch Nina on, she will automatically be set to level 2. To reduce her output to level 1, press the on/off button (6) again. If you press the on/off button a third time, the device will switch off.

2. If you find the lamps too bright (in a bedroom for example), you may reduce the light intensity by pressing the dimmer button (7). You can choose between three different modes:

3. Normal mode (switched on as standard)

4. Dimmed mode (press once)
   Light-off mode (press twice)

You can return to normal mode by re-pressing the dimmer button (7).

1. On the back of the bottom part next to the connection for the USB cable (3), you will find the status display for the battery (10):

2. Normal operation with fully charged battery: LED is not illuminated

3. Battery level 10% or lower: LED flashes
4. Battery is charging: LED is illuminated constantly

When the device is fully charged, the LED will go out. You can now disconnect the USB cable and use the device in battery mode (for up to 50 hours).

Note: There are 6 different fragrance types to choose from in the fragrance globe range: White Amber, Orange Bergamot, Red Jasmine, Blue Rosewood, Black Orchid, Yellow Vanilla. You can buy the fragrance globes from the same place you bought your Nina.

Cleaning

Before maintenance and after every use, switch the device off and pull the network adapter out of the socket.

Careful: Never immerse the device in water (danger of short circuit).

• Regularly as required: To clean the outside, rub with a damp cloth and then dry thoroughly.
• Regularly as required: Cleaning the inside: Take the fragrance globe out of the device and place it on a surface that is not sensitive to fragrances. Put a drop of washing-up liquid on a damp cloth or sponge, use it to wipe the inside of the top and bottom parts and then leave them to dry completely.

Repairs

• Repairs to electrical appliances must only be carried out by a qualified electrical technician. If improper repairs are carried out, the warranty lapses and all liability is refused.
• Never operate the appliance if the adaptor or plug is damaged, after it has malfunctioned, if it has been dropped or has been damaged in any other way (cracks/breaks in the casing).
• Do not push any object into the appliance.
• If the appliance is beyond repair, make it unusable immediately by cutting through the cable and hand it in at the collection point provided for the purpose.

Disposal

The European directive 2012 / 19 / CE on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out "wheeled bin" symbol on the product reminds you of your obligation, that when you dispose of the appliance it must be separately collected. Consumers should contact their local authority or retailer for information

concerning the correct disposal of their old appliance. The fragrance globe is made from chlorine-free plastic and can be disposed of with the household waste. Battery disposal method: do not throw into the trash can, the electrode is wrapped in insulating paper, it can be recycled and reused.

Specifications

Rated voltage 100-240 V / 50/60 Hz

Power output 3.5W

Running time up to 50h

Dimensions 100 × 160 ~mm (diameter x height)

Weight 360g

Sound level < 26 dB(A)

Battery charging

temperature range 0-45 °C

Battery model PN103040

Complies with EU

regulations CE / RoHS / EAC

All rights for any technical modifications are reserved

Deutsch

forskiftene CE / RoHS / EAC

He 3KcnpnyTe 3JeKtpoPn6OpbI B MeCTax C NOBbIeHHoB BlaXHO-CTbIO.

• Bo n36exaHne nopaxeHnA 3JIeKTPnueCKnM TOKOM 3aIpeuaeTcA 3KcNlyaTnpoBaTb apomatn3aTOp BO3dUxa B HeIocpeICTBeHHoB 6JIN3OCTn BaHHbl, Dy7a nII baccSeHa (MmHmAlbHoe pacCToHnE 0.7 metpa).

• Исторуты пленов и.apоматICALshapnik Bdajn OT nctochNKOB BOCПламенегия.

• Пибор осанцен Лптун-ионным akкулгтогрм.
• B clyuae noBpeJdeHnAkkymyIaTopa n36eraTe KOHTaKTa XnIDKOCTn n3 aKKymyIaTopa C rla3amn N KoxeJ.
  He yctaHabnBaIte apomatn3aTOp B03dyxa prdOM C nCTOuHKamn TeIIa.
  He donyckaite naeHn np6opa. 3To moKet npBecTu K nepeRpeBy akyMyIaTopa nIi HapUWeHIO cyHKuHOHaJIbHOCTn np6opa, BCJeIcTBne Yero moKet yMeHbWntbcra cPOK erO cLyX6bl.

