MBG 6023 CB - Oven BOMANN - Free user manual and instructions

Brand	Bomann
Model	MBG 6023 CB
Product type	Countertop oven
Power supply	220-240 V ~ 50/60 Hz
Power consumption	1500 W
Net weight	Approx. 7.5 kg
Protection class	I
Timer	Up to 90 minutes with automatic shut-off and audible signal
Maximum temperature (top and bottom heat)	230 °C
Maximum temperature (convection)	190 °C
Functions	Top heat, bottom heat, top + bottom heat, convection, rotisserie, combinations
Maximum load for baking tray/grill	3.5 kg
Included accessories	Grill, baking tray/drip tray, crumb tray, rotisserie with forks, grill and tray removal tool, rotisserie removal tool, pizza stone
Safety	Hot surface (warning), automatic shut-off, overheat protection, short power cord
Care and cleaning	Clean with a damp cloth and mild detergent; do not immerse; no abrasive products or metal brushes
Reparability	Contact an authorized technician; do not repair yourself; damaged cable must be replaced by the manufacturer or service

Frequently Asked Questions - MBG 6023 CB BOMANN

How to preheat the Bomann MBG 6023 CB oven?

Set the function knob to the desired position (e.g., top and bottom heat) and the temperature selector to the desired value. Let it heat empty for 5 to 10 minutes. The indicator light turns on and off when the temperature is reached.

How to use the rotisserie?

Thread the meat onto the spit using the forks. Place the tray/drip tray on the lower level to collect drippings. Insert the spit into the oven using the removal tool (13): first the end without notch into the motor, then the other end into the notch. Select the rotisserie function and set temperature and time. The spit rotates automatically.

Can glass containers be used in this oven?

No, do not use roasting bags or glass containers, as they may explode due to heat. Use only oven-safe utensils.

How to clean the pizza stone?

Clean the pizza stone after each use with a damp cloth, then let it dry completely. Only use it when dry to avoid cracking from thermal shock. Do not immerse in water.

What is the maximum load for the grill or baking tray?

Do not overload the baking tray or grill: maximum load is 3.5 kg.

Does the oven turn off automatically at the end of cooking?

Yes, once the set time has elapsed, the oven turns off automatically and an audible signal sounds. You can also turn it off manually by turning the timer knob to OFF.

How to set a cooking time less than 9 minutes?

First turn the timer knob to 15 minutes, then turn back to the desired time (e.g., 7 minutes). This allows precise adjustment.

What to do if the oven emits smoke or smell during first use?

This is normal: a protective layer on the heating elements burns off. Run the oven empty for about 15 minutes with convection at maximum temperature, ensuring good ventilation. This will remove manufacturing residues.

Is this oven suitable for children?

The oven can be used by children aged 8 and above under supervision. Children must not play with the appliance. Cleaning and maintenance must not be performed by children under 8 without supervision. Keep the appliance out of reach of children under 8.

How to save electricity with this oven?

Preferably use convection settings: the fan distributes hot air faster and more evenly, reducing cooking time and energy consumption. Preheat only 5 to 10 minutes.

USER MANUAL MBG 6023 CB BOMANN

ATTENTION: Aux surcharges

Thank you for choosing our product. We hope you will enjoy using the appliance.

Symbols in these Instruction Manual

Important information for your safety is specially marked. It is essential to comply with these instructions in order to avoid accidents and prevent damage to the appliance:

WARNING:

This warns you of dangers to your health and indicates possible injury risks.

CAUTION:

This refers to possible hazards to the appliance or other objects.

NOTE:

This highlights tips and information.

General Notes

Read the operating instructions carefully before putting the appliance into operation and keep the instructions including the warranty, the receipt and, if possible, the box with the internal packing. If you give this appliance to other people, please also pass on the operating instructions.

