Product type	Connected electrical socket
Brand	ebode
Model	RPT
Power supply	230 V AC, 50 Hz
Maximum power	3000 W (estimated)
Number of memorizable channels	32 (X10 mode) / 16 (ebode secure mode)
LED indicators	Green: reception of a radio command; Red: reception/transmission of a command from a remote control
Main functions	Remote on/off via wireless control (remote control, wall switch, timer)
Radio frequency	433.92 MHz (estimated)
Radio range	Up to 30 m indoors (estimated)
Dimensions	Approximately 60 x 40 x 80 mm (estimated)
Weight	Approximately 100 g (estimated)
Supported protocols	X10 and ebode secure protocol
Installation	Plug into a standard power outlet, initialize channels with a remote control
Reset (RESET)	Press 3-4 seconds in the hole with a paperclip until green light, then release
Safety	Do not open: risk of electric shock; any intervention by a professional
Maintenance	Clean with a dry, soft cloth; do not use abrasive products
Operating temperature	0 °C to 40 °C (estimated)
Humidity	5% to 90% without condensation (estimated)

Frequently Asked Questions - RPT EBODE

Can I use the plug receiver on a power strip extension cord?

Yes, provided the extension cord is not of surge protection or lightning protection type. In that case, the receiver may not work correctly.

What to do if the plug receiver no longer responds to the remote control?

First check the battery status of the remote control. If necessary, perform a RESET of the receiver (press 3-4 seconds in the hole with a paperclip) then reinitialize the channel.

How to initialize a channel on the plug receiver?

Using a paperclip, briefly press in the hole between the two LEDs until the green LED flashes. Then press the button on your remote control (remote, switch, timer) to associate the channel. The LED turns off when the initialization is successful.

How to erase all memorized channels (RESET)?

Press and hold the paperclip in the hole between the LEDs until the green LED lights up (about 3-4 seconds). Release: the green and red LEDs flash quickly then turn off. All channels are erased.

What is the memory capacity of the receiver?

The receiver can memorize up to 32 channels in X10 mode and up to 16 channels in ebode secure mode.

What do the LED indicators mean?

Green LED temporarily on: reception of a radio command. Red LED temporarily on: reception or transmission of a command from a remote control (etc.). Fast green flashing: awaiting initialization.

Can I use the receiver with a timer?

Yes, the receiver is compatible with ebode or X10 timers. Simply initialize the channel by pressing the timer button during the learning phase.

The receiver no longer responds to powerline carrier (PLC) commands, what to do?

Perform a RESET of the receiver (see question 4) then reinitialize the desired channel. Also check that the electrical network is not disturbed.

What safety precautions should be observed?

Do not open the housing: risk of electric shock. Any intervention must be entrusted to a professional. Avoid shocks, extreme temperatures, vibrations, and humidity. Use the product in accordance with the manual.

How to install the receiver for the first time?

Plug the device or lamp into the receiver, then plug the receiver into a power outlet. Ensure the switch of the device/lamp remains in the on position. Then initialize the channel (see question 3).

USER MANUAL RPT EBODE

Transceiver Plug-In Transceiver Module

User guide 6

General Security Note

For carefree and safe use of this product, please read this manual and safety information carefully and follow the instructions. Technical manipulation of the product or any changes to the product are forbidden, due to security and approval issues.

Please take care to set up the device correctly - consult your user guide. WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to life. No user-serviceable parts inside. Refer all servicing to qualified service personnel.

Important: the product must be used according the instructions in this manual and is not suitable for other purposes.

Please avoid the following: strong mechanical wear and tear, high temperature, strong vibrations, and high humidity.

Please also respect the additional security notes in the various user guide chapters. To ensure correct set up please read the manual and security notes carefully.

1. Plug the appliance or lamp into the module.

1. Plug the module into a socket.

NOTE: Make sure the appliance or light is powered on.

X10 address

The X10 address consists of a House Code and a Unit Code. In order for this module to respond to a command sent via the Power line, the module needs to be initialized. It is possible to configure multiple addresses for this module.

General information

• The RPT transceiver module can be configured to respond to up to 32 X10 addresses and 16 Secure ebode addresses.
• The factory default the protocol is set to X10 mode.
• The LED will blink green when receiving radio signals.
• The LED will blink red when ON/OFF command for a configured address are received.

Programming the RPT module

1. Use a small sharp object, e.g. a paper clip, to shortly press the setup button. This button is situated in the small opening between the two LEDs. When the button is pressed, the green led will blink quickly, waiting for a command.
2. Send the 'power on' command for the desired address.
3. The led will stop blinking.
4. The appliance module address is now stored.
5. If you wish to configure additional addresses repeat this procedure form from step 1.

Reset appliance module addresses

1. Use a small sharp object, e.g. a paper clip, to press and hold the setup button until the green led turns on. (about 3 or 4 seconds)
2. Release the button, the led will blink red and green and then turn off.
3. When the red and green LEDs are off, the module is reset.

Operating the RPT Module

Functions enabled by a wireless transmitter (EM, TPC, IMRF, etc..)

ON/OFFkey

Turns the lamp or appliance On & Off

Tips - Knowledge base available on www.ebodeelectronics.eu.

Can I plug transceiver module into a power strip?

This is no problem with a simple power strip however you can not use the module with a surge protected power strip.

The transceiver is not responding to RF commands?

• Check and/or change the remote control battery.
• Reset the transceiver (see paragraph 4) and reprogram the address.
• Then, proceed again using learning mode as explained in 2.

The RPT does not respond to command sent via the power line?

• Reset the RPT (see paragraph 3) then initialize the address.
• Then, proceed again using learning mode as explained in 2.

Installation des Transceivermoduls

Functions enabled by a wireless transmitter (EM, TPC, IMRF, etc..)

ON/OFFkey

Slår På & Av apparaten eller lampan

CE DECLARATION OF CONFORMITY

UK - We, BMB Electronics BV, Kortakker 10 - 4264 AE Veen - The Netherlands, herewith declare that the following designated product RPT, is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.

Device: The use of the symbol indicates that this product may not be treated as household waste. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.

Batteries: Do not dispose of used batteries in the household rubbish! They should be deposited at a collection point for used batteries.

Also available from ebode electronics:

On-Wall Modules

Product Description
EM 2-position	RF wall switch, ideal for retro fit installations to e.g. control blinds, shutter, home cinema screens but also lighting or appliances.
IMRF Single	position RF wall switch, ideal for retro fit installations to e.g. control applications or an inside or outside light.
RMV Control	your shutter, blind or e.g. cinema screen via the front panel keys, or remotely via any ebode / X10 compatible controller.
RMA Control	your appliance, light or e.g. pump via the front panel keys, or remotely via any ebode / X10 compatible controller.
RPA, RPL, RPT	Ideal for retro fit installations, the classic X10 plugin module in a new and stylish jacket. Control your appliance or lamps etc, via any ebode or X10 compatible controller via PLC AND RF!
TPC/ TMML	New stylish RF remote to control any ebode or X10 compatible RF receiver.

In-Wall Modules

Product Description

EMML 2-position RF in-wall module to install behind any mechanical wall switch. The EMML is battery operated.

RMML In-wall RF receiver, ideal for any switches lights and appliances up to 300W.

PMML A package containing both the EMML and the RMML.

Under development

Product	Description
RMP Update	on existing RMV with dry contact output. Ideal to control e.g a motorized gate.
RMSN In-wall	RF receiver without Neutral for light applications including incandescent, halogen, fluorescent, LED (even 0.5W charge).