He donyckaIte, yTo6bI cTeBOi shHyp kacalc rOpayix nobepxHOCTeJIO-6bIX hArpeBaTeJIbHbIX npN6OpOB, He donyckaIte KOHTaKTA cTeBOrO shHypa C MacJIraHHCTbIMN BeUceCTBAMN.

• Cnéinte 3a Tem, yTObI HeJIb3a 6bIIO cNOTKHyTbcra O cTeBOi shHyp npn XOJDeHn IIO KOMHaTe.
  He donyckaite nonadaHna 3neKtpnpnbop 6pbI3r BOdbI.
• Дяхаенья упakуITE apomatизатор B03duya в Коробку и xpaнITE BCYXOM ПOMESEHIN, В мectax, Нedoctуньix Дядтей.
  He 3Kcnpnyte yctpoBBO BHe nOmeueHn.
• Coхсан'te 3Tu INHCTpyKcIIO ДЯдьншИС спраВОК, a B cIvyaе nepeda-ун apOMATn3aTopa BO3dUxA dpyROMy BlaIeJIbUy, nepeda'ITE INHCTpyKcIIO BmecTe C 3JIeKTPoPnp6Opom.
• Перацьденим Тхиеского обслужиманя, чістки, a takіжсяпослі кождого Incnoьзовимя, Выкlioоче пибори otcoeindnite erо ot cetи.
• Pemont npnbopa moKet 6bITb BbINOJIHeH TOLbKO aBTOpN3nPoBAHHbIM cepBnCHbIM ueHTpOM.
• Повьтустсь только щадаптором пронзворителя, BXODЯЦМВ KOMПлекТацию рибopa.
• Apomatnieckn shapik. He ynoTpe6IbTB B nIuCy, MoKet Bbl3BaTb aJIleprnueckyH KOxHyO peakun, TOKcUeH dJa BOdHbIX opraHn3MoB. I0 OKOHuaHH cPoka clyk6bl He yTuIN3InpOBaTb C 6blTOBbIMN OTXoDAMN.
• YTO6bI npOJIINb CpOK cLJX6bl apOMaTnueCKOrO 7apNka, xpaHnte erO B BO3dYxOHeIpOnHuaemOi 6JIncTePepHOyNAKOBKe. Ppr nCNoJIb30BaHn Ha IpoTjXeHn HeCKoJIbKnx HeJeB pa3Mep apOMaTnueCKOrO 7apNka MoXeT yMeHbIITbcra.

3Kcnpnyatazaia

1. YctaHOBIne Nina b HuxHOM MeCTe Ha yCTOuYbU IOBepxHocTb. IOnKJIIO- ute USB-Ka6eIb (1) K cTeBOMy aAnTepy dIra IOnaun 3JeKtpoNTaHn (2) K np6Opy (3), a 3aTeM IOnKJIIOHTe aAnTep K po3Etke 3JeKTPocETn. Kpome TOrO, Bbl MoXeTe IOnKJIIOHTb USB-Ka6eIb K dpyrOmy nCTOHNky NITAHn, TAKOMy KaK KOMNbIoTEp IIIN BHeUHn AKKymJlAToP (c KaK MmHmym 2A). Ipn6Op oChauSeH 3apJXAeMbIM aKKymJlAToPom. Iprn IOnHom 3apJde aKKymJlAToPa np6Op Nina moXe pa60TaTb Do 50 yacOB 6e3 IOnKJIIOUeHn K 3JIeKTPocETn.
2. Chmnte BepxHIO (4) qactb npnbopa. BbInbTe BXoJiBn B ha6op nocTaBKn apomatueckn (9) 7apnk n3 noJn3TnJIeHOBoY naKOBKn n noJIoXnTe erO B np6op. 3aTeM cHOba 3akpeNte BepxHIO qactb npnbopa Ha HIXHei (5).
3. Вклочип prибop Nina, нажав на кногу петаня (6). С Beetондьи Иndикатор в Нжней частп prибopa загорается, создаяя мягкую рассегнию поCBETК. Кжды apomatческийширк сизаet неовториMbій apomat и осobую atmocфepу.
   4.При вклочен apomatuzatop Nina pa6oTaETВ ctaHapTHOM pexime nHTeHCNBHOCTn apomatuzaun - ckopoctb 2. NOBtOpHBIM haxaTneM ha KhoNKy (6) nItaHn Bbi moKeTe yMeHbUnTB nHTeHCNBHOCTb apomatuzaun, yCTaHOBuB ee Ha ckopoctb 1. Prn TpeTbeM haxaTnHa KhoNKy nItaHn prn60p BblKlIOUaETcra.

