USER MANUAL Wavelab LE 8 STEINBERG

EnglishCristina Bachmann, Heiko Bischoff, Christina Kaboth, Insa Mingers, SabinePfeifer, Benjamin Schütte The PDF document provides improved access for vision-impaired users. Please note that due to the complexity and number of images in this document, it is not possible to include text descriptions of images. The information in this document is subject to change without notice and does not represent a commitment on the part of Steinberg Media Technologies GmbH. The software described by this document is subject to a License Agreement and may not be copied to other media except as specifically allowed in the License Agreement. No part of this publication may be copied, reproduced, or otherwise transmitted or recorded, for any purpose, without prior written permission by Steinberg Media Technologies GmbH. Registered licensees of the product described herein may print one copy of this document for their personal use. All product and company names are ™ or ® trademarks of their respective holders. F or more information, please visit www.steinberg.net/trademarks. Release Date: June 18, 2013 © Steinberg Media Technologies GmbH, 2013. All rights reserved.4 ENGLISH Table of Contents 6 Introduction 6 Welcome! 7 About the Documentation and the Help 8 Typographical Conventions 9 How You Can Reach Us 10 System Requirements and Installation 10 System Requirements 11 Installing the Program 12 Registering and Activating Your License 13 Hardware Installation 16 Setting up Your System56 ENGLISH Introduction Welcome! Thank you for your interest in WaveLab LE 8. This product is the entry level version of the WaveLab product family, which includes a range of functions dedicated to make the entrance in the world of professional audio editing and publishing of audio material. Beside this OEM version, there're also full versions available, named WaveLab Elements 8 and WaveLab 8, which provide further functionalities. WaveLab LE 8 is for functional and temporal unlimited personal use*. WaveLab LE 8 raises the level of your audio productions yet again providing many func tions that improve and speed up the whole audio editing process. Next to a new Master Transport Panel that lets you move throughout the project with unmatched speed, WaveLab LE 8 comes with high-resolution zoom functions, a new plug-in organization and enhanced marker functions for better project organization. To facilitate the workflow, WaveLab LE 8 incorporates enhanced render-in-place commands as well as a renewed user interface and new recording options. Those being new to WaveLab will value the improved in-app help system that allows for a fast and convenient learning process. WaveLab LE 8 offers a limited number of Audio tracks and also limited editing functions. The complete Batch processing workspace and extended Audio analysis functions are not included in WaveLab LE 8. A much higher number of professional plug-ins, advanced import- and export functions, a higher number of supported audio formats, effect section and the Sonnox restoration suite, e.g. to correct errors within old recordings, are reserved for the professional versions, WaveLabIntroduction About the Documentation and the Help

Elements 8 and WaveLab 8. Furthermore, WaveLab 8 also provides batch and loudness processing, DDP support, professional dithering, Super Clips as well as a broad range of further professional editing and mastering tools. Additional functions are available through an upgrade to a full version of WaveLab Elements 8. Projects created with WaveLab LE 8 can also be used in WaveLab Elements 8 and WaveLab 8; however, WaveLab Elements 8 and WaveLab 8 projects cannot be used in WaveLab LE 8. We would be delighted if we could welcome you as a member of the WaveLab community. The WaveLab online forum can be reached via www.steinberg.net/forum. See you around! Your Steinberg WaveLab Team *WaveLab LE 8 can be used for 30 days right away. To unlock WaveLab LE 8 for unlimited use, please register your WaveLab LE 8 product at www.steinberg.net/mysteinberg. With registration you also gain access to the entire Steinberg Knowledge Base and receive information on updates and other news regarding Steinberg products. About the Documentation and the Help The WaveLab LE documentation is divided into a Quick Start Guide, an Operation Manual (PDF format), and an in-application help. The content of the help is the same as in the Operation Manual.

• To open the help in the program, select Hel p > Contents.

• To open the Operation Manual in PDF format, install the program and navigat e to the installation folder. The PDF documents are located in the Documentation folder.IntroductionTypographical Conventions

ENGLISH NOTE To read the PDF documents, a suitable PDF reader application must be installed on your computer. Quick Start Guide This is the document you are reading. It covers the following areas without going into details:

• System requirements, installation procedure, and license acti vation.

