USER MANUAL DKZ 2 A1 NEVADENT

SWIFT (BIC): PBNKDEFF 440

SWIFT (BIC): PBNKDEFF 440

Banca: Postbank Dortmund AG Se si paga tramite bonifi co bancario, sul modulo per i bonifi ci alla voce Spese contrassegnare il campo „shared“ (spese condivise). In caso contrario, non potremo elaborare l‘ordine. Indicare l‘articolo nella causale del bonifi co, nonché nome, cognome e indirizzo. Inviare quindi la cartolina di ordine interamente compilata, inse- rendola in una busta, all‘indirizzo indicato qui accanto. Kompernaß Handelsgesellschaft mbH Burgstraße 21 44867 Bochum Germania Aff rancare adeguatamente la busta. Scrivere il nome come mittente sulla busta. Mittente (si prega di compilare il modulo in stampatello) Cognome, Nome Via Cap, Città Paese Telefono IB_86273_DKZ2A1_LBCH.indb 30IB_86273_DKZ2A1_LBCH.indb 30 14.12.12 10:5414.12.12 10:54- 31 - Content Page Introduction 32 Intended use 32 Items supplied 32 Appliance description 32 Technical data 32 Safety instructions 33 Tips on usage 34 First use 34 Fitting / removing brush heads 35 Operation 35 Travelling case 35 Cleaning and Care 36 Changing the batteries 36 Disposal 37 Warranty and Service 37 Importer 38 Read these operating instructions carefully before using the appliance for the fi rst time and preserve this booklet for later reference. Pass this booklet on to whoever might acquire the appliance at a future date. IB_86273_DKZ2A1_LBCH.indb 31IB_86273_DKZ2A1_LBCH.indb 31 14.12.12 10:5414.12.12 10:54- 32 - Introduction Congratulations on the purchase of your new appliance. You have clearly decided in favour of a quality product. These operating instructions are a part of this product. They contain important information in regard to safety, use and disposal. Before using the product, familiarise yourself with all of these operating and safety instructions. Use the product only as described and only for the specifi ed areas of application. In addition, pass these documents on, together with the product, to any future owner. Intended use This appliance is intended exclusively for personal dental care. This appliance is intended exclusively for use in domestic households. The appliance is not intended for use in commercial, industrial or medical environments. It is not suitable for animal care. Items supplied Before using the appliance for the fi rst time, check to ensure that the following items are available and undamaged. Hand element 4 Brush heads 2 Batteries (fi xed under the plastic shell on delivery) Sandglass Travelling case Operating instructions Remove all packaging materials and foils from the appliance. Appliance description 1 Brush head 2 Hand element 3 On switch 4 Off switch 5 Battery compartment cover 6 Sandglass (2 minutes) Technical data Power supply: 2 x 1.5 V Battery type: 1.5 V, Mignon, AA, LR6 Protection class: IP X4 IB_86273_DKZ2A1_LBCH.indb 32IB_86273_DKZ2A1_LBCH.indb 32 14.12.12 10:5414.12.12 10:54- 33 - Safety instructions

• To avoid damage, do not permit liquids of any kind to enter the appliance and do not submerse it in water.

• Avoid also possible penetration by foreign objects.

• In the event of malfunction or apparent damage, please contact our Customer Services.

• Toothbrushes may be used by children and by persons with reduced physical, sensory or mental capabilities or lack of experience and/or knowledge if they are supervised or, in regard to the safe use of the appliance, have been instructed in its use and have understood the potential risks.

• Cleaning and user maintenance should not be per- formed by children, unless they are being supervised.

• Children may not play with the appliance.

• Do not submerse the hand appliance in water or other liquids. This would lead to irreparable damage to the appliance!

• This appliance is not intended for children under 3 years of age.

• This appliance may not come into contact with hot sur- faces. The appliance could be irreparably damaged!

• Do not open the appliance (except the battery compart- ment) yourself. There is a risk of injury with improper reassembly! Information regarding the handling of batteries When interacting with batteries, please observe the following:

• Do not throw batteries into a fi re. Do not recharge batteries. There is a risk of explosions and injuries!

• Never open batteries, never solder or weld batteries. There is a risk of explosions and injuries!

