Product type	Tabletop oven
Brand	Klarstein
Model	Mini 10030765
Article number	10030864, 10030865
Power supply	220-240 V ~ 50-60 Hz
Power	800 W
Capacity	Approx. 10 liters (estimate)
Number of cooking levels	3
Control type	Rotary knobs: thermostat and timer
Timer	Mechanical, up to 60 minutes
Adjustable temperature	Yes, via thermostat
Heating element	Top heating element
Door	Glass door
Included accessories	Drip tray, grid, handle
Cooking functions	Classic cooking (convection not available)
Cleaning and maintenance	Clean the housing and door with a dry sponge; the interior walls with a slightly damp sponge; do not use abrasives; the drip tray and grid are dishwasher safe or hand washable
Safety	Handle for removing accessories; do not clean the hot door; unplug before cleaning; do not use near gas
Recycling	Complies with WEEE directive 2012/19/EU
Compliance	CE (EMC, LVD, RoHS)

Frequently Asked Questions - Mini 10030765 Klarstein

How do I set the timer for 5 minutes?

Turn the control knob first to 6, then back one notch to 5 minutes. This action triggers the timer for a duration of 5 minutes.

Can I use aluminum foil in the oven?

Yes, you can use aluminum foil to cover the drip tray or the top of the dish to prevent oil splatters. However, do not cover the heating element.

How do I clean the inside of the oven?

Unplug the appliance and let it cool down. Clean the interior walls with a slightly damp sponge, without using abrasives or chemicals. Do not pour water directly inside.

What should I do if the oven does not heat up?

Check that the appliance is plugged into a 220-240 V outlet and that the timer is set to a time greater than zero. If the indicator light does not come on, contact customer service.

Can I cook frozen food directly?

Yes, but follow the cooking times indicated on the packaging. Adjust the time if necessary, as the oven heats up quickly.

How do I turn off the oven manually?

Turn the timer knob counterclockwise to the OFF position. The appliance turns off immediately.

Why does the oven emit a smell or smoke during first use?

This is normal. Heat the empty oven for 10 minutes to burn off manufacturing residues. The smell and smoke will disappear after a few uses.

Can I place the oven on a wooden worktop?

Yes, but ensure the worktop can withstand heat. Do not place flammable objects nearby, and leave at least 10 cm of space around the appliance.

How do I clean the drip tray and grid?

Wash them with a soft sponge, water, and a little dish soap. Rinse and dry thoroughly. Avoid abrasive sponges to prevent scratching the surface.

Does the oven turn off automatically?

Yes, once the set time has elapsed, the timer rings and the oven turns off automatically. You can also turn it off manually at any time.

USER MANUAL Mini 10030765 Klarstein

Congratulations on purchasing this equipment. Please read this manual carefully and take care of the following hints to avoid damages. Any failure caused by ignoring the mentioned items and cautions mentioned in the instruction manual are not covered by our warranty and any liability.

Contents

Technical Data 6

Safety Instructions 6

Product Description 7

Use and Operation 8

Cleaning and Care 9

Hints on Disposal 9

Declaration of Conformity 9

Technical Data

Item number 10030864, 10030865
Power supply 220-240 V ~ 50-60 Hz
Power consumption 800 W

Safety Instructions

• Always use the Food Fork when inserting or removing the tray. Touching these will cause severe burns.
• When hot, do not apply water to the glass window. It may cause the glass to break.
• When unplugging the cord, always take hold of the plug itself. Never pull on the cord. Doing so could break the wires inside the cord.
• Do not position the unit close to a gas burner or other source of high temperature or do not direct an electric fan, etc, at the unit during USE. Doing so could prevent correct temperature control.
• Do not wet the power cord nor handle the unit with wet hands. Always unplug the cord after use, or whenever the unit is to be left unattended. A malfunction while the plug is inserted into the outlet could cause a fire.
• When cooking oil-splashing dishes such as roast chicken, it is recommended to put 2 sheets of aluminum foils on a tray in order to diminish oil splashing. Put one on a tray. Then oil will drip to a gap between foils.

Hints on Location

• If the oven is positioned too close to a wall, the wall will be burned or stained. Be sure the curtain, etc. are not in contact with the body. Do not put anything between the bottom of the body and the surface on which it is set. An object so placed could be burned.