• The appliance is designed exclusively for private use and for the envisaged purpose. This appliance is not fit for commercial use.
• Do not use it outdoors. Keep it away from sources of heat, direct sunlight, humidity (never dip it into any liquid) and sharp edges. Do not use the appliance with wet hands. If the appliance is humid or wet, unplug it immediately.
• When cleaning or putting it away, switch off the appliance and always pull out the plug from the socket (pull the plug itself, not the lead) if the appliance is not being used and remove the attached accessories.
• Do not operate the appliance without supervision. If you leave the room you should always turn the appliance off. Remove the plug from the socket.
• The appliance and the mains lead have to be checked regularly for signs of damage. If damage is found the appliance must not be used.
• Use only original spare parts.
• In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

WARNING:

Do not allow small children to play with the foil. There is a danger of suffocation!

Special Safety Precautions for this Appliance

You will find the following symbol with warning character on the appliance:

WARNING: Hot surface!

Danger of burns!

The temperature of accessible surfaces can be very hot during and after operation.

• For this reason, always touch the appliance by its handle and controls. If necessary, use pot holders.

• Do not carry or lift the appliance during operation, but turn it off first and then disconnect the mains plug. Wait until the appliance has cooled down.

• Always operate the appliance under supervision. Very dry bread can catch fire inside the appliance!

• Make sure that the function switch is in the OFF position.

• Place the appliance on a heat resistant surface!
• Keep sufficient distance (30 cm) to highly flammable objects such as furniture, curtains, etc.! Never place the appliance inside a cabinet!
• Install the appliance with its back panel facing the wall.
• Due to rising heat and vapours do not place the appliance under wall cupboards.
• Ensure that the mains cord does not touch hot parts of the appliance during operation.
• Do not operate the appliance with an external timer or separate remote control system.
• Do not repair the appliance by yourself. Always contact an authorized technician. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
  Children shall not play with the appliance.
• Cleaning and user maintenance shall not be made by children unless they are older 8 years and supervised.
• Keep the appliance and its cord out of reach of children less than 8 years.

CAUTION:

This appliance is not intended for immersion in water during cleaning. Please refer to the instructions provided in the chapter, "Cleaning".

Unpacking the Appliance

1. Take the appliance out of its packaging.
2. Remove all the packaging material such as plastic foil, filling material, cable ties and cardboard packaging.
3. Check that all parts are supplied in the box.
4. In case of incomplete delivery or damage, do not operate the appliance. Return it to your dealer immediately.

NOTE:

There may still be dust or production residues on the appliance. We recommend to clean the appliance as described under "Cleaning".

Overview of the Components / Scope of Delivery

1 Operation indicator light
2 Temperature switch
3 Function switch
4 Time/main switch
5 Heating element
6 Glass door
7 Door handle
8 Grill rack
9 Baking tray/drip pan
10 Crumb tray
11 Removal tool for grill rack and baking tray
12 Revolving spit 12a Spit forks
13 Removal tool for revolving spit

No Illustration

Pizza stone

Controls

Top Control: Temperature Switch

• For convection, choose a temperature between 80 and 190^ .
• For top and bottom heat, choose a temperature between 100 and 230^ .

Centre Controls: Function Switch

OFFOff

Top heat and bottom heat

Top heat and bottom heat with convection

Top heat with convection

Top heat with revolving spit

Top and bottom heat with revolving spit and convection

Bottom Control: Time / Main Switch

Select an operating time of up to 90 minutes.

The oven is switched off at position OFF. The control lamp is off.

Notes for Use

Before Initial Use

There is a protective layer on the heating element. To remove this, operate the appliance for about 15 minutes without any contents. Set the function switch to

NOTE:

Any smoke or smells produced during this procedure are normal. Please ensure sufficient ventilation.

Electrical Connection

1. Make sure that the function switch is in the OFF position.
2. Check whether the mains voltage that you want to use matches the one of the appliance. You will find the information about this on the type plate.
3. Insert the plug in a duly installed protective contact socket.

CAUTION: Overload

When using extension cords, these should have a cable cross-section of at least 1.5mm^2

Removal Tool (11/13)

a) To remove the baking tray
b) To remove the grill rack

If you want to remove the revolving spit, use the removal tool (13).

CAUTION:

• The removal tools are not suitable for getting the pizza stone out of the appliance. The pizza stone could be damaged.
  To take the hot pizza stone out of the appliance, please use oven mitts.

