USER MANUAL Aspirovac Silence 3.0 Di4

6. Speed control ( or fixed) and dust indicator

7. Cord rewinding button

8. Air exhaust cover

9. Hook rack for tube

SAFETY INSTRUCTIONS This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction con- cerning use of the appliance in a safe way and under- stand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. If the supply cord is damaged it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Plug must be removed from socket-outlet before clean- ing or maintaining the appliance. ENGLISH12 IMPORTANT WARNINGS Prior to plugging in the product, check that your mains voltage is the same as the one indicated on the product label. The mains connection cable must not be tangled or wrapped around the product during use. Do not pull on the connection cord in order to unplug it. Do not use, connect or disconnect the device to the mains with your hands or feet wet. Proceed according to the conservation and cleaning section of this manual for cleaning. Unplug the product immediately from the mains in the event of any breakdown or damage and con- tact an authorised Technical support service. In order to prevent any risk of danger, do not open the device. Only qualified technical personnel from the brand´s Official Technical support service may carry out repairs or procedures on the device. Any incorrect use or improper handling of the product shall render the warranty null and void. Only an authorised technical support service centre may carry out repairs on this product. This appliance is designed exclusively for domestic use, in no case should be a commercial or indus- trial use. In case of misuse or tampering with the product, it will be out of warranty. Do not use the appliance to vacuum liquids (water, etc), sharp objects (pins, pins, nails, glass, etc), incandescent objects (matches, cigarettes) Never use the turbobrush to: Polish floors, suck (Liquids, wet or damp dust, hot ash, burning ob- jects, such as cigarettes, matches, sharp and hard items, such us: razors, pins, thumbtacks, pieces of glass, etc), flour, cement, plaster, printer or photocopier toner, etc. B&B TRENDS SL. disclaims all liability for damages that may occur to people, animals or objects, for the non-observance of these warnings.

INSTRUCTIONS FOR USE

1. Connect the hose accessories: insert the hose end into the hose socket at the block suction and

2. Connect the plastic tube to the curved end of the hose.

3. Connect the different nozzle tools to the metal extension tube for different cleaning purpose: Floor

brush (adjust to the type of ground) for carpet or floor; combined brush & nozzle for sofa, wall surface, curtain, corner or space between furniture and etc.

4. Start the machine: insert the plug of the cord into the power socket which satisfies the specification

on the rating label, and press the on/off switch pedal, the machine could start working.

5. Cord rewinding: hold the plug and pull out the cord; press the cord rewinding pedal, the power cord

6. When the indicator LED switch on means the dust bag is full and must be replaced.13

MAINTENANCE AND CLEANING

1. Clean the dirt cup when the dust inside are becoming more it’s time to clean the dirt cup.

• Get out the cup sets open the cover the cup

• Twist the filter get out the HEPA

2. Clean the air outlet plate filter remove the air outlet plate by hand wash it with wind water and dry

it before using it next time if the filter is broken, please change a new one. PRODUCT CARD Product card in accordance with the Delegate (EU) Commission Regulation 665/2013. Comercial Brand Di4 Model ASPIROVAC SILENCE 3.0 Energy efficiency class A Target annual energy consumption (kWh per year) calculated based on 50 cleaning sessions The real annual energy consumption will depend on how the appliance is used 26,7 Class of rugs and carpets cleaning power C Class of hard floors cleaning power A Class of (re-)emission of dust A Sound power level, db (A) 68db Nominal input power, W 80014 IF THERE IS A PROBLEM?

Power cable not connected. ON/OFF key off The cable or plug may be damaged Connect the power cable to a suitable electrical outlet. Switch the ON/OFF key on They must be repaired by an authorized service centre. LOSS OF SUCTION POWER Flexible tube / telescopic tube obstructed. Dust collection bag too full. The power regulator is not at the minimum level, if there is one. The dust collection bag is not fitted. The deposit cover is not fully closed Clean the tubes. Change the dust collection bag Increase the suction level. Introduce the dust collection bag. Close the cover properly. ADHERENCE TO THE FLOOR The pad is not adjusted to the type of floor it is attempting to clean Power regulator adjusted to a very high level Use the pad brushes for a smooth floor and remove them when vacuum cleaning rugs and carpets Reduce the suction power using dial (G) PRODUCT DISPOSAL This product complies with European Directive 2012/19/EU on electrical and electronic devices, known as WEEE (Waste Electrical and Electronic Equipment), provides the legal framework applicable in the European Union for the disposal and reuse of waste electronic and electrical devices. Do not dispose of this product in the bin, instead going to the electri- cal and electronic waste collection centre closest to your home.15 MERCI D’AVOIR PLACÉ LEUR CONFIANCE EN DI4 ET NOUS ESPÉRONS QUE CE PRO- DUIT VOUS DONNERA ENTIÈRE SATISFACTION ET PLAISIR. ATTENTION VEUILLEZ LIRE ATTENTIVEMENT LE MANUEL D’UTILISATION AVANT D’UTILISER LE PRODUIT. CONSERVEZ CE MANUEL D’UTILISATION DANS UN ENDROIT SÛR EN VUE DE CONSULTATION FUTURE. DESCRIÇÃO

Consumers should contact a technical service centre authorised by B&B TRENDS, SL. for repair of the product as any tampering thereof by persons not authorised by B&B TRENDS, SL., as well as misuse or inappropriate use, will lead to the cancellation of this warranty. The warranty must be fully completed and delivered along with the receipt or delivery docket for the effective exercise of rights under this warranty. Claims must take place within three years from delivery of the product according to the provisions of the warranty, and the consumer must inform the sales vendor of the lack of conformity, provided that such claim is made within the statutory period of warranty This warranty should be retained by the user as well as the invoice, receipt or the delivery docket to facilitate the exercise of these rights. For technical service and after-sales care outside the Spanish territory, please submit your query to the point of sale where you purchased the item or by contacting B&B TRENDS, SL.
