USER MANUAL Vinnie Springlane

Cleaning and care 25

Tips and tricks 26

Troubleshooting 27

Customer service 28

Disposal/Recycling

Battery power: 800 mAh

Power interface: max. 4,2 V

Dimensions (L/W/H): 5 × 5 × 8.5 cm

Weight: approx. 148 g

Equipment: Mini vacuum sealer

Vinnie, USB charging

cable

Accessories: vacuum bags,

Instruction Manual

PRODUCT DESCRIPTION

1. On/off button
2. Vacuum suction port
3. Connection port for micro USB
4. Bag seal
5. Fill marking
6. LED charge indicator
7. Adhesive valve

Subject to changes and mistakes in the equipment properties, technology, colors, and design.

SAFETY NOTES

Purpose of use

The mini vacuum sealer Vinnie and the vacuum bags are designed to vacuum-pack food. The vacuum bags are suitable for cooking food using the sous vide method.

Please read through the manual carefully before use and store it somewhere safe for reference.

GENERAL SAFETY

• Springlane GmbH is not obligated to compensation for consequential damage, property damage, or injuries that are caused by the non-observation of the safety notes or through improper usage of the device.

• Check that the specified voltage on the output sign from the device is compatible with the supply voltage before the power cable is plugged into the outlet.

• Children may not play with the device. Cleaning and maintenance may not be performed by children without supervision.

• The device may not be used by people (including children) with limited physical, sensory or mental capabilities, or insufficient experience and knowledge; unless they are supervised and instructed at all times by a person responsible for them.
• Keep the device and power cable away from children.
• Only use the device properly and only for the purpose described in this operating manual.
• Do not use the device if a part is defective or damaged. If the device is damaged or defective, repair it immediately.
• Check the power cable regularly for damage. Do not use the device if the power cable is damaged. If there is damage, the power cable must be replaced by the manufacturer or a person with similar qualification. Please contact our customer service to avoid hazards.
• The device is only suitable for domestic use. Do not use it for commercial purposes.
• Never submerge the device in water or other liquids. If it is submerged in liquid, do not remove it with your hands. Immediately remove the USB plug from the wall outlet. If the device was submerged in water or other liquids, it may no longer be used.

• Make sure that water never comes into contact with the electrical connections. If they do get wet, immediately remove the USB plug and let it dry out completely before using again.

• Do not suck any liquid into the device.

• Keep the device away from heat sources. Do not place the device on hot surfaces or near open flames.
• To avoid hazards, never insert wires, cables, or other foreign objects into the device openings if they do not belong to the device.
• Protect the device against environmental influences such as insects, dust, and moisture to avoid short circuits and other malfunctions. If the device will not be used for a longer period, keep it in the original packaging and clean it before the next use.
• Do not use the mini vacuum on your body.

ELECTRICAL SAFETY NOTES

• Immediately remove the device from the power supply and other devices if there are problems.
• Do not use the device if the power cable or the USB plug is damaged or defective. If the USB plug is damaged or defective, the USB plug must be replaced by a manufacturer or an authorized service partner.
• Before use, always make sure that the power supply is compatible with the voltage on the device label.
• Connect the device with a grounded wall outlet (with at least 10 A).
• Do not use a wall outlet if multiple devices are connected to it or if it is not suitable for the USB plug.

• Always completely unroll the power cable and extension cable.

• The device is not designed to be operated with an external time switch or a separate remote-control system.

• Do not move the device by pulling the power cable. Make sure that the power cable does not get tangled.
• Never submerge the device, power cable, or USB plug in water or other liquids.
• Do not leave the device unattended while the USB plug is connected to the power supply.

BEFORE INITIAL USE

Remove all transport locks and packaging as well as protective foils from the hob and keep these away from children - risk of suffocation!

Clean the device to remove any residue from production. Follow our cleaning and care notes.

