USER MANUAL CM8100 RUSSELL HOBBS

Please Read and Save this Use and Care Book.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the following:

• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against fire, electric shock and injury to persons do not immerse cord, plugs or appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by or near children.
• Unplug appliance from outlet when neither the appliance nor display clock is in use, and before cleaning.
• Allow to cool before putting on or taking off parts, and before cleaning the appliance.
• Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or has been damaged in any manner. Contact Consumer Support at the number listed in this manual. This appliance has important markings on the plug blade. The attachment plug or entire cordset (if plug is molded onto cord) is not suitable for replacement. If damaged, the appliance must be replaced.
• The use of accessory attachments not recommended by the appliance manufacturer may result in fire, electric shock or injury to persons.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• To disconnect while brewing or keeping warm, press the button, then remove plug from wall outlet. To disconnect while neither brewing nor keeping warm, just remove plug from wall outlet.
• Do not use this appliance for other than intended use.
• Keep lid on the carafe when in use.
• Scalding may occur if the lid is removed during the brewing cycles.
• The carafe is designed for use with this appliance. It must never be used on a range top.
• Do not set a hot carafe on a wet or cold surface.
• Do not use a cracked carafe or a carafe having a loose or weakened handle.
• Do not clean carafe with cleansers, steel wool pads or other abrasive material.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.

SAVE THESE INSTRUCTIONS.

This product is for household use only.

POLARIZED PLUG

This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.

TAMPER-RESISTANT SCREW

Warning: This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside. Repair should be done only by authorized service personnel.

ELECTRICAL CORD

a) A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.
b) Extension cords are available and may be used if care is exercised in their use.
c) If an extension cord is used:

1) The marked electrical rating of the extension cord should be at least as great as the electrical rating of the appliance;
2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord; and
3) The cord should be arranged so that it will not drape over the counter top or tabletop where it can be pulled on by children or tripped over.

Note: If the power cord is damaged, please contact the warranty department listed in these instructions.

WARNING

RISK OF FIRE OR ELECTRIC SHOCK. DO NOT OPEN.

The lightning symbol refers to "dangerous voltage"; the exclamation symbol refers to maintenance instructions. See below.

Warning: To reduce the risk of fire or electric shock, do not remove the cover of the coffeemaker. There are no user-serviceable parts inside. Repair should be done by authorized service personnel only.

BUTTON FUNCTIONS

hr

min

brew now/off hour program minute auto clean

How to Use

This appliance is for household use only.

GETTING STARTED

• Remove all packing materials, any stickers and the plastic band around the power plug.
  To register your product, go to www.prodprotect.com/russellhobbs.
• Wash all parts as instructed in CARE and MAINTENANCE section.
• Select a level surface where this unit is to be used allowing enough space for steam to escape without damage to counters, cabinets and walls.

PARTS

1. Reservoir lid (part no. CM8100-01)
2. Filter holder (part no. CM8100-02)
3. Filter compartment lid
4. Lid lock
5. Reservoir
6. Carafe with lid (part no. CM8100-03)
7. Display
8. Hotplate
9. Reusable filter (part no. CM8100- 04)

BEFORE USING FOR THE FIRST TIME

• Fill the reservoir to the max mark, and run the appliance without coffee.
• Let it cool, discard the water, and then use it normally.

SET THE CLOCK

1. Put the plug into the power outlet.
2. Use the hr and min buttons to set the correct time.
3. The clock will retain its settings until the coffee maker is unplugged.

FILLING

1. Lift the lid off the reservoir.
2. Fill with water to at least the 2 mark (0.25 L) but not above the max mark (1.25 L). The reservoir holds enough water for 8 servings at 5.0 oz. (148 ml) each.
3. Press the lid lock to open the filter compartment lid.
4. Put the reusable filter into the filter holder.
5. For each serving, add 7.5g (1^1 / 2Tbsp.) of ground coffee.
6. Close the lid, and press down to lock it.
7. Put the carafe on the hotplate.

MAKING COFFEE

1. Press the button - the icon will appear on the display.
2. Shortly afterwards, coffee will start to drip into the carafe.
3. When it's done, the hotplate will keep the carafe warm for 40 minutes.
4. If you want to stop the coffee maker while it's brewing, press the button.