4. EcIn Bbl 6nHApXKeTe, YTO NOcBcTka CInsKOM JpKaJ (HaPIMep, B CnAJIbHe), Bbl MoXeTe yMeHbWntb JpKOcTB CBeTa, HaxaB KHOkky peYIpOBKn JpKocTn (7). MoxHo Bbl6paTb OdIN n3 TpeX peXmOB:

5. 06bIyHbI pexnM (yCTaHaBnBaETcNo yMOJuaHIO npN BKJIIOyeHnN yCTpO'CTBa).

6. Pexim npnIyueHHoJ rpkocTn (HaKaTb oDIn pa3).
7. Pexim 6e3 noDCBETKn (HaxaTb Dba pa3a).

YTo6bI BepHyTbcB O6bHbI peKIM, HaxMITE KHOJky peyJInpOBKn npKocTn (7) eue pa3.

1. Ha 3aJHei cTOpOHe HIXHei qactn npnbopa pIOM C pa3bemom IJa USB-kaBeIa (3) haxoINTcH INdIKaTOP COCTOHNr 3apra aKKyMylrTopa (10):

2. CtahandapTna 3KcPnyataun, aKKymyIaTOP nOJIHOCTbIO 3apJxKeH: CBETO-IOHbI INDnKaTOp He rOpNT.

3. YpOBeHb 3apYda aKKymyIaTopa 10% nIIHnXe: CBEToNIOHbI INHnKaTOp Mmraet.
4. AkkymyJIaTOp 3apJxJaETc: CBeToIIOHbI INHdNKaTOp rOpNT nOCToHHO. Ipn noJIHOJ 3apJxKe akKymyJIaTOp a np6opa CBeToIIOHbI INHdNKaTOp rachet. Bbl moXete oTcoEiHNITb USB-Ka6eJIb n IcNoJIb30BaTb np6op BpeXIme pa60TbI akKymyJIaTOp, 6e3 IOdkJIuOHeHn erO K 3JIeKTPocEtN (do 50 y).

Yka3aHne: Hau accopTImeNT BkIouaET B c68 6 apomatnuecknx shapNKOB: White Amber, Orange Bergamot, Red Jasmine, Blue Rosewood, Black Orchid, Yellow Vanilla. Apomatnueckne shapKb Bi moXeTe KynItb y dinlepa, y koto- poro Bbl npno6pei npomatn3atop Nina.

06cIyXnBaHne n YnCTka

BhimaHne! Bo n36eXaHne nopaxeHnra 3JeKtpoTOKom HnKOrda He noRpyKaI-Te apOMaTn3aTOp B03dyxa B Body. Ipeed YnCTKO, a TaKxe NocJe NcNoJIb3O-BaHnra, O6r3aTeJbHO OTKnIOuayte apOMaTn3aTOp B03dyxa OT 3JeKtpocetN.

• Perylaryno npotnpaite BHeHnne nobepxHoctn 3JeKtpnpnbopa MrgkO cnEgKa BnaXHO caTko, nocle yero BbITpnte np6op hacyxo.
  BHytpenHra OuncTk a np6opa: BbInbTe apomatnueckn 7apnk n3 np6opau n noLoXHTe eO Ha HeBOcnpmMcyBIO K apOMaTnueckm BeIeCTBaM noBepxHOCTb. Ipotpnte BHytpenHHIO NOBepxHOCTb HIXHeN I BepxHeN YaCTN, NcNoJIb3yra He6OJIbShoe KOJIuYeCTBO CpeIcTBA dJa MbITbY PocUdbI IN BnaKHyIO caIΦETky IIN r6Ky, a 3aTeM XopoIo npocuWnte.

Pemont u yctpaheHne HencnpaBHOCTe

B ceIax 6e30nacHOCTn peMOHT 3JIeKTPoPnp6opa DOJKeH OcyIeCTBJIaTbCToJIbKO KBaJIuΦNcIupOBaHHbIMN CNeUaJIncTaMn ABTOpN3OBAHHOrO cepBnC-HOrO ueHTpa.