• Do not put anything on the oven while using it, the heat could cause deformation, cracking, etc.

• Any bottled or tinned food can not be heated directly as the bottle or tin would be broken out and scald the person

• Be careful! Not to burn yourself during use or immediately after use. The metal parts and glass window of the door become extremely hot during use. Be careful not to touch them when opening and closing the door.
• AC power must be taken from a properly wired outlet. Insert the plug completely into the socket. If it is not, it could become abnormally hot. Do not use an electric light outlet. Never connect multiple plugs to the same outlet
• If the supply cord is damaged, the manufacturer or its service agent or a similarly qualified person in order to avoid a hazard must replace it.

Product Description

1 Heating element
2 Glassdoor
3 Inner case
4 Rack support
5 Door handle
6 Cover
7 Thermostat
8 Timer knob
9 Indicator
10 Stand
11 Food tray
12 Tray handle
13 Wire rack

Use and Operation

How to use the Accessory

Food tray: Roast Chicken, Hamburg steak, Gratin, Sponge cake, almost all other oven-cooked foods.

Wire rack: Baked potatoes, Dry food.

Food tray and wire rack: For food which will drip/boiled fish, etc.

You can adjust the Tray at 3 different positions according to the dishes you want to cook. For instance, when making macaroni gratin and you want to have the top part cooked the most, use the second or the second rack support. For roasting a chicken, use the fourth or the bottom rack support.

Functional Controls

Set the “Temperature Control” by turning clockwise to select the suitable temperature according to the dishes you are going to cook.

Set the arrow on the “Timer” to the number which indicates the cooking time (minutes) according to the dishes you are going to cook. Set the “Timer” by turning it clockwise. The oven will turn off automatically at the end of the selected time and a bell will ring. When setting the Timer to less than 5 min, turn it to more than 6 min. and then back to the selected time. The oven can be turned off manually during cooking by turning the “Timer” anti-clockwise to the „OFF“ position.

Operation

Before using the unit for the first time: (1) Insert the tray and baking net. (2) Heat the empty oven for about 10 minutes. Note: There may be some smoke and a burning smell at first, but this is not a malfunction.

1. Set the arrow on the timer knob to the number which indicates the cooking time (minutes) according to the dishes you are going to cook.
2. Set the Timer by turning it clockwise.
3. The oven will turn off automatically at the end of the selected time and a bell will ring. When setting the Timer to less than 5 min, turn it to more than 6 min. and then back to the selected time. The oven can be turned off manually during cooking by turning the Timer counter-clockwise to the .OFF" position.

Note: If the inside of the oven is dirty, cooking may take slightly longer than usual. Clear all left over food residues in the oven before each use.

Baking Reference of Common Food

Type of food Number	Thickness Timer
Pizza 1 cm 3-4 minutes
Toast 2-3 pcs 2-3 minutes
Hamburger 2-3 pcs	6-8 minutes
Fish - 10-12 minutes
Ham 2 cm 5-10 minutes
Sausage 3-4 pcs 8-10 minutes
Steak 1-2 cm 10-12 minutes

Cleaning and Care

Take off the plug and cool down before cleaning.
- Use dry cloth to clean outer surface of oven and glass window.
- When cleaning inside of oven, mopping with cloth can be applied. Never wash it with water as it may cause current leakage when electric parts are wet.
- Food tray, wire rack and tray handle can wash with soft cotton (or sponge) and neutral cleaner. Then rinse thoroughly with clean water, then wipe dry. Do not use hard bruch that will scratch the interior surface of the oven, and to protect the tray, wire rack and tray handle.
- Do not use the toxic and abrasive cleaners such as gasoline, polishing powder, solvent.

Hints on Disposal

m = 311 ;

According to the European waste regulation 2012/19/EU this symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it should be taken to the appropriate collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local council or your household waste disposal service.

Declaration of Conformity

Producer: Chal-Tec GmbH, Wallstraße 16, 10179 Berlin, Germany.

This product is conform to the following European Directives:

2014/30/EU (EMC)

2014/35/EU (LVD)

2011/65/EU (RoHS)
