USER MANUAL Rogue R3X Wash Chauvet

Rogue R3X Wash QRG Rev. 5 About This Guide The Rogue R3X Wash Quick Reference Guide (QRG) has basic product information such as connection, mounting, menu options, and DMX values. Download the User Manual from www.chauvetprofessional.com for more details. Disclaimer The information and specifications contained in this QRG are subject to change without notice. LIMITED WARRANTY FOR WARRANTY REGISTRATION AND COMPLETE TERMS AND CONDITIONS PLEASE VISIT OUR WEBSITE. For Customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration

For Customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration

Chauvet warrants that this product shall be free from defects in material and workmanship under normal use, for the period specified in, and subject to the exclusions and limitations set forth in the full limited warranty on our website. This warranty extends only to the original purchaser of the product and is not transferable. To exercise rights under this warranty, you must provide proof of purchase in the form of an original sales receipt from an authorized dealer that shows the product name and date of purchase. THERE ARE NO OTHER EXPRESS OR IMPLIED WARRANTIES. This warranty gives you specific legal rights. You may also have other rights that vary from state to state and country to country. This warranty is valid only in the United States, United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, Germany and Mexico. For warranty terms in other countries, please consult your local distributor. Safety Notes These Safety Notes include important information about installation, use, and maintenance.

• DO NOT open this product. It contains no user-serviceable parts.

• DO NOT look at the light source when the product is on.

• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the product from power via breaker or by unplugging it.

• CAUTION: When transferring product from extreme temperature environments, (e.g. cold truck to warm humid ballroom) condensation may form on the internal electronics of the product. To avoid causing a failure, allow product to fully acclimate to the surrounding environment before connecting it to power.

• CAUTION: This product’s housing may be hot when lights are operating.

• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent surfaces.

• DO NOT leave any flammable material within 20 cm of this product while operating or connected to power.

• USE a safety cable when mounting this product overhead.

• DO NOT operate this product outdoors or in any location where dust, excessive heat, water, or humidity may affect it. (IP20)

• DO NOT operate this product if the housing, lenses, or cables appear damaged.

• DO NOT connect this product to a dimmer or rheostat.

• ONLY connect this product to a grounded and protected circuit.

• ONLY use the hanging/mounting bracket or the handles to carry this product.

• In the event of a serious operating problem, stop using immediately.

• The maximum ambient temperature is 113 °F (45 °C). Do not operate this product at higher temperatures.

• The luminaire should be positioned so that prolonged staring into the luminaire at a distance closer than 25.3 ft (7.7 m) is not expected.

• If the external flexible cable or cord of this luminaire is damaged, it shall be replaced with a special cable or cord exclusively available from the manufacturer or its service agent.

• The light source contained in this luminaire shall only be replaced by the manufacturer, its service agent, or a similarly qualified person.

• The luminaire is intended for professional use only. FCC Compliance This device complies with Part 15 Part B of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference, and

2. This device must accept any interference received, including interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Contact Outside the U.S., U.K., Ireland, Benelux, France, Germany, or Mexico, contact your distributor to request support or return a product. Refer to Contact Us at the end of this QRG for contact information. What is Included

Rogue R3X Wash QRG Rev. 5

QUICK REFERENCE GUIDE

AC Power This product has an auto-ranging power supply that can work with an input voltage range of 100–240 VAC, 50/60 Hz. Power Linking It is possible to power link up to 0 Rogue R3X Wash products at 100 V, 2 products at 120 V, 3 products at 208 V, 4 products at 230 V, or up to 4 products at 240 V. Never exceed this number. Power-linking cables can be purchased separately. AC Plug Replacing the Fuse

1. Disconnect the product from power.

2. Using a flat head screwdriver, unscrew the fuse holder cap from the housing.

3. Remove blown fuse and replace with a good fuse of the same type and rating.

4. Screw the fuse holder cap back in place and reconnect power.

DMX Connection The Rogue R3X Wash uses a 3- or 5-pin DMX data connection for its DMX personalities: 21CH, 62CH, 71CH, and 107CH. See the User Manual for information about connecting and configuring the product for DMX operation. RDM (Remote Device Management) Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate bi-directionally along existing DMX cabling. Check the DMX controller’s User Manual or with the manufacturer as not all DMX controllers have this capability. The Rogue R3X Wash supports RDM protocol that allows feedback to make changes to menu map options. Download the User Manual from www.chauvetprofessional.com for more details. Mounting Before mounting this product, read the Safety Notes. Use at least one mounting point per product. Make sure the mounting clamps are capable of supporting the weight of the product. For our Chauvet line of mounting clamps, go to http://trusst.com/productcategory/truss-clamps/

Mounting Diagram Connection Wire (U.S.) Wire (Europe) Screw Color AC Live Black Brown Yellow/Brass AC Neutral White Blue Silver AC Ground Green/Yellow Green/Yellow Green To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely disconnect the product from power via breaker or by unplugging it. When using only one mounting clamp, be sure to use a clamp with a captive bolt to prevent accidental loosening.

Safety cable Mounting clamp Overhead Mounting Floor Mounting

Rogue R3X Wash QRG Rev. 5 Control Panel Description Menu Map Refer for the Rogue R3X Wash product page on www.chauvetprofessional.com for the latest menu map. Button Function <MENU> Exits from the current menu or function <ENTER> Enables the currently displayed menu or sets the currently selected value into the selected function <UP> Navigates upwards through the menu list and increases the numeric value when in a function <DOWN> Navigates downwards through the menu list and decreases the numeric value when in a function Main Level Programming Levels Description Address 001-512 Sets the DMX starting address Running Mode DMX

Rogue R3X Wash QRG Rev. 5

QUICK REFERENCE GUIDE

Setup (cont.) Display OFF Determines how long the backlight of the display will stay on after last command button pressed

Screen Rev OFF Normal control screen view ON Rotates control screen view 180° C Mixing Mode RGBW Product mixes color using the RGBW method CMY Product mixes color using the CMY method Dimmer Curve Linear Liner dimmer Square Square curve dimmer I Squa Reverse square curve dimmer Scurve S curve dimmer Dimmer Speed Smooth Slow (Smooth) or fast (Fast) dimmer curves Fast PWM Option 600Hz Sets the PWM frequency 1200Hz 2000Hz 4000Hz 6000Hz 15000Hz Color calibration

Max. output when RGBW DMX channels are at full OFF Factory calibrated color temperature when RGBW DMX channels are at full Custom RED 100-255 Manual calibration of color temperature when RGBW DMX channels are at full GREEN BLUE White Mode On Calibrates white to 7500K Off Uses maximum output values Custom RED Sets red LED maximum value GREEN Sets green LED maximum value BLUE Sets blue LED maximum value WHITE Sets white LED maximum value Reset Function Pan/Tilt Yes Resets pan/tilt functions to the home position

Zoom Yes Resets all Zoom functions to the home position

All Yes Resets all functions to the home position

Factory Reset Yes Reverts the product back to the original factory settings

Open 210 224 Strobe 9 (fade on or off) with decreasing speed 225 229 Open 230 244 Strobe 10 (pulse strobe) with decreasing speed 245 255 Open 9CTC 000 No function 245 255 10,000K to 2800K
