USER MANUAL GME 36 FS Güde

Translation of the original instructions - Brush cutter attachment

Starting-up the machine

ENGLISH Read and understand the operating instructions before using the appliance. Familiarise with the control elements and how to use the appliance properly. Abide by all the safety measures stated in the service manual. Act responsibly toward third parties. The operator is responsible for accidents or risks to third parties. In case of any doubts about connection and operati- on refer please to our customer center WARNING! Please follow the safety instructions given in the instruction manuals of the GME 36 motor unit. Speci ed Conditions Of Use The brush cutter attachment may only be used with the GME 36 motor unit. The garden appliance has only been designed to cut grass and weed in gardens and along seed beds and borders in private house gardens and hobby gardens. Do not use this product in any other way as stated for normal use. Not observing general regulations in force and instructions from this manual does not make the manufacturer liable for damages. WARNING! Danger of injury ! The appliance must not be used to cut hedges, hard branches and wood or to crush material for compost. Always have your arms and legs in safe distance from the cutting mechanism, in particular after turning the engine on. Technical Data Brush cutter attachment GME 36 FS Knife Thread Art. No

(2) Cutting width 255 mm 420 mm Weight 3,1 kg The following details apply to a motor unit with mounted devices.

99 dB (A) 96 dB (A) Measured according to

WARNING: The vibration emission level will vary because of the ways in which a power tool can be used and

may increase above the level given in this information sheet. The vibration emission level may be used to compare one tool with another. It may be used for a preliminary assessment of exposure. An accurate estimate of the vibratory load shouldalso take into account the times when the tool isshut down or when it is running but not actually inuse. This may signi cantly reduce the vibratoryload over the total working period. Identify additional safety measures to protect theoperator from the e ects of vibration such as:maintain the tool and the accessories, keep thehands warm, organisation of work patterns.D

ENGLISH Residual risks Even when the device is used properly and all safety regulations are complied with, there still may be some residual risks. Rotating blades may lead to serious injuries by cutting or amputating parts of the body. Never touch under the housing body when the engine is running. Safety gloves to be used! Never use the string trimmer without the protec- tive cover. The cutting head keeps rotating for a few seconds after the appliance is switched o . Keep your hands and feet in safe distance. Thrown-o stones or soil may lead to injuries. Before mowing, check the area to be mowed for any undesirable objects. Wear safety goggles when working.

• Hearing damage A longer stay in the immediate vicinity of the running unit may cause hearing damage. Wear ear protectors!

• Damage to health arising from vibrations to hand and arms if the device is used for a long time or if the device is not guided and evaluated properly. Despite the observance of the operating instructions there still may be some hidden residual risks. Symbols WARNING/Caution! Read the Operating Instructions Wear eye protective goggles ! Wear ear protectors! Wear protective helmet ! Wear safety cut through resistant shoes with safety sole and steel toe ! Safety gloves to be used! Wear protective clothing with cut through resistant ply ! Take the replaceable battery from the appliance before any extension, cleaning and servicing works. Rotation direction Knife blade Warning against thrown-o items Warning against dangerous kickback. Warning against feet injury as a result of rotating knife. Risk by rotating knife. 15 m (50 ft) Do not let other persons get near due to foreign objects being thrown o . Protect against humidity. Never expose tool to rain. CE marking Any damaged or disposed electric or electronic devices must be delivered to appropriate collection centres. Protect against humidity This side up Safety instructions for Grass trimmer & Brush cutter attachment Keep all parts of the body in safe distance from the knife. Do not try to remove the material being cut or hold material to be cut when the knife is running. Jammed cuttings to be removed only when the machine is o and the battery taken out. A moment of inattention when using the hedge trimmer may result in serious injuries. Carry the string trimmer with the handle, with the blade being o (idle). The battery must be remo- ved for transport or storage of the string trimmer. Careful treatment with the appliance reduces the risk of injury by the blade. Warning against sharp knives. Be careful to avoid injury by the cutting tools. Kickback can lead to casualties. Carefully check the terrain where the appliance is going to be used and remove all objects that could get caught or thrown o by the appliance such as stones, branches, wires, animals, etc. Turn the appliance on only when in a normal working position. GBD

ENGLISH Poor lighting/light conditions represent a high safety risk. Provide adequate lighting or good lighting conditions when working with the machine. Do not use the appliance to cut grass that is not on the ground, e.g. grass growing on walls, rocks, etc. When being blocked, turn the appliance immediately o and remove the jammed item. Never cross any gravel roads or paths with the run- ning appliance. Maintenance Take the replaceable battery from the appliance before any extension, cleaning and servicing works. Repairs and works speci ed in these Instructions may only be performed by quali ed authorised sta . Use only original accessories and original spare parts. Keep the device, in particular the air vents, clean at all times. Never spray water on the device body! Never clean the machine and its components with solvents, ammable or toxic liquids. Us only a damp cloth making. After each use, clean the string trimmer and remove any grass remains. Check the cutting equipment function. Only a regularly maintained and treated appliance can serve as a satisfactory aid. Insu cient mainte- nance and care can lead to unforeseen accidents and injuries. If necessary, a list of spare parts can be found at www. guede.com. Disposal The disposal instructions are based on the icons placed on the appliance or its package. Any damaged or disposed devices must be delivered to appropriate collection centres. Transport packaging disposal The packaging protects the machine against damage during transport. Packaging materials are usually chosen based on environment aspects and waste treatment principles and are therefore recyclable. Re- turning the packaging into material circulation saves raw materials and reduces waste production. Parts of packagings (e.g. foils, styropor®) can be dangerous for children. Risk of su ocation! Keep parts of the packagings out of reach of children and dispose them as soon as possible. Guarantee Warranty period of 12 months applies to commercial use and 24 months applies to private use and com- mences on the day of purchase of the device. The guarantee solely covers inadequacies caused by material defect or manufacturing defect. Original payment voucher with the sales date needs to be sub- mitted for any claim in the guarantee period. The guarantee does not cover any unauthorised use such as appliance overloading, use of violence, damage as a result of any unauthorised interference or caused by foreign items. Failing to follow the ope- rating and assembly instructions and common wear are also not included in the guarantee. Important information for the customer Please be sure to know that returning the product in or after the warranty period must be made in the original packaging. Service Do you have any technical questions? Any claim? Do you need any spare parts or operating instructions? We will quickly help you and without needles bure- aucracy at our web pages at www.guede.com in the Servicing part. Please help us be able to help you. In order to identify your device in case of claim we need the serial No., product No. and year of production. All this data can be found on the type label. Please enter it here for future reference: Serial No.: Art. No: Year of production: Tel.: [phone] / 700-360 Fax: [phone] E-Mail: [e-mail]