Operation

WARNING:

• Never use containers made from plastic, cardboard, paper, or similar. Risk of fire!
• Do not use roasting bags or glass containers. These may burst.
• Also, when using the handles for the baking sheet or the revolving spit, protect yourself from the heat by using gloves or pot cloths.

CAUTION:

Do not overload the baking tray and the grill rack! (max. 3,5kg)

NOTE:

• Always slide the crumb tray under the bottom heating element.
  We recommend to preheat the oven for approx. 5-10 minutes.
• Save energy by using the switch settings with convection. In doing so, the heated air is distributed quicker and evenly via the fan inside the oven.
• The temperature switch features different temperature ranges for convection or top and bottom heat
  Always use the inserted drip pan when grilling or roasting. This prevents grease from dripping onto the bottom heating element.
• When using the pizza stone, make sure it is completely dry before inserting it. High heat can cause cracks in a wet pizza stone.

For best results when preparing your pizza, we recommend that you preheat the pizza stone separately for about 10-15 minutes.

When preheating, slide the grill rack into the upper tray slot. Place the pizza stone on the grill rack. Set the top and bottom heat at 230^ .

If you want to put a pizza with freshly prepared dough on the preheated pizza stone, dust the pizza stone with flour first.

Your oven offers you a number of settings. You can select a temperature and a time according to your recipe.

Here are a Few Examples of How You Can Use the Functions:

Top heat: For grilling
Functions with the revol- ing spit:	Poultry and large joints of meat are cooked evenly.
Top heat and bottom heat:	E. g. for pizza, pastries etc.

Overview of Baking Times

	Temperature in °C	Time in min.	Function	Rack level
Pizza 1	50-190 15-20		谁	Middle
Toast 1	20-150 3-5		谁	Middle
Pastries	120-170 10-15		谁	Middle
Cakes 1	50-180	According to recipe	谁	Bottom/ Middle
Roasts	190 60-	80		Middle
Poultry	190 40-	60		Middle
Steak	190	25-30	谁	Top
Fish	180	20-25	谁	Top

The times given are only guidelines and vary depending on weight. We recommend that you use a roasting thermometer for meat and fish.

NOTE:

• When selecting 9 minutes or less, please select 15 minutes with the time switch first. Turn it back to your desired time afterwards again.
  After the set time has elapsed, the appliance automatically switches off and a short bell signal will sound.

Revolving Spit

NOTE:

Do not select a roast which is too large. The food being grilled must be far enough away from the internal walls and the heating elements and must not touch them.

1. Insert the baking tray / drip pan into the bottom guide ridge of the oven.
2. Rub edible oil on to the revolving spit and spit forks.
3. Poultry has to be dressed before grilling. To do so, tie the wings and the legs closely to the body using kitchen yarn.

1. Place the dressed poultry or the piece of roast meat carefully on to the revolving spit. Push the spit forks on to the revolving spit and use them to fix the roast meat in place. Tighten the fixing clips by means of the screws.

2. Place the prepared revolving spit in the oven with the help of the removal tool (13). Put the end of the revolving spit without the notch into the motor on the right side of the oven first. Then hook the other end

of the revolving spit into the hanger on the left hand side of the oven.

1. Select a temperature and the function + . Set the operating time. The revolving spit begins to turn. Please ensure that the piece of roast meat can turn freely.
2. After the set time has expired a sound is heard and the appliance switches off automatically. When the meat is cooked remove the revolving spit using the handle.

End Operation

1. Set both switches to the OFF position.
2. Disconnect the mains plug from the socket.
3. Allow the appliance to cool before cleaning!

Cleaning

WARNING:

Always disconnect the mains plug before cleaning.
- Wait until the appliance has cooled down.
- Never immerse the appliance in water. It could result in an electric shock or fire.

CAUTION:

• Do not use any wire brush or other abrasive objects.
• Do not use any acidic or abrasive detergents.

Crumb Tray, Baking Tray, Grill Rack, Revolving Spit, Spit Forks

Clean these parts in hot water by adding some washing-up detergent. Then dry the parts well.