USING THE TIMER

1. Set the clock to the correct time. Use the hr and min buttons.
2. To set the timer to the time you want to start brewing:

a) Press the button.

1. b) Use the hr and min buttons to set the time you want brewing to start. If you don't press either the hr or min buttons within 5 seconds, the coffee maker will revert to "normal", and the current time will show. Press the ④ button to start programming process again.

2. When the time is programmed, press the button. The light above the ① button will come on and the ① icon will appear on the display. Your coffee maker is now set to make coffee at the selected time.

3. To check the programmed time, press the ① button. The programmed time will show for 3 seconds and then return to the time of day.

4. To cancel the timer before brewing has started or stop the coffee maker while it's brewing, press the button.

KEEP WARM/AUTO SHUT-OFF

1. The coffee maker will keep the coffee warm for about 40 minutes and 40:00 will be displayed and will count down in 1 minute increments.
2. 40 minutes after brewing, the icon will go out and the coffee maker will shut down and only the time of day will be displayed.
3. To wake the appliance, press any button.
4. For best flavour, coffee should be consumed within 40 minutes.

PAUSE AND POUR FEATURE

If you want a quick cup of coffee before the brewing cycle has finished:

1. You can remove the carafe at any time. The non-drip valve will prevent coffee dripping on to the hotplate.
2. To prevent the filter holder overflowing, replace the carafe on the hotplate within about 20 seconds.
3. When you replace the carafe the coffeemaker resumes brewing.

CARE AND MAINTENANCE

1. Unplug the appliance and let it cool.
2. Dispose of used coffee grounds.
3. Clean the outside surfaces of the appliance with a damp cloth.
4. Hand wash the carafe, reservoir lid, and filter holder.

SELF CLEAN

After 60 brewing cycles, the clean icon will appear on the display. This is to remind you to activate your coffee maker's self cleaning feature.

This operation will take approximately 45 minutes.

1. Pour 500ml (16 oz.) of white vinegar and 500ml (16 oz.) of water into the reservoir.
2. Close the lid.
3. Place the carafe on the hotplate.
4. Press the button. The light above the button will come on and the icon will appear on the display.
5. After the self clean cycle, empty carafe and replace it on the hotplate.
6. Fill reservoir with cold water to max line. Turn on coffeemaker for a complete brew cycle to flush out remaining cleaning solution. You may wish to repeat this step.
7. Hand wash the removable parts.

NEED HELP?

Warranty Information

(Appplies only in the United States and Canada)

For service, repair or any questions regarding your appliance, please call our Customer Service Line at 1-800-947-3744. Please DO NOT return the product to the place of purchase. Also, please DO NOT mail product back to manufacturer, nor bring it to a service center. You may also want to consult www.prodprotect.com/russellhobbs.

What does it cover?

• Any defect in material or workmanship provided; however, the liability of Spectrum Brands, Inc. will not exceed the purchase price of product.

How long is the warranty valid?

• In the United States: Two years from the date of original purchase with proof of such purchase.

• In Canada: Two years from the date of original purchase with proof of such purchase. Canadian residents can register online for an extra year of warranty at: www.prodprotect.com/russellhobbs.

What will we do to help you?

• Provide you with a reasonably similar replacement product that is either new or factory refurbished.

How do you get service?

• Save your receipt as proof of date of sale.
• Visit the online service website at www.prodprotect.com/russellhobbs, or call toll-free 1-800-947-3744, for general warranty service.
• If you need parts or accessories, please call 1-800-738-0245.

What does your warranty not cover?

• Damage from commercial use
• Damage from misuse, abuse or neglect
• Products that have been modified in any way
• Products used or serviced outside the country of purchase
  Glass parts and other accessory items that are packed with the unit
• Shipping and handling costs associated with the replacement of the unit
• Consequential or incidental damages (Please note, however, that some states do not allow the exclusion or limitation of consequential or incidental damages, so this limitation may not apply to you.)

How does state law relate to this warranty?

• This warranty gives you specific legal rights. You may also have other rights that vary from state to state or province to province.

IMPORTANT MISES EN GARDE

RUSSELL HOBBS and the RH logo are Trademarks of Spectrum Brands, Inc. or one of its subsidiaries.

All rights reserved.

© 2017 Spectrum Brands, Inc., Middleton, WI 53562

CM8100BKR, CM8100GYR

18170-00