• Setting up your system. Operation Manual and Help The Operation Manual and the in-application help are the main WaveLab LE reference documentation, with detailed descriptions of operations, parameters, functions, and techniques. Typographical Conventions Many of the default key commands in WaveLab LE use modifier keys, some of which are different depending on the operating system. For example, the default key command for Undo is [Ctrl]-[Z] on Windows and [Command]-[Z] on Mac OS X. When key commands with modifier keys are described in this manual, the y are shown with the Windows modifier key first, in the following way:

For example, [Ctrl]/[Command]-[Z] means “press [Ctrl] on Windows or [Command] on Mac OS X, then press [Z]”. Similarly, [Alt]/[Option]-[X] means “press [Alt] on Windows or [Option] on Mac OS X, then press [X]”. NOTE This manual often refers to right-clicking, for example, to open context menus. If you are using a Mac with a single-button mouse, hold down [Ctrl] and click. How You Can Reach Us On the Help menu in WaveLab LE you find items linking to additional information. The menu contains links to various Steinberg web pages. Selecting a menu i tem automatically launches your browser and opens the page. On these pages you can find support and compatibility information, answers to frequently asked questions, information about updates and other Steinberg products, etc. This requires that you have a web browser installed on your computer, and a working internet connection.10 ENGLISH System Requirements and Installation System Requirements Your computer must meet the following minimum requirements for the Windows and Mac versions of WaveLab LE: Mac OS X Windows Mac OS X Version 10.7/10.8* Intel dual-core processor CoreAudio-compatible audio hardware Windows 7/Windows 8* Intel or AMD dual-core processor Windows-compatible audio hardware** 2 GB RAM 8 GB of free hard-disk space Display resolution of 1280 x 800 pixels DVD ROM dual-layer drive required for installation Internet connection required for installation, activation, account setup, and personal/product registration. *Native 32-bit and 64-bit program version. **ASIO compatible audio hardware recommended for low-latency performance.System Requirements and InstallationInstalling the Program

Installing the Program You have two possibilities to install your program, via the Start Center application or manually. Launching Installation via the Start Center From the Start Center application you can easily install your program and inform yourself about the package contents.

• For Steinberg software delivered with an installation medium, the

art Center launches automatically as soon as you insert the disc in your computer’s CD/DVD drive, provided that autorun is activated.

• For Steinberg software downloaded from the internet, the Start

nter launches when you double-click the downloaded file. PROCEDURE

1. In the Start Center, choose your preferred language.

3. Follow the instructions on screen.

Launching Installation Manually If you do not want to install the program via the Start Center, you can install it manually.

• On Windows systems, double-click th e file “Setup.exe” and follow the instructions on screen.System Requirements and InstallationRegistering and Activating Your License

• On Mac OS X systems, double-click the file “WaveLab 8.pkg” and follow the instructions on screen. Registering and Activating Your License To be entitled to technical support, you must register WaveLab LE. Once you have subscribed to the Steinberg newsletter, you are kept aware of updates and other news regarding WaveLab. NOTE For information on how to activate your product visit www.steinberg.net/activate. Registering and Activating the DVD-Version If you have received WaveLab LE on a DVD, you can use the program out of the box for 30 days. After this period, you must register your program and activate your license permanently. PROCEDURE

1. Start WaveLab LE.

A dialog opens that informs you for how much longer you can use the program without registration and activation.

2. In this dialog, click Register Now to open the MySteinberg section

on the Steinberg web site in your standard web browser.

3. Follow the instructions on screen.

Once you have registered, you receive all the information required to activate your product.System Requirements and InstallationHardware Installation

Registering and Activating the Download-Version If you have downloaded WaveLab LE from MySteinberg using a download access code, you must activate WaveLab LE permanently using the activation code that you have received at MySteinberg. WaveLab LE are automatically registered when they are activated. Hardware Installation Installing the Audio Hardware and its Driver PROCEDURE

1. Install the audio hardware and related equipment on the computer,

as described in the hardware documentation.