Pizza Stone

Clean the pizza stone after each use with a damp cloth. Leave it to air dry. Only use it when completely dry. The extreme heat of the oven can cause cracks in a wet pizza stone.

Interior

Keep the interior of the oven clean.

1. Remove splashes and food remains on the oven wall with a damp cloth together with some detergent.
2. Wipe dry with a dry towel.

Base Unit

• Clean the housing after use with a slightly damp cloth.
• Put the crumb tray and other accessories back.

Storage

• Clean the appliance as described and let it completely dry.
  We recommend storing the appliance in the original packaging if you do not want to use it for long periods of time.
  Always store the appliance out of the reach of children in a well-ventilated and dry place.

Technical Data

Model: MBG 6023 CB

Power supply: 220-240V\~,50/60Hz

Power consumption: 1500 W

Protection class:

Net weight: approx. 7.5kg

The right to make technical and design modifications in the course of continuous product development remains reserved.

This appliance has been tested according to all relevant current CE guidelines, such as electromagnetic compatibility and low voltage directives, and has been constructed in accordance with the latest safety regulations.

Disposal

Meaning of the "Dustbin" Symbol

Protect our environment: do not dispose of electrical equipment in the domestic waste.

Please return any electrical equipment that you will no longer use to the collection points provided for their disposal.

This helps avoid the potential effects of incorrect disposal on the environment and human health.

This will contribute to the recycling and other forms of re-utilisation of electrical and electronic equipment.

Information concerning where the equipment can be disposed of can be obtained from your local authority.

Instrukcja obslugi

CTC Clatronic Sp. z 0.0

Ul. Brzeska 1

45-960 Opole

Usuwanie

Yka3bIbaeHa BO3MOxHyO ONaCHOCTb IIN3dJIIMN IN dpynx OKpyKaIOxN ppeDMTOB.

ПИМЕЧАнЯ:

JaetcoBtbnHOpMaIIO.

067a HΦopMaζη

Ipeed hauanom 3KcNpyataunn npnbopa BHmameIbHO npouHTaTe npnlaraeMyu INCTpykuno NO 3KcNpyataunn COxpaHNTe ee B HadeXHom MecTe, BMeCTe C rapaHTnHBIM TaHOHom, KaccOBbIM YekOM N, NO BO3MOXHOCTN, KAPTOHHO Kopo6koC ynaKoBOUHbIM MaTePnAionl. Ecn daeTe KoMy-1n6o IonoIb3ObaTbc np6Opom, O83aTeNbHO daJTe B pnuDauy daHHyo INCTpykuno NO 3KcNpyataunn.

-Поьзуйтесь пибором только чаТьим образим и по ha3haЧeMu. Пибор He пpeДha3HaЧeн ДЯ КOMМерчecKOrO ИСпОьЗOBАИ.
He nIb3yIeTcB np6bOp mOIO TkpbITbIM He6bOM. PpeDoxpaHnTe np6bOp OT kapbl, pRmblx CoNHeuHbIX Lyueh, BnaXHoCTn (Hn B Koem cnyae He nOrpykaTe ero B Body) n yApob 06 octpble yrbl. He npKacaiTe b K np6bOp ByaXHbIM pyKaMn. Ecn np6bOp yBaXHnncn HIn Hamok, TyT Xe BbIbTe BuIky n3 po3eKn.
- Pocne 3KcIpyaTuM,MOThaKe npHaIeXHOCTei, YNCTKe IIN NIOJOMKe pnp6opa Bcerda BbIHMaIte BnIKy n3 po3ETKn (TaNHTe 3a BnIKy,a He 3a KaBeJIb).
He octabTnIe BkIIOUeHHbIe 3NKeKTpOpnp6Opbl 6e3 npn-CMOtpa.BbIXoJr nI NOMEuEHNBcerda BbIKIOuayTe npnbop.BbHbTe wTekep n3 po3eKn.
- Pn6b np KabeB cTeBO rntaHnHeoXoHmO peryIpaH O6cneIOBaTb Ha Hauuue CneIOB NOpeKdHn. Pn6 ObhApJxHn IOBpeXdHn POJIb3OBaTbcr np6bopom 3anpeuaetc.
- VicnoJb3yIte ToJIbKO opRHaHaJbHbIe 3aIaCTM.
- V3 coo6paqhen 6e3onacchoCTn dIy deten He octabJIaIte Iexatb ynaKOBky (PiactNKOBbie MeWK, KapTOH, neHONlact n T.D.) 6e3 npncmOTpa.