-「apaHTnHe pacnpoctpaHReTcHa HeNCpabBHOCTN,ObycIOBLeHHbIe HeKBaJIncuPobAHbIM peMOHTOM,a TaKKe HEnpaBbHOBJ 3KcJIyatauNei eJneKTpOpi6opa.
- 3anpeuetaetcncnoIb30BaHne HeucnpaBnHO 3JIeKtpoPnp6opa, a TaKxe npMexaHnuecknx nII INhIX NOBpeXdEHNx CamOro 3JIeKtpoPnp6opa, cTeBOrO shHypa nII erO BnIKN.

• HNKoIa He pa3bnpaIe 3JIeKTpOpnp6Op camocToIeIbHo, He BCTaBJIte HnKaKne NOcTOPOHHne IpeDMeTbI B OTBepCTnB KOpnyce 3JIeKTpOpnp6Opa.

Yttnn3aun

Позьтсь об okржаюше! He BbIbpaBbAite HeicnpaHbIe 3JIeKTPoPn6Opby BmecTe C 6bITOBbIMN OTxOdaMn. 06paTntEcB ДЯ 3Tnx ZeIeB CNEuaJIIN3uPobAHbIy ПYNKT yTNIN3aUIM NJIeKTPoPn6OpOB. AApcea PYNKTOB IprEma 6bITOBbIX 3JIeKTPoPn6OpOB Ha Nepepa6tKy Bbl MoXete POnyHTB B MyHUnIaJIbHbIX CnyX6ax BaIero ropoda. HenpaBInbHaR yTNIN-3aUIN 3JIeKTPoPn6OpOB HahocNT HeNoPpABIMbI BpeD OkpyKaIOUeCpeDe. Ppi 3amHe HeNCpabHOrO 3JIeKTPoPn6OpBa Na HObI JOpINdUcckyIO OTBeTCTBeHHOCb 3a yTNIN3aUINO DoJxKeH HeCTN IpOdaBeU. Apomatueckn ShapIK

CdeJahn 3 PnaCTMaCCbI, He CopejkaUeXJlopa, N MoKet 6bITb yTIN3NpOBaH BmecTe C 6bITOBbIM Mycopom. AkKymyJIrTop RaBJIeTcR IpeE3apJxJaEMbIM, eRo HeJIb3r yTIN3NpOBaTb BmecTe C 6bITOBbIMN OTXODAMN.

CneunФнkaця

3neKtpoHtAnHe 100-240B / 50/60T

MoUHocTb 3.5BT

Bpempa60TbIdo50y

T6apntb1 100x160 MM (DnaMeTp x BbICota)

Macca, npimepno 360r

YpOBeHb 乌Ma < 26 d5(A)

Диапазон Temператур

ДяЗарядкнakкулгетopa 0-45 °C

CoOTBcTByeTeBpOneckm npaBnIam6e3oNaChoctn CE/RoHS/EAC

Ipon3BODntelb coxpaHReT 3a c6oB npaBO Ha BHeceHne n3MeHEnB TEXHnYeCKne XapaKTePncTnK, KOMJIeKTAuIO N KOHCTpyKcNIO daHHOJ MOeJIIN 6e3 IpeDbapNTelbHOrO yBeDOMLeHnR.

This warranty covers defects of construction, manufacturing and material. Excluded are all wearing parts and improper usage, or consequential damages due to lack of cleaning and/or descaling of the appliance.

2 Jahre Garantie

6300 Zug, Switzerland

Phone [phone]

DISTRIBUTION EU

Stadler Form Germany GmbH

Alt-Heerdt 104

40549 Dusseldorf, Germany

Phone [phone]

Design by Bernhard Burkard

Thanks to all people involved in this project: Barry Huang for his engagement and organization, Jerry Lee with Shen Yongjiu for the main engineering and Shu Hebo for his CAD work, Mario Rothenbuhler for the photos and Fabian Bernhard and Thomas Burkard for the unique design, Matti Walker for the elegant artwork.

Martin Stadler, CEO Stadler Form Aktiengesellschaft

www.stadlerform.com

Stadler Form