2. Install the driver for the audio hardware.

A driver is a piece of software that allows a program to communicate with a certain piece of hardware. In this case, the driver allows WaveLab LE to use the audio hardware. Depending on the operating system of your computer, there are different types of drivers that can be used.System Requirements and InstallationHardware Installation

ENGLISH Dedicated ASIO Drivers Professional audio hardware often comes with an ASIO driver written especially for the device. This allows for direct communication between WaveLab LE and the audio hardware. As a result, the devices with specific ASIO drivers can provide lower latency (input-output delay), which is crucial when monitoring audio viaWaveLab LE or using VST instruments. The ASIO driver may also provide special support for multiple inputs and outputs, routing, synchronization, etc. ASIO drivers are provided by the audio hardware manufacturers. Make sure to check the manufacturer’s web site for the latest driver versions. IMPORTANT If your audio hardware comes with a specific ASIO driver, we strongly recommend that you use this. Generic Low Latency ASIO Driver (Windows Only) On Windows systems, you can use the Generic Low Latency ASIO driver. This driver provides ASIO support for any audio hardware supported by Windows, thus allowing for low latency. The Generic Low Latency ASIO driver provides the Windows Core Audio technology inWaveLab LE. No additional driver is needed. This driver is included with WaveLab LE and does not require any special installation. NOTE This driver should be used if no specific ASIO driver is available. Although the Generic Low Latency ASIO driver supports all audio devices, you might get better results with on-board audio cards than with external USB audio interfaces.System Requirements and Installation Hardware Installation

Mac OS X Drivers (Mac only) If you are using a Macintosh computer, make sure that you are using the latest Mac OS X drivers for your audio hardware. Follow the manufacturer’s instructions to install the driver. About Audio Cards WaveLab LE works with any multimedia computer compatible audio card. However, the audio quality varies dramatically between cards. For professional use of WaveLab LE we recommend that you get a card with the highest possible specifications. However, if you use WaveLab LE to edit files for use with other hardware, such as a hard disc based recording system using its own audio converters, any loss in audio quality that you experience when listening to the files in WaveLab LE, due to deficiencies in the audio card, does not affect the final audio files. For professional use we recommend that you get a card capable of playing back files in 24-bit resolution. Testing the Audio Hardware To make sure that the audio device works as expected, perform the following tests:

• Use any software included with the hardware to make sure that you can record and play back audio without problems.

• If the hardware is accessed via a standard operating system driver, try playi ng back audio using the standard audio application of the computer, for example, Windows Media Player or Apple iTunes.System Requirements and InstallationSetting up Your System

ENGLISH Installing a MIDI Interface or USB MIDI Keyboard Although many USB MIDI keyboards and MIDI interfaces are plug&play devices, you may have to install a dedicated device driver. Follow the installation procedure described in the documentation that came with the device. NOTE You should also check the manufacturer’s web site for the latest driver updates. Setting up Your System Selecting the Driver for Your Audio Device PREREQUISITE Before you can set up the routing for your audio signals and start recording, you need to make sure that the correct ASIO driver is selected. PROCEDURE

1. Select Options > VST Audio Connections.

2. In the VST Audio Connections dialog, on the Audio Device

menu, select the driver that you want to use.System Requirements and InstallationSetting up Your System

Setting Up the VST Audio Connections The VST Audio Connections dialog allows you to set up the routing of input and output signals betweenWaveLab LE and your audio hardware. Depending on the selected driver, the setting up process can be different. PREREQUISITE Select the driver for your audio device. PROCEDURE

1. In any workspace, except the Podcast workspace, select Options

> VST Audio Connections.

2. Select the Playback tab, and select and name the audio ports

cording tab, and select and name the audio ports used for recording and input monitoring.

4. If you are using an ASIO driver, select the ASIO plug-ins tab, an

select the audio ports used by the ASIO plug-ins.

5. Optional: If you are using an ASIO driver, click the Control panel

but ton and make additional settings.