• Regularly check the condition of the batteries. Leaking batteries can cause damage to the appliance. IB_86273_DKZ2A1_LBCH.indb 33IB_86273_DKZ2A1_LBCH.indb 33 14.12.12 10:5414.12.12 10:54- 34 -

• If you do not intend to use the appliance for an extended period, remove the battery.

• In the event of the batteries leaking acids, fi rst put on a pair of protective gloves. Then clean the battery compartment and the battery contacts with a dry cloth.

• Keep batteries well away from children. Children might put batteries into their mouths and swallow them. If a battery is swallowed, medical assistance must be sought immediately. Tips on usage

• From about the age of 6 years children can use this battery powered toothbrush by themselves. It is however necessary that you explain to the child how to use both the toothbrush and the sandglass.

• Explain to the child that the best cleaning eff ect is obtained by moving the brush from tooth to tooth gently and without heavy pressure. First use Before taking the appliance into use check to ensure that it is in a fault-free condition. If it is not, it may not be used.

• Open the battery compartment in that you slide the battery compartment lid 5 downwards.

• Insert the batteries in the battery compartment as per the polarity diagram (see chapter entitled “Changing the batteries”).

• Replace the battery compartment lid 5 back onto the hand element 2. Ensure that it is fi rmly secured.

• Before the fi rst use, clean the new brush heads 1 with clear water. IB_86273_DKZ2A1_LBCH.indb 34IB_86273_DKZ2A1_LBCH.indb 34 14.12.12 10:5414.12.12 10:54- 35 - Fitting / removing brush heads To remove the brush head 1, turn it clockwise and then pull it upwards. To fi t the brush head 1 place it slightly off set on the hand element 2 and then turn it anti-clockwise. The brush head 1 must engage on being put back on. To avoid damage to the appliance, use only original brush heads. (For replacement brush heads, see the order card) Operation Warning Due to the unaccustomed operation some gum bleeding may initially occur, this is normal. Should this continue for more than two weeks, consult your dentist.

• Place the brush head 1 on the hand element 2.

• Moisten the brush under fl owing water.

• Apply some toothpaste to the moistened brush. Notice To avoid spraying toothpaste, fi rst place the toothbrush on the teeth before switching it on.

• Start the toothbrush with the on switch 3 and turn the sandglass 6 upside down. This indicates to you when the 2 minutes of cleaning recommended by dentists has been completed.

• Brush the outer surfaces of your teeth fi rst of all. Place the brush head 1 on your gums and move the brush upwards/downwards from the gums to over the crown of the tooth.

• Start again from the gums for each individual tooth.

• Clean the inner surfaces of your teeth with the same technique.

• To clean the chewing surfaces, direct the rotating brush head with light pressure over the chewing surfaces.

• Finally, thoroughly clean the back parts of the molar teeth.

• When the sand in the sandglass 6 has passed through and all teeth have been brushed, stop the toothbrush with the off switch 4 and fi rst then remove it from your mouth.

• After use, clean the brush heads 1 thoroughly under running water. Travelling case If you wish to take the toothbrush with you on your travels, you can pack it in the travelling case. IB_86273_DKZ2A1_LBCH.indb 35IB_86273_DKZ2A1_LBCH.indb 35 14.12.12 10:5414.12.12 10:54- 36 - Cleaning and Care

• Clean the hand element 2 and the sandglass 6 only with a soft and lightly moistened cloth. Do not use detergents or solvents. They can damage the plastic surfaces.

• After use, clean the brush heads 1 thoroughly under running water. We recommend cleaning the brush heads 1 in a standard commercial cleaning fl uid for prosthetics every 2 - 4 weeks. After about 3 months, at the latest however when the bristles bend outwards, you should fi t a new brush head 1. Warning regarding appliance damage! Do not use sharp objects to remove dried-on toothpaste from the hand element 2, they could damage the seals and thus the appliance. Changing the batteries When the movement become noticably weaker, the batteries must be exchanged.

• Open the battery compartment by sliding the the battery compartment lid 5 downwards and remove the old batteries.

• Insert two new batteries of the type AA/LR6 1.5 V. Always use batteries of the same type and never use a new and an old battery together.

• Ensure that the battery has the correct polarity when inserting it. This is marked on both contacts inside the battery compartment. Please observe the adjacent drawing.