IPEDYIPPEXDEHNE:

He no3BONJIte DeTm INrpaTb c NOIN3TNIEHOBOI nIeHKO. OnachocTb ydyuBa!

Oco6bIe yka3aHnI NO TexHnke 6e3OpacHOCTN dJa DaHHoro yCTpoiCTBa

Ha n3dennn nmeotc sceyuoune npedynpejdaoune cunboi:

TIOKJIIOUeHnE K cETn

1. Y6eIntecb, yTO BBIKIOHaTeIb neu yCTaHOBnE H B noIOXKeHne OFF.
   2.ПоверьтЕ, COOTBETCTByET JIN CTeBoE HAnpЯЖeHne HOMHaJIbHOMy HAnpЯЖeHIO npIb6pa.ИнфopMaция 06 3TOM coDEPkNTcR Ha TINOBOI Ta5JIuVe.
   3.Bctabte cetebyu Bnky Bpo3eKy C hnapjKeHnem cTeN, OCHaSeHHyU 3aunTHbIMN KOHTaTM N yCTaHOBJIeHHyU BOOTBetCTBmC npeDncaHnAIMN.

ПРМЕЧАнЯ:перрузka

Bcnyae nCNOJb3OBAHnY yDnHInTeJI TOT DOJKeH NMeTb CeHeHne MHN.1,5 MM2.

3axBaT (11/13)

a) Chartne npotnbHra Iy BIneueKn
b) Chartne NOBepxHocTn prnil

Toro,TO6bI CHaTb paWnep, Bocnonb3yntecb 3axBaTOM (13).

ПИМЕЧАНО:

CpeictBa n3BneueHn He npOxOaT dN BbIeMKn KaMn DnI pNcbln np6opa. KaMeHb nnI pNcbl MoXHO NOBpeNTb.
- UTo6bI n3BLeuH n3 pnp6opar oepa Kameh dIe IINcIbI, NOkanyiCTa, INCnObl3yTe npxXBaTKn.

3Kcnnyatauia

IPEUYIPEXDEHNE:

HnKOrda He nCNoIb3yIe EMKocTn, CdeJaHHbIe N3 pactika, KapToHa, BymaHn noDobhIX MaTePnaJIOB. Puck noXapa!
He nCnoB3yIte MeUkN IJIa O6KapuBaHnI NIN EMKoCTn I3 CTeKnA. OHN MOrT JONHyTb.
Takke nCnoJIb3y pykoTkn npOTnBHa nnBepTeJ, HadeBaIte nepaTk nnB6epTe npxBaTK, TTo6bl He o6KeYbcra.

BHIMAHNE:

He nepepykaTe npotBnBeHbДЯ BblneuKn n nobepx-HocTh rnpIra! (MaKc.3,5Kr)

TIPIMEYAHNA:

Bcerda cDnraTe noDoH dIg KpoWeK noI HxHnHarpeBaTeIbHbI 3JEMeHT.
- PekomeHnyetc npedBapntelbno pa3orpeBaTb DyXOBky B TeueHne, npimepHo, 5 - 10 MNHT.
3KOHOMbTe 3HeprHIO, nepeKIOUOaRcB Ha peXIMblc KOHBekuien. TocTynar TaKIM o6pa3OM, pa3oIpeTbIN BO3dyx pacIpoCtpanReTc8 bIcTpeE n paBHomepHee, C NOMOJIbTO BeHTINJrTopa BHyTpN DxyOBKn.
-ПepeKlHoyaTeIb TemnepaTpybl OBeCneuHBaET pa3HbIe TemnepaTpyHbIe Dnana3OHyI JnKOBekTMBHOpa30rpeBa n pa3OrpeBaHnCbePxy n CHn3y
Bcerda nCnoJb3yIte BCTaBHeHHb B dyXOBky noDOnH Dnra Jknp npj KApKe HIno6xkapuBaHN. 3To npedotBpaaaet CTeKaHne Jknp Ha HxKHi HarpeBaTeJIbHbI 3JIeMENT.
- PnHcNoB3OBAHnn KAMNd NnCbI y6eINTEcB, YTO nepeB BCTaBKO OH NOHOCbIO cyXoN. BbICOKN Jap MOKeT CO3aTb TpeuHb BO BNAXHOM KAMHe dIg NnCbI. DnHaHnIyUwero pe3yIbTaT aPn nprirotOBneHn NnCbIMbl peKOMeHdyem OTDeIbHO pOrpTeB KaMeHb dIg NnCbI pRImepHo 10 - 15 MNHyT.