USING THE MINI VACUUM SEALER

GENERAL USAGE NOTES

1. Provided that the mini vacuum is not charged:

Plug in the micro USB connection and connect the USB cable to the power through a suitable power adapter. The LED light illuminates in red when Vinnie is being charged. The light will

disappear once the battery is charged.

1. Open a vacuum bag and put food in the bag. Make sure that the bag is large enough and is filled at most up to the marking below the adhesive valve.
2. Seal the vacuum bag by pressing together the two seal strips with your fingers and make sure that the bag is sealed well.
3. Make sure that no food or liquid gets under the adhesive valve and place it on a level surface. For liquids: Let the bag hang over the edge of a table up to the marking so that the adhesive valve is on a level surface.
4. Place the mini vacuum sealer Vinnie on the adhesive valve so that the suction area is exactly in the middle. Push the on/off button on the top of the vacuum sealer - the vacuum process will begin. As soon as the air is visibly sucked out of the bag, you can let go of Vinnie. For liquids: Hold both the bag that is hanging over the edge of the table and the vacuum sealer throughout the process.
5. Make sure that no liquid is sucked in. As soon as no more air is extracted from the bag, push the on/off button again and remove the vacuum sealer.
6. Seal the adhesive valve by pushing lightly on the adhesive valve.

CLEANING AND CARE

Warning!

• Always turn off the device before cleaning or care;

pull out the USB plug from the wall outlet until the device has cooled down completely.

• Do not submerge the device in water or other liquids.
• Never use a scouring agent or solvent.
• Clean the outside of the device with a soft, moist towel. If necessary, use a little neutral cleaning agent. Dry the device thoroughly with a clean, dry towel.
• Do not try to repair the device yourself. If it does not work properly, replace it with a new one.
• The silicone attachment on the bottom of the device can be removed and cleaned in the dishwasher.
• The vacuum bags may be re-used up to 10 times, depending on prior use. Clean the bag with a moist towel and mild cleaning agent; the adhesive valves lose their functionality in the dishwasher. We recommend using bags only once when using as a sous vide bag.

TIPS AND TRICKS

• The mini vacuum sealer Vinnie vacuum-packs your food for space-saving storage. You can also freeze the bags or use them for sous vide preparation in a warm water bath.
• You can marinate meat better in a vacuum. Simply add herbs, spices, or lemon peel and oil, soy sauce, or other liquids to the bag together with your meat. Dry marinades (rubs) are also ideal for this method.
  The vacuum protects your food against air and makes it last longer.

Please go through the following steps if the mini vacuum sealer Vinnie does not work properly:

Problem Solution
No vacuum is generated.	·Make sure that you have correctly sealed the bag. ·Make sure that the mini vacuum sealer Vinnie is placed correctly onto the adhesive valve. Change Vinnie's position while it is running and see when the air is extracted.
The device does not start.	·Make sure that the battery is charged or connect Vinnie to a power supply through the USB cable. ·If the device still does not start, contact the customer service.

The bag loses its vacuum after some time.

Vacuum the bag again and then make sure that you have completely pressed and sealed the adhesive valve with your finger.
Make sure the that the bag, valve, and bag seal are not damaged.

CUSTOMER SERVICE

In principle, our products have a legal warranty duty of 2 years. Further claims can only be processed in conjunction with a proof of purchase. Wearing parts exclude any warranty claims, when usual abrasion has occurred. The durability is determined by the respective handling and use of the products and is thus variable.

For questions concerning handling and functionality of our products, please contact our customer-service:

Free hotline for Germany/Austria only:

0800 270 70 27

From other EU countries: +49 211 - 749 55 10*

*Different costs may apply.

Our products are manufactured with the highest degree of care and are designed for a long durability. Regular maintenance and cleaning help to prolong durability. If the

device is defective and cannot be repaired, it must not be disposed at home.

You must take the device to a designated disposal point for recycling electrical or electronic devices. Through proper disposal and recycling you are making an important contribution to protecting our environment.

This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of electrical and electronic equipment (WEEE).