Bo Bpemn ppeBapntbHoro nporeba BdbnhbTe peWetky rpnIb B cepXHne BbiEMKn InIaIOTka. IonoKInTe KaMeHb InI nnuIbHa peWetky rpnl. 3aanaTe pa3oRpeBaHnCbepy n Ch3y npn230°C.

EcHn HxHNO pnproTOBntb NmUy n3 CBexero TecTa Ha nporpeTOM KAMHe dnn NmUcbl, CHaHaNocbInbTe MyKoI KAmEhDnNnUcbl.

Ha BaWei neKe npedyCMOTpeHo HeckoJIbKO HAcTpoEe. Bbl MoKeTe BbIbpaTb Tempepatpy N Bpemr nprirotobneHn no peenty.

BOT HeckoJIbKO npIMePoB, KaK Bbl MoXeTe HcNoJIb30-BaTb 3TN FyHKUH:

I P E D U N P E X K D E H N E:

• Bcerda otknioaTe ceTeBOJ wTeNCeIb nepei ouNCTKOJ.
• Пождente, рoka устpoистбо OCTынет.
• HNKoIa He nOrgykaIte yCtpoIcTBO B BODY. 3To MoKeT npINBeCTn K nopaxeHnIO 3JIeKtpnueCKm TOKOM nII nOxapy.

BHIMAHNE:

He npimehnTe npoBOJIOHbIe UeTKN ININ ppeMeTbIC a6pa3NBbIM NOKpbITmEM.
He npimEnHnTe cnIbHbIe nIN a6pa3nBbIe moIOuIe cpeIcTBA.

Iodon dnn c6opa KpoeweK, npotBHeH nn BIneueKn peweTka dnn rpnna, Bepten, BNKN waMnpa

a1g211 a1g21g21g21g21g21g21g21g21g21g21g21g21g21g21g21g21g21g21g21g21

olj pdoaol,olgdu 1130s13. (13) aljyl

:

jSc jyll

4

j#j#j#j#

山

j 1
1
1
1
1
1
1

3

.
.
.1.2.3.4.5.
( 0 < x) x > 0

1. slwdi jglal y - 15 j5 1

a

jbsi icij jldgo

J 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8 8

.aaabblb1g5jgl aioT aaybrjglalplauwbyaolalglal

.1j11i
·jw|jgl

8

8 8

:

③ a1 + a2 + a_3 = 6 ②

"ddll"

10

jdl aagol gwl alj 11

12

12a

olgdu 13

a000000000000

1

jgljU Ugoo包

.

Jologg (g)alld olog. auiab1 jil 10 auiiul 1go Jj1 .2

.

.3

jll jaiy y. 4 100 g jol s jall paae aee

jgl 1e jgsl 0

:ab

soww

aJgll aJg Jgll 1

190g 80 gjg jy jol

230g 100 g jgjg jg jg jg jg jg jg jg

.

aagbglzaiao:ajsjgolsoollgol

Joff

ggl

golul ylaal golal

JouyI JyJyJU JxJxJxJxJxJxJx

sog 1. j. g. y

"aaaannnnn" aee 3g 25go go los jlaa

pulil 1b/ Ug5bl 1de oole oybi

Juswul jso 1

aJ 2

a1 = 2,an + 1 = n1 + n2

4

jssuai 5

j6

7

8

ybae 9

jlll llool ool
